Harman JBL PARTYBOX 1000 User manual

PARTYBOX 1000
Quick Start Guide

2
3)
• Press to enter Bluetooth pairing mode.
• Press and hold for 5 seconds to disconnect and
pair with a new device.
4)
• Press repeatedly to select a music source
(Bluetooth / USB / AUX / LINE IN).
5)
• LED indicators to show the current music source.
6)
• DJ control keys.
7)
• Press to record a new track. Up to 8 tracks can be
recorded.
8)
• Press to delete the last recorded track.
• Press and hold for 5 seconds to delete all recorded
tracks.
9)
• Press repeatedly to select a sound effect (Drums /
Piano / Guitar / DJ / Customized).
10)
• Press to enter color control mode to toggle between
different light colors of your PartyBox front panel and
wristband.
11)
• Press to play or pause the music.
12) /
• Press to decrease or increase the volume level.
• Press both simultaneously to mute the audio
output.
13)
• Press to turn the Bass Boost on or off.
14)
• Press to turn the Smart DJ on or off.
15)
• Rotate to adjust echo volume (Only in Karaoke
mode).
16)
• Rotate to adjust the key level (Only in Karaoke
mode).
17)
• Press to cancel or restore the human voice (Only in
Karaoke mode).
1What’s in the box
2Overview
2.1 Top panel
11
13
2
3
4
1
5
6
17 16 15 14
789
10
12
1)
• Press to switch light show patterns (Rock / Neon /
Club / Fire / Flash).
• Press and hold for 2 seconds to turn the light on
or off.
2)
• Power on/off.

3
EN
Customized effects
1) Insert a USB flash drive.
2) Press repeatedly to select customized effects.
3) The sound samples stored in the USB will be loaded.
During the loading, all keys will breathe in red.
Record and delete
1) Insert a USB flash drive.
2) Press to start recording, when a control key is
pressed, the white LED will light on. The harder
you press the keys, the louder sound will play.
After recording for 30 seconds, the recording will
automatically stop.
3) Press to record a new track. The newly recorded
track will overlap play in a loop with previously recorded
tracks. Later recorded tracks will be shorter or equal to
the first track.
4) Press to delete the last recorded track. To delete all
recorded tracks, press and hold for 5 seconds.
2.2 DJ pad
Color control
Press to enter color control mode, then press any DJ
control key to select color for the light of both PartyBox
and wristbands nearby. The color will stay for 5 seconds.
To keep the color constant, press and hold the DJ control
keys.
Sound effects
Press repeatedly to select a sound effect (Drums / Piano /
Guitar / DJ / Customized).
Drums (defaulted) Guitar
Piano DJ effects

4
3Power on
4
Connections
4.1 Bluetooth
10m (33ft)
2
DEVICES
JBL PartyBox 1000
Bluetooth
Bluetooth
1
2.3 Back panel
2
3
1
4
5
6
7
8
9
1) USB
• Connect to a USB storage device.
• Charge an external USB device.
2) AUX
• Connect to an external audio device through an
audio cable.
3) LINE OUT
• Connect to an analog audio input jacks to another
analog device through RCA audio cable.
4) LINE IN
• Connect to an analog audio output jacks to another
analog device through RCA audio cable.
5) GUITAR
• Connect to a guitar (not provided).
6) MIC
• Connect to a microphone (not provided).
7) VOLUME (MIC)
• Rotate the knob to adjust the microphone volume.
8) VOLUME (GUITAR)
• Rotate the knob to adjust the guitar volume.
9) GAIN
• Guitar and Mic gain control buttons.

