Symbol Convenons
The symbols that may be found in this document are dened as follows.
Symbol Descripon
Danger
Indicates a hazardous situaon which, if not avoided, will or could
result in death or serious injury.
Cauon
Indicates a potenally hazardous situaon which, if not avoided, could
result in equipment damage, data loss, performance degradaon, or
unexpected results.
Note Provides addional informaon to emphasize or supplement
important points of the main text.
Security Radar User Manual
ii

Contents
Chapter 1 Access to Client Soware/Web Client ......................................................................... 1
Chapter 2 Acvaon ................................................................................................................... 2
2.1 Acvate Device via Client Soware ........................................................................................ 2
2.2 Acvate via SADP ................................................................................................................... 2
2.3 Acvate Device via Web Browser .......................................................................................... 4
Chapter 3 Wired Network Sengs .............................................................................................. 5
Chapter 4 Radar Sengs ............................................................................................................ 6
4.1 Add Map ................................................................................................................................ 6
4.2 Add the Radar to the Map ..................................................................................................... 7
4.3 Add Radar Zone ..................................................................................................................... 9
4.4 Add Trigger Line ................................................................................................................... 12
4.5 Other Auxiliary Funcons .................................................................................................... 13
Chapter 5 Camera Linkage Sengs ........................................................................................... 15
5.1 Set Speed Dome Inial Posion ........................................................................................... 15
5.2 Link the Camera to the radar ............................................................................................... 16
5.3 Link the Camera to the Zone ................................................................................................ 17
5.4 Enable Alarm Triggered Pop-up Image ................................................................................. 18
5.5 Calibrate Camera .................................................................................................................. 20
5.5.1 One Point Calibraon .................................................................................................. 24
5.5.2 Mulpoint Calibraon ................................................................................................. 27
5.6 Enable Camera Tracking ....................................................................................................... 29
5.7 Set Park Funcon for Linked Camera ................................................................................... 30
Chapter 6 Set Record and Storage Sengs ................................................................................ 32
6.1 Set Storage Sengs ............................................................................................................. 32
6.1.1 Set Storage Schedule via Storage Server ..................................................................... 32
6.1.2 Set Storage Schedule via NVR ..................................................................................... 33
Security Radar User Manual
iii

6.1.3 Set Tracking Strategy ................................................................................................... 33
Chapter 7 Alarm Sengs .......................................................................................................... 34
7.1 Alarm Center ........................................................................................................................ 34
7.2 Nocaon Push .................................................................................................................. 34
7.3 Set Zone ............................................................................................................................... 35
7.4 Set Alarm Output ................................................................................................................. 36
7.5 Set Trigger Line ..................................................................................................................... 37
7.6 Set Arming/Disarming Schedule .......................................................................................... 37
7.7 Set Moon Speed ................................................................................................................ 38
7.8 Video Tracking Switch Sengs ............................................................................................. 38
Chapter 8 Set Radar Advanced Funcon ................................................................................... 39
8.1 Set Master-slave Tracking Sengs ....................................................................................... 39
8.2 Set Detecon Angle and Range ............................................................................................ 39
8.3 Set Scene Mode and Sensivity ........................................................................................... 40
8.4 Set Frequency Range Sengs .............................................................................................. 41
Chapter 9 View Alarm Informaon ........................................................................................... 42
Chapter 10 System Management .............................................................................................. 43
10.1 Set Time ............................................................................................................................. 43
10.2 Manage User ...................................................................................................................... 43
10.3 System Maintenance .......................................................................................................... 44
10.4 View Device Informaon .................................................................................................... 45
10.5 Search Log .......................................................................................................................... 45
10.6 Enabling Remote Debugging .............................................................................................. 45
Appendix A. Radar Mounng Height Recommendaon ............................................................ 46
Appendix B. Formang Descripon ......................................................................................... 47
Appendix C. Indicator Descripon ............................................................................................ 48
Appendix D. FAQ ...................................................................................................................... 49
D.1 How to Achieve an Opmum Detecon Range? ................................................................. 49
Security Radar User Manual
iv

