Hatco GLO-RAY QW-6 Series Application guide

GLO-RAY®
Que armer
REPLACEMENT
PARTS LIST
QW-6 Series

2Form No. QWRP-0308
1
2
3
4
5
7
6
5
8
10
9
12
13
11
14
15
16
17
Thermostat capillary
and bulb shown here
for assembly
purposes only.
Model Designation
QW-6
Que Warmer
Size of Built-In Pan
6 = 1/6 size Steam Table Pan
HATCO GLO-RAY QUE ARMER
Q -6 SERIES
24 Hour 7 Day Parts and Service
Assistance available in the
United States and Canada
by calling [phone].
Use of replacement parts other than those
supplied by Hatco Corporation may result
in damage to the unit or injury to personnel.
CAUTION

PARTS SPECIFIC TO MODEL Q -6
Item Description 100V 120V 208V 240V
15 On/Off Switch, Lighted -- -- -- 02.19.080.00 -- -- -- -- -- -
16 Power Cord/Plug -- -- -- R02.18.030.00 -- -- -- -- -- --
17 Heating Blanket, 110W -- -- -- 02.05.661.00 -- -- -- -- -- --
Electrical Diagram -- -- -- 10-01-199 -- -- -- -- -- --
Form No. QWRP-0308 3
NOTE: The las four digi s in a en digi numerical serial number is he manufac uring da e code.
Example: Serial number 9625060751 has a da e code of “0751” which indica es he following; 07 51 Year 2007
Week Fifty-One
Item Description Part No. Qty.
1 Pan Assembly, 1/6 Size 04.10.134.00 1
2 Top Casing 04.10.133.00 1
3 Bracket, T-Stat Bulb 04.10.137.00 1
4 Nut, T-Stat Bulb Bracket 05.04.023.00 2
5 Insulation, Sides 05.05.121.00 4
6 Snap Plug 02.20.201.00 1
7 Thermostat Control R02.16.060A.00 1
Item Description Part No. Qty.
8 Bracket, T-Stat Body 04.19.522.00 1
9 Bottom Casing 04.10.132.00 1
10 Label, Keep out of Water 07.03.075.00 1
11 Cord Grip Assembly 02.20.259.00 1
12 Insulation, Bottom 05.05.122.00 1
13 Bottom Cover 04.10.131.00 1
14 Foot Assembly R05.30.029.00 4
PARTS COMMON TO ALL Q -6 MODELS

Printed in U.S.A. arch 2008 Form No. QWRP-0308
