Hendi H90 User manual

You should read this user manual carefully before
using the appliance.
Bevor Sie das Gerät in Betrieb nehmen, sollten
Sie diese Gebrauchsanweisung aufmerksam lesen.
Alvorens de apparatuur in gebruik te nemen dient
u deze gebruiksaanwijzing aandachtig te lezen.
Przed uruchomieniem urządzenia należy koniecznie
dokładnie przeczytać niniejszą instrukcję obsługi.
Lisez attentivement ce mode d’emploi avant d’utiliser
l’appareil .
Prima di utilizzare l’apparecchio in funzione leggere
attentamente le istruzioni per l’uso.
Citiţi cu atenţie prezentul manual de utilizare înainte de
folosirea aparatului.
Внимательно прочитайте руководство пользователя
перед использованием прибора.
Πρέπει να διαβάσετε αυτές τις οδηγίες χρήσης
προσεκτικά πριν χρησιµοποιήσετε τη συσκευή.
CONVECTION OVEN H90
227060, 227374

2
Keep these instructions with the appliance.
Diese Gebrauchsanweisung bitte beim Gerät aufbewahren.
Bewaar deze handleiding bij het apparaat.
Zachowaj instrukcję urządzenia
Gardez ces instructions avec cet appareil.
Conservate le istruzioni insieme all’apparecchio.
Păstraţi maualul de utilizare alături de aparat.
Хранить руководство вместе с устройством.
Φυλάξτε αυτές τις οδηγίες μαζί με τη συσκευή.
For indoor use only.
Nur zur Verwendung im Innenbereich.
Alleen voor gebruik binnenshuis.
Do użytku wewnątrz pomieszczeń.
Pour l’usage à l’intérieur seulement.
Destinato solo all’uso domestico.
Doar pentru uz la interior.
Использовать только в помещениях.
Για χρήση μόνο σε εσωτερικό χώρο.

3
EN
Dear Customer,
Thank you for purchasing this Hendi appliance. Read this manual carefully, paying particular attention to
the safety regulations outlined below, before installing and using this appliance for the first time.
Safety regulations
• This appliance is intended for commercial use.
• Only use the appliance for the intended purpose it was designed for as described in this
manual.
• The manufacturer is not liable for any damage caused by incorrect operation and
improper use.
• Keep the appliance and electrical plug away from water and other liquids. In the event
the appliance falls into water, immediately remove the power plug from the socket. Do
not use the appliance until it has been checked by a certified technician. Failure to follow
these instructions will cause life threatening risks.
• Never attempt to open the housing of the appliance by yourself.
• Do not insert objects into the housing of the appliance.
• Do not touch the plug with wet or damp hands.
• Danger of electric shock! Do not attempt to repair the appliance by yourself, repairs
are only to be conducted by qualified personnel.
• Never use a damaged appliance! When it’s damaged, disconnect the appliance from the
socket and contact the retailer.
• Warning! Do not immerse the electrical parts of the appliance in water or other liquids.
• Never hold the appliance under running water.
• Regularly check the power plug and cord for any damage. When damaged it must be
replaced by a service agent or similarly qualified person in order to avoid danger or injury.
• Make sure the cord does not come in contact with sharp or hot objects and keep it away
from open fire. Never pull the power cord to unplug it from the socket, always pull the
plug instead.
• Make sure that the power cord and/or extension cord do not cause a trip hazard.
• Never leave the appliance unattended during use.
• Warning!
As long as the plug is in the socket the appliance is connected to the power
source.
• Turn off the appliance before unplugging it from the socket.
• Connect the power plug to an easily accessible electrical socket so that in case of emergency
the appliance can be unplugged immediately.
• Never carry the appliance by the cord.
• Do not use any extra devices that are not supplied together with the appliance.
• Only connect the appliance to an electrical outlet with the voltage and frequency mentioned
on the appliance label.
• Never use accessories other than those recommended by the manufacturer. Failure to do
so could pose a safety risk to the user and could damage the appliance. Only use original
parts and accessories.

