Three Tier Renaissance Fountain
5705F7
Assembly Instructions
1. Locate a suitable site for your Three Tier Renaissance Fountain.
Site should be level and provide a pleasing viewing angle. You should
always follow local electrical codes and use a GFCI Protected outlet.
NOTE: this is a tall vertical sculpture and care should be taken to
provide a level surface before assembly is started, as a slight angle
will be noticeable and can affect the fountain's water action.
2. Place the 7708 Large Renaissance Pedestal in the center of your
site. Level as necessary.
NOTE: There is a pattern on each of the Pedestals. You may choose
to align or alternate these patterns on the Pedestals as you assemble
each tier of the fountain.
3. Thread the 1" X 8" stand pipe in the 6708 Large Renaissance Bowl.
Pass the pump power cord down through the stand pipe and out the
bottom of the Bowl. Install a rubber stopper over the power cord and
insert it into the top of the stand pipe. The rubber stopper has a slit in
it, spread the stopper apart at the slit and slide the cord into the hole
in the center of the stopper. Place the Bowl on the Pedestal and pass
the power cord down through the Pedestal and out the bottom,
through the notch. Level as necessary.
4. Thread the Bushing onto the pump outlet. Slip a Flow Restrictor
over the end of the 42" piece of 3/4" NKT (No Kink Tubing)
approximately 4-6" from the end and connect the NKT to the bushing
with a clamp.
NOTE: the location of the spills in each of the bowls can be adjusted
during assembly. Spills can be alternated or placed directly above
each other as you prefer, by rotating the bowls.
5. Place the 7707 Medium Renaissance Pedestal on the flat boss in
the center of the Large Bowl while passing the NKT up through the
center of the Pedestal. Level and align as necessary.
6. Thread the 1" X 6" stand pipe into the 6706 Medium Bowl. Place the
Medium Bowl on the Medium Pedestal and pass the NKT through the
stand pipe. Level and align as necessary.
IMPORTANT- WINTER CARE:
Do not allow water to collect and freeze in fountain bowl(s) or shell. Do not allow fountain pieces to sit in a pool of ice. Disassemble entire
fountain and pump and store indoors during the winter season.
If you cannot store your fountain indoors during the winter season, you must at least protect it from ice collection or exposure. Protect your
fountain during the winter season: first remove the statue(s) and pump, storing them inside if possible. Next, locate the drain plug on the
underside of bowl(s) or shell. Remove drain plug to drain any water “trapped” between the walls of the bowl(s) or shell. Then fill the bowl(s) or
shell with an absorbent material such as burlap, blankets, etc. Finally, cover the entire fountain with a Henri Fountain Cover. Should
condensation droplets form on the inside of the cover, they will be absorbed by the material.
By following these simple and sensible precautions during the winter season, you will protect your fountain for years of beauty and enjoyment!
5705F7
#7708
Large
Renaissance
Pedestal
#6708
Large
Renaissance
Bowl
#7707
Medium
Renaissance
Pedestal
#6706
Medium
Renaissance
Bowl
#7705
Small
Renaissance
Stand
Pipe
Flow
Restrictor
Pump
Power
Cord
#5705
Finial
#6705
Small
Renaissance
Bowl
Tube
Clamp
Adapter
Bushing
Stand
Pipe
Rubber
Stopper

IS5705F7-11-02
Henri Studio Inc. Wauconda, IL 60084 IS5705F7-11-02
7. Place the 7705 Small Pedestal in the Medium Bowl and pass the NKT up through the
Pedestal. Level as necessary.
8. Place the 6705 Small Bowl on the Small Pedestal and pass the NKT through the Bowl. Level
and align as necessary.
9. Place the 5705 Finial in the Small Bowl and pass the NKT through the Finial so that the NKT
is level with the top edge of the hole in the Finial. Level as necessary.
10. Add water to the fountain and start the pump when there is sufficient water to cover the
pump. Adjust the flow restrictor for a pleasing flow into the bowls. The final level of the water
is generally recommended to be 1” below the edge of the bowl.
If apump does not start on the first attempt, unplug the pump and plug it in again. Sometimes an
airlock can occur and this simple restart most frequently clears the lock.
5705F7
Connection Kit Parts List
11/2" X 1/4" Bushing
11" X 8" Stand Pipe
1Rubber Stopper
2Clamps
11" X 6" Stand Pipe
1Flow Restrictor
1 42" X 3/4" NKT
