Haws 3500 Guide

03/17 Model 3500/3500D Page 1 of 5
1455 Kleppe Lane Sparks, NV 89431-6467 [phone] Fax [phone]
E-mail: [e-mail]  website: www.hawsco.com
Model 3500/3500D
Drinking Fountain
INSTALLATION, OPERATION
&
MAINTENANCE INSTRUCTIONS
No. 2077448 (15)
LIMITED WARRANTY
HAWS warrants that this specific product is guaranteed against defective material or
poor workmanship for a period of one year from date of shipment. HAWS liability
under this warranty shall be discharged by furnishing without charge F.O.B. HAWS
Factory any goods, or part thereof, which shall appear to the Company upon
inspection to be of defective material or not of first class workmanship, provided that
claim is made in writing to Haws within a reasonable period after receipt of the
product. Where claims for defects are made, the defective part or parts shall be
delivered to the Company, prepaid, for inspection. HAWS will not be liable for the
cost of repairs, alterations or replacements, or for any expense connected therewith
made by the owner or his agents, except upon written authority from HAWS, Sparks,
Nevada. HAWS will not be liable for any damages caused by defective materials or
poor workmanship, except for replacements, as provided above. Buyer agrees that
HAWS shall not be liable for general, special, or consequential damages claimed to
arise under the contract of sale. The drinking fountain manufactured by HAWS is
warranted to function if installation and maintenance instructions provided are
adhered to. The units also must be used for the purpose for which they were
intended.
NO OTHER WARRANTIES EXPRESSED OR IMPLIED ARE AUTHORIZED,
PROVIDED OR GIVEN BY HAWS.
NOTE TO INSTALLER: Please leave this information with the Maintenance Department.
SHOULD YOU EXPERIENCE DIFFICULTY WITH THE INSTALLATION OF THIS
MODEL PLEASE CALL:
TECHNICAL SUPPORT: 1-800-766-5612
FOR CUSTOMER SERVICE: 1-888-640-4297

03/17 Model 3500/3500D Page 2 of 5
RECOMMENDED TOOLS: Hack saw, pipe joint sealant, screwdriver, level, 12" adjustable
wrench, 10" pipe wrench, 5/32” pinned hex key wrench (supplied), 9/16”, 1/2", 7/16” socket
wrench or open- end wrench.
LOCATION OF UNIT: The Model 3500/3500D Drinking Fountain is a wheelchair accessible
drinking water facility. The height dimensions shown, meet current ADA requirements. When
installing this unit, local, state or federal codes should be adhered to. If height other than
shown is required, then dimensions must be adjusted accordingly.
SUPPLY LINE: The minimum recommended line size is 1/2“IPS with 30-90 psi (2-6 ATM)
flowing pressure. Where sediment or mineral content is a problem, an inlet filter is
recommended.
PLUMBING CONNECTIONS: Inlet is 3/8“O.D. compression fitting. Waste outlet is female 1-
1/2” slip PVC pipe.
MAINTENANCE: Periodically clean the strainer. Refer to 5874 Series Valve Operation and
Maintenance Sheet for more information.
TROUBLESHOOTING
PROBLEM
REPAIR CHECKLIST
1.
Insufficient bubbler flow.
1a.
Check that inlet screwdriver stop valve is
wide open.
b.
Verify minimum 30 psi flowing supply
pressure.
c.
Clean inlet strainer. See 5874 Series
Valve Manual.
d.
Adjust valve to increase flow. Use front
adjust screw or see 5874 Series Valve
Manual.
General Notes:
Before tightening nut and ferrule assembly, push tubing into fitting until it bottoms out
to ensure correct engagement with O-Ring.
For more information about Haws products, see our website: www.hawsco.com
© 2017 Haws®Corporation – All Rights Reserved
HAWS® and other trademarks usedin these materials are the exclusive property of Haws Corporation.

