Hatco HWB-11QT Installation instructions

Built-In Singular Heated Wells
HWB Series
Installation &
Operating Manual
I&W #07.05.167.00
This manual contains important safety information
concerning the maintenance, use and operation of this
product. Failure to follow the instructions contained in this
manual may result in serious injury. If you’re unable to
understand the contents of this manual, please bring it to
the attention of your supervisor. Do not operate this
equipment unless you have read and understood the
contents of this manual.
Este manual contiene importante información sobre
seguridad concerniente al mantenimiento, uso y
operación de este producto. Cualquier falla en el
seguimiento de las instrucciones contenidas en este
manual puede resultar en un serio daño. Si usted no
puede entender el contenido de este manual por
favor pregunte a su supervisor. No opere este
equipo al menos que haya leído y comprendido el
contenido de este manual.

Form No. HWBM-0107 i
CONTENTS
Important Owner Information...............................i
Introduction ...........................................................i
Important Safety Information..............................1
Model Designation...............................................2
Model Descriptions..............................................3
All Models........................................................3
Specifications.......................................................6
Electrical Rating Chart ....................................6
Dimensions......................................................8
Installation...........................................................11
Unpacking......................................................11
Location.........................................................11
Drain Assembly Models.................................17
Operation............................................................18
General..........................................................18
Power On/Off.................................................18
Temperature Control .....................................18
Food Warming...............................................18
Maintenance .......................................................19
General..........................................................19
Daily Cleaning...............................................19
Weekly Cleaning ...........................................19
Accessories........................................................20
Troubleshooting.................................................21
Hatco Limited Warranty.....................................22
Authorized Parts Distributors ............Back Cover
IMPORTANT OWNER INFORMATION
Record the model number, serial number
(identification decal located on the side of the unit),
voltage and purchase date of your Built-In Heated
Well in the spaces below. Please have this
information available when contacting Hatco for
service assistance.
Model No. ________________________________
Serial No. ________________________________
Voltage __________________________________
Date of Purchase __________________________
Business 8:00 a.m. to 5:00 p.m.
Hours: Central Standard Time
(Summer Hours: June to September –
8:00 a.m. to 5:00 p.m. C.D.T.
Monday through Thursday
8:00 a.m. to 2:30 p.m. C.D.T. Friday)
Telephone: [phone]
Fax: [phone] (Parts & Service)
[phone] (International)
Additional information can be found by visiting our
web site at www.hatcocorp.com
24-Hour 7-Day Parts & Service
Assistance available in the
United States and Canada by
calling [phone].
INTRODUCTION
The Hatco Built-In Heated Wells are specially
designed to hold heated foods at safe serving
temperatures. Designed for dry or wet applications,
the Wells are available in a variety of pan and pot
combinations, all heated with a long-life heating
element design with a 2 year warranty. Heat is
evenly distributed throughout the heavy gauge
stainless steel construction to assure hot food
without the guess work. The design allows for easy
maintenance and durable performance. The
standard unit is UL Approved, equipped with a
remote control box. An optional UR recognized unit
with remote switch is also available.
Units are equipped with EZ lock mounting hardware
(except for the insulated bottom mount models).
One year parts and on-site labor warranty is
standard.
This manual provides the installation, safety and
operating instructions for the Built-In Heated Wells.
We recommend all installation, operating and safety
instructions appearing in this manual be read prior to
installation or operation of your Built-In Heated Wells.
Safety information that appear in this manual after a
warning symbol and the words WARNING or
CAUTION printed in bold face are very important.
WARNING means there is the possibility of
serious personal injury or death to yourself or
others. CAUTION means there is the possibility
of minor or moderate injury. CAUTION without the
symbol signifies the possibility of equipment or
property damage only.
Hatco Built-In Heated Wells are a product of
extensive research and field testing. The materials
used were selected for maximum durability,
attractive appearance and optimum performance.
Every unit is thoroughly inspected and tested prior
to shipment.

