1
Versteifungsstrebe für Tankschutzbügel
Reinforcement bracket for tank guards
Honda CRF 1100 L Africa Twin Adventure Sports
ab Baujahr 2020 / from date of manufacture 2020
Artikel Nr.: / Item-no.:
42229522 00 01 schwarz/black
080220
INHALT
CONTENT
1x 700010827 Versteifungsstrebe
1x 700010826 Schraubensatz:
1x 700010827 Bracket
1x 700010826 Screw kit:
2x Linsenschraube M8x20
2x U-Scheibe Ø8,4
2x Selbstsichernde Bundmutter M8
1x Gummipuffer
2x Filister head screw M8x20
2x Washer Ø8,4
2x Self lock collar nut M8
1x Rubber buffer
Der Versteifungsbügel kann nur in Verbindung mit dem Tankschutzbügel 5029522 00 XX montiert werden.
The bracket can only be used in combination with the tank guard 5029522 00 XX
2
42229521 00 01
VORBEREITUNG
PREPARING
Die Schraube rechts unterhalb der Kühler entfernen, diese wird wiederverwendet. Den Gummipuffer in die
Bohrung des Bügels fügen (Fahrtrichtung links).
Remove the screw on the right underneath the radiator, this will be reused. Insert the rubber buffer into the hole
of the bracket (driving direction left).
BENÖTIGTE WERKZEUGE
TOOLS REQUIRED
WICHTIG
IMPORTANT
Beachten Sie die in Ihrem Land geltenden Zulassungsbestimmungen.
Für den Bereich der BRD gilt: Ein Eintrag in die Fahrzeugpapiere ist nicht erforderlich.
Die Voraussetzung für die Montage ist natürlich eine gewisse technische Erfahrung. Wenn Sie sich nicht sicher sind,wie
man eine bestimmte Arbeit ausführt, sollten Sie diese Ihrer Fachwerkstatt überlassen.
Ziehen sie alle zugänglichen Schrauben zuerst nur locker an. Nachdem alles montiert ist, werden die Schrauben dann auf
das entsprechende Anzugsmoment festgezogen. Dadurch wird sichergestellt, dass das Produkt spannungsfrei angebaut ist.
Anzugsmomente beachten! Nach der Montage alle Verschraubungen auf festen Sitz kontrollieren!
Observe the local local registration requirements.
Of course, the assembly requires a certain technical experience. If you are not sure how to execute a determined action,
you should ask your local distributor to do it. First, tighten all screws only loosely. After mounting all parts, the screws
should be tightened to the torque specified. This guarantees, that the product is mounted without tension. Observe
the tightening torques of the manufacturer! Control all screw connections after the assembling for tightness!
MONTAGEANLEITUNG
MOUNTING INSTRUCTIONS
1
Montage des Verbindungsbügels links/rechts:
Hinter den Laschen des Tankschutzbügels
mit den Linsenschrauben M8x20,
U-Scheiben Ø8,4 sowie selbstsichernden
Bundmuttern M8.
Fastening of the bracket left/right:
Behind the lugs of the tank guard with filister
head screws M8x20, washers Ø8,4 and self
lock collar nuts M8.
2x 2x 2x
3
Hepco & Becker GmbH
An der Steinmauer 6
D-66955 Pirmasens
Germany
Tel.: +49 (0)6331 - 1453 - 100
Fax: +49 (0)6331 - 1453 - 120
eMail: vertrieb@hepco-becker.de
www.hepco-becker.de
Weiteres Zubehör auf unsere Homepage. More accessories: see our homepage.
42229521 00 01
MONTAGEANLEITUNG
MOUNTING INSTRUCTIONS
2
ACHTUNG
CAUTION
Nach der Montage alle Verschraubungen auf festen Sitz kontrollieren ! Abgebaute Teile wieder montieren.
Bitte beachten Sie unsere beigefügten Serviceinformationen.
Control all screw connections after the assembling for tightness! Reassemble the dismantled parts.
Please notice our enclosed service information.
Montage des Verbindungsbügels mitte:
Am nun freien Gewinde mit der Original-
schraube.
Fastening of the bracket middle:
At the now free thread with the original
screw.
5029522 00 01/22 Tankschutzbügel / Tank guard
5019522 00 01/22 Motorschutzbügel / Engine guard
6539522 00 01 Kofferträger / Side carrier
6519522 00 22 Cutout Kofferträger / Cutout Side carrier
6629522 01 01 Easyrack
6559522 01 01 Alurack
5069522 00 01 Tankring
5059522 00 01 Hauptständer / Center stand
7009522 00 01 Lampenschutzgitter / Headlight grilles
42129522 00 01 Griffschutz / Handle guard
42119522 00 91 Seitenständerplatte / Side stand enlargement
Als weiteres Zubehör lieferbar:/ Also available:
