HIK VISION CSR-I Series User manual

CSR﹣IN(P)
Single Lane High- Precision Positioning and
Speed Measurement Radar
User Manual

Contents
Chapter 1 Product overview............................................................................................................................1
1. Product introduction................................................................................................................................1
2. Technical Specification ...............................................................................................................................1
3. Electrical interface.......................................................................................................................................2
a. Power supply interface................................................................................................................................2
b. Communication interface............................................................................................................................2
Chapter 2 Installation and Usage of Product...................................................................................................3
1. Common installation methods.................................................................................................................3
2. The steps of radar installation .................................................................................................................5
3. The debugging and usage of software.....................................................................................................7
Chapter 3 Radar Communication Protocol ...................................................................................................10
1. Overviews .............................................................................................................................................10
2. Set Command........................................................................................................................................10
Chapter 4 Maintenance and common fault judgment....................................................................................14
Appendix 1 The correction calculation method of the target speed..............................................................16
Appendix 2 The radar common parameters instruction ................................................................................19

-1-
Chapter 1 Product overview
1. Product introduction
The panel microwave speed measurement radar is implemented on Doppler principle, and
it is also called Doppler radar. The working principle is that the radar emits a fixed frequency
microwave signal towards a target and then receives the reflected signal. There will be a
frequency difference between the emission beam and the echo, which is called Doppler
frequency shift. We can calculate the speed of the target through the specific relationship
between this frequency shift and the speed.
CSR-IN（P）
Figure 1.1
2. Technical Specification
Antenna：Planar-type microstrip patch array antenna
Operation frequency：24.15GHz
Frequency deviation error：≤±45 MHz
Emission power：about 5mW
Operating temperature：－40℃～＋70℃
Operating humidity：5%RH～95%RH
Speed measurement range：（2 ～400）km/h
Speed measurement accuracy：±2 km/h
Response time：26ms

-2-
Rated voltage：12V DC
Rated current：0.3A
3. Electrical interface
a.Power supply interface
Table 1.1 Power Supply Interface Definition of CSR-I Radar
Color
Illustration
Remarks
Red
DC12V
Positive Terminal of Power Supply
Black
GND
Radar Earth
Attention：There is a requirement of polarity for 12V DC power supply，which cannot be connected
inversely。
b.Communication interface
Types of radar communication interface: full duplex RS232 and Half duplex RS485.
Full duplex RS232，9600bps
DB9 female
Wire color
Signal
Illustration
Remarks
2
Brown
TX
Transmission
Data is transmitted from radar to another
equipment
3
White
RX
Reception
Radar receives the data from another
equipment
5
Green
GND
Radar Earth
Signal Earth
Table 1.2 Communication Interface Definition of CSR-I Radar
Half duplex RS485，9600bps

-3-
DB9 female
Wire color
Signal
Illustration
Remarks
1
Brown
A＋
Transmission and
Reception
The positive terminal of receiving and
transmitting differential signal
2
White
B－
Transmission and
Reception
The negative terminal of receiving and
transmitting differential signal
5
Green
GND
Radar Earth
Signal Earth
Table 1.3 Communication Interface Definition of CSR-I Radar
Attention: The communication interface should be designated before leaving the factory. There
will be a specific mark on the rear cover of the radar with RS485 interface and it defaults to RS232 for
the radar without marks.
Chapter 2 Installation and Usage of Product
1. Common installation methods
a. Top loading mode
This mode is to install the radar on T-type pole, L-type ploe, gantry and so on, in order
to measure speed from the top of the target, shown in figure 2.1. It is suitable for static speed
measurement, security monitoring, traffic flow detection and so on.
Recommendation for the radar model: CSR-IN、CSR-IK、CSR-IX