Form No. HWBM-0107
1
IMPORTANT SAFETY INFORMATION
IMPORTANT! Read the following important safety information to avoid personal injury or
death, and to avoid damage to the equipment or property.
WARNINGS
To prevent electrical shock or injury, turn the
power switch OFF, disconnect the unit from
the power source and allow to cool before
performing any maintenance.
The Built-In Heated Wells are not waterproof.
To avoid electrical shock or personal injury,
DO NOT submerge in water. Do not operate if
it has been submerged in water.
Risk of fire, install Built-In Heated Well a
minimum of 3-1/2" (89 mm) from bottom of
appliance to all combustible surfaces to
assure safe and proper operation.
To avoid any injury or damage, Hatco
mounting kits must be used when mounting
unit in a combustible countertop.
To assure proper and safe operation the
remote control panel with thermostat control
must have at least a 6" (152 mm) clearance
from the Built-In Heated Well.
For proper and safe operation the remote
control panel location must be mounted on a
vertical wall.
Some exterior surfaces on the unit will get
hot. Use caution when touching these areas
to avoid injury.
To avoid injury or damage to the unit, do not
use harsh chemicals such as bleach or
cleaners containing bleach, oven cleaners,
or flammable cleaning solutions to clean the
Built-In Heated Wells.
The drain water may reach temperatures in
excess of 200°F (93°C). To avoid any injury or
damage to the unit use appropriate plumbing
materials when installing drain.
To avoid any injury or damage to the unit
turn unit off when filling with water and avoid
splashing.
Do not use Heated Well to melt or hold ice.
Doing so may cause condensation, an
electrical hazard, personnel injury, or
damage to the unit. Damage caused by
condensation is not covered by warranty.
To avoid personal injury or damage to
equipment, the Built-In Heated Wells must be
installed by qualified, trained installers.
Installation must conform to all local
electrical and plumbing codes. Check with
your local plumbing and electrical inspectors
for proper procedures and codes.
Hatco Corporation is not responsible for the
actual food product serving temperature. It is
the responsibility of the user to assure that
the food product is held and served at a safe
temperature.
If service is required on this unit, contact
your Authorized Hatco Service Agent, or
contact the Hatco Service Department at
800-558-0607 or 414-671-6350; fax 800-690-
2966 or International fax [phone].
This product has no “user” serviceable
parts. To avoid damage to the unit or injury
to personnel, use only Authorized Hatco
Service Agents and Genuine Hatco
Replacement Parts when service is required.
Genuine Hatco Replacement Parts are
specified to operate safely in the
environments in which they are used. Some
aftermarket or generic replacement parts do
not have the characteristics that will allow
them to operate safely in Hatco equipment. It
is essential to use Hatco Replacement Parts
when repairing Hatco equipment. Failure to
use Hatco Replacement Parts may subject
operators of the equipment to hazardous
electrical voltage, resulting in electrical
shock or burn.

Form No. HWBM-0107 2
IMPORTANT SAFETY INFORMATION
MODEL DESIGNATION
CAUTIONS
To avoid any injury or damage locate the unit
at the proper counter height, in an area that
is convenient for use. The location should be
level and strong enough to support the
weight of the unit and food product.
Unit is not weatherproof. For safe and proper
operation the unit must be located indoors
where the ambient air temperature is a
minimum of 70°F (21°C) and a maximum of
85°F (29°C).
To avoid injury or damage to the unit DO NOT
clean the unit while it contains any food
product. Remove food product and allow
unit to cool completely before cleaning.
Standard and approved manufacturing oils
and insulation binders will smoke up to 60
minutes during initial start-up. This is a
temporary condition. To assure safe
operation, operate unit without food product
until smoke dissipates.
CAUTIONS
Do not locate the Built-In Heated Well in an
area subject to excessive temperatures or
grease from grills, fryers, etc. Excessive
temperatures could cause damage to the
unit.
Damage to countertop material such as
Corian®and similar products caused by heat
generated from Hatco equipment is not
covered under the Hatco warranty. Contact
the manufacturer of the base material for
application information.
To avoid damage to the unit, do not use
steel wool for cleaning. Steel wool will
scratch the finish.
To assure proper operation the remote
mounted control panel must be installed in
the vertical position.
Use only non-abrasive cleaners. Abrasive
cleaners could scratch the finish of your
unit marring its appearance and making it
susceptible to soil accumulation.
HWB X X X - X X
Heated Well
Built-In
D - Drain
FUL
Full Size Pan 43 Full Size Pan
& 1/3 Pan
7QT
Round
7 Quart Pot
11QT
Round
11 Quart Pot
H
High Watt L
Low Watt
I
Insulated Top
Mount
IB
Insulated Bottom
Mount
RT - Thermostat Control (UR Only)
RN - Infinite Switch Control (UR Only)
Figure 1. Model Designation

