HIK VISION DS-TDSB00-EKT User manual

Fall Detection Radar
Integration Solution

Table of Contents
1Product introduction........................................................................................2
1.1 Product List ..................................................................................................................... 2
1.2 Application Scenarios...................................................................................................... 3
2Fall Detection Radar Configuration...............................................................3
2.1 Radar Installation ............................................................................................................3
2.2 Radar parameter settings ............................................................................................... 4
2.3 Radar network configuration ..........................................................................................8
2.4 Firmware upgrade......................................................................................................... 10
2.4.1 WIFI firmware upgrade .......................................................................................... 10
2.4.2 Radar firmware upgrade ........................................................................................12
3Integration Method ........................................................................................15
3.1 OTAP SDK....................................................................................................................... 15
3.1.1 How to use SDK demo to test radar....................................................................... 15
3.1.2 Source code of SDK demo......................................................................................23
4Fall detection alarm........................................................................................25
4.1 OTAP SDK Integration.................................................................................................... 25
4.2 Example of the fall detection data................................................................................ 30
1 Product introduction
1.1 Product List
Radar model: DS-TDSB00-EKT
Firmware version: total-603-wifi-10(3.4)-v3.0.2-af167aa8-side-b36-e2ff781-v3.0.1.bin

Configuration tool: IRS60-3 Fall Detection Tool V3.0.3
firmware and configuration tool：
https://one.hikvision.com/#/link/4HQuwNxg0OhGeGvzPflY 提取密码：hpne
OTAP SDK package：
https://one.hikvision.com/#/link/zjVtFXvPPBYrpjaBWgnf 提取密码：PxeJ
1.2 Application Scenarios
Fall detection radar can be applied to private spaces, such as shower rooms, rest rooms and bed
rooms. It can also be used in elderly care, home, community, and other fields to promptly alarm when
it detects falls and reduce personal injury.
Bed room rest room
2Fall Detection Radar Configuration
Before integration, we need to install radar according to the installation requirement.
2.1 Radar Installation
Please follow below steps to install the radar.
Choose a wall with no obstructions in front.
The radar is installed at a height of 2m and the detection area is centered horizontally
The rear of the radar panel is close to the wall. Ensure that the front of the radar panel is
tilted down by 45°.

There is an upward arrow on the panel perpendicular to the horizontal line.
2.2 Radar parameter settings
Please follow below steps to configure radar.
Step1 turn on the radar and connect your computer to the radar AP hotspot.
SSID format: IRS60_xxxx
Default password: abcd1234
Step2 run the configuration tool.

Step3 Press F2 button on your computer to connect radar by IRS60-3 Fall Detection V3.0.3 tool.
Step4 input IP and port to start to connect radar. Just use the default IP and port.
IP Adress: 192.168.4.1

Port: 6666
Once the tool connect to the radar successfully, you can see the WIFI version and other
information.

Step5 press 1 or click “x” to close network configuraion.

2.3 Radar network configuration
In order to connect to OTAP SDK by the radar, we also need to configure IP and port of the
computer that run OTAP SDK.
Step 1 Press F2 button on your computer to connect radar by IRS60-3 Fall Detection V3.0.1 tool
to set below parameters.
a)Work Mode: 3
b) Enter STA information according to the actual WIFI network situation.

c) Enter net information of your server in the same WIFI network with above AP (Router).
Device ID: 1~999999999
data report type : 0
service IP : IP computer that run OTAP SDK for receiving data.
service PORT : port of the computer that run OTAP SDK for receiving data.
radar debug PORT: 6666
radar Passthrough data PORT: 20000

2.4 Firmware upgrade
In this part, we need to upgrade WIFI and radar firmware. We need to use the above
configuration tool.
2.4.1 WIFI firmware upgrade
Connect to the radar AP hotspot by configuration tool. Follow below steps to upgrade the WIFI
firmware.
Step1 press F1 to start application upgrade.

Step2 Connect to the radar.
Step3 Choose the WIFI firmware file and set mode to Auto
Step4 start to upgrade.

2.4.2 Radar firmware upgrade
Connect to the radar AP hotspot by configuration tool. Follow below steps to upgrade the WIFI
firmware.
Step1 press F1 to start application upgrade.
Step2 Connect to the radar.

Step3 Choose the WIFI firmware file and set mode to Auto.
Step4 start to upgrade.

Step5 set radar mode to OTAP and reboot the radar.

3Integration Method
Currently, we provide OTAP SDK for integration of fall detection radar.
3.1 OTAP SDK
OTAP stands for Open Things Access Protocol. OTAP SDK is a software development kit
encapsulated on OTAP, which provides APIs, components, and library files for the third-party
platform to connect with devices, such as network cameras, network speed domes, DVRs (Digital
Video Recorders), NVRs (Network Video Recorders), mobile devices, security control devices,
access control devices, decoders, and so on.
Please read the OTAP SDK user manual from OTAP SDK package.
3.1.1 How to use SDK demo to test radar
In the OTAP SDK package, you can find OTAP SDK demo to test fall detection radar.
Step 1 run OTAP SDK demo in the SDK package.
Step2 select language as English.

Step3 Select CMS Type as “LBS+DAS”. Input LocalIP, Port, DAS IP and DAS Port to start receive
data from radar. In this case, we will use the same port for Port and DAS Port.

Note:
DAS IP, DAS Port and Port must be the same to the service IP and service PORT that configured on
the tool in Chapter 2.3 of this document. If you have multiple network interface on your
computer, you can leave LocalIP to 0.0.0.0.
Please make sure the port is available on your computer.
Step3 wait for the radar to register to the SDK demo.
Once the radar register to the OTAP SDK, you can see the device under the device tree on SDK
demo.

Step4 input OTAP key. The default OTAP key of the radar is 123456

Once the radar register success fully, we can see channel information on OTAP SDK.

Step5 Subscribe fall detection alarm from radar.
Start to subscribe the radar alarm.
