Hirschmann RSPE30 User manual

Installation RSPE30/32/35/37
Release 16 04/2019
Technical support
https://hirschmann-support.belden.com
User Manual
Installation
Industrial Ethernet Rail Switch Power
RSPE30/32/35/37

26.04.2019 Installation RSPE30/32/35/37
Release 16 04/2019
The naming of copyrighted trademarks in this manual, even when not specially indicated, should
not be taken to mean that these names may be considered as free in the sense of the trademark
and tradename protection law and hence that they may be freely used by anyone.
© 2019 Hirschmann Automation and Control GmbH
Manuals and software are protected by copyright. All rights reserved. The copying, reproduction,
translation, conversion into any electronic medium or machine scannable form is not permitted,
either in whole or in part. An exception is the preparation of a backup copy of the software for
your own use.
The performance features described here are binding only if they have been expressly agreed
when the contract was made. This document was produced by Hirschmann Automation and
Control GmbH according to the best of the company's knowledge. Hirschmann reserves the right
to change the contents of this document without prior notice. Hirschmann can give no guarantee
in respect of the correctness or accuracy of the information in this document.
Hirschmann can accept no responsibility for damages, resulting from the use of the network
components or the associated operating software. In addition, we refer to the conditions of use
specified in the license contract.
You can get the latest version of this manual on the Internet at the Hirschmann product site
(www.hirschmann.com).
Hirschmann Automation and Control GmbH
Stuttgarter Str. 45-51
72654 Neckartenzlingen
Germany

Installation RSPE30/32/35/37
Release 16 04/2019 3
Contents
Safety instructions 6
About this manual 18
Key 19
1 Description 20
1.1 General description 20
1.2 Device name and product code 21
1.3 Device views 25
1.3.1 Front view 25
1.3.2 Rear view 26
1.4 Power supply 27
1.4.1 Supply voltage with the characteristic value K9 27
1.4.2 Supply voltage with the characteristic value KK 27
1.4.3 Supply voltage with the characteristic value CC 27
1.4.4 Supply voltage with the characteristic value PP 27
1.5 Ethernet ports 28
1.5.1 10/100 Mbit/s twisted pair port 29
1.5.2 Gigabit combo port 29
1.5.3 100 Mbit/s F/O port (optional) 30
1.5.4 Support of PoE(+) 31
1.6 Display elements 32
1.6.1 Device state 32
1.6.2 Media module status 33
1.6.3 Port status 34
1.7 Management interfaces 36
1.7.1 V.24 interface (external management) 36
1.7.2 SD card interface 36
1.7.3 USB interface 37
1.8 Signal contact 37
2 Installation 38
2.1 Checking the package contents 38
2.2 Installing the SD card (optional) 38

4Installation RSPE30/32/35/37
Release 16 04/2019
2.3 Mounting a cover panel or a media module 39
2.3.1 Mounting a cover panel 39
2.3.2 Mounting a media module 39
2.4 Installing and grounding the device 39
2.4.1 Installing the device onto the DIN rail 40
2.4.2 Grounding the device 41
2.5 Installing an SFP transceiver (optional) 41
2.6 Connecting the terminal blocks 42
2.6.1 Supply voltage with the characteristic value K9 42
2.6.2 Supply voltage with the characteristic value KK 43
2.6.3 Supply voltage with the characteristic value CC 45
2.6.4 Supply voltage with the characteristic value PP 46
2.6.5 Signal contact 47
2.7 Operating the device 48
2.8 Connecting data cables 48
2.9 Filling out the inscription label 49
3 Making basic settings 50
4 Monitoring the ambient air temperature 51
5 Maintenance and service 52
6Disassembly 53
6.1 Removing the device 53
6.2 Removing an SFP transceiver (optional) 54
6.3 Removing a media module (optional) 54
7 Technical data 55
7.1 General technical data 55
7.2 Dimension drawings 59
7.3 EMC and immunity 61
7.4 Network range 64
7.5 Power consumption/power output 68
7.6 Scope of delivery, order numbers and accessories 68

Installation RSPE30/32/35/37
Release 16 04/2019 5
8 Underlying technical standards 71
A Further support 72