-4-
Figure 2.1
b. Side loading mode
This mode is to install the radar on the roadside or law enforcement vehicles, to measure
speed from the side of the target, shown in figure 2.2.It is suitable for static speed measurement,
moving speed measurement, vehicle speed prompt cards and so on.
Recommendation for the radar model: CSR-IR, CSR-IH, CSR-IX
Figure 2.2
c. Side and top loading mode
This mode is to install the radar on the roadside high pole, to measure speed from the side
and top of the target, shown in figure 2.3.It is suitable for the occasions when the radar is not
suitable for installing on the F pole, the gantry and so on.
Recommendation for the radar model: CSR-IN, CSR-IR

-5-
Figure 2.3
2. The steps of radar installation
a. Install the cardan
Before installing the radar, we need to install cardon first.
Cardon is one of the most common methods to install the radar of CSR-I series and it is
able to be installed in the different environmental conditions after adjusting appropriately.
The installation method of cardon is very simple, and please refer to figure 2.4. The design
sketch after installation can be referred to figure 2.5.
Figure 2.4 Figure 2.5
Attention: The installation direction of radar has a very vital influence upon the speed measured.
Please confirm the validity of installation direction when installing the radar and install it according to
the direction shown in figure 2.6.

-6-
Figure 2.6
b. Adjust the installation position of radar
For the top loading mode, install the radar right above the lane and the detection direction of the radar is
towards the middle of the lane as shown in the figure 2.7. For other methods, put the radar towards the
position expected.
Figure 2.7 Figure 2.8
c. Adjust the angle of pitch
The angle of pitch of radar installation is also called installation angle as shown in the figure 2.8.
Attention: The installation angle θrefers to the included angle between radar plane
and vertical plane instead of horizontal planes.
Please adjust the angle of pitch of radar to the scheduled installation angle, referring to the
recommended installation parameters of all kinds of radar in the table 2.1.
Table 2.1 Recommended installation parameters of the radar

-7-
Types of radar
Parameter
Mode N
Mode K、
Mode X（two-lane used）
Mode X
（one lane used）
Mode R
Mode H
Installation Height
（meter）
6
6
6
6
6
6
6
6
6
-
-
-
Trigger distance
（meter）
22
21
20
18
17
16
14
13
12
-
-
-
Installation angle
（degree）
15
16
17
18
19
20
23
25
27
Side loading angle
20°～ 30°
Remarks：It’s possible to improve the efficiency of installation during installing the radar of CSR-
I series, with the help of the assistant tool such as radar laser sight, digital protractor and hand-held
grading instrument.
d. Electrical connection
Refer to “Radar electrical interface” and connect the power line and communication line.
Attention: The power supply can be only electrified after finishing connecting all the cable
and checking without error.
3. The debugging and usage of software
a. Software introduction
The radar of CSR-I series are all allocated with the debugging software TSRadar2.01. Not
only can it set the all the kinds of parameters of the radar in detail, but also control the working
conditions of radar very easily.
TSRadar2.01 debugging software is developed based on Windows operation system so that it is able to
run in the main current Windows operation system including Window 7、Windows XP and so on.
This instruction book takes an example of Windows XP to explain the debugging and usage of
TSRadar2.01 in details.
b. Usage of the debugging software
1). The surface of the software
It’s divided into “the communication setting area(1)”, “The current speed display area
(2)”, “the main display area(3)”, “the auxiliary display area(4)”. As shown in the figure 2.10:
雷
达
类

-8-
Figure 2.10
2). Serial port
Please confirm the connection between radar and the host computer is correct and select
the correct serial port first on the surface of TSRadar2.01. As shown in the figure 2.11:
Figure 2.11
Attention: If the connection port is chosen incorrectly, the debugging software cannot
receive any information.
If cannot find the port number, please follow the steps as below:
First, open the control panel, find the “System”button, and click the “device manger”button in the
hardware options. Then find the “COM&LPT”and the port number shown in it is just the radar port number.
3). Radar electrification
Monitor the moment of the radar electrification and confirm if there is power-on identification:
0xFE, 0xFD, 0xFD, 0xFE in the communication area. The radar is in the speed measurement state
and can detect the target if the above string is displayed normally.
4). Parameters setup
If needed click the button of “Enter the setup”. As Shown in the figure 2.13, in the status of
setup, the relevant parameters can be adjusted in the communication area:
1
3
2
4

