Hatco Flav-R-Shield EP-950 ACRYLIC User manual

© 2022 Hatco Corporation 1
Legs in offset position. Legs in center position.
3. Install the vertical posts to the acrylic shield.
Leg
Leg
Bolt
a. Prepare the work surface
so that it will not scratch the
acrylic shield during assembly.
Use towels, blankets, or other
soft, non-abrasive material.
b. Lay the acrylic panel upside-
down on the prepared work
surface.
c. For each post: Thread the
post onto the bolt of the
clamp assembly, and tighten
securely.
4. Open up the stabilizer tabs, if necessary.
• The base plate of each post assembly has retractable
stabilizer tabs that can be pivoted out for extra stability.
Tabs in retracted postion. Tabs pivoted to open postion.
5. Flip over the sneeze guard so that it is right-side-up, and place
in the desired location.
6. Adjust the angle of the acrylic shield, if necessary.
NOTE: Always loosen the hex set screws on the clamp assemblies
before attempting to the adjust the angle of the acrylic
shield. Failure to loosen the screws will strip the internal
grip fittings.
a. On each clamp assembly, loosen the hex set screw.
b. Carefully move the acrylic shield to the desired angle.
c. Tighten the hex set screw on each clamp assembly.
Hex Set
Screw
Move shield
to desired
angle.
Shield
removed
for clarity.
continued...
P/N 07.14.004.00-0622 [EP950ACRYLIC_IG]
INSTALLATION GUIDE
Flav-R-Shield™
Portable Sneeze Guards
Model EP-950 ACRYLIC
Model EP-950 ACRYLIC Curved Portable Sneeze Guards
are available in five, single bay overall widths from 24″–72″
(610–1829 mm). All of the available widths are height adjustable
from 13″–24″ (330–610 mm) and have a common base plate
depth of 14″ (356 mm).
For additional information regarding Model EP-950 ACRYLIC,
scan the QR Code below:
Important Safety Information
To avoid injury and damage to equipment or property, read the
following safety information before installing this equipment.
Do not attempt to assemble and install sneeze guards
alone. Installation of sneeze guards requires two or
more people, dependent upon unit.
Do not place anything on top of sneeze guard. It is not
designed to be a weight-bearing component.
IMPORTANT—DO NOT use paper towel or glass cleaner
to clean acrylic/plastic surfaces. Paper towel and glass
cleaner may scratch the material. Wipe off plastic
surfaces using a soft, clean, water dampened cloth.
Use non-abrasive cleaners and cloths only. Abrasive
cleaners and cloths could scratch finish of unit,
marring its appearance and making it susceptible to
soil accumulation. Use of abrasive materials will void
warranty.
Assembly and Installation
1. Unpack all components. Model EP950 sneeze guards are
shipped in three pieces—the acrylic shield (w/clamp assemblies
installed) and two vertical post assemblies.
Acrylic Shield
Post
Assembly Stabilizer
Tabs
Clamp
A
ssembly
2. Verify the mounting position of the posts on each base plate.
• The posts are pre-installed on each base plate in the offset
position. They can be moved to the center position, if
necessary.
• Use a 7/16″ socket wrench to remove the post bolt on the
bottom of the base plates. Then, reinstall the posts in the
center position of the base plates. Use a torque wrench to
tighten the bolts to 20 ft-lbs.

© 2022 Hatco Corporation2
Cleaning/Maintenance
Clean the unit daily using non-abrasive cloths and cleaners.
• Never use glass cleaner or paper towel on acrylic shield. Paper
towel and glass cleaner may scratch the material. Wipe off
acrylic/plastic surfaces using a soft, clean, water dampened
cloth.
Accessories
End Panels
End Panels with a depth of 18″ (457 mm) are available for all
EP-950 ACRYLIC portable sneeze guards.
7. Adjust the height of the acrylic shield, if necessary. This step
will require two people.
a. On each post, loosen the safety set screw on the twist-lock
nut, and turn the twist-lock nut counterclockwise to loosen.
b. Carefully move the acrylic shield to the desired height.
c. On each post, turn the twist-lock nut clockwise to secure its
position, and tighten the safety set screw on the twist-lock
nut.
Safety Set
Screw
Twist-Lock
Nut
Move both
extendable
posts to desired
height.
Shield
removed
for clarity.
24 Hour 7 Day Parts and Service
Assistance available in the United States
and Canada by calling 414-671-6350.