Form No. HWBM-0107
3
MODEL DESCRIPTIONS
ALL MODELS (See Figure 2)
All Built-In Heated Well units are reliable and
versatile. Units have a stainless steel and
aluminized steel housing with a metal sheathed
heating element, available in low, standard, and
high wattage. The heating element is controlled two
ways, the first is UL listed with a thermostat and
remote control box connected to the unit with a 36"
(914 mm) flexible conduit assembly. (72" [1829 mm]
flexible conduit connection is optional, not available
for retrofit.) The second is a remote switch option
that is UR recognized with an on/off thermostat or
an infinite switch and a built in indicator light
assembly. Built-In Heated Wells are hard wired
directly to a power source for a secure and cord free
serving area. EZ locking hardware allows for Heated
Wells to be mounted into non-combustible
countertops and combustible countertops using
optional Hatco mounting kits. Built-In Heated Wells
are designed, manufactured, and tested to maintain
safe food holding temperatures.
HWB-FUL MODELS
HWB-FUL models are capable of holding a variety
of pan combinations listed below; contact factory for
details. These models are designed to be mounted
to the topside of a non-combustible countertop or
topside of a combustible countertop using the
appropriate countertop mounting kit.
• One full size pan
• Three 1/3 size pans with adapter bars.
• Two 1/2 sized pans with adapter bars.
• Two 7 quart round inserts with adapter top.
• Three 4 quart round inserts with adapter top.
Pans, Covers, Adapter Bars and Adapter Tops sold
separately.
HWB-FULD MODELS
HWB-FULD models have the same capabilities as
the HWB-FUL but is a Built-In Heated Well with a
drain. The drain includes a 3/4" NPT drain fitting and
flat drain screen that allows for pans to stay level for
consistent temperatures. These models are
designed to be mounted to the topside of a non-
combustible countertop or topside of a combustible
countertop using the appropriate countertop
mounting kit.
HWBI-FUL MODELS
HWBI-FUL models are the same as the HWB-FUL
models except the units are fully insulated. The
insulated unit conserves energy and preserves
more consistent heating temperatures. These
models are designed to be mounted to the topside
of a non-combustible countertop or topside of a
combustible countertop using the appropriate
countertop mounting kit.
HWBIB-FUL MODELS
HWBIB-FUL models are a fully insulated version of
the HWB-FUL models. These models are designed
to be mounted to the underside of a non-
combustible countertop.
HWBI-FULD MODELS
HWBI-FULD models are top mount insulated
versions that have the same capabilities as the
HWB-FUL but with a drain. The drain includes a 3/4"
NPT drain fitting and flat drain screen that allows for
pans to stay level for consistent temperatures.
These models are designed to be mounted to the
topside of a non-combustible countertop or topside
of a combustible countertop using the appropriate
countertop mounting kit.
HWBIB-FULD MODELS
HWBIB-FULD models are bottom mount insulated
versions that have the same capabilities as the
HWB-FUL but with a drain. The drain includes a 3/4"
NPT drain fitting and flat drain screen that allows for
pans to stay level for consistent temperatures.
These models are designed to be mounted to the
underside of a non-combustible countertop.

Form No. HWBM-0107 4
MODEL DESCRIPTIONS
HWB-43 MODELS
HWB-43 models are capable of holding a variety of
pan combinations listed below; contact factory for
details. These models are designed to be mounted
to the topside of a non-combustible countertop or
topside of a combustible countertop using the
appropriate countertop mounting kit.
• One full size pan and one 1/3 size pan with
adapter bars.
• Four 1/3 size pans with adapter bars.
• Two 1/2 size pans and one 1/3 size pan with
adapter bars.
• Two 11 quart round inserts with adapter top.
Pans, Covers, Adapter Bars and Adapter Tops sold
separately.
HWB-43D MODELS
HWB-43D models have the same capabilities as the
HWB-43 but is a Built-In Heated Well with a drain.
The drain includes a 3/4" NPT drain fitting and flat
drain screen that allows for pans to stay level for
consistent temperatures. These models are
designed to be mounted to the topside of a non-
combustible countertop or topside of a combustible
countertop using the appropriate countertop
mounting kit.
HWB-7QT MODELS
HWB-7QT models are round Built-In Heated Wells
that hold up to a 7 QT pan. These models are
designed to be mounted to the topside of a non-
combustible countertop or topside of a combustible
countertop using the appropriate countertop
mounting kit.
HWB-7QTD MODELS
HWB-7QTD models are the same as the HWB-7QT
but is equipped with a drain. The drain includes a
3/4" NPT drain fitting and flat drain screen that
allows for pans to stay level for consistent
temperatures. These models are designed to be
mounted to the topside of a non-combustible
countertop or topside of a combustible countertop
using the appropriate countertop mounting kit.
HWB-11QT MODELS
HWB-11QT models are round Built-In Heated Wells
that hold up to an 11 QT pan. These models are
designed to be mounted to the topside of a non-
combustible countertop or topside of a combustible
countertop using the appropriate countertop
mounting kit.
HWB-11QTD MODELS
HWB-11QTD models are the same as the HWB-
11QT but is equipped with a drain. The drain
includes a 3/4" NPT drain fitting and flat drain screen
that allows for pans to stay level for consistent
temperatures. These models are designed to be
mounted to the topside of a non-combustible
countertop or topside of a combustible countertop
using the appropriate countertop mounting kit.

