1
130216/040418
Adapter
für Montage des Lampenschutzgitters 700994/9512 00 01
for mounting of the headlight grilles 700994/9512 00 01
1x Adapter / adapter
1x Schraubensatz/Screw kit:
2x Sechskantschraube M6x30
hexagon screw M6x30 4x Selbstsichernde Mutter M6
self lock nut M6
2x Karosseriescheibe Ø6,4xØ18
body washer Ø6,4xØ18
6x U-Scheibe ø6,4
washer ø6,4
2x Linsenkopfschraube M6x16
filister head screw M6x16
4x Kunststoffkappen M6
plastic cap M6
HONDA CRF 1000 L Africa Twin / DCT
Baujahr 2016-2017 / date of manufacture 2016-2017
Artikel Nr.: / Item-no.: 4213994 00 01 schwarz / black
HONDA CRF 1000 L Africa Twin / DCT
ab Baujahr 2018 / from date of manufacture 2018
Artikel Nr.: / Item-no.: 42139512 00 01 schwarz / black
INHALT
CONTENTS
The adapter will be fixed at the free
borings under the cockpit.
From above with hexagonal screws
M6x30 and washers Ø6,4. Secure with
body washers ø6,4xø18 and self lock
nuts M6. Put the plastic caps over the
nuts.
2
Größe/Size 10
2x Größe/Size 4
Den Adapter an den freien Bohrungen
unter dem Cockpit befestigen. Hierfür
von oben die Sechskantschrauben M6x30
sowie die U-Scheiben ø6,4 verwenden
und von unten mit den Karosserie-
scheiben ø6,4xø18 und den selbst-
sichernden Muttern M6 verschrauben.
Mutter mit Kunststoffkappen versehen.
Adapter
für Montage des Lampenschutzgitters 700994/9512 00 01
for mounting of the headlight grilles 700994/9512 00 01
HONDA CRF 1000 L Africa Twin / DCT
Baujahr 2016-2017 / date of manufacture 2016-2017
Artikel Nr.: / Item-no.: 4213994 00 01 schwarz / black
HONDA CRF 1000 L Africa Twin / DCT
ab Baujahr 2018 / from date of manufacture 2018
Artikel Nr.: / Item-no.: 42139512 00 01 schwarz / black
Baujahr 2016-2017 / date of manufacture 2016-2017
Of course, the assembly requires a certain technical experience. If you are not sure how to execute a determined action,
you should ask your local distributor to do it. First, tighten all screws only loosely. After mounting all parts, the screws
should be tightened to the torque specified. This guarantees, that the product is mounted without tension. Observe
the tightening torques of the manufacturer! Control all screw connections after the assembling for tightness!
To mount this tank guard, a second person is helpful.
Die Voraussetzung für die Montage ist natürlich eine gewisse technische Erfahrung. Wenn Sie sich nicht sicher sind,
wie man eine bestimmte Arbeit ausführt, sollten Sie diese Ihrer Fachwerkstatt überlassen. Ziehen sie alle zugänglichen
Schrauben zuerst nur locker an. Nachdem alles montiert ist, werden die Schrauben dann auf das entsprechende
Anzugsmoment festgezogen. Dadurch wird sichergestellt, dass das Produkt spannungsfrei angebaut ist. Anzugsmomente
beachten! Nach der Montage alle Verschraubungen auf festen Sitz kontrollieren!
Zur Montage ist eine zweite Person hilfreich.
WICHTIG
IMPORTANT
2x2x
BENÖTIGTE WERKZEUGE
TOOLS REQUIRED
MONTAGEANLEITUNG
MOUNTING INSTRUCTIONS
2x 2x
2x
The adapter will be fixed at the free
original threads under the cockpit with
hexagonal screws M6x30 and body
washers ø6,4xø18.
3
HONDA CRF 1000 L Africa Twin / DCT
Baujahr 2016-2017 / date of manufacture 2016-2017
Artikel Nr.: / Item-no.: 4213994 00 01 schwarz / black
HONDA CRF 1000 L Africa Twin / DCT
ab Baujahr 2018 / from date of manufacture 2018
Artikel Nr.: / Item-no.: 42139512 00 01 schwarz / black
Adapter
für Montage des Lampenschutzgitters 700994/9512 00 01
for mounting of the headlight grilles 700994/9512 00 01
Den Adapter an den freien Original-
gewinden unter dem Cockpit befestigen.
Hierfür die Sechskantschrauben M6x30
sowie die Karosseriescheiben ø6,4xø18
verwenden.
ab Baujahr 2018 / from date of manufacture 2018
MONTAGEANLEITUNG
MOUNTING INSTRUCTIONS
2x 2x
The grilles will be fixed at the adapter
with filister head screws M6x16, washers
Ø6,4 and self lock nuts M6.
Put the plastic caps over the nuts.
Das Lampengitter am Adapter mit den
Linsenkopfschrauben M6x16, den U-
Scheiben ø6,4 und selbstsichernden
Muttern M6 verschrauben.
Mutter mit Kunststoffkappen versehen.
4
Als weiteres Zubehör lieferbar / Also available:
Hepco & Becker GmbH
An der Steinmauer 6
D-66955 Pirmasens
Germany
Tel.: +49 (0)6331 - 1453 - 100
Fax: +49 (0)6331 - 1453 - 120
eMail: [email protected]
www.hepco-becker.de
ACHTUNG
CAUTION
Nach der Montage alle Verschraubungen auf festen Sitz kontrollieren!
Bitte beachten Sie unsere beigefügten Serviceinformationen.
Control all screw connections after the assembling for tightness!
Please notice our enclosed service information.
Weiteres Zubehör auf unsere Homepage. More accessories: see our homepage.
Easyrack
Alurack
Seitenträger festverschraubt, schwarz / Side carrier firmly attached, black
C-Bow Halter, schwarz / C-Bow holder, black
Motorschutzbügel, schwarz / Engine guard, black
Motorschutzplatte / Skid plate
Griffschutz / Handle protection
HONDA CRF 1000 L Africa Twin / DCT
Baujahr 2016-2017 / date of manufacture 2016-2017
Artikel Nr.: / Item-no.: 4213994 00 01 schwarz / black
HONDA CRF 1000 L Africa Twin / DCT
ab Baujahr 2018 / from date of manufacture 2018
Artikel Nr.: / Item-no.: 42139512 00 01 schwarz / black
Adapter
für Montage des Lampenschutzgitters 700994/9512 00 01
for mounting of the headlight grilles 700994/9512 00 01
2x 2x
MONTAGEANLEITUNG
MOUNTING INSTRUCTIONS
2x 2x
