1
Minirack
Voge 500 R
Artikel Nr.: / Item-no.:
6607609 01 01 schwarz/black
271120
INHALT
CONTENT
1x 700009031 Minirack
1x 700011288 Rohradapter links
1x 700011289 Rohradapter rechts
1x 700011290 Schraubensatz:
1x 700009031 Minirack
1x 700011288 Tube adapter left
1x 700011289 Tube adapter right
1x 700011290 Screw kit:
BENÖTIGTE WERKZEUGE
TOOLS REQUIRED
4x Zylinderschraube M8x50
4x Senkschraube M6x16
4x Selbstsichernde Mutter M6
4x U- Scheiben Ø6,4
4x U-Scheiben Ø8,4
1x Logo Hepco & Becker ø30m
4x Verschlussstopfen 8mm
4x Aludistanzen Ø18xØ9x27
4x Allen screw M8x50
4x Countersunk screw M6x16
4x Self lock nut M6
4x Washer Ø6,4
4x Washer Ø8,4
1x Emblem Hepco & Becker ø30m
4x Plastic plugs 8mm
2x Alu spacer Ø18xØ7x27
2
WICHTIG
IMPORTANT
Die Voraussetzung für die Montage ist natürlich eine gewisse technische Erfahrung. Wenn Sie sich nicht sicher sind,wie
man eine bestimmte Arbeit ausführt, sollten Sie diese Ihrer Fachwerkstatt überlassen.
Ziehen sie alle zugänglichen Schrauben zuerst nur locker an. Nachdem alles montiert ist, werden die Schrauben dann auf
das entsprechende Anzugsmoment festgezogen. Dadurch wird sichergestellt, dass das Produkt spannungsfrei angebaut ist.
Anzugsmomente beachten! Nach der Montage alle Verschraubungen auf festen Sitz kontrollieren!
Of course, the assembly requires a certain technical experience. If you are not sure how to execute a determined action,
you should ask your local distributor to do it. First, tighten all screws only loosely. After mounting all parts, the screws
should be tightened to the torque specified. This guarantees, that the product is mounted without tension. Observe
the tightening torques of the manufacturer! Control all screw connections after the assembling for tightness!
VORBEREITUNG
PREPARING
Die Originalhaltegriffe entfernen, diese entfallen.
Remove the original pillion handles, these are omitted.
MONTAGEANLEITUNG
MOUNTING INSTRUCTIONS
1
4x
Montage der Rohradapter rechts/links:
In die freien Gewinde die Aludistanzen
Ø18xØ9x27 einstellen und die Rohradapter
jeweils links und rechts, mit den Zylinder-
schrauben M8x50 und den U-Scheiben Ø8,4
festschrauben.
Fastening of the tube adapters right/left:
Set the alu spacers Ø18xØ9x27 in the free
threads and tighten the tube adapters left and
right with the allen screws M8x50 and the
washers Ø8,4.
4x 4x
6607609 01 01
Fahrtrichtung/driving direction
3
MONTAGEANLEITUNG
MOUNTING INSTRUCTIONS
2
4x 4x
4x
4x
Montage der Alupalette:
Auf den zuvor montierten Rohradaptern mit
den Senkkopfschrauben M6x16.
Von unten mit den selbstsichernden Muttern
M6 sowie U-Scheiben Ø6,4 verschrauben.
Nun alle Teile festziehen und Logo einkleben.
Die nicht benutzten Bohrungen mit den Ver-
schlussstopfen Ø8mm verschließen.
Fastening of the alu palette:
On the tube adapters with countersunk head
screws M6x16. Secure it with self lock nuts
M6 and washers Ø6,4.
Now, screw on all bolts and nuts and stick
the logo into the cutout. Seal up the 4 holes
not in use with the plastic plugs Ø8mm.
Hepco & Becker GmbH
An der Steinmauer 6
D-66955 Pirmasens
Germany
Tel.: +49 (0)6331 - 1453 - 100
Fax: +49 (0)6331 - 1453 - 120
eMail: vertrieb@hepco-becker.de
www.hepco-becker.de
Als weiteres Zubehör lieferbar:/ Also available:
Weiteres Zubehör auf unsere Homepage. More accessories: see our homepage.
ACHTUNG
CAUTION
Nach der Montage alle Verschraubungen auf festen Sitz kontrollieren! Abgebaute Teile wieder montieren.
Bitte beachten Sie unsere beigefügten Serviceinformationen.
Control all screw connections after the assembling for tightness! Reassemble the dismantled parts.
Please notice our enclosed service information.
6307609 00 01 C-Bow Halter / C-Bow holder
6617609 01 01 Easyrack
6527609 01 01 Alurack
5017609 00 01 Motorschutzbügel / Engine guard
5037609 00 01 Frontschutzbügel / Front guard
5047609 00 01 Heckschutzbügel / Rear guard
5067609 00 01 Tankring
6607609 01 01