Form No. HWBM-0107
5
MODEL DESCRIPTIONS
Figure 2. Built-In Heated Well Models
OFF ON
4567
8
9
10 9
10
HWB-7QTD Models
HWB-11QT Models
OFF ON
4567
8
9
10 9
10
OFF ON
4567
8
9
10 9
10
OFF ON
4567
8
9
10 9
10
OFF ON
4567
8
9
10 9
10
OFF ON
4567
8
9
10 9
10
OFF ON
4567
8
9
10 9
10
OFF ON
4567
8
9
10 9
10
OFF ON
4567
8
9
109
10
OFF ON
4567
8
9
10 9
10
HWB-FUL Models HWB-FULD Models
HWBI-FUL & HWBI-FULD Models HWBIB-FUL & HWBIB-FULD Models
HWB-43 Models HWB-43D Models
HWB-7QT Models
HWB-11QTD Models

Form No. HWBM-0107 6
SPECIFICATIONS
ELECTRICAL RATING CHART FOR STANDARD WATTAGE HWB-43 MODELS
ELECTRICAL RATING CHART FOR LOW WATTAGE HWBL-43 MODELS
Voltage Watts Amps Phase Shipping Weights
120 750 6.3 1 30 lbs. (14 kg)
208 --- --- --- ---
240 --- --- --- ---
Voltage Watts Amps Phase Shipping Weights
120 1200 10.0 1 30 lbs. (14 kg)
208 1200 5.8 1 30 lbs. (14 kg)
240 1200 5.0 1 30 lbs. (14 kg)
220 1200 5.5 1 30 lbs. (14 kg)
240 1200 5.0 1 30 lbs. (14 kg)
220-230 CE*1200 5.5 1 30 lbs. (14 kg)
230-240 CE*1200 5.0 1 30 lbs. (14 kg)
ELECTRICAL RATING CHART FOR STANDARD WATTAGE HWB-FUL MODELS
ELECTRICAL RATING CHART FOR LOW WATTAGE HWBL-FUL MODELS
Voltage Watts Amps Phase Shipping Weights
120 750 6.3 1 21 lbs. (10 kg)
208 --- --- --- ---
240 --- --- --- ---
ELECTRICAL RATING CHART FOR HIGH WATTAGE HWBH-FUL MODELS
NOTE: Shipping Weight includes packaging.
* Not available on “UR” series models.
Voltage Watts Amps Phase Shipping Weights
120 1200 10.0 1 21 lbs. (10 kg)
208 1200 5.8 1 21 lbs. (10 kg)
240 1200 5.0 1 21 lbs. (10 kg)
220 1200 5.5 1 21 lbs. (10 kg)
240 1200 5.0 1 21 lbs. (10 kg)
220-230 CE*1200 5.5 1 21 lbs. (10 kg)
230-240 CE*1200 5.0 1 21 lbs. (10 kg)
The electrical information in the shaded areas pertains to Export models only.
Voltage Watts Amps Phase Shipping Weights
120 1650 13.8 1 21 lbs. (10 kg)
208 1650 7.9 1 21 lbs. (10 kg)
240 1650 6.9 1 21 lbs. (10 kg)
220 1650 7.5 1 21 lbs. (10 kg)
240 1650 6.9 1 21 lbs. (10 kg)
220-230 CE*1650 7.5 1 21 lbs. (10 kg)
230-240 CE*1200 6.9 1 21 lbs. (10 kg)

