OPERATOR’S
MANUAL
REGISTER WARRANTY ONLINE AT WWW.HENNYPENNY.COM
MULTIPURPOSE PASS-THRU HOLDING CABINET
MODEL
MPC-21L
MPC-222
Read instructions before operating the appliance

iSept. 2013
TABLE OF CONTENTS
Section Page
Section 1. INTRODUCTION ..................................................................................................... 1-1
1-1. Safety ............................................................................................................... 1-1
1-2. Heated Holding Cabinet................................................................................... 1-2
1-3. Feature.............................................................................................................. 1-2
1-4. Proper Care ...................................................................................................... 1-2
1-5. Assistance ........................................................................................................ 1-2
Section 2. INSTALLATION ....................................................................................................... 2-1
2-1. Introduction...................................................................................................... 2-1
2-2. Unpacking........................................................................................................ 2-1
2-3. Location ........................................................................................................... 2-2
2-4. Electrical Connection....................................................................................... 2-2
2-5. Cabinet Dimensions......................................................................................... 2-3
Section 3. OPERATION ............................................................................................................. 3-1
3-1. Introduction...................................................................................................... 3-1
3-2. Start-Up............................................................................................................ 3-1
3-3. Operation with Product.................................................................................... 3-1
3-4. Cleaning Procedures ........................................................................................ 3-2
Section 4. TROUBLESHOOTING............................................................................................. 4-1
4-1. Error Codes ...................................................................................................... 4-1

2Sept. 2013
1-1
SAFETY
The instructions in this manual have been prepared to aid you
in learning the proper procedures for your equipment. Where
information is of particular importance or is safety related, the
words NOTICE, CAUTION, or WARNING are used. Their usage
is described below.
If a problem occurs during the first operation of a new unit,
recheck the Installation Section of the Operator’s Manual.
Before troubleshooting, always recheck the Operation
Section of the Operator’s Manual.
SAFETY ALERT SYMBOL is used with DANGER, WARNING
or CAUTION which indicates a personal injury type hazard.
NOTICE is used to highlight especially important information.
CAUTION used without the safety alert symbol indicates a
potentially hazardous situation which, if not avoided, may result
in property damage.
CAUTION used with the safety alert symbol indicates a
potentially hazardous situation which, if not avoided, could result
in minor or moderate injury.
WARNING indicates a potentially hazardous situation which,
if not avoided, could result in death or serious injury.
DANGER INDICATES AN IMMINENTLY HAZARDOUS
SITUATION WHICH, IF NOT AVOIDED, WILL RESULT IN
DEATH OR SERIOUS INJURY.
SECTION 1: INTRODUCTION
Where information is of particular importance or is safety related,
the words DANGER, WARNING, CAUTION, or NOTICE are
used. Their usage is described as follows:
This appliance is not intended for use by
persons (including children) with reduced
physical, sensory, or mental capabilities, or
lack of experience and knowledge, unless they
have been given supervision or instruction
concerning use of the appliance by a person
responsible for their safety

3Sept. 2013
• Easily cleaned
• MPC-21L shipped with 1 large pan
• MPC-222 shipped with 4 small pans
• 2-color LED allows for instant operating information
• Easy service access to electrical components
• Stainless steel construction
1-3.
FEATURES
1-2.
HEATED HOLDING
CABINET
As of August 16, 2005, the Waste Electrical and Electronic
Equipment directive went into effect for the European Union.
Our products have been evaluated to the WEEE directive. We
have also reviewed our products to determine if they comply
with the Restriction of Hazardous Substances directive (RoHS)
and have redesigned our products as needed in order to comply.
To continue compliance with these directives, this unit must not
be disposed as unsorted municipal waste. For proper disposal,
please contact your nearest Henny Penny distributor.
The Henny Penny Multipurpose Holding Cabinet is a
basic unit of food processing equipment designed to
hold hot foods at proper temperature in commercial food
operations.
Read instructions before operating the appliance
1-4.
PROPER CARE
As in any unit of food service equipment, the Henny Penny
Multipurpose Holding Cabinet does require care and
maintenance. Requirements for the maintenance and cleaning are
contained in this manual and must become a regular part of the
operation of the unit at all times.
1-5.
ASSISTANCE
Should you require outside assistance, just call your local inde-
pendent Henny Penny distributor in your area, call Henny Penny
Corp. 1-800-417-8405 toll free or 1-937-456-8405, or go to
Henny Penny online at www.hennypenny.com.

4Sept. 2013
This section provides the installation instructions for the Henny
Penny Multipurpose Holding Cabinet.
The Henny Penny Multipurpose Holding Cabinet has been
tested, inspected, and expertly packed to ensure arrival at its
destination in the best possible condition. The cabinet rests on
cardboard pads that sit on a wooden skid. The unit is then packed
inside a heavy cardboard carton with sufficient padding to
withstand normal shipping treatment.
To remove the Henny Penny Multipurpose Holding Cabinet
from the carton, you should:
1. Carefully cut banding straps.
2. Lift the carton off the unit.
3. Lift the unit off the cardboard padding and skid.
4. Peel off any protective covering from the exterior of the cabinet.
5. The unit is now ready for location and set up.
MPC-21L = 25 lbs, MPC-222 = 45 lbs
SECTION 2: INSTALLATION
Do not puncture the unit with any objects such as
drills or screws as electrical shock or component
damage could result.
Installation of this unit should be performed only by a
qualiedservicetechnician.
2-1.
INTRODUCTION
2-2.
UNPACkING
Any shipping damage should be noted in the presence
of the delivery agent and signed prior to his or her
departure.

