HID iCLASS SE R10F User manual

hidglobal.com An ASSA ABLOY Group brand
2 Wire the reader
3 Secure the reader to the backplate
4 Power and test the reader
Optional Features
Optical Tamper enabled by default – Once activated, when the mounting plate is
removed, the optical tamper will open the circuit between Tamper#1 and Tamper#2
reader control lines. Tamper#1 and Tamper#2 control lines are interchangeable. Either of
these lines can be connected with the reader ground line to reduce the number of cable
cores required in the reader cable. The tamper control lines can operate within 0-12 VDC
and 0-100 mA.
Configuration – The reader can be modified to meet the specific requirements of an
installation. Configuration options include; audio visual, and CSN outputs. See the HID
Reader Manager™ solution on www.hidglobal.com for further details.
PIGTAIL DESCRIPTION
Yellow Beeper Input
Orange LED Input (GRN)
Black Ground (RTN)
Red +VDC
Drain Unused
Violet *Tamper #1
Violet/White *Tamper #2
White Wiegand Data 1
Green Wiegand Data 0
* Tamper Output. When activated or when the
reader is unpowered, the circuit between
Tamper#1 and Tamper#2 reader control lines
will open.
Note: Wiring the reader incorrectly may
permanently damage the reader.
www.hidglobal.com/PLT-03681
Scan the QR code or visit the link to
see the multi-language electronic
version of this document.
Lisez le code QR ou suivez le lien
pour consulter la version française de
ce document.
Escanee el código QR o visite el
vínculo para consultar la versión en
Español de este documento.
Scannen Sie den QR-Code oder
öffnen Sie den Link für die deutsche
Version dieses Dokuments.
Faça a leitura do código QR ou acesse
o link da versão em português deste
documento.
Scansiona il codice QR o visita il
link della versione Italiana di questo
documento.
Отсканируйте QR-код или пройдите по
ссылке, чтобы получить версию этого
документа на русском языке.
扫描 QR 码或访问此 文档的中文版本的
链接。
この文書の日本語版を表示するには、QR
コードをスキャンするか、リンクを クリ
ックします。
QR 코드를 스캔하거나 링크를 방문하면 이
문서의 한국어 버전을 볼 수 있습니다.
Turn on the power.
The reader should beep and the
light bar should flash.
1
3
2
4
9"
(0.23m)
© 2018 HID Global Corporation/ASSA ABLOY AB. All rights reserved.
HID, the HID Brick logo, the Chain Design, HID Reader Manager,
HID Mobile Access, and iCLASS SE are trademarks or registered
trademarks of HID Global, ASSA ABLOY AB, or its aliate(s) in the
US and other countries and may not be used without permission. All
other trademarks, service marks, and product or service names are
trademarks or registered trademarks of their respective owners.
Supplied parts
iCLASS SE R10 Reader (1)
Installation Guide (1)
0.138-20 x 1.5" screws (2) – for installing the
reader directly to a wall (no junction box)
0.138-32 x 0.375" screws (3) – for Imperial
(US) junction box installation (2) and
attaching the reader to the back plate (1)
M3.5 x 12mm screws (2) – for Metric (EU etc)
junction box installation
0.138-32 x 0.375" security screw (1) –
alternative security screw for attaching the
reader to the back plate
Recommended parts (not supplied)
Cable, 5-9 conductor (Wiegand or
Clock-and-Data)
Certified DC power supply
Metal or plastic junction box
Security tool HID 04-0001-03 (for anti-
tamper screw)
Drill with various bits for mounting hardware
Mounting hardware
Reader spacer (PN: 6132AKB) when
mounting on or near metal or metal junction
boxes - see How to Order Guide
IP65 Mounting gasket (PN: IP65GSKT-R10,
10 pcs per kit), recommended for outdoor
installation
Junction box
INSTALLATION GUIDE
iCLASS SE® Reader
13.56 MHz / 2.4 GHz Contactless
R10 PLT-03314, Rev. A.1
1. Align the top of the reader with the top of the backplate.
2. Hook the top of the reader on the top of the backplate.
3. Align the bottom of reader with the bottom of the backplate.
4. Secure the reader to the backplate using one of the supplied screws:
Security/non-tamper screw: 0.138-32 x 0.375" screw (supplied)
