HATHASPACE HSP001 User manual

Smart True HEPA
Air Purifier
Model HSP001

Specifications 1
Features 1
Product Diagram 3
Smart Air Quality Sensor 4
Filter Installation 5
Filter Maintenance 6
Operations 7
9
Precautions
Troubleshooting 13
CONTENTS

1
Product Name Smart True HEPA Air Purifier
AC 110V~120V or 220V~240V
Please refer to the nameplate on the back of machine.
50 / 60HZ
40W
Rated Voltage
Rated Frequency
Rated Power
Replaces the air 2x per hour in 350 Sq Ft
Replaces the air 1x per hour in 700 Sq Ft
Room Coverage
160 m3/hr
CADR
Nano Cold Catalyst Filter
Removes larger particles like dust and pet dander, as well as toxic
household chemicals like formaldehyde, ammonia, benzene,
and other harmful gases.
Activated Carbon Filter
Activated carbon molecules absorb and remove smoke, odors, gases,
and volatile organic compounds (VOC's) found in household products.
Antibacterial Filter
Nano-materials in the antibacterial filter eliminate and destroy bacteria,
viruses, and molds in the air.
SPECIFICATIONS
FEATURES

2
True HEPA Filter
Efficiently removes 99.97% of airborne pollutants in the air as small
as 0.3 microns like dust mites, allergens, pollen, mold spores,
bacteria, and viruses.
Ionizer/Anion Filter
Releases negative ions (anions) that attach to positively charged air
pollutant particles, neutralizing them and making them easier for the
air purifier to capture.
UV-C Light Sterilizer
245nm UV-C light sterilizes and kills a variety of bacteria by targeting
their DNA. It also eliminates odors and produces negative ions,
making your air fresher and preventing the spread of viruses.

3
(10)
(11)
(12)
(1)(2)
(3)
(8)
(9)
(4)
(5)
(6)
(7)
PRODUCT DIAGRAM
(1) Display
(2) Control Panel
(3) Power
(4) UV Sterilizer
(5) Timer
(6) Fan Speed
(7) Ionizer
(8) Sleep Mode
(9) Front plate
(10) Air Inflow
(11) Handle
(12) Air Outflow

AIR QUALITY SENSOR
4
88
H
SLEEP
POWERANiONTIMER
AIR QUALITY
STERILIZE
Color
Green
Yellow
Red
Good
Moderate
Bad
Low
Medium
High
Air Quality Fan Speed
The air quality sensor detects you air environment in
real-time, feeding information to the air purifier about
the quality of your air. To maintain optimal function,
use a compressed air can once a year to blow off
particles that have accumulated on or near the sensor.
Sensor is located on the bottom left when you remove
the front cover.

Place Filter 2 (Antibacterial and HEPA Filter) back into
the unit.
Note: Please ensure the tab side is facing you.
Place filter 1 (Nano-Cold Catalyst Filter) back into
the unit.
Note: Please ensure the tab side is facing you.
Pull the front plate toward you from its base and its
magnets will release the bottom of the front cover. Then
lift upward on the front plate to remove it completely,
exposing the filter.
Turn bucklesand remove filter gently by pulling outward.
Remove packaging film from filters before use.
FILTER INSTALLATION
5

It is recommended to change the filters every 6 months. You may need
to do so sooner depending on your air conditions. It is important to be
aware of the following signs of expired filters:
Increased operating noise
Decreased air flow
Filters smell of odors when removed
Filters are visibly covered in debris
Make sure filters are installed correctly, with tabs facing
you. Lock filters in place by turning the buckles to secure
them.
Reinstallthe front plate by first placing the top of the
front plate into the notches on the top of the purifier.
Next, let the bottom magnets connect. Make sure the
front plate is secure before powering on.
To extend the filter life, expose the filters to sunlight
periodically for 15-30 minutes in order to release any
gases, bacteria, or odors accumulated on the filters.
FILTER MAINTENANCE
6

Plug in the purifier. The red power indicator on the
display will light up. Use the Power button on theunit
or remote to turn on/off. The purifier will start in auto
mode and the smart sensor will automatically initiate
when the unit is turned on. Give thesensor a few
minutes to process theair quality. The unit will adjust
the fan speed automatically according to the air quality,
always beginning in high and moving down as needed.
Press the Timer button on theunit or remote to cycle
through preset time intervals. You can choose up to
12 hours, or not use the timer and let thepurifier run
continuously. The time interval is displayed on the unit
display. The unit will power off after the time interval
ends.
Press the Speed button on the unit or remote to adjust
the fan speed.A faster fan speed increases airflow
through the unit, thus purifying your air faster. Choose
from Low (Green), Medium (Orange), High (Red), and
OFF. Fan speed is indicated on the unit display.
The Hathaspace purifier includes a remote, which is
powered by 2 AAA batteries (not included).
On/Off
Speed
Sleep
Timer
Anion
Sterilize
Air Quality
H
Timer Sterilize Anion Power
Low Medium High Sleep
Power
Air Quality
H
Timer Sterilize Anion Power
Low Medium High Sleep
Timer
Air Quality
H
Timer Sterilize Anion Power
Low Medium High Sleep
Speed
OPERATION
7