-9-
Figure 2.13
For instance: if the mode of “contact terminal” is needed, click the button of “Enter the setup”
first and then choose the contact terminal, and then, click the “work mode” to confirm. Click the
“Quit the setup” in the final.
4) Mutual information
“ The main display area(3)” will provide the information of radar, communication results,
debug parameters and so on, in hexadecimal format.
5) Speed display
“The current speed display area (2)” will provide the current speed value. Please select the
“locked” button to display in advance.
Attention: Before using, you need to choose in the data formatting options on the right, which is the
auxiliary display area(4). Please ensure that it has no difference from the data formatting of the radar so
that it can show the correct speed.
6) Auxiliary display
The auxiliary display area(4) is mainly designed for assisting the main display area(3) and it
can make all the bytes displayed by decimalism in area(4) instead of by hexadecimal in
area(3),which is very convenient for users to oberserve.
You can click the ‘Help’ in the software in order to get more help information;
for the more detailed direction for usage, please refer to software manuals.

-10-
Chapter 3 Radar Communication Protocol
1. Overviews
The radar outputs FEh FDh FDh FEh after power is on and reset, and then enters the speed
measurement state. The default measurement range is between 05h and F0h (corresponding to 5～
240km/h).The parameters of radar can be set after pressing the “Enter the setup” command, which
takes the radar into the configuration state. The radar can return to the measurement state when
pressing the “Exit the setup” after parameter settings are completed.
There are three kinds of working mode:
The first is continuous mode. The radar outputs a speed data with interval of 26 milliseconds
when the target is passing through the detection area, and outputs 00h when there is no target.
The second is trigger mode. The radar outputs data only when the target is detected and has
no output if there is no target;
The third is answer mode. The radar outputs the speed data only when the host computer
sends command for request (F7h) in the speed measurement state. The ex-factory setting is
trigger mode and the speed measurement data is a single byte.
Attention: The default of this equipment is the second mode.
2. Set Command
Set Command Format
Frame header
Command
Parameter(Double byte)
Frame tail
FAh
3xh
yyh yyh
FBh
x indicates specific commands
Reply from the radar
Frame header
Length
Content
Frame tail
FAh
3xh
FBh
x indicates the number of bytes
The relevant order and response is shown as following:

-11-
1, Enter the setup: FAh 31h 30h 30h FBh
Stop sending and then reply: FAh 32h xxh 3xh FBh
Defining of xx: 30h indicates execute the command correctly,
31h indicates incorrectly. The same as the below.
3xh is flag byte, undefined.
2, Exit the setup: FAh 32h 30h 30h FBh
In the setup state, reply: FAh 32h xxh 3xh FBh, then restore the measurement state;
In the measurement state, don’t reply. The same as the below.
3, Select work mode: FAh 33h 3xh 30h FBh
Defining of x,
0: continuous mode (Ignore the trigger threshold setting, output data with 26
milliseconds interval if there is a target, else output 00h.)
1: the front trigger mode (Don’t output any data if no target and only output one data
if the target appears in detective area.)
2: the rear trigger mode (Don’t output any data if no target and only output one data if
the target appears in detective area.)
5: the responsive model
Reply from the radar: FAh 32h xxh 3xh FBh
4, Set angle Correction: FAh 35h yyh 30h FBh
Define yy as angle, the effective range is between 0 and 70 deg.
The default is 0 deg, no correction is needed.
Reply from the radar: FAh 32h xxh 3xh FBh
5, Set Sensitivity: FAh 36h yyh 30h FBh
Define yy as Sensitivity, the higher the value, the higher the threshold and the lower the
sensitivity. The effective range is between 1 and 240. The default is 20.
Reply from the radar: FAh 32h xxh 3xh FBh
6, Set directional mode: FAh 37h 3xh 30h FB (Apply to radar with direction recognition only)
Defining of x:
0: output the data in either direction, it’s default mode.
1: only output the data of target close to the radar.
2: only output the data of target away from the radar.
Reply from the radar: FAh 32h xxh 3xh FBh
7, Set data format: FAh 38h 3xh 30h FBh