4
EN
• This appliance should not be operated by persons with reduced physical, sensory or mental
capabilities, or persons that have a lack of experience and knowledge.
• This appliance should, under any circumstances, not be used by children.
• Keep the appliance and its power cord out of reach of children.
• WARNING: ALWAYS switch off the appliance and unplug from power socket before
cleaning, maintenance or storage.
Special Safety Regulations
• This appliance is only intended for cooking food. Any other use might lead to damage of
the appliance or personal injury.
• Caution! Danger of burns! The temperature of accessible surfaces & door of the
appliance get very hot during use. Touch the appliance only with its handle & knobs.
• Allow at least 15cm spacings for ventilation purposes during use.
• This appliance is not intended to be operated by means of an external timer or separate
remote-control system.
• Place the appliance on a heat resistant surface only.
• Do not place any objects on top of the appliance and cover the appliance during use.
• Do not use this appliance for cooking food or liquids in a closed container as it may lead
to explosion.
• Do not cover the smoke vent at the rear side of the appliance.
• Keep the appliance away from any hot surfaces and open flames. Protect the appliance
against heat, dust, direct sunlight, moisture, dripping and splashing water.
• Do not pour out the water towards the glass door, or the door may break during operation.
• Do not place articles on top of the appliance. Do not place objects with open sources of
fire (e.g. candles) on top or beside the appliance. Do not place objects filled with water
(e.g. vases) on or near the appliance.
• An equipotential bonding terminal is provided to allow cross bonding with other
equipment.
• Mind that surfaces of the oven may become very hot during use. Do not touch these
surfaces.
• Never cover the oven during use. This causes a fire hazard.
• Do not use metal scouring pads. Parts of these may break off, and cause an electrical
hazard in the oven.
• Do not use the oven to prepare food or liquids in a closed container as the container may
explode.

5
EN
Intended use
• The appliance is intended for professional use.
• Heating elements may be hot even though they
are not glowing. Interior surfaces of an oven be-
come hot enough to cause burns. External parts
of the oven such as the door glass, vents, and the
control panel can become hot. During and after
use, do not touch, or let clothing or other flam-
mable materials come into contact with heating
elements or interior surfaces of the oven until
they have had sufficient time to cool.
• Operating the appliance for any other purpose
shall be deemed a misuse of the device. The user
shall be solely liable for improper use of the de-
vice.
Grounding installation
This appliance is classified as protection class
I and must be connected to a protective ground.
Grounding reduces the risk of electric shock by
providing an escape wire for the electric current.
This appliance is fitted with a power cord that has a
grounding wire and grounded plug. The plug must
be plugged into an outlet that is properly installed
and grounded.
Preparation before using for the first time
• Remove all protective packaging and wrapping.
Make sure no packaging debris remain on or in-
side the appliance.
• Check for completeness (4 trays and 1 tray han-
dle included) and any transport damage. In case
of damages or incomplete delivery, please con-
tact supplier (See --- > Warranty page).
• Keep the packaging for storing your appliance
when not in use for an extended period of time.
• Place all the trays & the tray handle inside.
• Connect the power plug to a suitable electrical
wall outlet.
• Select the following settings consecutively.
Control Setting
Temp control 300°C
Timer control 10 minutes
• The Temp control indicator , Timer control indi-
cator and the internal light of the appliance
are all lights up.
Note: Due to the manufacturing residues, the ap-
pliance may emit a slight odor. This is normal and
does not indicate and defect or hazard. Make sure
the appliance is well ventilated.
• When the set time ends, the appliance tempera-
ture and timer indicators goes off.
• Allow the appliance to cool down completely and
clean it afterwards (See ---> Cleaning and main-
tenance).

6
EN
Electric diagram
-HL1
-S1- PT
L
N
E
-HL2 -EH1 -EH2-EL
M1 M2
-S2
Operation
1). Preparation:
• Open the glass door using the door handle.
• Insert the trays in a proper position.
• Place the food on the trays and close the door.
• Ensure there is enough space between the food
for the heat to be evenly distributed.
• Connect the power plug to a suitable electrical
outlet.
Note: • Do not overload the tray to avoid any dam-
age.
• Check the recipe first for the Timer & Tem-
perature setting.
Attention: Do not use this trays for storage and pro-
cessing of acidic, alkaline or salty food.
2). Start cooking
• Set the 2 controls: Timer control and the Temp
control to the desired settings. The Timer control
indicator , Temp control indicator and in-
ternal light of the appliance are all lights up. The
appliance start heating up.
Note: The ideal cooking time depends on food
type and size, as well as the selected settings.
Some types of food may get burned, if they are
baked, roasted or grilled too long. Therefore,
check the food for doneness in regular intervals
through the glass door.
• When the set time ends, the temperature & timer
indicator goes off.
• To terminate the cooking process manually, just
set the Timer control to the “0”.
• After cooking, set the Temp control to the “0°C”.
• Open the glass door using the door handle and
remove the food.
Caution! Risk of burns!
• Always open the glass door using the door han-
dle.
• To remove the food, use the tray handle (supplied)
and/or oven mittens (not supplied). Make sure
not to touch and damage the heating elements.
• Keep hands away from steam exiting the appli-
ance.
• After use, disconnect the power plug from the
wall outlet.
• Allow the appliance to cool down completely be-
fore cleaning and storing.

