GLO-RAY ®
CARVING STATIONS
Models GRCSCL-24, GRCSCLH-24
The Glo-Ray Carving Station is the ideal
attachment to extend food holding times
during serving periods. This adjustable
height station features ceramic heating
elements, incandescent lights and sturdy
right-hand breath protector to protect the
work area.
FLEXIBILITY
Models are available with or without
base heat. Independent controls define
the temperature settings for the ceramic
element top heat and the blanket
element base heat.
The Glo-Ray Carving Station can sit
on top of the Flav-R-Savor®Portable
Holding Cabinet as well as on
countertops, designing a complete
serving station for buffet lines.
The height of this station can be adjusted
to provide a clearance of 171⁄2" up to 231⁄2"
(445-597 mm) from the top of the base to
the bottom of the foodwarmer housing.
The Carving Station features ceramic
heating elements, specially coated
incandescent lights, and a sturdy breath
protector on the right-hand side. A left-
hand breath protector is available both
as an accessory and as a retrofit kit.
The
Carving Station comes with a
6' (1829 mm) cord and plug attached.
Custom drip pan and cutting board
are also available.
QUALITY
The following features assure the finest
performance for years to come:
• Ceramic heating element from above
extend food holding times safely
during serving periods.
• Models available with or without
heated base.
• The Carving Station features ceramic
heating elements, incandescent lights,
and a sturdy right-hand breath
protector.
• Coated shatter-resistant incandescent
lights enhance brilliant product
display while safeguarding food
products from bulb breakage.
• Add Carving Station to
Flav-R-Savor
holding cabinets to design a complete
serving station for buffet lines.
• Optional left-hand breath protector,
custom drip pans, and NSF approved
cutting boards available.
Model GRCSCLH-24 with
optional base heat, left-hand
breath protector, drip pan, and
cutting board
CERAMIC AND BLANKET HEATING ELEMENTS
GUARANTEED AGAINST BURNOUT AND BREAKAGE
FOR ONE YEAR.

SPECIFICATIONS
Model Volts Watts Amps Shipping Weight
GRCSCL-24 120 990 8.3 55 lbs. (25 kg)
GRCSCLH-24* 120 1290 10.8 56 lbs. (25 kg)
* “H” model indicates heated base.
OPTIONS
❑Halogen Bulb in lieu of Standard Display Light
ACCESSORIES
❑Left-Hand Breath Protector Kit (3 lbs. (1 kg))
❑Stainless Steel Custom Drip Pan
20" x 263⁄4" x 1" (508 x 679 x 25 mm) (9 lbs. (4 kg))
❑NSF Approved Cutting Board
18" x 24" x 13⁄4" (457 x 610 x 44 mm) (19 lbs. (9 kg))
ITEM#
25" (635 mm)
28" (711 mm)
191⁄2" (495 mm)
23" (584 mm)
26" (660 mm)
FRONT VIEW SIDE VIEW
171⁄2" to 231⁄2"
(445 to 597 mm)
21⁄2" (64 mm)
21⁄2" (64 mm)
221⁄2" to 281⁄2"
(572 to 724 mm)
PRODUCT SPECS
Carving Station
The Infrared Foodwarmer shall be a Glo-Ray®, manufactured by
the Hatco Corporation, Milwaukee, WI 53234 U.S.A.
The Foodwarmer shall be a Glo-Ray Model ...., rated at ....watts,
....volts, single phase, and be ....inches (millimeters) in
overall width.
The Glo-Ray shall consist of ceramic heating elements,
incandescent lights, and breath protector.
The foodwarmer shall be factory-assembled ready for
electrical installation.
Accessories shall include left-hand breath protector kit, stainless
steel custom drip pan, and NSF approved cutting board.
GLO-RAY ®
CARVING STATIONS
Models GRCSCL-24, GRCSCLH-24
DIMENSIONS
26"W (including left- and right-hand breath protectors)
x 28"D x 221⁄2"-281⁄2"H (660 x 711 x 572-724 mm)
VOLTAGE
120 volts, single phase (uses NEMA 5-15P).
Export voltages available.
CORD LOCATION
Back side on base.
PLUG CONFIGURATIONS
BS-1363CEE 7/7 SchukoNEMA 5-15P