Non-security/standard screw: 0.138-32 x 0.375" screw (supplied)
ATTENTION
Observe precautions for handling
ELECTROSTATIC SENSITIVE DEVICES
1 Mount the backplate
Test the reader with a card.
The reader should beep and the
light bar should flash.
For Imperial (US):
Use supplied 0.138-32 x 0.375" screws
For Metric (EU etc):
Use supplied M3.5 x 12mm screws
Use supplied 0.138-20 x 1.5" screws
Junction box (not supplied)
Mud ring required to mount on single
gang junction box (not supplied)
Mounting directly to the wall/
mullion mount
Mounting to a junction box
11
22
Optional gasket
HID Global
15 Equipment
8T2 9
ACC Control READER
General Signaling
Equipment
E4662 ABCD12345678
Brazil
Condomínio Business Center
Av. Ermano Marchetti, 1435
Galpão A2 - CEP 05038-001
Lapa - São Paulo / SP
Brazil
Phone: +55 11 5514-7100
Asia Pacific
19/F 625 King's Road
North Point, Island East
Hong Kong
Support: 852-3160-9833
Fax: 852-3160-4809
Americas & Corporate
611 Center Ridge Drive
Austin, TX 78758
USA
Support: 866-607-7339
Fax: 949-732-2120
Europe, Middle East & Africa
Phoenix Road
Haverhill, Suolk CB9 7AE
United Kingdom
Support: 44 (0) 1440 711 822
Fax: 44 (0) 1440 714 840
hidglobal.com An ASSA ABLOY Group brand
PLT-03314, Rev. A.1
Korean KCC
R10F
항목 규격
송신주파수 RFID:13.56 MHz, BLE 2.4 -2.48GHz
수신주파수 RFID:13.56 MHz, BLE 2.4 -2.48GHz
출력 RFID: 10m에서
47.544mv이하
전원 DC 12.0V
전파형식 A1D
발진방식 X-tal
변조방식 RFID: ASK, NFC: GFSK
Russia EAC
Дата изготовления указана на маркировке оборудования
Представитель в Российской Федерации
Название ООО «Дофин»
Адрес 140573, РФ, Московская обл., Озерский район, с. Бояркино
Контактное лицо Л.Н. Голубова
Телефон +7 495 223 6008
e-mail [email protected]
Japan MIC
“ この装置は総務省の型式指定を受けています。”
(総務省指定番号は第AC-xxxxx号です)
本製品は電波を使用したRFID 機器の読み取り・書き込み装置です。
そのため使用する用途・場所によっては、医療機器に影響を与える恐れがあります
Japan Giteki for BLE
xxx-xxxxxx
R
Israel
השימוש במכשיר הינו על בסיס ״משני״ ופטור מרשיון הפעלה אלחוטי.
רק ״בפעולת בזק״ לשימוש עצמי של הלקוח בלבד, הלקוח פטור מרשיון הפעלה אלחוטי.
אסור להחליף את האנטנה המקורית של המכשיר, ולא לעשות בו כל שינוי טכני אחר.
Brazil
Compliance Statement
Este produto está homologado pela ANATEL, de acordo com os procedimentos regulamentados pela
Resolução 242/2000, e atende aos requisitos técnicos aplicados. Para maiores informações, consulte o
site da ANATEL - www.anatel.gov.br
This product is homologated at ANATEL according to procedure regulated by Resolution 242/2000, and
it complies with the applicable technical requirements. For more information, consult ANATEL website -
www.anatel.gov.br
RF Warning Statement
Per Article 6 of Resolution 506, equipment of restricted radiation must carry the following statement in a
visible location:
Este equipamento opera em caráter secundário, isto é, não tem direito a proteção contra interferência
prejudicial, mesmo de estações do mesmo tipo, e não pode causar interferência a sistemas operando em
caráter primário.
This equipment operates in secondary character, meaning it does not have the right of protection against
harmful interference, even against those the same character, and it cannot cause any interference to
systems operating in the primary character.
HHHHH-AA-FFFFF
UAE Singapore Indonesia
TRA
REGISTERED NO:
nnnnnnn
DEALER NO:
DA37204/14
Complies with
IDA Standards
DA123456*
(Certificate Number)
(PLG ID Number)
South Africa Australia and New Zealand
TA XXXX-YYYY
APPROVED
E4662
Specifications
INPUT VOLTAGE (VDC) 12 VDC
CURRENT
STANDBY AVG146 mA
MAX AVG260 mA
PEAK 250 mA
OPERATING TEMPERATURE -30° F to 150° F
(-35° C to 66° C)
CABLE LENGTH4Communication Lines (Wiegand)
22 AWG: 500 ft (152 m)
REGULATORY REF NUMBER R10FKNN
FREQUENCY BLE: 2.4 - 2.480 GHz, HF: 13.56 MHz
FCC & IC IDS FCC-ID: JQ6-iCLASSR10F, IC-ID: 2236B-ICLASSR10F
1
 Standby AVG - RMS current draw without a card in the RF field.
2
 Maximum AVG - RMS current draw during continuous card reads. Not evaluated by UL.
