YSetu® Disassembly Instructions
Tools Needed:
2 lbs Hammer
Small Flathead
Screwdriver
T-20 Torx Driver
Power Driver
T-27 Torx Bit
(2.75” or longer)
Disassembly Steps:
1
1.1. Lay chair on back.
2
2.1. Grasp and pull to remove Casters
from the Base.
Caster
Utility KnifeSafety Glasses
Where possible, plastic components are marked with recycling codes. Use these codes to identify material type
for recycling. Non marked components should be treated as mixed plastic. Ferrous metals can be identified using
a small magnet for recycling. Non-ferrous metals should be separated and recycled separately.
Materials Identification and Segregation:

2
Z
© 2010 Herman Miller, Inc. Zeeland, Michigan. Printed in the U.S.A.
® Y, Z, Action Office, Mirra and Setu are among the registered trademarks of Herman MIller, Inc. Part no. 1b5vn8 rev A.
Vivo® is among the trademarks of Herman Miller, Inc.
Illustrations and specifications are based on the latest product information available at the time of publication.
The right is reserved to make changes in design and specifications at any time, without notice, and also to discontinue products.
3.1.Hold Base legs firmly and strike the 4.1. Remove Base.
43
hammer until Base comes loose.
5
5.1. Use small Flathead Screwdriver to
disengage black plastic connector
of Height Adjustment Cable from
Screwdriver
Height Adj
Cable
top of Cylinder.
6.1. Use small Flathead Screwdriver to
disengage ball of Height Adjustment
Cable from top of Cylinder.
Screwdriver
Height Adj
Cable
6
bottom of cylinder with a 2 pound
Hammer

3