D.2 How to Solve the Problem that the Radar is not Shown in the Device List on the Radar
Page? ......................................................................................................................................... 49
D.3 How to Adjust the Sensivity to Avoid False Alarm? ........................................................... 49
D.4 How to Raise the Precision of Camera Tracking? ................................................................. 50
D.5 How to Solve the Problem that No Reference Point is on the Frame While Seng the Speed
Dome Inial Posion? ................................................................................................................ 50
D.6 What is the Reason that Failed to Draw a Zone Automacally? .......................................... 52
D.7 What Makes a Failed Arming? ............................................................................................. 52
D.8 Why Is It Required to Remove Reecve Objects from the Radar Area? ............................ 52
D.9 Why Is the Camera Unable to Track the Target? .................................................................. 52
D.10 Common Mistakes of Calibrang Camera ......................................................................... 52
Security Radar User Manual
v

Chapter 1 Access to Client Soware/Web Client
You can login the Client Soware or the web client to congure the device's parameters. You can
also congure the radar's network parameters, alarm, permission, system, log search via the web
client.
Note
You should acvate the device the rst me you access it to the network for safety reasons. For
details, see Device Acvaon.
Access to Client Soware
Download and install the iVMS-4200 client soware. Register to the soware and add device in
Control Panel → Device Management → Device for Management .
Note
• You should set the device port No. as 80.
• The user name and password when adding device are the acvaon user name and password.
Aer the device is completely added, click Remote Conguraon to enter the device conguraon
page. You can congure the device parameters in this page.
Access to Web Client
Aer the device is connected to the network, you can search the device IP address via the
iVMS-4200 client soware and the SADP soware. Input the searched IP address in the address bar
in the web page and press Enter. Use the acvaon user name and password to login. You can
congure the device parameters in the web page.
Security Radar User Manual
1

Chapter 2 Acvaon
In order to protect personal security and privacy and improve the network security level, you
should acvate the device the rst me you connect the device to a network.
2.1 Acvate Device via Client Soware
Before You Start
• Get the iVMS-4200 client soware from the supplied disk or the ocial website hp://
www.hikvision.com/en/ . Install the soware by following the prompts.
• The device and the PC that runs the soware should be in the same subnet.
Steps
1. Run the client soware.
2. Enter Device Management or Online Device.
3. Check the device status from the device list, and select an inacve device.
4. Click Acvate.
5. Create and conrm the admin password of the device.
Cauon
STRONG PASSWORD RECOMMENDED-We highly recommend you create a strong password of
your own choosing (using a minimum of 8 characters, including upper case leers, lower case
leers, numbers, and special characters) in order to increase the security of your product. And
we recommend you reset your password regularly, especially in the high security system,
reseng the password monthly or weekly can beer protect your product.
6. Click OK to start acvaon.
Device status will change to Acve aer successful acvaon.
7. Edit IP address of the device.
1) Select a device and click Modify Nenfo at Online Device.
2) Change the device IP address to the same subnet with your computer by either modifying
the IP address manually or checking DHCP.
3) Input the admin password of the device and click OK to complete modicaon.
2.2 Acvate via SADP
SADP is a tool to detect, acvate and modify the IP address of the device over the LAN.
Security Radar User Manual
2

Before You Start
• Get the SADP soware from the supplied disk or the ocial website hp://
www.hikvision.com/en/ , and install the SADP according to the prompts.
• The device and the PC that runs the SADP tool should be within the same subnet.
The following steps show how to acvate a device and modify its IP address. For batch acvaon
and IP addresses modicaon, refer to User Manual of SADP for details.
Steps
1. Run the SADP soware and search the online devices.
2. Find and select your device in online device list.
3. Input new password (admin password) and conrm the password.
Cauon
STRONG PASSWORD RECOMMENDED-We highly recommend you create a strong password of
your own choosing (using a minimum of 8 characters, including upper case leers, lower case
leers, numbers, and special characters) in order to increase the security of your product. And
we recommend you reset your password regularly, especially in the high security system,
reseng the password monthly or weekly can beer protect your product.
4. Click Acvate to start acvaon.
Status of the device becomes Acve aer successful acvaon.
5. Modify IP address of the device.
1) Select the device.
2) Change the device IP address to the same subnet as your computer by either modifying the
IP address manually or checking Enable DHCP.
3) Input the admin password and click Modify to acvate your IP address modicaon.
Security Radar User Manual
3

2.3 Acvate Device via Web Browser
Use web browser to acvate the device. Use SADP soware or PC client to search the online device
to get the IP address of the device, and acvate the device on the web page.
Before You Start
Make sure your device and your PC connect to the same LAN.
Steps
1. Open a web browser and input the IP address of the device.
Note
If you connect the device with the PC directly, you need to change the IP address of your PC to
the same subnet as the device. The default IP address of the device is 192.0.0.64.
2. Create and conrm the admin password.
Cauon
STRONG PASSWORD RECOMMENDED-We highly recommend you create a strong password of
your own choosing (using a minimum of 8 characters, including upper case leers, lower case
leers, numbers, and special characters) in order to increase the security of your product. And
we recommend you reset your password regularly, especially in the high security system,
reseng the password monthly or weekly can beer protect your product.
3. Click OK to complete acvaon.
4. Edit IP address of the device.
1) Enter IP address modicaon page.
2) Change IP address.
3) Save the sengs.
Security Radar User Manual
4