-12-
Defining of x,
0: single byte, no direction and no frame format, it’s default format.
1: Double bytes, with direction and no frame, the first byte means direction--close, F9h;
away, F8h; uncertainty, F7h; The second byte means the target speed. The radar with no
direction recognition fixed outputs F7h and outputs F7h 00h with no speed in the
continuous mode.
2: ASCII, the output data are four bytes, the first byte means direction--closing, ‘ + ’,
away, ‘ - ’, uncertainty, ‘ * ’, the first byte is fixed as ‘*’ if the radar with no direction
recognition function. Output ‘ *000’ in the continuous mode.
Eg.: The speed of the target close to the radar is 125 km/h, output 2Bh 31h 32h 35h
The speed of target with uncertain direction is 89 km/h, output 2Ah 30h 38h 39h
Reply from the radar: FAh 32h xxh 3xh FBh
8, Set low-limit speed: FAh 39h yyh 30h FBh
Define yy as the speed of target, the effective range is between 1 and 150 km/h.
The default is 5.
Reply from the radar: FAh 32h xxh 3xh FBh
9, Save Current settings: FAh 3dh 31h 30h FBh
Reply from the radar: FAh 32h xxh 3xh FBh
10, Restore factory settings: FAh 3dh 32h 30h FBh
Reply from the radar: FAh 32h xxh 3xh FBh
11, Read the current settings: FAh 3dh 34h 30h FBh
Reply from the radar: FAh 3yh xxh yyh … yyh FBh
Define yy as the number of the following byte except FBh.
Define yyh … yyh as the saved parameters, their order is: work mode, TTL trigger up-limit,
angle correction, sensitivity, data format, low-limit speed, speed jump threshold, and five
reserved bytes at the end.
12, Soft reset the radar: FAh 3Eh 30h 30h FBh
Reply from the radar: FAh 32h xxh 3xh FBh
Going to reset state immediately after reply, it will not take about 1 second. After resetting, any
command will not be responded.
13, Inquire the software version: FAh 3Fh 30h 30h FBh
Reply from the radar: FAh 3xh 30h version character string(ASCII, non-tail byte 00h) FBh

-13-
Define x as the length of the character string including 00h which is the tail byte of the
character string.
Eg.: FAh 3dh 30h 6Bh 30h 31h 2dh 76h 32h 2eh 31h 30h 2eh 33h 33h FBh
Same as, k 0 1-v2.10. 3 3
14, Inquire the product serial number: FAh 3fh 32h 30h FBh
Reply: Ah 32h 31h 30h FBh if there is no product serial number or the product serial umber
is illegal.
Else reply, Ah 3dh 30h the character string of series number (ASCII, 12 byte ) FBh

-14-
Chapter 4 Maintenance and common fault judgment
The radar is the product applied to domain with high technique and high sensitivity. Please read
the direction of the product carefully before using.
1. Please use the high quality DC power supply voltage which could meet the requirements and an
independent power supply is needed to prevent crosstalk from other devices.
2. The positive side of the radar is the antenna radiating surface, so do not cover it when using.
3. Avoid shock and drop damage to the products, and prevent the product from rain,dust and lightning when
using.
4. Our company provides radar with RS232 interface and RS485 interface and they are not hot-
pluggable. Please turn off the power first to avoid accidental burns when connection .
5. RS232 and RS485 standards do not have clear and consistent rules for ports and lines sequence.
Please pay attention to their own definitions when connected between different devices.