Press the Sleep button on the unit or remote to put the
purifier in sleep mode. In sleep mode, the unit will run
at a low speed, and the intelligent sensor turns off.
This keeps the purifier whisper-quiet. When sleep
mode is on, the unit will only run at low fan speed and
the display lights will turn off.
Press the Anion button on theunit or remote to turn on
the ionizer. The Anion light will turn green on the
display when the ionizer is on.
Press the Sterilize button on theunit or remote to turn
on theUV Germicidal Lamp. The Sterilize light will turn
blue on the display when theUV Germicidal Lamp is on.
Air Quality
H
Timer Sterilize Anion Power
Low Medium High Sleep
Sleep
Air Quality
H
Timer Sterilize Anion Power
Low Medium High Sleep
Anion
Air Quality
H
Timer Sterilize Anion Power
Low Medium High Sleep
Sterilize
8

9
Before use, read entire manual thoroughly and keep it for future reference.
Hazardous
To avoid electric shock or fire, ensure that the product is
dry at all times and keep the product away from water or
any other liquid.
Warning
Make sure the local power supply voltage is the same as
indicated on the nameplate on the back of machine.
If the power cord is damaged, do not plug in or turn on the purifier.
Email Hathaspace at [e-mail].
Keep the filters away from high temperatures or sparks/flames.5.
Do not block the air inlet or outlet with any objects.
For safety, do not allow children to handle the purifier
unsupervised.
PRECAUTIONS

Notice
Do not use the purifier as a chemical ventilator, dust
cleaner, or cooker ventilation hood.
Ensure your power outlet is functioning properly.
This product must be placed on a dry, stable and flat surface
Keep 8 inches of space on either side of the purifier
while in operation, to allow proper airflow through the
unit. Leave 12 inches of space above the top of the
air purifier. Containing the purifier in a small space will
restrict airflow and efficiency of the unit.
Do not place any objects on top of or on the side of the
unit.
10

11
Do not drop or hit the product, handle it gently.
Do not operate this product while using flammable gas sprays such as
insect repellent, and common household cleaning chemicals.
Unplug the power cord when cleaning or changing filters.
Do not operate the purifier in a space where temperature changes are
drastic. This will cause condensation to form in the unit and ruin
electrical components.
This product is intended for household use under normal operating
conditions.
Do not use this product near gas appliances, heating9
10
11
12
13
devices, or near a stove.
Do not place the purifier under an air conditioning unit, or any place
where water may drip onto it.
Do not use this product in a space with high humidity,
such as a bathroom with the shower on, sauna, or
steam room.

Smart Air Quality Sensor System memory reset instructions:
If the air quality indicator displays red color and the machine power is cut
off suddenly, you may have to reset the intelligent memory. Otherwise, the
red color display will remain.
Unplug the machine and wait for 15-20 seconds. Plug again and start
the machine.
Keep the machine running for 1 minute. The air quality indicator should
begin functioning normally again.
Please perform the steps above in a clean environment without air
pollution. Otherwise, the air quality display lights will be disrupted.
12

Problem Solution
No air comes out from
the outlet.
Check if purifier is on using the red power
indicator on the display.
Decreased Airflow
The filters are dirty and they need to be cleaned
or replaced.
The filter packaging bag is not removed.
Please remove the filter packaging bag.
Air quality has not improved
after running the purifier.
Make sure the filters are installed in the proper
order and positioned correctly in the unit.
Filters are worn out, please replace all the
filters.
When to replace the filters.
The filter replacement period is dependent on
the air it filters, time used, and amount of
particles collected. For optimal air purification,
it is best to replace the filters every 6 months.
When the surface of the first filter is dirty and
fades in color, it has collected many particles,
and will perform better if replaced with a clean
filter. Typical operating conditions require
changing the filter every 6 months.
Change the filter when the HEPA filter becomes
discolored, or every 6 months.
TROUBLESHOOTING
13
For all other questions, email [email protected]
