Hans Grohe AXOR Trim Kits 39224 0 Series Installation guide

Installation Instructions / Warranty
Vertical Spray Bidet Fitting
Rough 1322X181
Axor Trim Kits
Citterio cross handle 39224XX0
Citterio lever handle 39225XX0
Starck 10220XX0
Steel 35220800
Uno 38220XX0
Terrano cross handle 37224XX0
Terrano lever handle 37225XX0
Carlton cross handle 17224XX0
Carlton lever handle 17225XX0
Phoenix cross handle 17226XX0
Phoenix lever handle 17227XX0
Montreux 16521XX0

2
Technical Specification
Recommended operating pressure 45 - 80 psi
Recommended hot water temp. 120oF - 140oF*
Flow rate 2.2 gpm
Hole sizes
valves 1 1/4”
transfer valve 1 1/4”
pull rod 3/8” min.
*Know and follow all applicable local plumbing codes when setting the temperature on the water heater. In
Massachusetts, the water heater may be set no higher than 112oF.
Important: This valve is for use on vertical spray bidets only. It is not suitable for use on
other fixtures.
The transfer valve has an integral vacuum breaker.
Installation Considerations
For best results, Hansgrohe recommends installation by a licensed professional plumber.
The hot and cold valves require 1/2” supply lines, which are not provided by Hansgrohe.
Large differences in pressure between the hot and cold supplies should be balanced.
The hot and cold supplies must be thoroughly flushed before installation to prevent damage to the
valve cartridges.

3
Rough-in Installation Instructions
Install the transfer valve
Install the y-connector and seal on the bottom of the
transfer valve. Screw the connecting hoses to the
y-connector.
Screw the elbow connector to the outlet port on the
side of the transfer valve. The arrow on the elbow
connector indicates the direction of the water flow. It
should point downward. Screw the spray hose to the
elbow connector.
Push the transfer valve, nylon washer, and one of
the china seals (tapered side up) through the transfer
valve hole in the bidet.
Install the second china seal, tapered side down.
Thread the valve mounting nut to the top of the trans-
fer valve as far as it will go. The valve mounting nut
should rest on the mounting surface.
Make sure that the transfer valve stands straight.
Install the spray assembly
Position the spray and sealing washer in the hole in
the bidet.
Install the washer and mounting nut.
Connect the spray hose to the spray, being careful not
to twist or kink the hose.

4
Install the pop-up guide assembly
Remove the nut, metal washer, and sealing washer
from the pop-up guide assembly.
Position the pop-up guide and sealing washer on the
proper hole on the bidet.
Install the metal washer and nut.
Install the pop-up drain
Remove the plunger assembly.
Unscrew the drain outlet flange from the tee.
Unscrew the tailpiece from the tee. Wrap the threads
with Teflon tape and replace.
Install the white, flexible sealing gasket on the flange.
Sith it in the sink outlet.
From below, install the black mack gasket, friction
ring, and retainer nut to the flange. Do not fully
tighten the nut at this time.
Thread the tee and tailpiece on the flange. The pivot
must face the faucet. Turn the drain assembly if neces-
sary.
Tighten the retainer nut.
Place the plunger assembly in the drain.
Install the horizontal rod so that the end goes through
the loop in the bottom of the height adjuster.
Install and tighten the pivot ball nut.
plunger
height adjuster
flange
sealing gasket
mack gasket
friction ring
retainer nut
pivot ball nut
tee
tailpiece
horizontal rod
swivel connector
vertical rod

5
Attach the swivel connector to the end of the horizontal rod.
Attach the swivel connector to the end of the vertical rod. Position as desired, and tighten with a
small, flathead screwdriver.