Chapter 3 Wired Network Sengs
You can set the device IP address and other network parameters.
Steps
Note
Funcons varied depending on the model of the device.
1. In the client soware, enter Device Management page.
2. Select the device in the Device for Management list, click Remote Conguraon.
3. Click Communicaon Parameters → Wired Network Sengs to enter the page.
Figure 3-1 Wired Network Sengs Page
4. Set the parameters.
-Automac Sengs: Enable DHCP and set the HTTP port.
-Manual Sengs: Disabled DHCP and set IP Address, Subnet Mask, Gateway Address, DNS
Server Address.
Note
By default, the HTTP port is 80, which is not editable.
5. Oponal: Set correct DNS server address if the device needs to visit Hik-Connect server via a
domain name.
6. Set correct DNS server address if the device needs to visit server via a domain name.
7. Click Save.
Security Radar User Manual
5

Chapter 4 Radar Sengs
You can add zones, and set camera tracking parameters for the radar in the Radar module of the
client soware.
Click Control Panel → Modules Customizaon , check Radar, and click OK.
4.1 Add Map
Steps
1. Click Control Panel → Radar to enter the radar page.
2. Click Select Picture to load a map.
Note
Supported picture formats: jpg/png/bmp.
Figure 4-1 Add a Map
3. Click OK.
Note
Aer the addion is complete, a prompt will pop up: You need to set the plong scale.
Connue?
4. Click OK in the popup window, or click ... → Edit The Scale to enter the page.
Security Radar User Manual
6

Note
Edit the scale will remove all radars on the map.
5. Click on the map to draw a straight line, select the end posion and click again to complete the
drawing.
6. Enter the actual distance between two points.
Note
The gray word is the predicted distance range of system, for reference only.
Figure 4-2 Edit Plong Scale
7. Click Save.
4.2 Add the Radar to the Map
Aer adding the map, you need to add a radar to the map for seng radar zones.
Before You Start
Make sure that you have added the radar (when adding the device, check Export to Group) to the
client soware, and add the map.
Steps
1. Expand the device group in the le list, and then click and drag the radar onto the map.
Security Radar User Manual
7

Figure 4-3 Add the Radar to the Map
2. Adjust the radar posion. Drag the radar to change the posion, and rotate and drag on
the arc side of the fan to rotate the direcon of the radar detecon area.
Note
• You can click the direcon buons in the upper le corner on the map or drag the yellow
slider in the lower right corner on the map to adjust the range of displayed map, and slide the
block on the zoom in/out bar on the zoom control strip on the le side of the map to adjust
the size of displayed map.
• Right click on the radar area (gray sector), you can click Delete to delete the radar area, and
click Arm or Disarm to start/stop the arming mode.
3. Right click in the radar area, select pin to x the radar area. Try to ensure that the posion and
direcon of the radar on the map are consistent with the actual installaon posion and
direcon of the radar.
4. Oponal: Right click on the radar area (the fan area) to open the radar sengs menu.
Menu Descripon
Delete Delete the radar from the map.
Arm Open the arming mode of the radar detecon area.
Note
If there is a target in the warning zone when arming, a prompt will appear:
There are targets in the zone, enable mandatory arming?, and click OK to arm.
Disarm Close the arming mode of the radar dectcon area.
Pin Fix the radar on the map.
Security Radar User Manual
8

Unpin Unlock the radar locaon, and then you can move the radar detecon area
On Watch Set the camera watch point for the radar.
Note
For more informaon, see Set Park Funcon for Linked Camera .
Aer enabling the radar park mode, the main radar will control the camera to
return to the set watch point when no target appears within 10 seconds in the
radar detecon area.
4.3 Add Radar Zone
Before You Start
You need to disarm the radar before the operaon. Right-click on the radar detecon area, and
click Disarm to disarm the radar.
Steps
1. In the client soware, click Control Panel → Radar to enter the page.
2. Oponal: Check Enable Auxiliary Funcon on the upper le corner of the map. The target track
will appear on the radar detecon area. You can draw a zone with reference to the track. The
track cleared when unchecked.
3. Click … → Draw Zone Manually , and click the mouse to draw a zone on the radar detecon
area.
Figure 4-4 Draw a Zone
Security Radar User Manual
9

