4 150.885 allen screw M6 x12
4 150.763 allen screw M6 x 20
2 150.769 allen screw M6 x 50
2 150.782 allen screw M8 x 20
2 150.838 hexagon bolt M8 x 16mm
6 150.809 washer ø6,4
4 150.810 washer ø8,4
4 150.799 self-lock nut M6
2 151.118 spacer ø18 x ø7 x 23mm
4 150.164 special washer 20 x 20 x ø6,4
211111//280117
4 150.885 Inbusschraube M6 x12
4 150.763 Inbusschraube M6 x 20
2 150.769 Inbusschraube M6 x 50
2 150.782 Inbusschraube M8 x 20
2 150.838 Sechskantschraube M8 x 16mm
6 150.809 U-Scheibe ø6,4
4 150.810 U-Scheibe ø8,4
4 150.799 Selbstsichernde Mutter M6
2 151.118 Aludistanz ø18 x ø7 x 23mm
4 150.164 Viereck-Scheiben 20 x 20 x ø6,4
APRILIA Tuono V4 1000 RR
ab Baujahr 2015 / from date of manufacture 2015
APRILIA Tuono V4R/
ab Baujahr 2012 / from date of manufacture 2012
Easyrack
Artikel Nr.: / Item-no.: 6
6617501 01 01 schwarz/black
Alurack
Artikel Nr.: / Item-no.: 6
6507501 01 01 schwarz/black
1 700007704 Rohradapter links
1 700007705 Rohradapter rechts
1 700007706 Halteadapter
1 700008650 Easyrack
1 700008647 Abdeckblende links
1 700008648 Abdeckblende rechts
Bei Bestellung eines Aluracks zusätzlich:
Bei Bestellung eines Easyracks zusätzlich:
1 799.901HB Alu-Rack
1 799.902HB TC-Bügel für Alu-Rack
1 799.903HB Abdeckplatte für Rack
1 Schraubensatz/Screw kit:
1 700008650 Easyrack
1 700008647 plastic cover left
1 700008648 plastic cover right
When ordering a Alurack:
When ordering a Easyrack:
1 799.901HB alu-rack
1 799.902HB bow for Alu-rack
1 799.903HB plastic cover for rack
1 700007704 tube adapter left
1 700007705 tube adapter right
1 700007706 holding adapter
INHALT
CONTENTS
2
2
1
Montage des Halteadapters:
Der Halteadapter wird von unten zusammen mit der Kennzeichen-
halterung verschraubt. Zwischen Halteadapter und Kennzeichen-
halterung die Aludistanzen Ø18 x Ø7 x 23mm einsetzen.
Die Verschraubung erfolgt mit den Inbusschrauben M6 x 50mm,
U-Scheiben Ø6,4 und den Originalmuttern.
Vorbereitung:
Soziussitzbank abnehmen. Zündspule herausnehmen, um die
darunterliegenden Muttern der Kennzeichenhalterung (Pfeil) zu
erreichen. Die Originalschrauben entfallen.
Blick unter die Soziussitzbank
2x 2x
2x
Werden Alu-Rack und C-Bow in Kombination montiert, entfallen die Alu-
distanzen und der Halteadapter wird direkt auf den C-Bowhalter montiert.
ACHTUNG: auf die korrekte Position des Halteadapters achten.
Vorbereitung:
dismantle the pillion seat. Remove the ignition coil to reach the nuts
of the the license plate bracket (arrow). The original screws are
obsolete.
View under the pillion seat
NOTICE: notice correkt position of the holding adapter
If Alurack and C-Bow were mounted together, the spacers are not used.
Mount the holding adapter directly over the C-Bow holder.
Fastening of the holding adapter:
together with the number plate holder. Add alu spacer Ø18 x Ø7
x 23mm between adapter and numer plate holder. Use allen screws
M6 x 50mm, washers Ø6,4 and original nuts.
APRILIA Tuono V4R/
ab Baujahr 2012 / from date of manufacture 2012
Easyrack
Artikel Nr.: / Item-no.: 6
6617501 01 01 schwarz/black
Alurack
Artikel Nr.: / Item-no.: 6
6507501 01 01 schwarz/black
APRILIA Tuono V4 1000 RR
ab Baujahr 2015 / from date of manufacture 2015
Fahrt-
richtung
driving
direction
Of course, the assembly requires a certain technical experience. If you are not sure how to execute a determined action,
you should ask your local distributor to do it. First, tighten all screws only loosely. After mounting all parts, the screws
should be tightened to the torque specified. This guarantees, that the product is mounted without tension. Observe
the tightening torques of the manufacturer! Control all screw connections after the assembling for tightness!
