Henri Studio 5231F21 User instructions

SETTING UP THE 5231F21
1) Place 6719 Fiberglass Pool on your prepared
surface.
2) Check the standpipe in the 6719 pool center to make sure it is tight. Place pump in center of pool
and feed power cord through attached standpipe and (using channel area built under pool) out to
desired area outside of pool. Open the slit in the large rubber stopper, place around the power cord
near the top of the standpipe, close the slit, then press into the pipe to make it
watertight. Insert largest barbed adapter into the pump exhaust. Attached
18” tube and clamp it tight to the adapter.
3) With help, place the 7234 Base in the center of the
fiberglass pool, making sure to pull the tube safely up
through it.
4) Thread the two Bushings into the top and bottom of
the coupling in the 6234 Bowl’s floor, then thread a 1”
Barbed Adapter into each of the bushings. Set the
6234 bowl on the base, pushing and clamping
the tube onto the bottom barb as you set it
down. Attach the 8” x 1” clear tube to the barb
inside this bowl. Push the other end of the tube
over the straight leg of the 1” tee. Push the 4”
x 1” tube over the opposing straight leg of the
tee and push the 1” x 1” tube sleeve over the
middle leg of the tee. Insert the Elbow into the
1” tube sleeve and then press the ¾” x 4” long
clear tube over the barbed end of the elbow.
Position a flow Restrictor over the ¾” x 4”
tube and tighten it just enough to stay in place.
(Later, you can tighten the restrictor further if you
want to adjust down the water flow.)
5) Set the 7232 Base into the 6234 bowl. Insert
a 1” Barbed Adapter into the bottom of the
6232 Bowl and insert the smaller ¾” Barbed
Adapter into the top side of the same
bowl. Set the 6232 onto the 7232 base,
pressing the open end of the 1”
x 4” tube over the adapter’s
barbed underneath.
6) Build another tee assembly similar to the one in the bowl below. This time, attach a ¾” x 8”
flexible tube onto each leg of the ¾” Tee. Position and slightly tighten a flow Restrictor over the
tube on the middle leg of the tee. Then push the open end of a tube on a straight leg over the barb
inside the bowl.
Make sure to place your fountain on a firm and level
surface which will not settle. Note: Always follow
local electrical codes and use a 110V GFCI protected
outlet. Do not let children climb on fountain.

7) Insert two ¾” Barbed Adapters in the top and underside of the 6231 Bowl/Base unit. Attach the
12” tube to the top adapter. As you lower the bowl/base unit into place, push the other end of the
tube from the tee below (not the restricted tube) onto the barbed adapter under the 6231 unit.
8) Place the 5231 Finial within the top of the 6231 bowl/base unit. As you lower the finial into
place, slip the top of the 12” tube up inside of the finial.
9) Now, install the 6233A and 6233B ledge rim sections in alternating order on the top edge of the
large 6234 bowl. A steel strapping system is provided to hold these securely in place and caulk is
provided for you to make a water tight seal (so the water will spill over the rim sections rather than
through them). Remove the bolts provided under the rim edges and above the bowl edge. Hold a
slotted strap against the top edge of the 6234 bowl and bolt in, using the washers between the head
of the bolt and the strap. Apply caulk generously to the top edge of the 6234 bowl. Set one of the
rim edges in place and insert a bolt (with washer) from the bottom up into the bolt hole under the
middle of the rim edge and tighten. Apply caulk to the left and right ends of the ledge rim section
(all the way up to the highest level of the end. Repeat until all the rim edges are on.
10) While allowing the caulk some time to cure (see caulk instructions) place the 9029a and 9029b
Toscano Pool Surrounds around the pool in alternating sequence.
11) After filling the pool and bowls of the fountain with water, read your pump instruction. Then
connect the pump to a GFCI protected. Turn on the pump and check for balance. If necessary, use
shims to adjust bowls (starting from bottom up).
You can tighten restrictors now if you desire to
adjust the water flow from any section.
Csd 11/2022
