HATHASPACE HSP001 User manual

HSP001 Smart True
HEPA Air Purifier
PRODUCT MANUAL
PURE AIR,
ALWAYS.

NOTE:
Remove plastic bag from
filter before use

Precautions 4-5
Specifications 6
Features 6-7
Product Diagram 8
Smart Air Quality Sensor 9
Filter Installation 10-11
Filter Maintenance 11
Operation 12-13
Troubleshooting 14
Customer Support 15
Contents

Precautions
Before use, read entire manual thoroughly and keep it for future reference.
Hazardous
To avoid electric shock or fire, ensure that the product is dry at all times and keep the
product away from water or any other liquid.
Warning
1. Make sure the local power supply voltage is the same as indicated on the nameplate on
the back of machine.
2. If the power cord is damaged, do not plug in or turn on the purifier.
Email [email protected].
3. Do not block the air inlet or outlet with any objects.
4. For safety, do not allow children to handle the purifier.
5. Keep the filters away from high temperatures or sparks/flames.
6. To reduce the risk of electric shock, this equipment has a polarized plug (one blade is
wider than the other). This plug will fit in a polarized outlet only one way. If the plug does
not fit fully in the outlet, reverse the plug. If it still does not fit, contact qualified personnel
to install the proper outlet. Do not alter the plug in any way.
Ozone can be harmful and can cause irritation and injury.When using the Ionizer/Anion
feature, this device should be used in unoccupied spaces only. Do not use while humans or
animals are present. Wait 30 minutes after completing use for reentry.
Notice
1. Do not use the purifier as a chemical ventilator, dust cleaner, or cooker ventilation hood.
2. Ensure your power outlet is functioning properly.
3. Place the purifier on a dry, stable, and flat surface.
4. Keep 8 inches of space on either side of the purifier, while in operation, to allow proper
airflow through the unit. Leave 12 inches of space above the top of the air purifier.
Containing the purifier in a small space will restrict airflow and eciency of the unit.
4

5. Do not place the purifier under an air conditioning unit, or any place where
water may drip onto it.
6. Do not drop or hit the product, handle it gently.
7. Do not operate this product while using flammable gas sprays such as insect
repellent, and common household cleaning chemicals.
8. Do not use this product near gas appliances, heating devices, or near a stove.
9. Unplug the power cord when cleaning or changing filters.
10. Do not operate the purifier in a space where temperature changes are drastic.
This will cause condensation to form in the unit and ruin electrical components.
11. This product is intended for household use under normal operating conditions.
12. Do not use this product in a space with high humidity, such as a bathroom with
the shower on, sauna, or steam room.
Smart Air Quality Sensor System memory reset instructions:
If the air quality indicator displays red color and the machine is cut
o suddenly, you may have to reset the memory. Otherwise, the
red color display will remain.
1. Unplug the machine and wait for 15-20 seconds. Plug again and start the
machine.
2. Keep the machine running for 1 minute. The air quality indicator should begin
functioning normally again.
3. Please perform the reset steps above in a clean environment without
air pollution. Otherwise, the air quality display lights will be disrupted.
5

Specifications
Features
Product
Rated Voltage
Rated Frequency
Rated Power
Room Coverage
CADR (PM)
HSP001
120 V / Please refer to the nameplate on the back of
the machine.
60HZ
45W
Replaces the air 2x per hour in 350 Sq Ft
Replaces the air 1x per hour in 700 Sq Ft
160 m3/ hr
5-IN-1 PURIFICATION SYSTEM
3HEPA Pre-Filter
4Activated Carbon Filter
2True HEPA Filter
1Ionizer
Cold Catalyst Filter
5
2-5
1
6

1. Ionizer/Anion Generation
Hathaspace’s California Air Resources Board (CARB) approved anion feature uses voltage
to electrically charge air molecules and can be turned on or o anytime. When on, negative
ions are released, which are particles with one or more extra electron. This eliminates
odors, smoke, and gases in the air. It also makes smaller particles easier to capture within
the physical filters.
2. True HEPA Filter
Hathaspace HEPA material is the trusted standard in high eciency particulate air
purification. True HEPA filter removes particles from the air, including dust and smoke.
3. HEPA Pre-Filter
Captures larger particles like dust, lint, and pet hair.
4. Activated Carbon Filter
High Grade Active Carbon absorbs smoke, odors, gases, and volatile organic compounds
(VOC’s). We don’t skimp on the carbon. Every filter contains over 300 grams of high grade
active carbon, meaning more absorption, and a longer useful life of the filter.
5. Cold Catalyst Filter
Targets Volatile Organic Compounds (VOC’s) and gases like formaldehyde,
benzene, and ammonia.
7

Product Diagram
1. Display
2. Control Panel
3. Power
4. Light
5. Timer
6. Fan Speed
7. Ionizer
8. Sleep Mode
9. Front Plate
10. Air Inflow
11. Handle
12. Air Outflow
12
5 3
8
9
6
4
7
10
11
12
8

Smart Air Quality Sensor
The Smart Air Quality Sensor detects particles and odors
in real time, feeding that info to the purifier so it can
adjust. This keeps your air quality consistently clean, while
reducing power consumption and your electric bill.
Color
Green
Yellow
Red
Air Quality
Good
Moderate
Bad
Fan Speed
Low
Medium
High
9