Die Voraussetzung für die Montage ist natürlich eine gewisse technische Erfahrung. Wenn Sie sich nicht sicher sind,
wie man eine bestimmte Arbeit ausführt, sollten Sie diese Ihrer Fachwerkstatt überlassen. Ziehen sie alle zugänglichen
Schrauben zuerst nur locker an. Nachdem alles montiert ist, werden die Schrauben dann auf das entsprechende
Anzugsmoment festgezogen. Dadurch wird sichergestellt, dass das Produkt spannungsfrei angebaut ist. Anzugsmomente
beachten! Nach der Montage alle Verschraubungen auf festen Sitz kontrollieren!
WICHTIG
IMPORTANT
VORBEREITUNG
PREPARING
3
3
Montage der Rohradapter oben rechts und links:
Die Rohradapter werden am Halteadapter mit den Inbusschrauben
M8 x 20mm und U – Scheiben Ø 8,4 verschraubt.
2x 2x
4
Vorbereitung des Alu-Racks:
Den beiliegenden TC-Bügel mit den Inbusschrauben 6 x 12
hinten unter dem Alu-Rack verschrauben.
4x
HINWEIS:
Der TC-Bügel ist nur bei Anbringung eines Hepco & Becker
Topcases erforderlich.
5
Montage der Rohradapter vorne rechts und links:
Die Rohradapter werden an der Rückseite der Soziusfußrasten
(Gewinde M8) mit den Sechskantschrauben M8 x 16mm und
U – Scheiben Ø8,4 verschraubt.
2x 2x
Fastening of the tube adapters front left +right:
at the inner side of the passenger footrests (free thread).
Use hexagon bolts M8 x 16mm and washers Ø8,4.
Fastening of the tube adapters top left +right:
at the holding adapter mounted before.
Use allen screws M8 x 20mm and washers Ø8,4.
APRILIA Tuono V4R/
ab Baujahr 2012 / from date of manufacture 2012
Easyrack
Artikel Nr.: / Item-no.: 6
6617501 01 01 schwarz/black
Alurack
Artikel Nr.: / Item-no.: 6
6507501 01 01 schwarz/black
Fastening of the bow for the rack:
Fix the bow to the rack with allen screws M6 x 12.
NOTICE:
The bow is only needed in use with a Hepco & Becker topcase.
APRILIA Tuono V4 1000 RR
ab Baujahr 2015 / from date of manufacture 2015
MONTAGEANLEITUNG
MOUNTING INSTRUCTIONS
4
Fastening of the Alurack/Easyrack:
On the tube adapters.
Use allen screws M6 x 20 and special
washer 20 x 20 x ø6,4. Secure with
washers ø6,4 and self-lock nuts M6.
Mount the plastic cover.
APRILIA Tuono V4R/
ab Baujahr 2012 / from date of manufacture 2012
Easyrack
Artikel Nr.: / Item-no.: 6
6617501 01 01 schwarz/black
Alurack
Artikel Nr.: / Item-no.: 6
6507501 01 01 schwarz/black
Nach der Montage alle Verschraubungen auf festen Sitz kontrollieren ! Abgebaute Teile
wieder montieren. Bitte beachten Sie unsere beigefügten Serviceinformationen.
Control all screw connections after the assembling for tightness! Reassemble the
dismanteled parts. Please notice our enclosed service information.
ACHTUNG
CAUTION
Als weiteres Zubehör lieferbar:/ Also available:
Hepco & Becker GmbH
An der Steinmauer 6
D-66955 Pirmasens
Germany
Tel.: +49 (0)6331 - 1453 - 100
Fax: +49 (0)6331 - 1453 - 120
eMail: [email protected]
www.hepco-becker.de
Weiteres Zubehör auf unsere Homepage. More accessories: see our homepage.
APRILIA Tuono V4 1000 RR
ab Baujahr 2015 / from date of manufacture 2015
Montage des Aluracks/Easyracks:
es wird mit den Inbusschrauben M6x20,
den Viereck-Scheiben 20x20x6,4, den
U-Scheiben ø6,4 und den selbst-
sichernden Muttern M6 auf den
Rohadaptern verschraubt.
Anschließend die Kunststoffabdeckung
montieren.
4x
4x 4x
4x
MONTAGEANLEITUNG
MOUNTING INSTRUCTIONS
6307501 00 01 C-Bow Halter/C-Bow holder
