This Hawking AR740 10Base-T ADSL Router with
Modem + 4-port 10/100M Switch is the ideal solution
for users looking for high-speed data access across
regular phone lines. Easily connect and share your
ADSL connection with multiple users. By placing the
ADSL signal above the frequency of the voice signal,
ADSL service is able to coexist on the same line with
your telephone service. The Hawking ADSL series
provide ANSI T1.413 issue 2, ITU-T G.hs, G.dmt and
G.lite, allowing high-speed connections over a single
twisted pair and ensuring widespread interoperability
with service providers' ADSL systems. The AR740
provides an always-on connection to your phone
company’s central office through the existing phone
line and you can also make your voice calls
simultaneously. Hawking’s AR740 ADSL Router with
Modem + 4-port 10/100M built in Switch can easily
be connected to your PC or LAN through the
10Base-T Ethernet Interface. The Firmware is fully
upgradeable for new features and updates. The
AR740 employs ATM (Asynchronous Transfer Mode)
framing for fast transmission over high-speed
networks.
AR740
Easily Network and Share your
ADSL connection
• Compliant with IEEE 802.3 over UTP
(10Base-T)
• Built-in Router with 4 Port 10/100M Switch
• Friendly Configuration and Management
Software
• Supports ADSL always-on
• Software Upgradeable
• Supports third party PPP over Ethernet
(PPPoE) clients.
• DSL downstream data rates up to 8 Mbps
(125 faster than standard 56K modem)
• Free Tech Support
Get Connected With Hawking
Package Contents:
• One ADSL Router w/ Modem + 4-port 10/100M
Switch
• One standard RJ-11 cable
• One 10Base-T RJ-45 cable
• One 9V DC Adaptor
• One 9-pin 25/9-pin RS-232 cable
• Easy to follow owner's manual
Systems Requirement:
• Pentium compatible processor 133MHz
and above
• Windows 95/98/ME/2000/XP/NT4.0, Mac,
Unix or Linux
• 10Base-T Networking Interface card

Ready, Connect & Go!
It's easy to install, it's easy to use! Everyone can
do it.
Step1 Connect to Computer
Connect your PCs to any of the 4 available
10/100M ports on the AR740
Step2 Connect to your phone line
Connect your 10Base-T ADSL modem to your
phone line jack using a standard phone cable (RJ-
11 cable included).
Step3 Setup
Connect the Hawking’s ADSL Bridge to a console
through the serial port using RS-232 cable
included to setup the modem. Then setup network
according to your operating system.
That’s it. It’s that easy.
Application Diagram
Features Benefits
Up to 8 Mbps
downstream / Up to
640 Kbps upstream
data rate
125Times faster than standard
56K modems
ATM
(Asynchronous
Transfer Mode)
Framing
Packets are divided into small
fixed sizes for rapid transmission
over high-speed networks
LED 1 - Power = on or off
1 – DSL-Link = Status
1 – DSL-ACT Ethernet Link
status
4 – PC LAN-LINK = LAN Activity
Easy to setup Friendly GUI configuration and
management software
Built in Router with
4 port 10/100M
Switch
Share your internet connection
with 4 PCs instantly. No need
to buy a separate router and
switch. It’s all built in!
Ordering Information:
AR710 10BT 8Mbps ADSL Router w/ Modem
AR740 10BT 8Mbps ADSL Router w/Modem + 4-
Port 10/100M Switch
AM100U USB 8M bps ADSL Modem
PN9239 4-Port DSL/Cable Firewall Router w/
10/100 WAN Port
Hawking Technologies, INC.
6A Faraday, Irvine, California, USA
Sales: [phone], [phone]
Fax: [phone]
Email: [email protected]
Tech Support: [phone]
Email: T[email protected]
Web Site: www.hawkingtech.com
Copyright Hawking Technologies, Inc. 2002. All rights
reserved. All trademarks herein are the property of their
respective owners. Product specification subjects to change
without notice
Specification:
Host Interface: 4x 10/100M RJ-45 ports
ADSL: RJ-11 jack
Console: RS-232
Data Connection
- Downstream – Up to 8 Mbps
- Upstream – Up to 640 Kbps
- Rate – Adaptive in 32Kbps steps
Compliance
Standard Compliance ANSI T1.413 issue2
ITU-T G.992.1(Full rate DMT)
ITU-T G.992.2(Lite DMT)
ITU-T G.994.1(Multimode)
RFC 1483 BPDU(Bridge Ethernet over ATM PVC,
LLC/SNAP)
RFC 1483 RPDU(Routed IP over ATM PVC,
LLC/SNAP)
RFC 1577(Classic IP over ATM, MTU=1500)
RFC 2364(PPP over ATM)
ATM supports AAL5, AAL3/4 and AAL0
ATM Traffic shaping supports CBR and UBR
ATM Forum UNI 3.0, 3.1 and 4.0 signaling
ATM Forum ILMI 4.0
ATM Forum LANE 1.0 client, MTU=1516, over
SVC only
Transparent Bridging features conformance to
IEEE 802.1d and supports spanning tree
protocol and bridge filters
TCP/IP with RIP version 1(RFC 1058) and
version 2(RFC 1723) compatible
ARP(RFC 1293, supports only one single subnet)
BOOTP(RFC 2131, RFC 2132)
SNMP version 1(RFC 1155, RFC 1157, RFC 1213)
TELNET server(RFC 854, 855, 857, 858)
NAT server
TFTP revision 2(RFC 1350)
PPP (Point-to-Point Protocol) support
OAM F4 and F5 segment end-to-end loopback are
supported(F4 on all VPIs, F5 on VIP 0 only)
DHCP(RFC 2131, RFC 2132) server and client
PAP/CHAP user Authentication with PPP
PPTP tunneling
Dimensions:
8.0” x 7.5” x 1.25” (L x W x H)
Environment:
Temperature:
Operating: 0°– 40°C
Storage: -20°- 60°C
Humidity: 5% – 95% RH Non-condensing
Casing Material: Metal
Weight: 1.4 lbs
EMI: FCC Class B & CE
Connect to phone jack
With RJ-11 cable
To PC’s NIC
To PC serial port
for modem setup
RS-232 cable
(included)