5
EN
5
DJ wristband
5.1 Power on / off
• Press and hold for 2 seconds to power on the DJ
wristband, and it will be automatically paired with the
PartyBox.
• Press and hold for 2 seconds to power off the DJ
wristband.
Note:
• The DJ wristband will be connected automatically with the closest
PartyBox.
PAIRING
USING
15m
15m
5.2 Control PartyBox by using DJ
wristband through gesture
Gesture Action
Clap Play sound effect 1
Shake Play sound effect 2
Rotate Switch light patterns
6
Mixing sound with
microphone/guitar (not
provided)
4.2 USB
4.3 AUX
2
1
4.4 LINE IN
R
L
AUDIO OUT
.
.
.
LINE IN

6
9Specications
• AC power input: 100-240V ~ 50/60Hz
• Power consumption: 150W
• Standby power consumption: <2W with BT
connecting; <0.5W without BT connecting
• USB output: 5V 2.1A
• Speaker drivers: 1 x Sub woofer + 2 x Mid-range + 1 x
Compression driver
• Speaker impedance: Sub woofer 3ohm / Mid-range
4ohm / Compression driver 4 ohm
• Total output power: 1100W
• Frequency response: 40Hz -18kHz(-6dB)
• - Input Sensitivity
- Analog Input
- RCA In: 500mV rms
- Aux In: 250mV rms
- Digital Input
- Buetooth: -12dBFS
- USB : -12dBFS
• Signal-to-noise (S/N) ratio: 80 dBA
• Input sensitivity: Analog Input-RCA IN: 500mV rms
• Digital Input-Bluetooth / USB:-12BFS
• Bluetooth version: 4.2
• Bluetooth profile: A2DP, AVRCP
• Bluetooth transmitter frequency range:
2402-2480MHz
• Bluetooth maximum transmitter power: 15dBm (EIRP)
• Bluetooth transmitter modulation: GFSK, π/4 DQPSK,
8DPSK
• Bluetooth range: Approx. 10m (33feet)
• USB file system: FAT16, FAT32
• USB file format: .mp3, .wma, .wav
• Air gesture wristband: BLE technology
• Dimensions (W x H x D): 397 x 1050 x 390 mm /
15.6 x 41.3 x 15.4 in
• Net weight: 34.7 kg / 76.5 lbs
7
TWS (true wireless stereo)
mode
10m (33ft)
1) Press and hold on both speakers for 5 seconds,
TWS connection will be built up. By default, the
speaker which connected to your smartphone is the
master (L channel), the other one is the slave
(R channel).
2) Press L/R button on one speaker to toggle between
L channel / Stereo, the other speaker will change the
setting automatically.
8LED Behavior
Off Power off
White (Constant) Power on
Amber (Constant) Standby
Off Not connected
White (Constant) Connected
White (Flashing) Pairing
Off Off
White (Constant) On
Off Off
White (Constant) On
Off Off
White (Constant) On
Off Off
White (Constant) On

7
DA
3)
• Tryk for at aktivere Bluetooth-parringstilstand.
• Tryk og hold i 5 sekunder for at afbryde
forbindelsen og parre med en ny enhed.
4)
• Tryk flere gange for at vælge musikkilde (Bluetooth
/ USB / AUX / LINE IN).
5)
• LED-indikatorer viser den valgte musikkilde.
6)
• DJ-kontrolknapper.
7)
• Tryk for at optage et nyt track. Der kan optages op
til 8 tracks.
8)
• Tryk for at slette det sidst optagede track.
• Tryk, og hold i 5 sekunder, for at slette alle
optagede tracks.
9)
• Tryk flere gange for at vælge en lydeffekt (Trommer
/ Piano / Guitar / DJ / Skræddersyet).
10)
• Tryk for at gå til farvekontroltilstand og skifte mellem
forskellige lysfarver på fronten af din PartyBox og
armbånd.
11)
• Tryk for at afspille eller sætte musikken på pause.
12) /
• Tryk for at skrue op eller ned for lydstyrken.
• Tryk på begge samtidig for at slå lyden fra.
13)
• Tryk for at tænde eller slukke for Bass Boost.
14)
• Tryk for at tænde eller slukke for Smart DJ.
15)
• Drej for at justere ekko-lydstyrken (kun i Karaoke-
tilstand).
16)
• Drej for at justere key-level (kun i Karaoke-tilstand).
17)
• Tryk for at annullere eller gendanne sangstemmen
(kun i Karaoke-tilstand).
1Hvad er der i æsken
2Oversigt
2.1 Toppanel
11
13
2
3
4
1
5
6
17 16 15 14
789
10
12
1)
• Tryk for at skifte mellem lysshow-mønstre (Rock /
Neon / Club / Fire / Flash).
• Tryk og hold I 2 sekunder for at tænde og slukke
lyset.
2)
• Tænd/sluk.