6Installation RSPE30/32/35/37
Release 16 04/2019
Safety instructions
General safety instructions
You operate this device with electricity. Improper usage of the device
entails the risk of physical injury or significant property damage. The
proper and safe operation of this device depends on proper handling
during transportation, proper storage and installation, and careful
operation and maintenance procedures.
Before connecting any cable, read this document, and the safety
instructions and warnings.
Operate the device with undamaged components exclusively.
The device is free of any service components. In case of a damaged
or malfunctioning device, turn off the supply voltage and return the
device to Hirschmann for inspection.
Certified usage
Use the product only for the application cases described in the
Hirschmann product information, including this manual.
Operate the product only according to the technical specifications.
See “Technical data” on page 55.
Connect to the product only components suitable for the requirements
of the specific application case.
Installation site requirements
Install the device in a fire enclosure according to EN 60950-1.
Only for device variants featuring supply voltage with characteristic
value K9 or KK:
Install this device solely in a switch cabinet or in an operating site with
restricted access, to which maintenance staff have exclusive access.
Install the device at ambient temperatures greater than +113 °F
(+45 °C) in “restricted access locations” based on EN 60950-1
exclusively.
WARNING
UNCONTROLLED MACHINE ACTIONS
To avoid uncontrolled machine actions caused by data loss, configure all
the data transmission devices individually.
Before you start any machine which is controlled via data transmission, be
sure to complete the configuration of all data transmission devices.
Failure to follow these instructions can result in death, serious injury,
or equipment damage.

Installation RSPE30/32/35/37
Release 16 04/2019 7
Device casing
Only technicians authorized by the manufacturer are permitted to open
the casing.
Never insert pointed objects (narrow screwdrivers, wires, etc.) into the
device or into the connection terminals for electric conductors. Do not
touch the connection terminals.
Keep the ventilation slits free to ensure good air circulation.
Mount the device in the vertical position.
At ambient air temperatures > 140 °F (+60 °C):
The surfaces of the device housing may become hot. Avoid touching
the device while it is operating.
Qualification requirements for personnel
Only allow qualified personnel to work on the device.
Qualified personnel have the following characteristics:
Qualified personnel are properly trained. Training as well as practical
knowledge and experience make up their qualifications. This is the
prerequisite for grounding and labeling circuits, devices, and systems
in accordance with current standards in safety technology.
Qualified personnel are aware of the dangers that exist in their work.
Qualified personnel are familiar with appropriate measures against
these hazards in order to reduce the risk for themselves and others.
Qualified personnel receive training on a regular basis.
National and international safety regulations
Verify that the electrical installation meets local or nationally applicable
safety regulations.
Grounding the device
Grounding the device is by means of a separate ground connection on the
device.
Ground the device before connecting any other cables.
Disconnect the grounding only after disconnecting all other cables.
Always ground the device via the grounding screw.
Shielding ground
The overall shield of a connected shielded twisted pair cable is connected
to the grounding connector on the front panel as a conductor.
Beware of possible short circuits when connecting a cable section with
conductive shielding braiding.
Requirements for connecting electrical wires
Before connecting the electrical wires, always verify that the
requirements listed are complied with.

8Installation RSPE30/32/35/37
Release 16 04/2019
Requirements for connecting the signal contact
Requirements for connecting the supply voltage
All of the following requirements are complied with:
The electrical wires are voltage-free.
The cables used are permitted for the temperature range of the application case.
Table 1: Requirements for connecting electrical wires
All of the following requirements are complied with:
The voltage connected complies with the requirements for a safety extra-low voltage
(SELV) as per IEC/EN 60950-1.
The connected voltage is limited by a current limitation device or a fuse.
Observe the electrical threshold values for the signal contact.
See “General technical data” on page 55.
Table 2: Requirements for connecting the signal contact
Device variant Requirements
All variants All of the following requirements are complied with:
The supply voltage corresponds to the voltage specified on the type
plate of the device.
The power supply conforms to overvoltage category I or II.
The power supply has an easily accessible disconnecting device (for
example a switch or a plug). This disconnecting device is clearly
identified. So in the case of an emergency, it is clear which
disconnecting device belongs to which power supply cable.
The cross-section of the ground conductor is the same size as or
bigger than the cross-section of the power supply cables.
Relevant for North America:
The power supply cables are suitable for ambient air temperatures of
at least 167 °F (75 °C). The power supply cable wires are made of
copper.
Table 3: Requirements for connecting the supply voltage