-15-
Typical radar abnormal and self-diagnosis methods
Failure
phenomenon
General troubleshooting methods
No reaction
after
electrification
1、At the moment of electrifying the radar，please check if the serial port is able to
receive the bytes FE、FD、FD、FE. If not, please check if the line is connected
firmly, if the line sequence is correct, if the upper computer’s serial port is chosen
correctly, if the positive and negative electrode of radar power line is correct(red
is positive and black is negative), and if the radar power supply voltage(DC 12V) and
the operating current(DC about 200mA) are regular.
2、In the case of using serial converter, ensure converter works normally. Try to pull
and plug the convert again, and open the testing software to establish the
communication again.
The failure of
velocity
measurement
after
electrification
1、The radar does not work when the vehicles pass. Please check if the radar
installation angle is towards the target lane.
2、The radar works normally, but camera cannot take a photo after connecting the
camera.
①Please check if the communication line is correct
②Please check if the formatting of radar velocity is matching with the
communication protocol of camera.
③Please ensure that the camera is able to be used normally.
Picture shows
the velocity
abnormally
1、Please check if the radar is matching with the communication protocol of the camera
2、Please check if the communication line is connected firmly, if line sequence is
correct, and if it is disturbed strongly.
3、Use the dedicated pitchfork to ensure if the output of the radar is normal
Show the
velocity when
no vehicles
pass
1、Please check if the installation positions of the radar is towards the lane, and
inaccuracy may be able to lead the radar to the interference from the vehicle in the
adjacent lanes.
2、Ensure if the installing pole is shaking or there is a strong electromagnetic
interference around, and you can adjust the range of velocity measurement to shield;
Please check if the ground connection is rational.
3、Please check if there is a rotating object interference around, for example the
electric fan.

-16-
Appendix 1 The correction calculation method of the target
speed
The radar measures the radial speed of the moving target relative to the radar. The component speed
of the target is

cosv
in the beam axis of radar , where theta is formed between the radiation
direction of the radar and the moving direction of the target. The measurement of the radar is this
component speed, which is called the radial speed.
As shown in figure 5.1.
v

Figure 5.1 The angle between the beam of the radar and the direction of the moving target
In practical application, set the output speed of the radar equal to and set the actual speed
of the target equal to ,thus,

cos/
1vv 
(5.1)
Use the equation 5.1 for adjusting the speed by the users is determined by the
installation and usage condition.
2. In another practical situation, the radar needs to adjust with the position and pitch
angle.As shown in figure 5.2 .The equation is as follow,
L
ddLhv
v
v2
12
22
1)(
cossin



(5.2)

-17-
Figure 5.2 Install diagram of the radar for correcting the speed
Where
1
v
---the speed of the target(km/h)
v
---the speed output of the radar(km/h)
h
---the suspension height between the radar and the ground(m)
L
---the longitudinal distance between the center of the radiation and the
vertical pole.(m)
1
d
---the distance between the position of the radar and the vertical pole(m)
2
d
---the horizontal distance between the center of the radiation and the
vertical pole.(m)
Attention: The
1
d
in the equation 5.2 equal to 0 if the radar is installed on the
vertical pole aside the road, and the
2
d
－
1
d
equal to 0 if the radar is installed above and
faced the lane.
3. Some roads include two lanes with less traffic, so you can use the radar with direction
recognition to detect the two lanes at the same time. The installation method of the
radar is shown in figure 5.3

d22
d21
L2
L1
h
Figure 5.3 detect two lanes with one radar
In this situation, the equation (5.2) is still valid and just calculates the two lanes separately.
For the near lanes, the correction equation is as follow,

-18-
1
2
21
2
1
2
11 L
dLhv
v

(5.3)
For the far lanes, the correction equation is as follow,
2
2
22
2
2
2
12 L
dLhv
v 
(5.4)
In (5.3) and (5.4),
11
v
means the speed of the near lanes(km/h) and means the speed of
the far lanes(km/h). The meaning of
1
L
,
2
L
,
21
d
,
22
d
is shown in figure 5.3.
Users can use the above equations for a more accurate speed correction according to the
actual trigger position.
Especially, the speed correction equation approximates equation(5.1) if the height
between the radar and the ground is lower(Eg, less than 3m) and the radiation almost is
horizontal(don’t need radiate to the ground because the target has a certain height).
