Magnafire® Custom Cab Brow Mounts (1500, 2500, 3500, and 3600 Series)
Can be mounted flush to the roof
line and won’t interfere with your
emergency light bar or ladder.
Illuminate the emergency scene upon
arrival and identify the incident!
Above: Spartan custom cab mount and Magnafire 3000® Floodlight
Model shown: KR-153X-SP-KOV
Custom cab brow mounting with a Magnafire 3000 or 5000® high intensity light. This mount is available for Spartan, KME, E-
ONE, E-ONE Quest Chassis, American LaFrance, Freightliner, and other manufacturers.
Each mount is vehicle specific, cast formed to match roof radius for easy installation and a professional look.
The Magnafire® cast aluminum housing floodlight 10° downward angle design provides optimal scene lighting around your
truck to see and be seen at the incident!
The new smaller Magnafire 5000® (available for KR-2500, KR-3500 and KR-3600 series) allows you to save mounting space.
More light, less watts! Allows you to add more lights to your apparatus without increasing the total electrical load (i.e.
bigger generator).
Contact your OEM dealer for availability for your vehicle!
•
•
•
•
•
KR-15XX
KR-25XX
E-One Mount
KR-35XX
E-One Quest Chassis
Brow Mount
KR-36XX
E-One Quest Chassis
Side Mount
KR-15XX-ALF-X
KR-25XX-ALF-X
American LaFrance
Mount
KR-15XX-SP-KOV
KR-25XX-SP-KOV
Spartan Mount
KR-15XX-FM2-X
KR-25XX-FM2-X
Freightliner Mount
NEW!
NEW!
Call Today for Quick Delivery 1-800-524-9900 or visit www.havis.com
Manufactured by:
Brow Mount ®
Custom to fit your cab
NEW

KR-15XX^25XX^35XX^36XX_NPR-8-07
Call Today for Quick Delivery 1-800-524-9900 or visit www.havis.com
Manufactured by:
Brow Mount ®
Custom to fit your cab
NEW
Brow Mounts for
Magnafire 3000® Lightheads Available
KR-15XX-ALF-X
KR-15XX-FM2-X
KR-15XX
KR-15XX-SP-KOV
KR-35XX
KR-36XX
KR-31 (70 Watt, 12 Volt)
KR-31-24 (70 Watt, 24 Volt)
KR-32 (150 Watt, 12 Volt)
KR-32-24 (150 Watt, 24 Volt)
KR-33 (350 Watt, 120 Volt)
KR-36 (750 Watt, 120 Volt)
KR-37 (750 Watt, 220 Volt
KR-39 (900 Watt, 240 Volt)
XX = Lighthead (specify 31, 31-24, 32, 32-24 33, 36, 37, or 39)
X = Center, Driver, or Passenger Mount (specify -C, -D, or -P)
Part Number Watts Volts Amps Bulb Type Bulb Lumen Rating* Bulb Life
KR-31 70 12 6 Metal Halide HID 6,000 10,000 hrs
KR-31-24 70 24 3 Metal Halide HID 6,000 10,000 hrs
KR-32 150 12 13 Metal Halide HID 11,250 10,000 hrs
KR-32-24 150 24 7 Metal Halide HID 11,250 10,000 hrs
KR-33 350 120 3 Quartz Halogen 13,250 400 hrs
KR-36 750 120 6.25 Quartz Halogen 25,200 400 hrs
KR-37 750 220 3.5 Quartz Halogen 19,200 1500 hrs
KR-39 900 240 4.2 Quartz Halogen 32,000 2,000 hrs
MAGNAFIRE 3000 SERIES LIGHTHEADS
MAGNAFIRE 5000 SERIES LIGHTHEADS
Part Number Watts Volts Amps Bulb Type Bulb Lumen Rating* Bulb Life
KR-51 70 12 6 Metal Halide HID 6,000 10,000 hrs
KR-51-24 70 24 3 Metal Halide HID 6,000 10,000 hrs
KR-53 350 120 3 Quartz Halogen 13,250 400 hrs
KR-55 500 120 4.5 Quartz Halogen 10,500 2,000 hrs
KR-56 750 120 6.25 Quartz Halogen 25,200 400 hrs
KR-57 750 220 3.5 Quartz Halogen 19,200 1500 hrs
AVAILABLE MODELS
Magnafire
3000
KR-15XX-ALF-C
KR-15XX-FM2-C
(Center Mount)
KR-15XX-ALF-D
KR-15XX-FM2-D
(Driver side Mount)
KR-15XX-ALF-P
KR-15XX-FM2-P
(Pass. side Mount)
KR-15XX
(E-ONE Mount)
KR-15XX-SP-KOV
(Center Mount)
KR-35XX
(Center Mount)
KR-36XX
(Side Mount)
Magnafire
5000
KR-25XX-ALF-C
KR-25XX-FM2-C
(Center Mount)
KR-25XX-ALF-D
KR-25XX-FM2-D
(Driver side Mount)
KR-25XX-ALF-P
KR-25XX-FM2-P
(Pass. side Mount)
KR-25XX
(E-ONE Mount)
KR-25XX-SP-KOV
(Center Mount)
KR-35XX
(Center Mount)
KR-36XX
(Side Mount)
Brow Mounts for
Magnafire 5000® Lightheads Available
KR-25XX-ALF-X
KR-25XX-FM2-X
KR-25XX
KR-25XX-SP-KOV
KR-35XX
KR-36XX
KR-51 (70 Watt, 12 Volt)
KR-51-24 (70 Watt, 24 Volt)
KR-53 (350 Watt, 120 Volt)
KR-55 (500 Watt, 120 Volt)
KR-56 (750 Watt, 120 Volt)
KR-57 (750 Watt, 220 Volt)
XX = Lighthead (specify 51, 51-24, 53, 55, 56, or 57)
X = Center, Driver, or Passenger Mount (specify -C, -D, or -P)
