Lee & Plumpton Atmosphere Meeting Point User manual

Assembly instruction leaflet no. 66A
Atmosphere Meeting Point
-Trumpet Base Assembly
Assembly steps
Step 1. Fixing the trumpet base
1. Assemble the trumpet base using the instructions provided.
2. Place top upside down on a soft clean surface.
3. Align the trumpet base (part A) to the holes on the underside of the top.
4. Fix the trumpet base to the top using the four washers (parts C) and screws
(parts B).
5. Stand the product on the base and level the accompanying desks to the
height of the Meeting Point.
Step 2. Adding the brackets
2a.Follow if fixing to slab ends
1. Position the brackets (parts D) so they are aligned with the correct holes
on the top as shown.
2. Ensuring the brackets are pushed firmly against the slabs,
fix the brackets to top using the washers (parts E) and screws (parts F).
3. Fix the brackets to the slabs using the washers (parts E) and screws (parts F).
It may be necessary to create pilot holes before adding the screws.
Note: Part K is used on 1000mm only, Secure to pilot hole in meeting point
located at the front end of the desk using part L. Pilot drill hole to desk top
and secure wing with part L.
2b.Follow if fixing to cantilever ends
1. Position the brackets (parts G) so they are aligned with the correct holes
on the top and cantilever as shown.
2. Fix the brackets to the cantilever frame using the bolts provided (parts H).
3. Fix the brackets to the top using the washers (parts I) and screws (parts J).
Note: Part K is used on 1000mm only, Secure to pilot hole in meeting point
located at the front end of the desk using part L. Pilot drill hole to desk top
and secure wing with part L.
Tools required
Pozi head screw
driver
Allen key (4mm)
Part J
Part I
Part H
Part G
Part A
Part B
Part C
Part F
Part F
Part E
Part D
Part E
Step 2b.
Cantilever
not shown
(Example of
assembly
for a Cant end
attachment)
Step 2a.
Slab not shown
(Example shown for an assembly
of slab end attachment)
Step 1.
Parts
Supplied
Specific to
1000MP
Part K

Quantity = 1
Part L
F/0414
Quantitiy = 2

Assembly instruction leaflet no. 66B
Atmosphere Meeting Point
-Round Leg Assembly
Assembly steps
Step 1. Fixing the round legs
1. Place top upside down on a soft clean surface.
2. Position bolts (parts A) in the underside of leg plates (parts B) as shown
3. Align the leg plates (parts B) to the holes on the underside of the top.
4. Fix the leg plates to the top using the screws (parts C) as shown.
5. Screw the legs (parts D) on to the leg plates.
6. Stand the product onto the legs. With two people holding the unsupported
edge of the product, level to the height of the desks.
Step 2. Adding the brackets
2a.Follow if fixing to slab ends. (Two people should hold the unsupported edge
at each side of the panel until fixed).
1. Position brackets (parts E) aligning them with correct holes on the top
as shown.
2. Ensuring brackets are pushed firmly against slabs, fix the brackets to top
using the washers (parts F) and screws (parts G).
3. Fix the brackets to the slabs using the washers (parts F) and screws
(parts G).It may be necessary to create pilot holes before adding the screws.
2b.Follow if fixing to cantilever ends. (Two people should hold the unsupported
edge at each side of the panel until fixed).
Note: Part K is used on 1000mm only, Secure to pilot hole in meeting point
located at the front end of the desk using part L. Pilot drill hole to desk top
and secure wing with part L.
1. Position the brackets (parts H) so they are aligned with the correct holes on
the top and cantilever as shown.
2. Fix the brackets to the cantilever frame using the bolts provided (parts I).
3. Fix the brackets to the top using the washers (parts J) and screws (parts K).
Note: Part K is used on 1000mm only, Secure to pilot hole in meeting point
located at the front end of the desk using part L. Pilot drill hole to desk top
and secure wing with part L.
Tools required
Pozi head Allen key (4mm)
screw driver
Step 2b.
Cantilever
not shown
(Assembly shown for Cant end
attachment)
Step 2a.
Slab not shown
(Assembly shown for slab end
attachment)
Part I
Part K
Part J
Part H
Part F
Part F
Part G
Part G
Part E
Part B
Part C
Part D
Step .1
Part A
Parts
Supplied
Specific to
1000MP
Part K

Quantity = 1
Part L
F/0414
Quantitiy = 2
