INSTALL INSTRUCTIONS C-TCB-24
1999-2006 FORD EXCURSION &
1999-2008 F-250/F-350/F-450/F-550 PICKUP
TOOLS REQUIRED:
Torx Bit Set (T-55)
3/16” Allen wrench
3/8” Standard Socket Set
3/8” Metric Socket Set
3/8” Ratcheting Wrench
Powered drill
3/16” & 5/16” Drill bits
Open-end wrench set
COMPONENTS & HARDWARE:
ITEM # QTY DESCRIPTION PART #
1 1 Pole Support Assembly CM93071-24
2 1 Telescoping Pole Assembly CM93072-3
3 1 Lateral Brace Arm CM93338
4 2 5/16” Hex nut GSM30007
5 1 5/16” Nylock Nut GSM30017
6 6 5/16” Flat Washer GSM31006
7 2 5/16” Lock Washer GSM31027
8 1 5/16-18 x 1” Hex Head Bolt GSM33012
9 2 5/16-18 x 1 ¼” Hex Head Bolt GSM33013
10 2 ¼” x ¾” Hex head lag bolt GSM33060-1
C-TCB-24_INST_9-08

Always!
¾Read all instructions before installing any Havis-Shields Equipment Corp products.
¾Check for obstructions (Wire, brake lines, fuel tank, etc.) before drilling any holes!
¾Use hardware provided with install kit
INSTALLATION:
•Remove front passenger seat bolts. Loosen but do not remove rear bolts.
Telescoping
Pole Assembly
Note: When installing C-TCB-24 into Extended Cab or Crew Cab pick-ups, the air duck on
the passenger side floor must be cut out or completely removed to install.
•Slide base of the pole support assembly under the seat base brackets.
•Align the holes of the seat base, the pole support assembly and floor holes. Replace
front seat bolts. Firmly tighten all seat bolts without over tightening.
•Attach lateral brace arm assembly to the pole support assembly with 5/16” x 1” Hex
head bolt, washer and nylock nut.
•Secure lateral brace arm to side of the transmission hump using ¼” x ¾” Hex head
lag bolts.
Note: When mounting side support brace to floor of vehicle, be sure to check for obstructions prior to
drilling or lag bolting to floor.
•Tighten the screw that attaches the brace arm to the pole support assembly last.
•Tighten down factory passenger seat bolts and 5/16-18-nylock nut holding side
support brace to pole support assembly.
•Mount optional C-3090, computer-mounting platform, to telescoping pole assembly
using hardware and instructions provided with C-3090.
Pole Support
Assembly
C-TCB-24_INST_9-08