1
2
3
STRAINER
4
BUBBLER HEAD
5
6
1
3
2
PARTS BREAKDOWN
4
KEY, 5/32" HEX PINNED
DOOR KEY, TEE7
80002981127
BOTTOM PLATE
6
9SANDTRAP (OPTIONAL)
9
SAND TRAP
MODEL 6635
W/ MOUNTING
PLATE (OPTIONAL)
8
7
PLATE, MTG, 3500 SERIES (OPTIONAL)
10
MOUNTING SYSTEM (OPTIONAL)
11
PET PEDESTAL
STANDARD WITH
MODEL 3500D
ONLY
MODEL MTG.3500
KIT MOUNTING PLATE
(OPTIONAL)
MODEL MTG.3501
KIT MOUNTING SYSTEM
(OPTIONAL)
4 BOLTS
4 WASHERS
MOUNTING PLATE
WITH ANCHORS
4 BOLTS
4 WASHER
4 ANCHORS 10
11
A
PBM1035
6452
5703M
0002049640
MTG.3501
MTG.3500
6635
SCREWDRIVER STOP
1/2" NPT
(NOT SUPPLIED)
APPROVED
DRAWN
PART NUMBER
SCALE: SHEET OF
REVISION
DRAWING TYPE: SIZE: A
BYECN NO.
PAGE
DATE
DATE
ECN:
REVISED PER
CHKD
Haws Corporation - All Rights Reserved
HAWS and other trademarks used in these materials are the exclusive property of Haws Corporation.
CR
MODEL(S)
1455 KLEPPE LANE
SPARKS, NEVADA 89431
[phone] FAX [phone]
E-MAIL: [email protected]
WEBSITE: WWW.HAWSCO.COM
ITEM DESCRIPTION
THIS DOCUMENT IS TRUE AND CORRECT AT TIME OF PUBLICATION. CONTINUED PRODUCT IMPROVEMENTS
MAKE SPECIFICATIONS AND MEASUREMENTS SUBJECT TO CHANGE WITHOUT NOTICE.
WHEN ORDERING PARTS PLEASE SPECIFY MODEL NUMBER.
PART NO.
F. VASQUEZ
02-04-99
15
0002077448
3500/3500D
.
1:4
11
FV 07/07/17
.
VWC
3 OF 5
PARTS BREAKDOWN
5189
2017
JP
5
BUTTON, PUSH, REC W/ VALVE
VALVE REPAIR KIT VRK5874
5874PB
2REF
ROTATED 90° INTO VIEW
DETAIL A
REMOVE INSERT
WITH 5/16 HEX SOCKET
(NOT SUPPLIED)
2
NOTES:
1 5874PB (ITEM 3) INCLUDES VRK5874 CARTRIDGE ASSEMBLY
(ITEM 4) AND PBA7 RECESSED PUSH BUTTON (ITEM 5).
2 ENSURE TUBE IS DISCONNECTED FROM PUSH BUTTON
VALVE BODY PRIOR TO REMOVAL. APPLY ONE DROP OF
LOCTITE 222MS TO NOZZLE THREADS PRIOR TO FASTENING
BACK ONTO BUBBLER HEAD. RE-ATTACH TUBE TO VALVE.
BUTTON, ASSY, PUSH, 5874 PBA7
1
1
1

WASTE
TUBING SUPPLY
(NOT SUPPLIED
7"
178mm
MIN.
686mm
27"
864mm
34"
14"
356mm
11-1/2"
292mm
28-1/2"
724mm
41-1/2"
1054mm
18"
457mm
SCREWDRIVER STOP
(NOT SUPPLIED)
902mm
35-1/2"
4X Ø0.75
1
2X
CONCRETE SLAB
30" SQUARE
(NOT SUPPLIED)
2
(TO SPOUT OUTLET)
(TO SPOUT OUTLET)
NOTES: (UNLESS OTHERWISE SPECIFIED)
1. PET FOUNTAIN IS STANDARD FOR MODEL 3500D ONLY.
SEE SHEET 2 FOR INSTALLATION DETAILS.
2. OPTIONAL SAND TRAP MODEL 6635 W/ MOUNTING PLATE AND 1-1/2"
O.D. TAILPIECE. SEE MODEL 6635 FOR ADDITIONAL INSTALLATION
INSTRUCTIONS.
3. REFER TO 5874 SERIES OPERATION AND MAINTENANCE
MANUAL FOR PUSH BUTTON AND VALVE
INSTALLATION/MAINTENANCE INSTRUCTIONS.
(NOTES CONTINUED ON SHEET 2)
3
10 7/8
276mm
MODEL MTG.3501
(OPTIONAL)
OR
MODEL MTG.3500
(OPTIONAL)
ADJUST LOCATION
AS NEEDED WHEN
INSTALLING PET
FOUNTAIN MODEL
ON MODEL 3500)
3/8" O.D.
3/8" O.D. CONNECTOR
(MODEL 3500 ONLY)
1/2" NPT
3/8" O.D. SUPPLY
CONNECTION
(NOT SUPPLIED)
1/2" IPS FROM SHUT-OFF
1-1/2" SLIP PVC
(NOT SUPPLIED)
1-1/2" O.D. TAILPIECE
2
APPROVED:
DRAWN:
PART NUMBER
SCALE: SHEET OF
REVISION
DRAWING TYPE: SIZE: A
BY:ECN NO.
PAGE
DATE:
DATE:
ECN:
REVISED PER
CHK'D.:
Haws Corporation - All Rights Reserved. HAWS and other trademarks used in these materials are the exclusive property of Haws Corporation.
CR
MODEL(S)
1455 KLEPPE LANE
SPARKS, NEVADA 89431
[phone] FAX [phone]
E-MAIL: [email protected]
WEBSITE: WWW.HAWSCO.COM
THIS DOCUMENT IS TRUE AND CORRECT AT TIME OF PUBLICATION. CONTINUED PRODUCT IMPROVEMENTS
MAKE SPECIFICATIONS AND MEASUREMENTS SUBJECT TO CHANGE WITHOUT NOTICE.
F. VASQUEZ
02-04-99
15
0002077448.D
3500/3500D
.
1:13
12
FV 07/07/17
.
VWC
4 OF 5
INSTALLATION
5189
2017
JP
MODEL 3500 SHOWN
(SEE SHEET 2 FOR MODEL 3500D)

