General Information
Henny Penny open fryers offer
high-volume frying with
programmable operation, oil
management functions and fast, easy
filtration.
Henny Penny’s unique heat-
exchange design produces extremely
fast temperature recovery—typically
in seconds—while requiring less than
2 kW per gallon of oil or shortening.
This level of efficiency has earned
the Henny Penny 320 series open
fryer the ENERGY STAR®mark.
Fast recovery also translates into
frying program profits with higher
throughput, lower energy costs and
longer frying oil life that comes from
reduced temperature fluctuations.
A built-in filtration system filters hot
frying oil in under 4 minutes, with no
separate pumps or pans required.
Hot filtered oil returns directly to the
Single-well open fryer model OFG-321
Henny Penny Corporation
PO Box 60 Eaton OH 45320 USA
+1 937 456.8400 800 417.8417
+1 937 456.8434 Fax [phone] Fax
www.hennypenny.com
Standard Features
•Stainless steel construction for
easy-cleaning and long life.
•Heavy-duty stainless steel
rectangular fry pot with 7-year
warranty.
•COMPUTRON™8000 control
(additional charge.)
12 programmable cook cycles
Melt mode
Idle mode
Load compensation
Proportional control
Optional filter prompt and
customizable filter tracking
Clean-out mode
16-character digital display with
multiple language settings.
COMPUTRON
™
1000 simple digital
control.
▪Programmable
▪LED Time/Temp display
▪Simple UP/DOWN arrows
•Fry pot protection system.
•Built-in filtration (additional charge.)
•Easy basket set and release.
•Specially designed cold zone
prevents scorching.
•4 heavy-duty casters, 2 locking.
Accessories shipped with unit
•Fry baskets—please select one
1 full basket
2 half baskets
•Basket support
Accessories and options available
separately
Direct Connect shortening disposal
(filtration equipped units, only)
Shortening shuttle
Filter rinse hose
Fry well cover
APPROVED APPROVED AS NOTED RESUBMIT
AUTHORIZED SIGNATURE DATE
fry well. Frequent filtering extends
frying oil life, improves product quality
and reduces oil costs.
The OFG-321 open fryer features
Henny Penny’s heavy-duty stainless
steel rectangular fry pot that promotes
fast even cooking and comes with a 7-
year warranty—the best in the
business.
The COMPUTRON™8000 control
provides fully automatic,
programmable operation, as well as
energy-saving, filtration and cook
management features.
The COMPUTRON™1000 control
offers programmability in a simple,
easy to use digital control panel with
LED display.
Open fryers MODEL OFG-321 gas

Capacity
Product 12.5 lbs. (5.7 kg)
Oil 65 lbs. (30.3 l)
Electrical
© 2006 Henny Penny Corporation, Eaton, OH 45320 USA Revised 09/10/08
Laboratory certifications
Continuing product improvement may subject specifications to change without notice.
PROJECT ITEM NO
www.hennypenny.com
Bidding Specifications
•Provide Henny Penny model OFG-321
single-well gas open fryer, 12.5 lbs. (5.7 kg)
capacity per load and built-in filtration
system (additional charge.)
•Units shall incorporate either
COMPUTRON™1000 simple digital controls
or COMPUTRON™ 8000 control system
(additional charge.)
•Materials—cabinet, deck, exhaust stack,
filter drain pan and various fittings are
stainless steel. Fry pot is heavy duty
stainless steel.
•Units shall incorporate high-efficiency heat-
exchange design for extremely fast
recovery.
•Units qualify for the ENERGY STAR®mark.
•Unit’s controller provides for programmable
or manual operation with press-key controls
and LED digital display. COMPUTRON™
8000 control offers idle and melt modes,
load compensation, filtration tracking and 7-
day history.
•Units will include four heavy-duty casters,
two locking.
•
Units with filtration system ship with stainless
steel Max filtration screen and 2 PHT filter
envelopes. All units ship with choice of 1 full
basket or 2 half baskets.
MODEL OFG-321 gas
Open fryers
17 3/8 in. (441 mm)
37 3/8 in. (949 mm)
44 in.
(1118 mm)
Height includes
casters
Dimensions
Width 17 3/8 in. (441 mm)
Depth 37 3/8 in. (949 mm)
Height 44 in. (1118 mm)
Required clearances
Sides: 6 in. (152 mm) air flow
Back: 6 in. (152 mm) air flow, connections
Front: 30 in. (762 mm) filter pan removal
Crated dimensions
Length 40 in. (1016 mm)
Depth 25 in. (635 mm)
Height 52 ¾ in. (1340 mm)
Volume 30.5 cu. ft. (0.86 m³)
Net weight N/A
Crated weight: 305 lbs. (138 kg)
Heating
Natural or liquid petroleum
2 burners, 85,000 BTU/hr (25 kW)
½ in. connection
PLAN
FRONT
Power cord ½ in. gas connection
Volts Phase Cycle/Hz Watts Amps Wire
120 1 60 N/A 12.0 2+G
230 1 50 N/A 2.5 1NG