Note
• Adding zones is a batch operaon. If you only add zones to one radar, you need to right-click
on the remaining radar detecon zones and click Cancel.
• Zones can overlap, but the relaonship between low priority and high priority should be
sased. Priority is: Disabled Zone>Warning Zone>Early Warning Zone. That is, Early Warning
Zone can contain Warning Zone and Disabled Zone, and Warning Zone can contain Disabled
Zone.
• If the size of the displayed radar area is too small, you can slide the block on the Zoom in/out
bar on the le to adjust the size of the displayed radar area.
Figure 4-5 Overlap zones
4. Right-click to complete drawing, and the system will pop up a window. Enter the zone name,
and select Early Warning Zone, Warning Zone, or Disabled Zone as the zone type.
Figure 4-6 Zone Sengs
Security Radar User Manual
10

Note
• Early Warning Zone: When the zone is an early warning zone, target with potenal risks
entering the zone will be idened and alarmed, but the alarm track will not be stored. It is
green when the warning zone is not alarming and orange when the alarm is triggered.
• Warning Zone: When the zone is an warning zone, the target entering the zone will be
idened and alarm occurred. It is displayed in orange.
• Disabled Zone: When the zone is an disabled zone, the track of the target entering the zone
will be disabled. It is displayed in grey.
5. Click OK.
6. Oponal: Modify or delete the zone.
1) Right-click on the zone, select Edit.
2) Hovering over the edge of the zone will change the cursor to a cross, click to add a marker.
Figure 4-7 Add a Marker
3) Drag the marker to change the shape of the zone.
Figure 4-8 Drag a Marker
4) Hold to drag the zone.
Security Radar User Manual
11

Figure 4-9 Drag the Zone
5) Right-click on the zone and select Exit the sengs mode.
Note
To delete a zone, right-click the zone in the edit state and select Delete.
4.4 Add Trigger Line
You need to draw at least one trigger line for the radar detecon area and set alarm rules.
Before You Start
• The radar is added to the map.
• Right-click on the radar detecon area, and click Disarm to disarm the radar.
Steps
1. In Radar page, click … → Draw Trigger Line .
Note
You can draw trigger line for all radars on the map.
2. Draw the trigger line.
1) Click on the radar detecon area to draw a trigger line.
2) Select Le -> Right, Le <- Right or Le <-> Right in the pop-up window.
Note
•Direcon determinaon: Set the starng point as the center of the circle, the trigger line is
clockwise to the right, and counterclockwise to the le.
• Up to 4 trigger lines can be drawn.
• Alarm rules: A single arrow -> indicates that the target triggers an alarm when it crosses the
trigger line in the direcon of the arrow; a double arrow <-> indicates that the target triggers
an alarm when it crosses the trigger line in any direcon.
Security Radar User Manual
12

Figure 4-10 Draw a Trigger Line
3. Click Cancel to complete the drawing.
4. Oponal: Edit the trigger line: right-click on the trigger line.
-Trigger Line: L1: Display the name of the trigger line.
-Edit: The cursor hovering over the trigger line will becomes the palm of the hand. Hold to
move the gger line. The cursor hovering over the end of the trigger line will becomes a
cross. Click to adjust the posion of the trigger line.
Figure 4-11 Edit the Trigger Line
-Set Rule: Select the trigger rule.
-Delete: Delete the trigger line.
4.5 Other Auxiliary Funcons
Security Radar User Manual
13

Speed Dome Field of View
Note
Before using this funcon, you need to conrm that the speed dome has been calibrated and the
speed dome has an linked zone.
In Radar page, click … → Enable Speed Dome Field of View .
Aer turning on, you can see the target tracked by the currently linked speed dome.
Figure 4-12 Speed Dome Field of View
You can click ... → Disable Field of View to close the funcon.
OSD
In Radar page, click OSD → Open .
Aer turning on, the speed and distance of the target will be displayed on the radar.
Mandatory Tracking
Select the radar and click Remote Conguraon in the client soware, or enter the IP address of
the radar in the address bar of the web browser. Click Smart Rule Sengs → Video Tracking
Switch Sengs to enter the page.
Aer enabled, when you click a target track in the radar detecon area, the camera will mandatory
track the target.
Security Radar User Manual
14