10"
PEDESTAL
DOG BOWL
ROTATE
4
9 A CHECK VALVE IS INSTALLED IN THIS
LOCATION TO PREVENT CROSS
CONNECTION BETWEEN BUBBLERS.
4 SLIDE DOWELS ON DOG BOWL INTO
HOLES OF PEDESTAL AND ROTATE UPWARD.
5 INSTALL 7/16-14UNC NUT ON STUD
AND TIGHTEN 3/4 TURN PAST HAND TIGHT.
6 BOND JOINTS WITH PVC CEMENT AND PRIMER.
7. APPLY SUPPLY HOSE AND WASTE LINE.
8. TEST SYSTEM AFTER ASSEMBLY.
*NOTE: TEE SHOWN ASSEMBLED FOR REFERENCE ONLY.
POSITION TEE AND TRIM TUBING AS NEEDED TO FIT
INSTALLATION APPLICATION.
10 NOTE: DRAINAGE ASSEMBLY SLIDES VERTICALLY ON HOLDER.
UPON COMPLETION OF INSTALLATION, PUSH UP ON BOTTOM OF
ELBOW TO ENSURE POSITIVE DRAINAGE OF WASTE.
3
CONNECTOR*
(SUPPLIED)
3/8" O.D. SUPPLY TUBING
(NOT SUPPLIED)
TEE*
(SUPPLIED)
3/8" O.D. TUBING
TO FTN VALVE*
(SUPPLIED)
3X 6
WASTE
(NOT SUPPLIED)
10
59
9 3/8"
10 1/4"
1/2" NPT
SCREWDRIVER STOP
(NOT SUPPLIED)
1-1/2" SLIP PVC
APPROVED:
DRAWN:
PART NUMBER
SCALE: SHEET OF
REVISION
DRAWING TYPE: SIZE: A
BY:ECN NO.
PAGE
DATE:
DATE:
ECN:
REVISED PER
CHK'D.:
Haws Corporation - All Rights Reserved. HAWS and other trademarks used in these materials are the exclusive property of Haws Corporation.
CR
MODEL(S)
1455 KLEPPE LANE
SPARKS, NEVADA 89431
[phone] FAX [phone]
E-MAIL: [email protected]
WEBSITE: WWW.HAWSCO.COM
THIS DOCUMENT IS TRUE AND CORRECT AT TIME OF PUBLICATION. CONTINUED PRODUCT IMPROVEMENTS
MAKE SPECIFICATIONS AND MEASUREMENTS SUBJECT TO CHANGE WITHOUT NOTICE.
M.F.
06-06-00
15
0002077448.D
3500/3500D
.
1:12
22
FV 07/07/17
.
VWC
5 OF 5
INSTALLATION
5189
2017
JP
MODEL 3500D SHOWN
(SEE SHEET 1 FOR MODEL 3500)