Form No. HWBM-0107
7
SPECIFICATIONS
ELECTRICAL RATING CHART FOR HIGH WATTAGE HWBH-43 MODELS
ELECTRICAL RATING CHART FOR STANDARD WATTAGE HWB-7QT MODELS
ELECTRICAL RATING CHART FOR HIGH WATTAGE HWBH-7QT MODELS
Voltage Watts Amps Phase Shipping Weights
120 1650 13.8 1 30 lbs. (14 kg)
208 1650 7.9 1 30 lbs. (14 kg)
240 1650 6.9 1 30 lbs. (14 kg)
220 1650 7.5 1 30 lbs. (14 kg)
240 1650 6.9 1 30 lbs. (14 kg)
220-230 CE*1650 7.5 1 30 lbs. (14 kg)
230-240 CE*1650 6.9 1 30 lbs. (14 kg)
Voltage Watts Amps Phase Shipping Weights
120 500 4.2 1 10 lbs. (5 kg)
208 536 2.6 1 10 lbs. (5 kg)
240 600 2.5 1 10 lbs. (5 kg)
220 600 2.7 1 10 lbs. (5 kg)
240 600 2.5 1 10 lbs. (5 kg)
220-230 CE*600 2.7 1 10 lbs. (5 kg)
230-240 CE*600 2.5 1 10 lbs. (5 kg)
NOTE: Shipping Weight includes packaging.
* Not available on “UR” series models.
The electrical information in the shaded areas pertains to Export models only.
Voltage Watts Amps Phase Shipping Weights
120 800 6.7 1 10 lbs. (5 kg)
208 715 3.4 1 10 lbs. (5 kg)
240 800 3.3 1 10 lbs. (5 kg)
220 800 3.6 1 10 lbs. (5 kg)
240 800 3.3 1 10 lbs. (5 kg)
220-230 CE*800 3.6 1 10 lbs. (5 kg)
230-240 CE*800 3.3 1 10 lbs. (5 kg)

Form No. HWBM-0107 8
SPECIFICATIONS
Models:
HWB-FUL HWBRN-FUL HWBRT-FUL
HWB-FULD HWBRN-FULD HWBRT-FULD
HWBL-FUL HWBLRN-FUL HWBLRT-FUL
HWBL-FULD HWBLRN-FULD HWBLRT-FULD
HWBH-FUL HWBHRN-FUL HWBHRT-FUL
HWBH-FULD HWBHRN-FULD HWBHRT-FULD
Width Depth Height
(A) (B) (C)
13-3/4" 21-3/4" 8-5/8"
(349 mm) (552 mm) (219 mm)
ELECTRICAL RATING CHART FOR STANDARD WATTAGE HWB-11QT MODELS
ELECTRICAL RATING CHART FOR HIGH WATTAGE HWBH-11QT MODELS
DIMENSIONS
Figure 3. Dimensions – HWB-FUL Models
Non-Insulated – Top Mount
A
B
C
Voltage Watts Amps Phase Shipping Weights
120 500 4.2 1 11 lbs. (5 kg)
208 536 2.6 1 11 lbs. (5 kg)
240 600 2.5 1 11 lbs. (5 kg)
220 600 2.7 1 11 lbs. (5 kg)
240 600 2.5 1 11 lbs. (5 kg)
220-230 CE*600 2.7 1 11 lbs. (5 kg)
230-240 CE*600 2.5 1 11 lbs. (5 kg)
Voltage Watts Amps Phase Shipping Weights
120 800 6.7 1 11 lbs. (5 kg)
208 715 3.4 1 11 lbs. (5 kg)
240 800 3.3 1 11 lbs. (5 kg)
220 800 3.6 1 11 lbs. (5 kg)
240 800 3.3 1 11 lbs. (5 kg)
220-230 CE*800 3.6 1 11 lbs. (5 kg)
230-240 CE*800 3.3 1 11 lbs. (5 kg)
NOTE: Shipping Weight includes packaging.
* Not available on “UR” series models.
The electrical information in the shaded areas pertains to Export models only.

Form No. HWBM-0107
9
SPECIFICATIONS
Models:
HWBIB-FUL HWBIBRT-FUL
HWBIB-FULD HWBIBRT-FULD
HWBLIB-FUL HWBLIBRT-FUL
HWBLIB-FULD HWBLIBRT-FULD
HWBHIB-FUL HWBHIBRT-FUL
HWBHIB-FULD HWBHIBRT-FULD
Width Depth Height
(A) (B) (C)
14-7/16" 22-7/16" 9-1/2"
(366 mm) (569 mm) (241 mm)
DIMENSIONS (CONTINUED)
Figure 4. Dimensions – HWB-FUL
Insulated – Bottom Mount Models
A
B
C
Models:
HWBI-FUL HWBIRT-FUL
HWBI-FULD HWBIRT-FULD
HWBLI-FUL HWBLIRT-FUL
HWBLI-FULD HWBLIRT-FULD
HWBHI-FUL HWBHIRT-FUL
HWBHI-FULD HWBHIRT-FULD
Width Depth Height
(A) (B) (C)
13-3/4" 21-3/4" 9-1/2"
(349 mm) (552 mm) (241 mm)
Figure 5. Dimensions – HWB-FUL
Insulated – Top Mount Models
A
B
C

