Hirschmann RS20 series User manual

RM Web L2B
Release 4.2 07/08
Technical Support
[email protected]
Reference Manual
Web-based Interface
Industrial ETHERNET Switch
RS20

The naming of copyrighted trademarks in this manual, even when not specially indicated, should
not be taken to mean that these names may be considered as free in the sense of the trademark
and tradename protection law and hence that they may be freely used by anyone.
© 2008 Hirschmann Automation and Control GmbH
Manuals and software are protected by copyright. All rights reserved. The copying, reproduction,
translation, conversion into any electronic medium or machine scannable form is not permitted,
either in whole or in part. An exception is the preparation of a backup copy of the software for
your own use. For devices with embedded software, the end-user license agreement on the en-
closed CD applies.
The performance features described here are binding only if they have been expressly guaran-
teed in the contract. This publication has been created by Hirschmann Automation and Control
GmbH according to the best of our knowledge. Hirschmann reserves the right to change the con-
tents of this manual without prior notice. Hirschmann can give no guarantee in respect of the
correctness or accuracy of the details in this publication.
Hirschmann can accept no responsibility for damages, resulting from the use of the network
components or the associated operating software. In addition, we refer to the conditions of use
specified in the license contract.
Printed in Germany
Hirschmann Automation and Control GmbH
Stuttgarter Str. 45-51
72654 Neckartenzlingen
Germany
Tel.: [phone]
Rel. 4.2-01-0708 – 29.7.08

Content
RM Web L2B
Release 4.2 07/08 3
Content
Content 3
About this Manual 7
Key 9
1 Opening the Web-based Interface 11
2 Basic Settings 15
2.1 System 16
2.2 Network 20
2.3 Software 22
2.3.1 Update via file selection 22
2.3.2 tftp update 23
2.4 Port Configuration 24
2.5 Load/Save 26
2.5.1 Loading the configuration 27
2.5.2 Saving the configuration 27
2.5.3 URL 28
2.5.4 Deleting a configuration 28
2.5.5 Using the AutoConfiguration Adapter (ACA) 29
2.6 Restart 31
3 Security 33
3.1 Password / SNMP 34
3.2 SNMPv1/v2 Access Setting 36
3.3 Web Access 39
3.3.1 Description of Web access 39
4Time 41
4.1 SNTP configuration 43
4.2 PTP configuration 46
4.2.1 PTP Global (MS20/MS30, Power MICE) 46

Content
4RM Web L2B
Release 4.2 07/08
5 Switching 49
5.1 Switching Global 50
5.2 Filters for MAC addresses 51
5.3 Multicasts 53
5.3.1 Global settings 54
5.3.2 Unknown Multicasts 55
5.3.3 Known Multicasts 55
5.3.4 Settings per port (table) 56
6 QoS/Priority 59
6.1 Global 60
6.2 Port configuration 62
6.2.1 Entering the port priority 63
6.3 802.1D/p Mapping 64
6.4 IP DSCP mapping 66
7 Redundancy 69
7.1 HIPER-Ring 70
7.1.1 Configuring HIPER-Ring Version 1 71
7.1.2 Configuring HIPER-Ring Version 2 (MRP Draft) 74
8 Diagnostics 77
8.1 Event log 78
8.2 Ports 79
8.2.1 Statistics table 79
8.2.2 Utilization 80
8.2.3 SFP modules 81
8.3 Topology Discovery 83
8.4 Port Mirroring 85
8.5 Device Status 87
8.6 Signal contact 89
8.6.1 Manual setting 89
8.6.2 Function monitoring 89
8.6.3 Device status 91

Content
RM Web L2B
Release 4.2 07/08 5
8.6.4 Configuring traps 91
8.7 Alarms (Traps) 92
8.8 Report 94
8.9 Self-test 95
9 Advanced 97
9.1 DHCP Relay Agent 98
A Technical Data 101
B Reader´s comments 103
C Index 105
D Further support 107

Content
6RM Web L2B
Release 4.2 07/08

About this Manual
RM Web L2B
Release 4.2 07/08 7
About this Manual
The "Web-based Interface" reference manual contains detailed information
on using the Web interface to operate the individual functions of the device.
The "Command Line Interface" reference manual contains detailed informa-
tion on using the Command Line Interface to operate the individual functions
of the device.
The “Installation” user manual contains a device description, safety instruc-
tions, a description of the display, and all the other information that you need
to install the device before you begin with the configuration of the device.
The “Basic Configuration” user manual contains all the information you need
to start operating the device. It takes you step by step from the first startup
operation through to the basic settings for operation in your environment.
The “Redundancy Configuration” user manual contains all the information
you need to select a suitable redundancy procedure and configure it.
The Network Management Software HiVision provides you with additional
options for smooth configuration and monitoring:
XEvent logbook.
XConfiguration of „System Location“ and „System Name“.
XConfiguration of the network address range and SNMP parameters.
XSaving the configuration on the device.
XSimultaneous configuration of multiple devices.
XConfiguration of the port display color red for a connection error.