5Jan. 2014
The unit should be placed on a supportive structure or shelf so the
entire bottom of the unit is evenly supported, and also, where the
pans can be removed without interruption and easy loading and
unloading of product. For proper operation, the cabinet must be
level.
Access to the controls are on the side of the unit. The controls do not
need to be accessed for normal operation.
2-4.
ELECTRICAL
CONNECTION The data plate, located on the side of the unit on the MPC-21L &
222, specifies the correct electrical supply. The unit requires a
grounded receptacle with a separate electrical line protected by a
fuse or circuit breaker of the proper rating. Electrical code may also
require GFCI protection.
The units are supplied with a 4 foot (274.3 cm) power cord.
Refer to the table below for electrical ratings:
Product Number Volts Watts Amps
MPC-21L 120 110 .92
MPC-222 120 400 3.3
MPC-21L 230 110 .47
MPC-21L 230 400 1.74
(FOR EQUIPMENT WITH CE MARK ONLY!)
To prevent electric shock hazard this appliance must be
bonded to other appliances or touchable metal surfaces
in close proximity to this appliance with an equipotential
bonding conductor. This appliance is equipped with an
equipotential lug for this purpose. The equipotential lug is
marked with the following symbol
To avoid electrical shock, the cabinet must be
adequately and safely grounded (earthed) according
to local electrical codes.
2-3.
LOCATION

6Feb. 2014
2-5.
CABINET
DIMENSIONS
MPC-21L
MPC-222

7Sept. 2013
1. Place hot product into the pans and place the pans in the
appropriate areas in the unit.
MPC-21L holds 1 large pan.
MPC-222 holds 4 small pans.
2. Always use proper product rotation procedures to ensure the
highest quality product.
This section provides operating procedures for the multipurpose
holding cabinet. The Introduction, Installation and Operation
Sections should be read, and all instructions should be followed
before operating the cabinet.
SECTION 3: OPERATION
3-1.
INTRODUCTION
3-2.
START-UP
3-3.
OPERATION WITH
PRODUCT
Before using the multipurpose holding cabinet,the
unit should be thoroughly cleaned as described in the
Cleaning Procedures Section of this manual.
Place hot product into unit and be sure to push the pans
in as far as they will go to minimize heat loss.
1. Press the power switch to the ON position. The red (CE:
yellow) LED a illuminates (not flashing) and the unit should
be heating. If the red (CE: yellow) LED does not come on, or
is flashing, refer to Troubleshooting Section.
2. Allow the unit to heat for at least 30 minutes before placing
product into unit. Once the LED turns green, the unit should
be at proper holding temperature and now product can be
loaded into unit.

8Sept. 2013
3-4.
CLEANING
PROCEDURES
1. Turn all controls to the OFF position.
2. Disconnect the electrical supply to the cabinet.
3. Remove all pans from the cabinet and take the pans to a sink
and clean them thoroughly.
4. Clean inside cabinet with a soft cloth, soap, and water. DO
NOT use excessive amounts of water.
5. Wipe the control panel with a damp cloth. Do not splash water
around the controls.
6. Clean the exterior of the cabinet with a damp cloth.
To avoid burns, allow the unit to cool before
cleaning.
Do not use steel wool, scrub pads, other abrasive cleaners
or cleaners/sanitizer containing chlorine, bromine, iodine or
ammonia chemicals, as these will deteriorate the stainless steel
material and shorten the life of the unit.
Do not use a water jet (or any kind of pressure sprayer) to
clean the unit, or component failure could result.

9Sept. 2013
DISPLAY CAUSE PANEL BOARD CORRECTION
“E-4” Control board overheating
Turn POWER switch to OFF then back ON; if
display still shows “E-4”, the unit is overheating or
louvers are clogged
“E-6” Faulty temperature temperature
probe Check probe for loose connection or probe faulty
“E-41” Memory scrambled
Press and hold the UP and DOWN buttons and
turn unit on. After SP shows on display, press
SET button twice. en press and hold the UP or
DOWN button until In-SYS shows in display; if
“E-41” persists, replace the control board
“Hi” Unit overheating; faulty relay or
control board Have relay or control board replaced
4-1.
ERROR CODES
SECTION 4: TROUBLESHOOTING

*FM05-091-* Henny Penny Corp., Eaton, Ohio 45320, Revised 2-13-14
Henny Penny Corporation
P.O.Box 60
Eaton,OH 45320
1-937-456-8400
1-937-456-8402 Fax
Toll free in USA
1-800-417-8417
1-800-417-8434 Fax
www.hennypenny.com