3
 Peak - highest instantaneous current draw during RF communication.
4
 Wiegand Cable Lengths: 500 ft (152 m) 22 AWG @ STANDBY AVG 46 mA, MAX AVG 62.5 mA, PEAK 250 mA
Regulatory
UL
Connect only to a Listed Access Control / Burglary power-limited power supply. These readers are
intended to be used with listed (UL294) control equipment. Suitable for outdoor use.
Only Wiegand and Bluetooth communications have been evaluated by UL.
iCLASS SE readers are compatible with HID Mobile Access® version 3.0.0 and later using mobile devices
with BLE version 4.2 and later listed at:
https://www.hidglobal.com/mobile-access-compatible-devices.
Install in accordance with NFPA70 (NEC) Local Codes, and authorities having jurisdiction. Follow all
National and Local Codes.
UL 294 Performance Levels
Model #
Access Control
Line Security
Level
Destructive
Attack Level
Endurance
Level
Stand-by
Power Level Conditions
R10F Level I Level I Level IV Level I
FCC
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
CAUTION: Any changes or modifications to this device not explicitly approved by the manufacturer could
void your authority to operate this equipment.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant
to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
Consult the dealer or an experienced radio/TV technician for help.
Canada Radio Certification
This device complies with Industry Canada license-exempt RSS standard(s). Operation is subject to the
following two conditions: (1) this device may not cause interference, and (2) this device must accept any
interference, including interference that may cause undesired operation of the device.
Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils radio exempts de
licence. L’exploitation est autorisée aux deux conditions suivantes : (1) l’appareil ne doit pas produire de
brouillage, et (2) l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique subi, même si le
brouillage est susceptible d’en compromettre le fonctionnement.
CE Marking
HID Global hereby declares that these proximity readers are in compliance with the essential requirements
and other relevant provisions of Directive 2014/53/EU.
Por el presente, HID Global declara que estos lectores de proximidad cumplen con los requisitos esenciales
y otras disposiciones relevantes de la Directiva 2014/53/EU.
HID Global déclare par la présente que ces lecteurs à proximité sont conformes aux exigences essentielles
et aux autres stipulations pertinentes de la Directive 2014/53/EU.
A HID Global, por meio deste, declara que estes leitores de proximidade estão em conformidade com as
exigências essenciais e outras condições da diretiva 2014/53/EU.
HID Global bestätigt hiermit, dass die Leser die wesentlichen Anforderungen und anderen relevanten
Bestimmungen der Richtlinie 2014/53/EU erfüllen.
HID Global dichiara che i lettori di prossimità sono conformi ai requisiti essenziali e ad altre misure rilevanti
come previsto dalla Direttiva europea 2014/53/EU.
Download copies of the Radio Equipment Directive (RED) Declaration of Conformity (DoC) at: http://www.
hidglobal.com/certifications
Taiwan
According to “Administrative Regulations on Low Power Radio Waves Radiated Devices” Without
permission granted by the NCC, any company, enterprise, or user is not allowed to change frequency,
enhance transmitting power or alter original characteristic as well as performance to an approved
low power radio-frequency device. The low power radio-frequency devices shall not influence aircraft
security and interfere legal communications; If found, the user shall cease operating immediately until
no interference is achieved. The said legal communications means radio communications is operated in
compliance with the Telecommunications Act. The low power radio-frequency devices must be susceptible
with the interference from legal communications or ISM radio wave radiated devices.