About this Manual
8RM Web L2B
Release 4.2 07/08

Key
RM Web L2B
Release 4.2 07/08 9
Key
The designations used in this manual have the following meanings:
Symbols used:
XList
Work step
Subheading
Link Indicates a cross-reference with a stored link
Note: A note emphasizes an important fact or draws your
attention to a dependency.
Courier ASCII representation in user interface
Router with firewall
Switch with firewall
Router
Switch
Bridge
Hub

Key
10 RM Web L2B
Release 4.2 07/08
A random computer
Configuration Computer
Server
PLC -
Programmable logic
controller
I/O -
Robot

Opening the Web-based Interface
RM Web L2B
Release 4.2 07/08 11
1 Opening the Web-based Inter-
face
To open the Web-based interface, you will need a Web browser (a program
that can read hypertext), for example Mozilla Firefox version 1 or later, or
Microsoft Internet Explorer version 6 or later.
Note: The Web-based interface uses the “Java™ Runtime Environment Ver-
sion 1.4.2.x, 1.5.x or 6.x” plug-in. If it is not installed on your computer yet, it
will be installed automatically via the Internet when you start the Web-based
interface for the first time. This installation is very time-consuming.
For Windows users: cancel the installation. Install the plug-in from the
enclosed CD-ROM. To do this, you go to “Additional Software”, select Java
Runtime Environment and click on “Installation”.
Figure 1: Installing Java
Start your Web browser.
Make sure that you have activated JavaScript and Java in the security
settings of your browser.

Opening the Web-based Interface
12 RM Web L2B
Release 4.2 07/08
Establish the connection by entering the IP address of the device which
you want to administer via the Web-based management in the address
field of the Web browser. Enter the address in the following form:
http://xxx.xxx.xxx.xxx
The login window appears on the screen.
Figure 2: Login window
Select the desired language.
In the drop-down menu, you select
– user, to have read access, or
– admin, to have read and write access
to the device.
The password “public”, with which you have read access, appears in the
password field. If you wish to have write access to the device, then high-
light the contents of the password field and overwrite it with the password
“private” (default setting).
Click on OK.
The Web site of the device appears on the screen.

Opening the Web-based Interface
RM Web L2B
Release 4.2 07/08 13
Note: The changes you make in the dialogs are copied to the device when
you click on “Write”. Click on “Load” to update the display.
Note: You can block your access to the device by entering an incorrect con-
figuration.
Activating the function “Cancel configuration change” in the “Load/Save”
dialog enables you to return automatically to the last configuration after a set
time period has elapsed. This gives you back your access to the device.
Figure 3: Website of the device with speech-bubble help

Opening the Web-based Interface
14 RM Web L2B
Release 4.2 07/08
The menu section displays the menu items. By placing the mouse pointer in
the menu section and clicking the right mouse button you can use “Back” to
return to a menu item you have already selected, or “Forward” to jump to a
menu item you have already selected.

Basic Settings
RM Web L2B
Release 4.2 07/08 15
2 Basic Settings
The basic settings menu contains the dialogs, displays and tables for basic
settings configuration:
XSystem
XNetwork
XSoftware
XPort configuration
XLoad/Save
XRestart

Basic Settings
16
2.1 System
RM Web L2B
Release 4.2 07/08
2.1 System
The "System submenu in the basic settings menu is structured as follows:
XDevice status
XSystem data
XDevice view
XReloading data
Figure 4: "System" submenu
Device status
This section of the website provides information on the device status and
the alarm state of the device.

Basic Settings
RM Web L2B
Release 4.2 07/08
2.1 System
17
Figure 5: Device status and alarm display
System data
This area of the website displays the system parameters of the device.
Here you can change,
– the system name,
– the location description,
– the name of the contact person for this device,
– the availability of the media modules (see fig. 6) and
– the temperature threshold values.
Name Meaning
Name System name of this device
Location Location of this device
Contact person Contact person for this device
Basic module Hardware version of the basic module
Media module 1 Hardware version of media module 1
Media module 2 Hardware version of media module 2
Media module 3 Hardware version of media module 3
Media module 4 Hardware version of media module 4
Media module 5 Hardware version of media module5
Media module 6 Hardware version of media module 6
Media module 7 Hardware version of media module 7
Power supply (P1/P2) Status of the power supply units
Operating time Time that has elapsed since the device was last restarted.
Temperature Temperature in the device. Lower/upper temperature thresh-
old values. If the temperature goes outside this range, the
device generates an alarm message.
Table 1: System data
Time of the oldest existing alarm
Cause of the oldest existing alarm
Symbol indicates the Device Status

Basic Settings
18
2.1 System
RM Web L2B
Release 4.2 07/08
Figure 6: Availability of the media modules
Device view
The device view shows the device with the current configuration. The
symbols underneath the device view represent the status of the individual
ports.
Figure 7: Device view
Module present
Empty slot
Module was removed.
Click this check mark
to define this slot as an
empty slot.

Basic Settings
RM Web L2B
Release 4.2 07/08
2.1 System
19
Meaning of the symbols:
The port (10, 100 Mbit/s, 1, 10 Gbit/s) is enabled
and the connection is OK.
The port is disabled by the management
and it has a connection.
The port is disabled by the management
and it has no connection.
The port is in autonegotiation mode.
The port is in HDX mode.
The port is in RSTP discarding mode (100 Mbit/s).
The port is in routing mode (100 Mbit/s).
Updating
This area of the website at the bottom left displays the countdown time
until the applet requests the current data of this dialog again. Clicking the
"Update" button calls the current dialog information immediately.
The applet polls the current data of the device automatically every 100
seconds.
Figure 8: Time until update

Basic Settings
20
2.2 Network
RM Web L2B
Release 4.2 07/08
2.2 Network
With the Basics:Network dialog you define the source from which the
device gets its IP parameters after starting, and you assign the IP parameters
and VLAN ID and configure the HiDiscovery access.
Figure 9: Network parameters dialog
Under "Mode", enter where the device is to obtain its IP parameters:
XIn the BOOTP mode, the configuration is via a BOOTP or DHCP serv-
er on the basis of the MAC address of the device (see page 27 „Saving
the configuration“).
XIn the DHCP mode, the configuration is via a DHCP server on the ba-
sis of the MAC address or the name of the device (see page 27 „Sav-
ing the configuration“).
XIn the local mode the net parameters in the device memory are used.
Enter the parameters on the right according to the selected mode.