6
Trim Kit Installation
Install the valves: Starck and Citterio only
Remove the valve mounting nuts from the valves.
Push the valves up into the holes. Install the mounting
plates on the holes.
Tighten the tensioning screws.
Install the valves: all other styles
Remove the plaster shields, mounting plates, and stop
rings from the valves.
Push the valve up through the hole. Slide the stop ring
onto the valve. Install the mounting plate. The stop
ring will stop it at the proper height.
Rest the mounting plate on the mounting surface. Tight-
en the mounting nut firmly against the underside of the
mounting surface. Tighten the tensioning screws.
All models:
Connect the connecting hoses to the valve outlets.
Hold the hose steady with one wrench while tighten-
ing the hose nut with a second wrench.
Install the hot and cold supply lines (not included) on
the valve inlets.

7
Install the transfer valve trim
Screw the sleeve down onto the transfer valve.
Push the handle over the stem and secure it with the
screw.
Line up the locator tab on the screw cover with the
notch in the handle. Press down firmly.
Install the handles
Carlton/Phoenix/Terrano
Screw the escutcheons down over the mounting
plates.
Position the handle over the valve with the lever or
cross in the desired off position. Hold the lever or
cross steady with one hand. With the other hand,
rotate the “bell clockwise, so that it threads down over
the valve.
Uno / Steel
Install the white plastic snap connectors and screws
on the valves.
Screw the escutcheons into place over the mounting
plates.
Position the handle over the valve. Press downward
firmly, so that the handle snaps into place over the
snap connector.

8
Citterio / Starck
Position the handle over the valve. While holding
the cross or lever steady with one hand, use the other
hand to thread the escutcheon down over the mount-
ing plate.
Montreux
Position the handle over the valve. While holding the
cross steady with one hand, use the other hand to turn
the escutcheon clockwise to thread it onto the valve.
Lightly grease the o-rings. Press the hot and cold caps
into place on the handles.
User Instructions
Turn the left handle to obtain hot water, the right handle for cold water.
Turn the transfer valve handle to select between the vertical spray and the rim wash. While the
vertical spray is functioning, water will also come from the rim wash.

9
Replacement Parts - Rough
Replacement Parts - Trim
1
2
3
4
5
6
7
8
9
10
11 12
13
14
15
16
17
18
19
20
21
22
23
24 25
26
39
39

10
1 transfer valve 88632000
2 connection hose 88631000
3 spray hose 88630000
4 pull rod 88634XX0
5 aerator 88633XX0
6 drain 94159XX0
7 hinged connector 96100000
8 plastic screw and filter 97592000
9 valve set for Starck, Citterio 97960001
10 hot cartridge 96766000
11 cold cartridge 96765000
12 valve set 88503000
13 hot cartridge 94009000
14 cold cartridge 94008000
15 fixing set 88511000
16 sleeve 88635XX0
17 transfer valve handle 88636XX0
18 Starck handle 10091XX0
19 Citterio cross, cold 39297XX0
hot 39298XX0
20 Citterio lever, cold 39093XX0
hot 39094XX0
21 Steel handle 35293800
22 color ring set 97127000
23 escutcheon 97128800
24 Uno handle 38092XX0
25 color ring set 96422000
26 escutcheon 96462XX0
27 Montreux handle 16291XX0
28 escutcheon 97988XX0
29 index cap set 97987XX0
30 Terrano cross, cold 37291XX0
hot 37292XX0
31 Terrano lever, cold 37296XX0
hot 37295XX0
32 screw cover set, cross 96481XX0
33 screw cover set, lever 97798XX0
34 Carlton cross, cold 17291XX0
hot 17292XX0
35 Carlton lever, cold 17295XX0
hot 17296XX0
36 escutcheon 94035XX0
37 Phoenix cross 96793XX0
38 Phoenix lever, cold 96629XX0
hot 96628XX0
39 snap connector 94184000
XX = colors
00 = chrome
62 = oil rub bronze
80 = steel
81 = satinox
82 = brushed nickel
83 = polished nickel
27
28
29
30 31
32 33
34 35
36
37
38
36