7
EN
3). Timer control
• A cooking time of maximum 120 minutes can be
set. For this purpose, set the Timer control to the
desired time. The cooking time can be increased
or decreased at any time during operation.
Note: To set time with higher precision, first turn
the Timer control over the desired time position
a little, then return back to the desired time po-
sition.
• When the set time ends, the Timer control &
the Temp control indicator lights go off and a
sound will be heard.
4). Temp control
• A cooking temperature of maximum MAX (300°C)
can be set. For this purpose, set the Temp control
to the desired temperature.
• Similarly, the cooking temperature can be in-
creased or decreased at any time during oper-
ation.
Note: When the temperature reaches the desired
setting, the Temp control indicator will go off.
If the temperature drops, the Temp control indi-
cator will light on again. This process will be
repeated automatically.
Note: Please note that there is a safety thermal
cut out device for protection located at the lower
rear side of the appliance with a protective cap
(See ---> RESET with the SAFETY CUT-OUT ).
This is to prevent the appliance from getting too
high and turn off automatically.
Tips for cooking
• Check the recipe first for the Timer control and
Temp control setting.
• Ensure there is enough space between the food
for the heat to be evenly distributed.
• Cooked food and parts of the appliance get very
hot for some time after cooking. Do not touch
them with bare hands while in use or shortly af-
ter use.
0
50
100
125
150
175
200
225
250
275
MAX
0
10
20
30
40
50
60
70
80
90
10 0
110
120
Handle
Timer knobTemperature
control knob Timer indicator
light
Temperature
light
Fan
Wire rack
mounts

8
EN
RESET with the SAFETY CUT-OUT
Please note that there is a SAFETY CUT-OUT device
for protection located at the lower rear side of the
appliance with a protective cap. This is to turn off
the appliance automatically when the temperature
is too high.
• Unplug the appliance from the electrical outlet
first.
• Allow the appliance to completely cool down.
• Unscrew (tool not supplied) the black protective
cap of the “SAFETY CUT-OUT”.
• Push the button to RE-SET the overload circuit.
You should hear a click sound.
• Screw back the protective cap on the “SAFETY
CUT-OUT” button.
Cleaning and Maintenance
Warning!
• Always disconnect the appliance and open the
door to allow it to cool down completely before
cleaning.
• Never use abrasive sponges or detergents, steel
wool or metallic utensils to clean the interior or
exterior parts of the appliance.
• Avoid the use of sprays as this may damage the
appliance’s surface.
• The appliance should be cleaned regularly and
any food deposits removed.
• Wipe out any remaining oil or fat.
• Note: The trays holder on two sides can be un-
screwed (tools not supplied) to detach for clean-
ing.
Parts How to clean Remark
All accessories such as trays, tray
handle, tray holders
- Soak in warm, soapy water for about 10 to
20 minutes
- Rinse under running water thoroughly.
Dry all parts well at last.
External housing - Wipe clean with a soft cloth and a little mild detergent. Make sure no water or moisture
enters inside of the appliance.
Inside of the appliance - Remove any food deposits.
- Wipe with a damp cloth and a little cleaning
detergent to remove any spills or splatters.
- Note: Be sure not to damage the heating
elements.
Glass door
Storage
• Always make sure the appliance has already
been disconnected from the electrical wall outlet
and cooled down completely.
• Store the appliance in a cool and clean place.