Form No. HWBM-0107 10
SPECIFICATIONS
Figure 6. Dimensions – HWB-43 Models
Non-Insulated – Top Mount
Figure 7. Dimensions – HWB-7QT Models
Non-Insulated – Top Mount
Figure 8. Dimensions – HWB-11QT Models
Non-Insulated – Top Mount
A
B
C
A
A
B
B
DIMENSIONS (CONTINUED)
Models:
HWB-43 HWBRN-43 HWBRT-43
HWB-43D HWBRN-43D HWBRT-43D
HWBL-43 HWBLRN-43 HWBLRT-43
HWBL-43D HWBLRN-43D HWBLRT-43D
HWBH-43 HWBHRN-43 HWBHRT-43
HWBH-43D HWBHRN-43D HWBHRT-43D
Width Depth Height
(A) (B) (C)
13-5/8" 28-5/8" 8-5/8"
(346 mm) (727 mm) (219 mm)
Models:
HWB-7QT HWBRN-7QT HWBRT-7QT
HWB-7QTD HWBRN-7QTD HWBRT-7QTD
HWBL-7QT HWBLRN-7QT HWBLRT-7QT
HWBL-7QTD HWBLRN-7QTD HWBLRT-7QTD
HWBH-7QT HWBHRN-7QT HWBHRT-7QT
HWBH-7QTD HWBHRN-7QTD HWBHRT-7QTD
Diameter Height
(A) (B)
10-3/8" 8-3/4"
(264 mm) (222 mm)
Models:
HWB-11QT HWBRN-11QT HWBRT-11QT
HWB-11QTD HWBRN-11QTD HWBRT-11QTD
HWBL-11QT HWBLRN-11QT HWBLRT-11QT
HWBL-11QTD HWBLRN-11QTD HWBLRT-11QTD
HWBH-11QT HWBHRN-11QT HWBHRT-11QT
HWBH-11QTD HWBHRN-11QTD HWBHRT-11QTD
Diameter Height
(A) (B)
12-1/4" 8-3/4"
(311 mm) (222 mm)

Form No. HWBM-0107
11
INSTALLATION
UNPACKING
Built-In Heated Well units are shipped from the
factory with most components assembled and ready
for use.
All Built-In Heated Wells require the control panel be
remote mounted.
NOTE: Drain models (“D” in the model designation)
require installation of the drain assembly after the
unit is installed into the countertop.
1. Remove unit from box.
2. Remove information packet. To prevent delay
in obtaining warranty coverage, fill out and
mail in the warranty card.
3. Remove tape and protective packaging from all
surfaces of unit.
LOCATION
NOTE: A qualified electrician is recommended for
connecting the Built-In Heated Well units to a power
source. A qualified plumber is recommended for
connecting drain.
WARNING
To avoid personal injury or damage to
equipment, the Built-In Heated Wells must be
installed by qualified, trained installers.
Installation must conform to all local electrical
and plumbing codes. Check with your local
plumbing and electrical inspectors for proper
procedures and codes.
WARNING
Risk of fire, install Built-In Heated Well a
minimum of 3-1/2" (89 mm) from bottom of
appliance to all combustible surfaces to assure
safe and proper operation.
WARNING
To assure safe and proper operation the remote
control panel with thermostat control must have
at least a 6" (152 mm) clearance from the Built-
In Heated Well.
CAUTION
To avoid any injury or damage locate the unit
at the proper counter height, in an area that
is convenient for use. The location should be
level and strong enough to support the weight of
the unit and food product.
CAUTION
To avoid injury or damage to the unit DO NOT
clean the unit while it contains any food product.
Remove food product and allow unit to cool
completely before cleaning.
CAUTION
Do not locate the Built-In Heated Well in an area
subject to excessive temperatures or grease
from grills, fryers, etc. Excessive temperatures
could cause damage to the unit.
CAUTION
Damage to countertop material such as Corian®
and similar products caused by heat generated
from Hatco equipment is not covered under the
Hatco warranty. Contact the manufacturer of the
base material for application information.