Filter Installation
Pull the front plate toward you from its base and its magnets
will release the bottom of the front cover. Then lift upward on
the front plate to remove it completely, exposing the filter.
Turn buckles and remove filter gently by pulling outward.
Remove packaging film from filters before use.
Place Filter 2 (HEPA Pre-Filter and HEPA Filter) back into unit.
Note: ensure tab is facing you.
Place Filter 1 (Cold Catalyst & Activated Carbon Filter)
back into the unit.
Note: ensure tab is facing you.
10

Make sure filters are installed correctly, with tabs facing you.
Lock filters in place by turning the buckles to secure them.
Reinstall the front plate by first placing the top of the front
plate into the notches on the top of the purifier. Next, let the
bottom magnets connect. Make sure the front is secure before
powering on.
Filter Maintenance
Note: To avoid shortening the life of your air purifier, use only certified Hathaspace
filters for HSP001.
Guidelines:
• Replace filters every 4 months for optimal performance.
• Do not clean the filters with water or other liquids. Use a keyboard duster to
gently remove any physical debris such as lint and hair.
JOIN OUR FILTER CLUB
New filters delivered to your door,
right when you need them.
SCAN
&
SAVE
11

Operation
Your included remote gives full control of your purifier
from across the room and is powered by 2 AAA batteries
(not included).
Plug in the purifier. The red power indicator will light up.
Use the Power button on the unit or remote to turn on/o. The
purifier will start in AUTO mode and the smart sensor will
automatically initiate when the unit is turned on. The unit will
adjust the fan speed automatically, beginning in high for a few
minutes and moving down as needed.
Note: When restarting the air purifier in AUTO mode, the unit will always
start back in high mode and slowly adjust down to make sure the air is
clean. Once in low mode, it will adjust in real time according to your air
environment.
The timer allows you to set your purifier to turn o after a set
amount of time. You can choose up to 12 hours, or not use it
at all and let the purifier run continuously. The time interval is
displayed on the unit. It will turn o once the timer runs out.
Press the Speed button on the unit or remote to adjust the
fan speed. A faster speed increases the airflow through the
unit, thus purifying your air faster. Choose from Low (Green),
Medium (Orange), High (Red), and AUTO mode. In AUTO mode,
the fan speed will automatically adjust based on the air quality
in the room.
12

Press the Sleep button on the unit or remote to put the purifier
in sleep mode. In sleep mode, the unit will run at a whisper-
quiet speed with the lights o, and the smart sensor will turn
o. If you would like to have the lights o while operating
in other fan modes, then just press the Light button in your
preferred mode and the lights will shut o. Press any of the
buttons to exit sleep mode.
Press the Anion button on the unit or remote to turn on the
ionizer. The Anion light will turn green on the display when the
ionizer is on.
Press the Light button on the unit or remote to turn on/o the
lights on the display. You can turn the lights o in any of the fan
modes (Low, Medium, High, or AUTO), giving you more control
over your purifier. If you power o the unit, the unit will always
restart with the lights back on.
13

Troubleshooting
Problem
No air comes out from
the outlet
Decreased airflow
Air quality has not improved
after running the purifier
When to replace the
filters
Solution
Check if purifier is on using the red power indicator on
the display. Test outlet.
The filters are dirty and they need to be cleaned or
replaced.
The filter packaging bag is not removed. Please remove
the filter packaging bag.
Make sure the filters are installed in the proper order
and positioned correctly in the unit.
Filters are worn out, please replace all the filters.
When the surface of the first filter is dirty and fades in
color, it has collected many particles, and will perform
better if replaced with a clean filter. Typical operating
conditions require changing the filter every 4 months.
Change the filter when the HEPA filter becomes
discolored, or every 4 months.
The filter replacement period is dependent on the air
it filters, time used, and amount of particles collected.
For optimal air purification, it is best to replace the
filters every 4 months.
If you notice a chemical/burning like smell after using
the unit for a while, this can be from the active carbon
being overly saturated with gas. It is time to replace
the filters.
For all other questions, email [email protected]om
14

Hathaspace strives to make every part of your experience exceptional. If you have any
questions or concerns about your air purifier, please feel free to contact our Customer
Support.
Email: [email protected]
Website: https://hathaspace.com
Customer Support
Welcome to the Hathaspace family. For questions, contact us at
[email protected]
In Harmony.
JOIN OUR FILTER CLUB
New filters delivered to your door,
right when you need them.
SCAN
&
SAVE
Note: To avoid shortening the life of your air purifier, use only certified Hathaspace
filters for HSP001.
Guidelines:
• Replace filters every 4 months for optimal performance.
• Do not clean the filters with water or other liquids. Use a keyboard duster to
gently remove any physical debris such as lint and hair.
15

www.hathaspace.com
[email protected]om
1-800-446-0535
Hathaspace
HSP001 Smart True
HEPA Air Purifier
Manufactured for Hathaspace EPA Est. No. 99346-CHN-1
© Hathaspace. All rights reserved.