Installation RSPE30/32/35/37
Release 16 04/2019 9
Only for device
variants featuring
supply voltage with
the characteristic
value CC:
If you connect 2 independent power sources, verify that the minus
terminal is grounded. Failure to follow this instruction can result in
equipment damage.
The wire diameter of the power supply cable is at least 1 mm² (North
America: AWG16) on the supply voltage input.
The following requirements are alternatively complied with:
Alternative 1 The power supply complies with the requirements
for a limited power source (LPS) as per EN 60950-1.
Alternative 2 Relevant for North America:
The power supply complies with the requirements
according to NEC Class 2.
Alternative 3 All of the following requirements are complied with:
The power supply complies with the
requirements for a safety extra-low voltage
(SELV) as per IEC/EN 60950-1.
A fuse suitable for DC voltage is located in the
plus conductor of the power supply.
The minus conductor is on ground potential.
Otherwise, a fuse is also located in the minus
conductor.
Regarding the properties of this fuse:
See “General technical data” on page 55.
Device variant Requirements
Table 3: Requirements for connecting the supply voltage

10 Installation RSPE30/32/35/37
Release 16 04/2019
Supply voltage
The supply voltage is connected to the device casing through protective
elements exclusively.
For supply voltage connections with protective conductor connection:
First connect the protective conductor before connecting the wires for
the supply voltage.
Exclusively for
device variants
featuring supply
voltage with
characteristic
value PP:
If you connect 2 independent power sources, verify that the plus terminal
of the power sources is not connected to each other. Failure to follow
these instructions can result in equipment damage.
The wire diameter of the power supply cable is at least 1 mm² (North
America: AWG16) on the supply voltage input.
The following requirements are alternatively complied with:
Alternative 1 The power supply complies with the requirements
for a limited power source (LPS) as per EN 60950-1.
Alternative 2 All of the following requirements are complied with:
The power supply complies with the
requirements for a safety extra-low voltage
(SELV) as per IEC/EN 60950-1.
A fuse suitable for DC voltage is located in the
plus conductor of the power supply.
The minus conductor is on ground potential.
Otherwise, a fuse is also located in the minus
conductor.
Regarding the properties of this fuse:
See “General technical data” on page 55.
Only for device
variants featuring
supply voltage with
characteristic
value K9 or KK:
All of the following requirements are complied with:
Supply with DC voltage:
A fuse suitable for DC voltage is located in the plus conductor of the
power supply.
The minus conductor is on ground potential. Otherwise, a fuse is also
located in the minus conductor.
Regarding the properties of this fuse:
See “General technical data” on page 55.
The wire diameter of the power supply cable is at least 1 mm² (North
America: AWG16) on the supply voltage input.
Supply with AC voltage:
A fuse is located in the outer conductor of the power supply.
The neutral conductor is on ground potential at both voltage inputs.
Otherwise, a fuse is also located in the neutral conductor.
Regarding the properties of this fuse:
See “General technical data” on page 55.
The wire diameter of the power supply cable is at least 0.75 mm²
(North America: AWG18) on the supply voltage input.
Device variant Requirements
Table 3: Requirements for connecting the supply voltage

Installation RSPE30/32/35/37
Release 16 04/2019 11
ATEX directive 2014/34/EU – specific regulations for safe
operation
Relevant for RSPE devices when operating in explosive gas atmospheres
according to ATEX directive 2014/34/EU, the following applies:
List of standards:
EN 60079-0:2012, A11:2013
EN 60079-15:2010
Certificate No.: DEKRA 15ATEX0016X
Use only device variants featuring supply voltage with characteristic
value CC.
Make sure that the device has the following label:
II 3G Ex nA IIC T4 Gc DEKRA 15ATEX0016X
for RSPE types
Ambient rating and temperature code for RSPE types:
T4: 0 °C ≤Ta ≤+60 °C for “S” types or
T4: −40 °C ≤Ta ≤+70 °C for “T” or “E” types
The modules shall be installed in a suitable enclosure in accordance
with IEC 60079-15 providing a degree of protection of at least IP54
according to IEC 60529, taking into account the environmental
conditions under which the equipment will be used.
When the temperature under rated conditions exceeds 158 °F (70 °C)
at the cable or conduit entry point, or 176 °F (80 °C) at the branching
point of the conductors, the temperature specification of the selected
cable and cable entries shall be in compliance with the actual
measured temperature values.
Provisions shall be made to prevent the rated voltage from being
exceeded by transient disturbances of more than 119 V.
Connectors shall be connected or disconnected exclusively in dead-
voltage state.
DIP switches shall be switched exclusively in dead-voltage state.
The USB port shall remain disconnected.