Form No. HWBM-0107 12
INSTALLATION
Installing Unit into Combustible Countertop
WARNING
To avoid any injury or damage Hatco mounting
kits must be used when mounting unit in a
combustible countertop.
NOTE: Cut opening for both the unit and control
panel before placing unit into countertop opening.
NOTE: Top Mount, HWB-FUL Series, insulated
models (“I” in the Model Designation) cannot be
installed into mounting flange.
1. Cut appropriate opening in countertop.
(See Figure 12 for size requirements.)
2. Cut appropriate opening for control panel.
(See Figure 14 for size requirements.)
3. Place gasket putty around cutout edge. Make
sure the gasket putty overhangs the cutout edge
or seal unit with silicone adhesive.
4. Place mounting flange into countertop opening.
5. Secure mounting flange tabs to edge or
underside of combustible countertop using
appropriate hardware. (Mounting hardware not
provided.) (See Figure 9.)
NOTE: For underside mounting, tabs on mounting
flange must be bent to underside of countertop.
6. Place gasket putty around cutout in mounting
flange. Make sure the gasket putty overhangs
the flange or seal unit with silicone adhesive.
7. Place the unit into the countertop opening.
8. Use a screwdriver to rotate the EZ locking
mounting system on the Built-In Heated Well
outward, to secure the unit from the underside of
the mounting flange. Twist as many tabs as
needed to secure unit to mounting flange.
(See Figure 10.)
9. Using a razor, carefully trim the excess gasket
putty material and remove.
Figure 9. Installation of Mounting Flange Kit
Figure 10. EZ Locking Tabs
Countertop
EZ Locking
Tab
Mounting Flange
Mounting Flange Tabs
Countertop Edge Mounting
Countertop Underside Mounting

Form No. HWBM-0107
13
INSTALLATION
Installing Unit into Non-Combustible Countertop
NOTE: Mounting flange kit is not required for
installation into non-combustible material.
NOTE: Cut opening for both the unit and control
panel before placing unit into countertop opening.
1. Cut appropriate opening in countertop.
(See Figure 13 for size requirements.)
2. Cut appropriate opening for control panel. (See
Figure 14 for size requirements.)
3. Place gasket putty around cutout edge. Make
sure the gasket putty overhangs the outside rim
of the unit or seal with silicone adhesive.
4. Place the unit into the countertop opening.
5. Use a screwdriver to rotate the EZ locking
mounting system on the Built-In Heated Well
outward, to secure the unit from the underside of
the countertop. Twist as many tabs as needed to
secure unit to the countertop. (See Figure 11.)
Note: EZ locking mounting systems works on
countertops that have a maximum thickness of 3/16"
(5 mm). Twist as many tabs as needed to secure
unit into countertop.
6. Using a razor, carefully trim the excess gasket
putty material and remove.
Figure 11. EZ Locking Tabs
Countertop
EZ Locking
Tab

Form No. HWBM-0107 14
INSTALLATION
HWB-FUL & HWBIB-FUL Models
HWB-43 Models
HWB-7QT Models
HWB-11QT Models
A
B
A
B
Figure 12. Combustible Countertop Mounting Flange Templates
COMBUSTIBLE COUNTERTOP CUTOUT
(A) (A) (B) (B)
Model Minimum Width Maximum Width Minimum Depth Maximum Depth
All HWB-FUL Models 14" 14-1/4" 22" 22-1/4"
(356 mm) (362 mm) (559 mm) (565 mm)
All HWB-43 Models 14" 14-1/4" 29" 29-1/4"
(356 mm) (362 mm) (737 mm) (743 mm)
All HWB-7QT Models 11" *11-1/4" *11" *11-1/4" *
(279 mm) (286 mm) (279 mm) (286 mm)
All HWB-11QT Models 13" *13-1/4" *13" *13-1/4" *
(330 mm) (337 mm) (330 mm) (337 mm)
*Combustible Countertop opening is a “square” cut-out.
NOTE: Required minimum clearance below countertop cutout is 8-5/8" (219 mm). Allow additional clearance for units
equipped with drain.
A
B
A
B

Form No. HWBM-0107
15
INSTALLATION
Figure 13. Non-Combustible Countertop Mounting Templates
HWB-FUL & HWBIB-FUL Models
HWB-43 Models
HWB-7QT Models
HWB-11QT Models
NOTE: Required minimum clearance below countertop cutout is 8-5/8" (219 mm). Allow additional clearance for units
equipped with drain.
NON-COMBUSTIBLE COUNTERTOP CUTOUT
(A) (A) (B) (B)
Model Minimum Width Maximum Width Minimum Depth Maximum Depth
All HWB-FUL Models 12-5/8" 12-15/16" 20-5/8" 20-15/16"
(321 mm) (328 mm) (524 mm) (531 mm)
All HWB-43 Models 12-11/16" 12-15/16" 27-11/16" 28"
(322 mm) (329 mm) (703 mm) (711 mm)
All HWB-7QT Models 9-1/8" 9-9/16" --- ---
(232 mm) (243 mm) --- ---
All HWB-11QT Models 11" 11-3/8" --- ---
(279 mm) (289 mm) --- ---
(A) Width (B) Depth
All HWBIB-FUL Models 12-1/32" 20-1/32"
(306 mm) (509 mm)
A
B
A
BA
A

