Chapter 1 Product Introduction
Introduction
Based on the 60 GHz frequency band, fall detection radar (hereinafter referred to as “device”)
adopts FMCW, MIMO, beamforming, deep learning, and other technologies. It can obtain target
information, including person location, speed, posture, etc., and can provide non-contact and non-
privacy fall detection.
Key Feature
No privacy disclosure.
High detection accuracy and low false alarm rate.
Target tracking.
Remote and non-contact posture detection.
Small size, light, and easy installation.
Specification
Refer to the table below for the device specification.
DS-TDSB00-EKT/4m Fall Detection Radar Specification
Parameters
Values
Working Frequency
60 to 64 GHz
Modulation Wave
FMCW
Frequency Span
2 GHz
Horizontal FoV
-45°to +45°
Vertical FoV
-45°to +45°
Range Resolution
0.08 m
Detection Range
0.1 to 6 m
Speed Resolution
0.10 m/s
Data Cycle
70 ms
Communication Interface
RS-485/Wi-Fi
Working Voltage
9 to 12 VDC
Working Electric Current
≤ 200 mA @ 12 VDC

Fall Detection Radar • User Manual
2
Dimension and Appearance Overview
Refer to the figures below for the device dimension and appearance overview.
Dimension (unit: mm)
Appearance
Cables Description
Refer to the table below for the cables description.
DS-TDSB00-EKT/4m Fall Detection Radar Cables Description
Consumption
< 2.4 W
Working Temperature
-40 °C to +50 °C (-40 °F to +122 °F)
No.
Color
Name
Function
1
Red
+12 V
12 VDC
2
Black
GND
Power ground
3
Green
RS-485A
RS-485 communication port
4
Blue
RS-485B
5
Yellow
OC controlled signal
VOH/VOL controller

Fall Detection Radar • User Manual
3
Installation Requirements
Install the device on the wall at a height of 2 m. Make sure that the device is centered horizontally
in the detection area and there is no obstruction in front of it. Refer to the figures below for the
device installation overview.
DS-TDSB00-EKT/4m Radar Installation Overview
6
Brown
GND
Power ground

Fall Detection Radar • User Manual
4
Chapter 2 Software Instruction
Device Connection
You can connect the device via Wi-Fi or RS-485. Enter the corresponding information according to
the different connection modes.
You can connect the radar via Wi-Fi.
Before You Start
Power on the radar (12 V).
Connect your computer to the radar AP hotspot.
SSID format: IRS60_xxxx.
Default password: abcd1234.
Use “ping” command to test if the computer is connected to the radar Wi-Fi.
1) Press the Win button and R button at the same time.
2) Enter “cmd” and click OK.
3) Enter “ping 192.168.4.1” in the command line.
Open the IRS60-3 Radar PC tool and click On/OFF.
Set the network port parameters.

Fall Detection Radar • User Manual
5
IP address: 192.168.4.1.
Port No. : 20000.
Connection Setting
Click Confirm.
You can connect the radar via the serial port.
Open the IRS60-3 Radar PC tool.
Click Connection Settings.
Select Serial Port.
Select Port.
Set BaudRate as 115200, Stop bit as 1, and Data bit as 8. No parity.
Click Confirm.
Parameter Settings
Click Parameter Settings to view the radar firmware version and set the delay time and the radar
detection area.

Fall Detection Radar • User Manual
6
Parameter Settings
Click Parameter Settings and click Get after SoftVersion to view the software version.
Go to Parameter Settings → Delay Time to set the delay time. If the radar detects the target
person fell and stood up within the set delay time, it will not alarm. Otherwise, it will report a
falling alarm signal.
The radar only detects falling within the range of detection boundary.

Fall Detection Radar • User Manual
7
Detection Boundary
Click Parameter Settings to set the radar status.
Enter standby mode
The radar will be standby and stop emitting electromagnetic waves. If the radar is powered
off and does not receive wakeup command after powered on again, then it will still be
standby mode.
Awake
If the radar is powered off, the awake mode will be kept after it is powered on again.
Falling Indication
When the radar detects a person, the left icon will be highlighted. When the radar detects the
target falls, the right icon will be highlighted.
Falling Indication
Upgrade
You can upgrade the firmware version.

Fall Detection Radar • User Manual
8
Open the IRS60-3 Radar PC tool.
Press F1 button on the keyboard.
Menu Page
Enter IP Address and Radar Port (IP address: 192.168.4.1; radar port: 6666).
Click Connect.
Click Browse to select the firmware to be upgraded.
Select Network Segment as the same network segment with radar and Mode as Auto.
Application Upgrade

Fall Detection Radar • User Manual
9
Click Confirm.
Click Start Update.
Upgrade
Radar Network Configuration
You can set the radar network.
Open IRS60-3 Radar PC tool.
Press F2 button on the keyboard.
Enter IP Address and Port (IP address: 192.168.4.1; port: 6666).

Fall Detection Radar • User Manual
10
Network Configuration
Click Connect.
Set Work Mode as 3.
Click Set.
Set AP (Router) SSID and AP (Router) PWD.
AP (Router) SSID means the router name. AP (Router) PWD means the router password.
Set DHCPC as 0.
Set IP, Netmask, and gateway.
Click Set.
Set AP SSID and AP PWD.

Fall Detection Radar • User Manual
11
AP SSID means the Wi-Fi name. AP PWD means the Wi-Fi password.
Set AP
Click Set.
Set Device ID as an integer (range: 1 to 999999999).

Fall Detection Radar • User Manual
12
Set Device Information
Set data report type as 0.
Set service IP as Hikcentral Pro service IP.
Set service PORT as 20000.
Set radar debug PORT as 6666.
Set radar Passthrough data PORT as 20000.
Set report interval as 1000.
Click Data Save.
Click Reboot.