12 Installation RSPE30/32/35/37
Release 16 04/2019
Relevant for use in explosion hazard areas (Hazardous
Locations, Class I, Division 2):
The relay connections are to be installed and used within their Entity
Parameters as per Control Drawing 000182303DNR.
Avertissement - Risque d'explosion - Ne pas débrancher tant que le
circuit est sous tension à moins que l'emplacement soit connu pour ne
contenir aucune concentration de gaz inflammable.
Avertissement - Risque d'explosion - La substitution de tout composant
peut rendre ce matériel incompatible pour une utilisation en classe I,
division 2.

Installation RSPE30/32/35/37
Release 16 04/2019 13
Control Drawing for RSPE devices according to Class ,Division 2 Hazardous Locations
Rev.: 1Document No.: 000182303DNR Page 1/2
For Use in Hazardous Locations Class I Division 2 Groups A, B, C, D:
Only allowed for RSPE/RSPM model No´s. which are individually labeled
“FOR USE IN HAZARDOUS LOCATIONS”.
This equipment is suitable for use in Class I, Division 2,
Groups A, B, C, and D OR non-hazardous locations only.
Nonincendive eld wiring circuits must be wired in accordance with the National Electrical Code
(NEC), NFPA 70, article 501.
WARNING – EXPLOSION HAZARD
Substitution of any components may impair suitability for hazardous locations or explosive
atmospheres.
WARNING – EXPLOSION HAZARD
Do not disconnect equipment unless power has been switched off or the area is known to be
known to be non-hazardous.

14 Installation RSPE30/32/35/37
Release 16 04/2019
Control Drawing for RSPE devices according to Class ,Division 2 Hazardous Locations
Rev.: 1 Document No.: 000182303DNR Page 2/2
Ordinary Location,
Non-Hazardous Area,
Non-Explosive Atmosphere
Explosive Atmosphere
Class ,Division 2
Groups A, B, C, D
Hazardous Location
RSPE - Industrial Ethernet
Rail Switch Power Enhanced
Relay
USB
P1
P2
The earth conductor must
be at least of the same
wire size (mm² or AWG)
as the supply conductors.
Temperature Code: T4
Ambient Temperature rating:
Ta: 0 °C to +60 °C for “S” temperature types
Ta: í40 °C to +70 °C for “T” or “E” temperature types
(Refer to the temperature code of the type designation on the
device.)
Power Supply connectors
*) Notes:
The nonincendive eld wiring circuit concept allows interconnection
of nonincendive eld wiring apparatus and associated nonincendive
eld wiring apparatus using any of the wiring methods permitted for
unclassied locations when certain parametric conditions are met.
Capacity: CaCi+ CCable ; Inductivity: LaLi+ LCable
WARNING!
The USB is for temporary connection only, for maintenance
use. Do not use, connect or disconnect unless the area is
known to be non-hazardous.
Connection or disconnection in an explosive atmosphere
could result in an explosion.
The maximum cable length has to be determined as follows:
(a) max. Cable Length < (LaíLi) / CableL
(”CableL” denotes the inductance per unit length of used cable)
and
(b) max. Cable Length < (CaíCi) / CableC
(“CableC” denotes the capacitance per unit length of used cable)
The lower value of (a) and (b) is to apply.
Relay contacts:
Equipment with nonincendive eld wiring parameters.
Polarity is not relevant.
The relay terminals are dependent upon the following
Entity parameters:
UiIiCiLi
30 V 90 mA 2 nF 1 H

Installation RSPE30/32/35/37
Release 16 04/2019 15
IECEx – Certification Scheme for Explosive Atmospheres
For RSPE devices labeled with an IECEx certificate number, the following
applies:
List of standards:
IEC 60079-0:2011 + Cor.2012 + Cor.2013
IEC 60079-15:2010
The equipment is suitable for use in an area with maximum pollution
degree 2, as defined in IEC 60664-1.
Make sure that the device has the following label:
Ex nA IIC T4 Gc IECEx DEK 15.0013X
for RSPE types
Environmental class and temperature code for RSPE types:
T4: 0 °C ≤Ta ≤+60 °C for “S“ types or
T4: −40 °C ≤Ta ≤+70 °C for “T“ or “E“ types
The modules shall be installed in a suitable enclosure in accordance
with IEC 60079-15 providing a degree of protection of at least IP54
according to IEC 60529, taking into account the environmental
conditions under which the equipment will be used.
When the temperature under rated conditions exceeds 158 °F (70 °C)
at the cable or conduit entry point, or 176 °F (80 °C) at the branching
point of the conductors, the temperature specification of the selected
cable and cable entries shall be in compliance with the actual
measured temperature values.
Provisions shall be made to prevent the rated voltage from being
exceeded by transient disturbances of more than 119 V.
Connectors shall be connected or disconnected exclusively in dead-
voltage state.
The USB port shall remain disconnected.

