Model 8901B
Hose Spray
INSTALLATION, OPERATION
&
MAINTENANCE INSTRUCTIONS
LIMITED WARRANTY
HAWS®warrants that all of its products are guaranteed against defective material or poor
workmanship for a period of one year from date of shipment. HAWS liability under this
warranty shall be discharged by furnishing without charge F.O.B. HAWS Factory any
goods, or part thereof, which shall appear to the Company upon inspection to be of
defective material or not of first class workmanship, provided that claim is made in writing
to company within a reasonable period after receipt of the product. Where claims for
defects are made, the defective part or parts shall be delivered to the Company, prepaid,
for inspection. HAWS will not be liable for the cost of repairs, alterations or replacements,
or for any expense connected therewith made by the owner or his agents, except upon
written authority from HAWS, Sparks, Nevada. HAWS will not be liable for any damages
caused by defective materials or poor workmanship, except for replacements, as provided
above. Buyer agrees that Haws has made no other warranties either expressed or implied
in addition to those above stated, except that of title with respect to any of the products or
equipment sold hereunder and that HAWS shall not be liable for general, special, or
consequential damages claimed to arise under the contract of sale.
The emergency equipment manufactured by HAWS is warranted to function if installation
and maintenance instructions provided are adhered to. The units also must be used for
the purpose, which they were intended. This product is intended to supplement first-aid
treatment. Due to widely varying conditions HAWS cannot guarantee that the use of this
emergency equipment will prevent serious injury or the aggravation of existing or prior
injuries.
NO OTHER WARRANTIES EXPRESSED OR IMPLIED ARE AUTHORIZED,
PROVIDED OR GIVEN BY HAWS.
NOTE TO INSTALLER: Please leave this information with the Maintenance Department.
SHOULD YOU EXPERIENCE DIFFICULTY WITH THE INSTALLATION OF THIS
MODEL, PLEASE CALL: 1-800-766-5612
FOR PARTS CALL: 1-800-758-9378
(U.S.A. AND CANADA ONLY) MONDAY-THURSDAY: 6:00 A.M. –4:00 P.M. PST
FRIDAY: 6:00 A.M –1:00 P.M. PST

11/17 Model 8901B Page 2 of 4
LOCATION OF UNIT: The Model 8901B Hose Spray should be installed in close
proximity to potential accident areas. It should be clearly identified free from
obstructions and easy to access. In order to comply with state codes, the use of a
vacuum breaker is required with all hand held eye/face wash and body spray units
(Haws offers Model SP212).
Supply Line: The minimum recommended line size is 1/2” IPS with 30-90 psi (2-6
ATM) pressure. Where sediment or mineral content is a problem, an inlet filter is
recommended.
Plumbing Connections: Inlet supply is male 1/2” IPS.
TROUBLESHOOTING
PROBLEM
REPAIR CHECKLIST
1.
No flow.
1.
a.
Check the main shut-off valve.
2.
Insufficient water flow.
2.
a.
Verify minimum 30 psi (2 ATM)
flowing supply line pressure.
b
Probable clogging of flow control
due to inadequate line flushing.
Disassemble eyewash at inlet
connection to gain access and
clean rubber flow control.
c.
Unscrew eye/face wash head cap
off to gain access to the buffer and
clean it.
3.
Valve leaks in shut-off position.
3.
Refer to installation drawing. Clean
valve washer and seat thoroughly,
then reassemble the valve. If valve
still leaks, contact HAWS and
purchase VRKSP248 to repair
valve.
For more information about Haws products, see our website: www.hawsco.com
© 2017 Haws®Corporation –All Rights Reserved
HAWS® and other trademarks usedin these materials are the exclusive property of Haws Corporation.

1
2
EYE/FACE WASH HEAD 0002974804
3
SP42 FLOW CONTROL
4
SP248 VALVE ASSEMBLY
5
SP140 HOSE ASSEMBLY
SP176 HOSE SPRAY SIGN
1
2
3
4
5
PARTS BREAKDOWN
6
6SP170 TEST TAG
VRKSP248 VALVE REPAIR KIT
7
APPROVED
DRAWN
PART NUMBER
SCALE: SHEET OF
REVISION
DRAWING TYPE: SIZE: A
BYECN NO.
PAGE
DATE
DATE
ECN:
REVISED PER
CHKD
Haws Corporation - All Rights Reserved
HAWS and other trademarks used in these materials are the exclusive property of Haws Corporation.
CR
MODEL(S)
1455 KLEPPE LANE
SPARKS, NEVADA 89431
[phone] FAX [phone]
E-MAIL: [email protected]
WEBSITE: WWW.HAWSCO.COM
ITEM DESCRIPTION
THIS DOCUMENT IS TRUE AND CORRECT AT TIME OF PUBLICATION. CONTINUED PRODUCT IMPROVEMENTS
MAKE SPECIFICATIONS AND MEASUREMENTS SUBJECT TO CHANGE WITHOUT NOTICE.
WHEN ORDERING PARTS PLEASE SPECIFY MODEL NUMBER.
PART NO.
CLF
3/17/93
9
0002080191
8901B
EYE/FACE WASH BODY SPRAY
NA
11
FV 11/23/17
.
VWC
3 OF 4
PARTS BREAKDOWN
5242
2017
VWC
VRKSP248
SP170
SP176
SP140
SP248
SP42
0002974804
7

STEM ASSEMBLY DETAIL
SEAT & OPERATOR
VALVE REPAIR DETAIL
WALL BRACKET DETAIL
SEE SEAT & OPERATOR
STEM ASSEMBLY DETAIL
MODEL VRK SP248
OPTIONAL
NOTES:
1. IN ORDER TO COMPLY WITH STATE CODES, THE USE OF A VACUUM BREAKER
IS REQUIRED WITH ALL HAND HELD EYE/FACE WASH AND BODY SPRAY UNITS
(HAWS OFFERS MODEL SP212).
APPROVED:
DRAWN:
PART NUMBER
SCALE: SHEET OF
REVISION
DRAWING TYPE: SIZE: A
BY:ECN NO.
PAGE
DATE:
DATE:
ECN:
REVISED PER
CHK'D.:
Haws Corporation - All Rights Reserved. HAWS and other trademarks used in these materials are the exclusive property of Haws Corporation.
CR
MODEL(S)
1455 KLEPPE LANE
SPARKS, NEVADA 89431
[phone] FAX [phone]
E-MAIL: [email protected]
WEBSITE: WWW.HAWSCO.COM
THIS DOCUMENT IS TRUE AND CORRECT AT TIME OF PUBLICATION. CONTINUED PRODUCT IMPROVEMENTS
MAKE SPECIFICATIONS AND MEASUREMENTS SUBJECT TO CHANGE WITHOUT NOTICE.
CH
05/20/91
9
0002080191.D
8901B
EYE/FACE WASH BODY SPRAY
NA
11
FV 11/23/17
VWC
4 OF 4
INSTALLATION
5242
2017
VWC