8
Skræddersy effekter
1) Isæt et USB-flashdrev.
2) Tryk flere gange på for at vælge skræddersyede
effekter.
3) De lydsamples, der er lagret på USB'en, vil blive indlæst.
Under indlæsningen vil alle taster pulsere rødt.
Optag og slet
1) Isæt et USB-flashdrev.
2) Tryk for at starte optagelse. Når en kontrolknap
aktiveres, vil den hvide LED tænde. Jo hårdere du
trykker på knapperne, desto højere vil lyden afspilles.
Efter 30 sekunders optagelse stopper optagelsen
automatisk.
3) Tryk på for at optage et nyt track. Det nyoptagede
track vil spille i et loop ovenpå tidligere optagede tracks.
Tracks, der er optaget senere, vil have en varighed, der
er kortere eller lig med det første track.
4) Tryk på for at slette det sidst optagede track. Hold
inde i 5 sekunder for at slette alle optagede tracks.
2.2 DJ-pad
Farvekontrol
Tryk på for at gå til farvekontrol-tilstand, og tryk så
enhver DJ-kontrolknap for at vælge en farve til lyset for
både PartyBox og armbånd i nærheden. Farven fastholdes
i 5 sekunder. For at holde farven konstant skal du holde DJ-
kontrolknapperne nede.
Lydeffekter
Tryk flere gange på for at vælge en lydeffekt (Trommer /
Piano / Guitar / DJ / Skræddersyet).
Trommer (standard) Guitar
Piano DJ-effekter

9
DA
3Tænd
4forbindelser
4.1 Bluetooth
10m (33ft)
2
DEVICES
JBL PartyBox 1000
Bluetooth
Bluetooth
1
2.3 Bagpanel
2
3
1
4
5
6
7
8
9
1) USB
• Tilslut en USB-lagerenhed.
• Oplad en ekstern USB-enhed.
2) AUX
• Tilslut en ekstern lydenhed med et lydkabel.
3) LINE OUT
• Tilslut til den analoge indgang på en analog enhed
via RCA-lydkabel.
4) LINE IN
• Tilslut til den analoge udgang på en analog enhed
via RCA-lydkabel.
5) GUITAR
• Forbind til en guitar (medfølger ikke).
6) MIC
• Forbind til en mikrofon (medfølger ikke).
7) VOLUME (MIC)
• Drej knappen for at justeres mikrofonens lydstyrke.
8) VOLUME (GUITAR)
• Drej knappen for at justeres guitarens lydstyrke.
9) GAIN
• Knapper til forstærkerkontrol for guitar og mikrofon.

10
5
DJ-armbånd
5.1 Tænd/sluk
• Tryk og hold i 2 sekunder for at tænde DJ-
armbåndet. Det parres automatisk med PartyBox.
• Tryk og hold i 2 sekunder for at slukke DJ-
armbåndet.
Bemærk:
• DJ-armbåndet forbindes automatisk med den nærmeste PartyBox.
PAIRING
USING
15m
15m
5.2 Kontrollér PartyBox ved hjælp af
DJ-armbånd ved hjælp af gestikulation
Bevægelse Effekt
Klap Spil lydeffekt 1
Ryst Spil lydeffekt 2
Rotér Skift lysmønstre
6
Mixe lyd med mikrofon/guitar
(medfølger ikke)
4.2 USB
4.3 AUX
2
1
4.4 LINE IN
R
L
AUDIO OUT
.
.
.
LINE IN