Form No. HWBM-0107 16
INSTALLATION
Remote Mounted Control Panel
WARNING
For proper and safe operation the remote
control panel location must be mounted on a
vertical wall.
CAUTION
To assure proper operation the remote mounted
control panel must be installed in the vertical
position.
NOTE: A qualified electrician is recommended for
connecting the Heated Well units to a power source.
A qualified plumber is recommended for connecting
drain(s).
1. Remove trim cover from control panel assembly.
2. Position control panel into opening through the
backside.
3. Secure control panel to surface using screws
(#8 sheet metal screw supplied).
4. Connect proper power source to the mounted
remote control panel .
5. Reinstall trim cover.
NOTE: Standard UL Approved units are equipped
with a 72" (1829 mm) flexible conduit connected to
the control panel.
Figure 14. Control Panel Opening Dimensions
B
CONTROL PANEL CUTOUT DIMENSIONS
Opening Dimensions Screw Hole Dimensions
Model (A) (B) (C) (D)
Control Assembly 2-3/16" 3-3/8" 2-1/2" 3-1/4"
Without Bezel (Standard) (55 mm) (86 mm) (64 mm) (83 mm)
Control Assembly 3-1/4" 3-3/4" 4-1/8" ---
With Bezel (Standard) (83 mm) (92 mm) (105 mm) ---
Control Assembly 5-7/8" 6-3/8" 3-7/8" 6-13/16"
Large (Optional) (149 mm) (162 mm) (98 mm) (173 mm)
B
B
A
A
A
C
C
C
DD
Control Assembly Without
Bezel (Standard) Control Assembly With Bezel (Standard) Control Assembly Large (Optional)

INSTALLATION
DRAIN ASSEMBLY MODELS
WARNING
The drain water may reach temperatures in
excess of 200°F (93°C). To avoid any injury or
damage to the unit use appropriate plumbing
materials when installing drain.
For proper drain plumbing installation conforming to
local plumbing codes consult a licensed plumbing
contractor.
Drain Assembly (See Figure 15)
After installing unit in countertop, install the drain
assembly as follows:
NOTE: Approved air gap or other back-flow
prevention device must be installed by plumber if
required.
1. Connect one end of drain pipe (supplied by
others) to 3/4" NPT drain fitting.
2. Connect other end of drain pipe to drain valve,
(supplied by others).
3. Accessible drain valve (supplied by others) must
connect to external drain pipe.
Figure 15. Drain Connection
Drain
Fitting
Form No. HWBM-0906
17

Form No. HWBM-0107 18
OPERATION
OFF ON
110
567
8
9
4
3
2
Figure 16. Control Panel
GENERAL WARNING
Some exterior surfaces on the unit will get hot.
Use caution when touching these areas to avoid
injury.
WARNING
To avoid any injury or damage to the unit turn
unit off when filling with water and avoid
splashing.
WARNING
Do not use Heated Well to melt or hold ice.
Doing so may cause condensation, an electrical
hazard, personnel injury, or damage to the unit.
Damage caused by condensation is not covered
by warranty.
CAUTION
Unit is not weatherproof. For safe and proper
operation the unit must be located indoors
where the ambient air temperature is a minimum
of 70°F (21°C) and a maximum of 85°F (29°C).
CAUTION
Standard and approved manufacturing oils and
insulation binders will smoke up to 60 minutes
during initial start-up. This is a temporary
condition. To assure safe operation, operate unit
without food product until smoke dissipates.
Hatco Built-In Heated Wells are designed for WET
or DRY operation.
NOTE: Built-In Heated Wells cannot be used wet-to-
dry or dry-to-wet unless the unit has been allowed to
cool down to room temperature before changing the
operation.
We recommend wet operation for consistent food
heating.
If the unit is operating wet and is allowed to run dry,
turn it off and allow to cool before adding water.
POWER ON/OFF
Place the On/Off switch in the “ON” position. The
indicator light glows when the unit is on.
(See Figure 16.)
Thermostat Control Knob On/Off Switch
TEMPERATURE CONTROL
Turn thermostat control knob to adjust the
temperature of the Built-In Heated Well to the
desired safe food temperature.
Allow heated well to preheat for approximately
30 minutes.
WARNING
Hatco Corporation is not responsible for the
actual food product serving temperature. It is
the responsibility of the user to assure that the
food product is held and served at a safe
temperature.
FOOD WARMING
Place appropriate sized food pan into the Built-In
Heated Well opening.
NOTE: Always use a food pan. Do not place food
directly into the warmer.
NOTE: Stir thick food items frequently to keep food
heated uniformly.
NOTE: Keep pans covered to maintain food quality
and temperature.