16 Installation RSPE30/32/35/37
Release 16 04/2019
CE marking
The labeled devices comply with the regulations contained in the following
European directive(s):
In accordance with the above-named EU directive(s), the EU conformity
declaration will be at the disposal of the relevant authorities at the
following address:
Hirschmann Automation and Control GmbH
Stuttgarter Str. 45-51
72654 Neckartenzlingen
Germany
www.hirschmann.com
The product can be used in the industrial sector.
Interference immunity: EN 61000-6-2
Emitted interference: EN 55032
Reliability: EN 60950-1
You find more information on technical standards here:
“Technical data” on page 55
Warning! This is a class A device. This device can cause interference in
living areas, and in this case the operator may be required to take
appropriate measures.
Note: The assembly guidelines provided in these instructions must be
strictly adhered to in order to observe the EMC threshold values.
LED or laser components
LED or LASER components according to IEC 60825-1 (2014):
CLASS 1 LASER PRODUCT
CLASS 1 LED PRODUCT
Device variant Directive
All variants 2014/30/EU (EMC)
Directive of the European Parliament and the council for
standardizing the regulations of member states with regard to
electromagnetic compatibility.
2011/65/EU (RoHS)
Directive of the European Parliament and of the Council on the
restriction of the use of certain hazardous substances in
electrical and electronic equipment.
Only for device variants
featuring supply voltage with
characteristic value K9 or KK:
2014/35/EU
Directive of the European Parliament and of the Council on the
harmonisation of the laws of the Member States relating to the
making available on the market of electrical equipment
designed for use within certain voltage limits.

Installation RSPE30/32/35/37
Release 16 04/2019 17
FCC note:
This device complies with part 15 of the FCC rules. Operation is subject
to the following two conditions: (1) this device may not cause harmful
interference; (2) this device must accept any interference received,
including interference that may cause undesired operation.
Appropriate testing has established that this device fulfills the
requirements of a class A digital device in line with part 15 of the FCC
regulations.
These requirements are designed to provide sufficient protection against
interference when the device is being used in a business environment.
The device creates and uses high frequencies and can also radiate these
frequencies. If it is not installed and used in accordance with this
operating manual, it can cause radio transmission interference. The use
of this device in a residential area can also cause interference, and in this
case the user is obliged to cover the costs of removing the interference.
Recycling note
After usage, this device must be disposed of properly as electronic waste,
in accordance with the current disposal regulations of your county, state,
and country.

18 Installation RSPE30/32/35/37
Release 16 04/2019
About this manual
The “Installation” user manual contains a device description, safety
instructions, a description of the display, and the other information that you
need to install the device.
Documentation mentioned in the “User Manual Installation” that is not
supplied with your device as a printout can be found as PDF files for
downloading on the Internet at https://www.doc.hirschmann.com

Installation RSPE30/32/35/37
Release 16 04/2019 19
Key
The symbols used in this manual have the following meanings:
Listing
Work step
Subheading

20 Installation RSPE30/32/35/37
Release 16 04/2019
1 Description
1.1 General description
The RSPE30/32/35/37 devices are designed for the special requirements of
industrial automation. They meet the relevant industry standards, provide
very high operational reliability, even under extreme conditions, and also
long-term reliability and flexibility.
You can choose from between a wide range of variants. You have the option
to set up your device individually based on different criteria:
Support of PoE(+)
Temperature range
Supply voltage range
Certifications
Redundancy functions
You have the option of choosing various media to connect to the end devices
and other network components:
Multimode optical fiber
Singlemode optical fiber
Twisted pair cable
The device is mounted by latching in place on a DIN rail.
The devices work without a fan.
By using media modules, you obtain up to 16 additional Fast Ethernet ports.
You will find more information on the media modules in the “User Manual for
Installation of RSPM”.
You find these manuals as PDF files on the Internet at http://
www.doc.hirschmann.com
The redundancy concept allows the network to be reconfigured quickly.
There are convenient options for managing the device. Manage your devices
via:
Web browser
SSH
Telnet