Other HID Card Reader manuals

HID iCLASS SE U90 Series User manual

HID

HID iCLASS SE U90 Series User manual

HID iCLASS RK40 User manual

HID

HID iCLASS RK40 User manual

HID ProxPoint Manual

HID

HID ProxPoint Manual

HID iCLASS bio500 User manual

HID

HID iCLASS bio500 User manual

HID iCLASS SE User manual

HID

HID iCLASS SE User manual

HID Technology Solutions 1060 User manual

HID

HID Technology Solutions 1060 User manual

HID MiniProx 5365 User manual

HID

HID MiniProx 5365 User manual

HID EdgeReader User manual

HID

HID EdgeReader User manual

HID ProxPro II Reader User manual

HID

HID ProxPro II Reader User manual

HID iCLASS SE User manual

HID

HID iCLASS SE User manual

HID iCLASS R90 Manual

HID

HID iCLASS R90 Manual

HID OMNIKEY 2061 User manual

HID

HID OMNIKEY 2061 User manual

HID iCLASS RK40 User manual

HID

HID iCLASS RK40 User manual

HID iCLASS R10 User manual

HID

HID iCLASS R10 User manual

HID MaxiProx DFM Reader - 5375 User manual

HID

HID MaxiProx DFM Reader - 5375 User manual

HID SmartID SK10 User manual

HID

HID SmartID SK10 User manual

HID iCLASS SE Express R10 User manual

HID

HID iCLASS SE Express R10 User manual

HID iCLASS SE R10EB User manual

HID

HID iCLASS SE R10EB User manual

HID ProxPro II 5455 User manual

HID

HID ProxPro II 5455 User manual

HID Mercury MR62e User manual

HID

HID Mercury MR62e User manual

HID iCLASS R10 User manual

HID

HID iCLASS R10 User manual

HID iCLASS SE Biometric Reader User manual

HID

HID iCLASS SE Biometric Reader User manual

HID ProxPoint Plus User manual

HID

HID ProxPoint Plus User manual

HID Miniprox User manual

HID

HID Miniprox User manual

Popular Card Reader manuals by other brands

Hama 34634 Quick reference guide

Hama

Hama 34634 Quick reference guide

Konig CMP-SMARTRW10 manual

Konig

Konig CMP-SMARTRW10 manual

Magtek IntelliStripe 60 Technical reference manual

Magtek

Magtek IntelliStripe 60 Technical reference manual

STYL SR272A Hardware user manual

STYL

STYL SR272A Hardware user manual

Logic Controls MR1000 installation guide

Logic Controls

Logic Controls MR1000 installation guide

ACS ACR30 Reference manual

ACS

ACS ACR30 Reference manual

Atech Flash Technology XM-28U user guide

Atech Flash Technology

Atech Flash Technology XM-28U user guide

SpringCard FunkyGate-DW NFC installation guide

SpringCard

SpringCard FunkyGate-DW NFC installation guide

Tricubes sekure 2 user guide

Tricubes

Tricubes sekure 2 user guide

Dynex DX-CR212 Guía del usuario

Dynex

Dynex DX-CR212 Guía del usuario

NCR 9700-0006-7761 Kit instructions

NCR

NCR 9700-0006-7761 Kit instructions

Advanced Card ACR89U-A2 Technical specifications

Advanced Card

Advanced Card ACR89U-A2 Technical specifications

Gallagher T11 Installation note

Gallagher

Gallagher T11 Installation note

Stid SPECTRE UHF EXTREM SLE-W52-A-U04 INSTALLATION PROCEDURE

Stid

Stid SPECTRE UHF EXTREM SLE-W52-A-U04 INSTALLATION PROCEDURE

Renkforce 1095090 operating instructions

Renkforce

Renkforce 1095090 operating instructions

Cardax Prox Plus Mifare Installation notes

Cardax

Cardax Prox Plus Mifare Installation notes

Nortech SP1 instructions

Nortech

Nortech SP1 instructions

Amano OPUS-4000 Series instruction manual

Amano

Amano OPUS-4000 Series instruction manual

manuals.online logo
manuals.online logoBrands
  • About & Mission
  • Contact us
  • Privacy Policy
  • Terms and Conditions

Copyright 2025 Manuals.Online. All Rights Reserved.
