Hay NEW ORDER User manual

– INSTRUCTION MANUAL –
DESIGN BY STEFAN DIEZ
WOODEN PARTS
NEW ORDER

 NEW ORDER SAFETY INSTRUCTIONS 
SAFETY INSTRUCTIONS
FOR NEW ORDER
DRAWERS =
SAFETY BRACKETS
MAX WEIGHT
30 KG / PER LAYER DO NOT CLIMB
Trains, ships etc.
Airports, lobbies,
medical centres etc. Environments with children
Public places
ALWAYS USE SAFETY BRACKETS
IN THE FOLLOWING CASES
FREESTANDING
WITH FLOOR
SAFETY BRACKETS WITH WALL SAFETY BRACKETS
FREESTANDING
CONNECTED
MAX BUILDING HEIGHT

WOODEN SET
 INSTRUCTIONS 

Wooden set 150 Wooden set wall 150
Wooden set 100 Wooden set wall 100
Wooden set left wall 100Wooden set left 100
 WOODEN SLIDING DOOR AND PANEL SETS OVERVIEW 


E Slider hook

D Back panel fastener

A Wooden back panel

C Wooden side panel

B Wooden sliding door
 PARTS 

1.
Start by inserting the panel clips

C into the grooves on the top
and bottom of the back panel

A .
SOFTENING THE PLASTIC
The panel clip needs to be
wiggled slightly to facilitate
a smoother assembly.
IF MOUNTING WALL PANELS
Make sure to turn the panel so the
cutout section is facing upwards.

2.
Make sure that you start by mounting the wooden end first.
1
1
2
2
WOODEN END
Insert this end first.
PLASTIC TAP END
Insert this end after the wooden end.

3.
Mount the panel through the inside of the shelf. Make sure the wooden end fits
into the groove in the shelf profile.
1
2

4.
Then push in the other side so the plastic tap bends and locks in place.
1
2

5.
Insert the back panel fastener

C into the grooves on the
top and bottom of the back panel.

6.
Mount the side panels

C in the same way as the back panel.
1
2
1
2

7.
Insert the slider hooks

E into the grooves on the top and bottom of the shelf.
1
2
3

90°
8.
Mount the sliding door

B by inserting the bottom plastic hinge into
the profile groove and apply pressure moving upwards.
(The action is mirrored if it is a left door)

9.
Align the end of the door with the slider hooks

E .Press the end
hinge into the hooks while supporting the hooks with your hand.
Test the door by sliding it.
PLEASE NOTE
Support the hooks from the back with
your hand while clicking in the door.

 CARE & MAINTENANCE 
Our Care & Maintenance offers guidance for optimal
maintenance of your HAY product. It includes advice
and instructions on cleaning and caring for specific
materials to prolong the life of your furniture.
Please find our Care & Maintenance
guide by scanning the QR code
You can find more relevant information
on New Order by scanning the
QR code
You can also find the same information here
hay.dk/downloads

19

20