9
EN
Troubleshooting
If the appliance does not function properly, please
check the below table for the solution.
If you are unable to solve the problem, please con-
tact the supplier/service provider.
Problem Possible cause Possible solution
When connected to the electrical
power outlet, the control settings are
made & indicator lights are on. But the
appliance does not heat up.
The thermostat is defeated Take the appliance to your supplier or
service provider for repair.
At least one of the heating element is
burnt out.
When connected to the electrical
power outlet, the control settings are
made. It heats up normally. But the
indicator is not on.
The indicator light is defective. Take the appliance to your supplier or
service provider for repair.
Neither the indicator nor the heating
element works.
The power cord & plug is not connect-
ed firmly with the electrical power
socket.
Check again the connection. And
make sure all the connections are
firmly connected.
Technical specification
Item no.: 227060 & 227374
Operating voltage and frequency: 220-240V~
50/60Hz
Power: 2670W
Net weight: Approx. 35kg
Protection class: Class I
Water protection class: IPX3
Outer dimension: 595x595x(H)570mm
Remarks: Technical specification is subjected to change without prior notification.
Warranty
Any defect affecting the functionality of the ap-
pliance which becomes apparent within one year
after purchase will be repaired by free repair or re-
placement provided the appliance has been used
and maintained in accordance with the instructions
and has not been abused or misused in any way.
Your statutory rights are not affected. If the appli-
ance is claimed under warranty, state where and
when it was purchased and include proof of pur-
chase (e.g. receipt).
In line with our policy of continuous product devel-
opment we reserve the right to change the product,
packaging and documentation specifications with-
out notice.
Discarding & Environment
When decommissioning the appliance, the prod-
uct must not be disposed of with other household
waste. Instead, it is your responsibility to dispose to
your waste equipment by handing it over to a des-
ignated collection point. Failure to follow this rule
may be penalized in accordance with applicable
regulations on waste disposal. The separate col-
lection and recycling of your waste equipment at
the time of disposal will help conserve natural re-
sources and ensure that it is recycled in a manner
that protects human health and the environment.
For more information about where you can drop off
your waste for recycling, please contact your local
waste collection company. The manufacturers and
importers do not take responsibility for recycling,
treatment and ecological disposal, either directly
or through a public system.
Important notice to UK users
This appliance is fitted with a UK approved mains
plug and a 13A fuse. Should the fuse need to be re-
placed, an ASTA or BSI approved BS1362 fuse, rat-
ed at 13A must be used. The plug can be replaced
by qualified electrician if it is damaged, and ensure
that the fuse is removed beforehand. Always dis-
pose of defunct plugs and fuses immediately.

10
DE
Sehr geehrter Kunde,
Vielen Dank für den Kauf dieses Hendi Gerät. Lesen Sie dieses Handbuch sorgfältig und achten Sie
besonders auf die unten aufgeführten Sicherheitsvorschriften, bevor Sie dieses Gerät zum ersten Mal
installieren und verwenden.
Sicherheitsvorschriften
• Dieses Gerät ist für den gewerblichen Gebrauch bestimmt.
• Verwenden Sie das Gerät nur für den vorgesehenen Zweck, für den es entworfen wurde,
wie in diesem Handbuch beschrieben.
• Der Hersteller haftet nicht für Schäden, die durch fehlerhafte Bedienung und
unsachgemäße Verwendung verursacht werden.
• Halten Sie das Gerät und den elektrischen Stecker von Wasser und anderen Flüssigkeiten
fern. Falls das Gerät in Wasser fällt, entfernen Sie sofort den Netzstecker von der
Steckdose. Verwenden Sie das Gerät erst, wenn es von einem zertifizierten Techniker
überprüft wurde. Die Nichtbefolgung dieser Anweisungen führt zu lebensbedrohlichen
Risiken.
• Versuchen Sie niemals, das Gehäuse des Geräts selbst zu öffnen.
• Legen Sie keine Objekte in das Gehäuse der Appliance ein.
• Berühren Sie den Stecker nicht mit nassen oder feuchten Händen.
• Gefahr eines elektrischen Schlags! Versuchen Sie nicht, das Gerät selbst zu
reparieren, Reparaturen sind nur von qualifiziertem Personal durchzuführen.
• Verwenden Sie niemals ein beschädigtes Gerät! Wenn es beschädigt ist, trennen Sie das
Gerät von der Steckdose und wenden Sie sich an den Händler.
• Warnung! Tauchen Sie die elektrischen Teile des Geräts nicht in Wasser oder andere
Flüssigkeiten ein.
• Halten Sie das Gerät niemals unter fließendem Wasser.
• Überprüfen Sie regelmäßig den Netzstecker und das Kabel auf Beschädigungen. Bei
Beschädigung muss es durch einen Dienstleister oder eine ähnlich qualifizierte Person
ersetzt werden, um Gefahren oder Verletzungen zu vermeiden.
• Stellen Sie sicher, dass das Kabel nicht mit scharfen oder heißen Gegenständen in
Berührung kommt und halten Sie es von offenem Feuer fern. Ziehen Sie niemals das
Netzkabel, um es von der Steckdose zu trennen, ziehen Sie stattdessen immer den
Stecker.
• Stellen Sie sicher, dass das Netzkabel und/oder das Verlängerungskabel keine
Auslösegefahr verursachen.
• Lassen Sie die Appliance während des Gebrauchs niemals unbeaufsichtigt.
• Warnung!
Solange sich der Stecker in der Steckdose befindet, wird das Gerät an die
Stromquelle angeschlossen.
• Schalten Sie die Appliance aus, bevor Sie sie vom Sockel trennen.
• Schließen Sie den Netzstecker an eine leicht zugängliche Steckdose an, so dass das Gerät
im Notfall sofort abgenommen werden kann.
