Hisense AP1019CW1G Technical manual

Hi sense


。

．／／
 

Model/Modelo:
AP1019CW1G
AP1219CR1W
AP1419CR1G
AP1419CW1G
AP1319HR1G

TABLE OF CONTENTS
4
5
5
6
6
8
7
10
9
11
2
15
Draining the Air Conditioner(non-Heating models)
13
IDENTIFICATION OF PARTS
AIR CONDITIONER SAFETY 4
INSTALLATION REQUIREMENTS 4
Tools and Parts
Electrical Requirements
Location Requirements
INSTALLATION INSTRUCTIONS
Unpack the Air Conditioner
Window Vent Panel And Extensions
Install The Portable Air Conditioner
Installation In Vertical Sliding Windows
Installation In Horizontal Sliding Windows
Starting Your Portable Air Conditioner
PORTABLE AIR CONDITIONER USE
Using the Remote Control
Normal Sounds
PORTABLE AIR CONDITIONER CARE
Draining the Air Conditioner(Heating models)
16
16
16
Cleaning the Air Filter 16
Storing After Use 16
TROUBLESHOOTING 17
12
Cleaning the Outside 16

1
2
5
4
6
7
8
9
10
11
12
13
3
/Display
The figures in this manual are based on the external view of a standard model.
They may differ from that of the air conditioner you have selected.

1
2
5
4
6
7
8
9
10
11
12
13
3
/Display
(AP14 Models)
The figures in this manual are based on the external view of a standard model.
They may differ from that of the air conditioner you have selected.

Tools and Parts
Gather the required tools and parts before starting installation.
Read and follow the instructions provided with any tools listed
here.
Tools needed
Parts supplied
Check that all parts are included in parts package.
■Phillips screwdriver ■Pencil ■Scissors
■Cordless drill and ¹⁄₈" bit
4
All safety messages will tell you what the potential hazard is and tell you how to reduce the chance of injury.
We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety
messages.
This is the safety alert symbol.
This symbol alerts you to potential hazards that can kill or hurt you and others.
All safety messages will follow the safety alert symbol and either the word "DANGER" or "WARNING ."
These words mean:
DANGER
WARNING
IMPORTANT SAFETY INSTRUCTIONS
WARNING: To reduce the risk of fire, electrical shock or injury when using your air conditioner, follow these basic precautions:
SAVE THESE INSTRUCTIONS
Unplug air conditioner before servicing.
Use two or more people to move and install air conditioner.
Plug into a grounded 3 prong outlet.
Do not remove ground prong.
Do not use an electrical adapter.
Do not use an extension cord.
Your safety and the safety of others is very important.
STORAGE AND DISPOSING OF THE UNIT
Please recycle or dispose of the packaging material for product in an environmentally responsible manner.
Never store or ship the air conditioner upside down or sideways to avoid damage to the compressor .
The appliance is not intended for use by young children or impaired persons without supervision. Young children should be
supervised to ensure that they do not play with the appliance.
A hazard that if not avoided will result in death or
serious injury.
A hazard that if not avoided could result in death or
serious injury.
Dispose of this appliance in accordance with Federal and Local regulations. Refrigerants must be evacuated before
disposal.
A.Foam seal
B.Coupling
C.Flexible exhaust hose
D.Window exhaust adapter
E.Rivets(4)
F.Screws(4)
G.Window-lock bracket(2)
H.Outer slider section with vent
I. Inner slider section-short
J.Inner slider section
K.Outer slider section
L.Foam seal-long(2)
M.Foam seal-short(2)

5
Location Requirements
Up to 15'x 20' Room
Up to 20' x 20'Room
Up to 20' x 25' Room
Up to 10'x 20' Room
Area to be cooled
200 sq ft.
400 sq ft.
300 sq ft.
500 sq ft.
Up to 20' x 30' Room
600 sq ft.
DOE Capacity needed(BTUs)
5,000/5,500
7,000/7,500
6,000/6,500
8,000/8,500
9,000/9,500
Electrical Shock Hazard
Plug into a grounded 3 prong outlet.
Do not remove ground prong.
Do not use an adapter.
Do not use an extension cord.
Failure to follow these instructions can result in death,
WARNING
fire, or electrical shock.
Recommended Grounding Method
Wiring requirement
NOTE:
Your air conditioner’s device may differ from the one shown.
To test your power supply cord:
1. Plug power supply cord into a grounded 3 prong outlet.
2. Press RESET (on some devices, a green light will turn on).
3. Press TEST (listen for click; Reset button will trip, and on
some devices, a green light will turn off).
4. Press and release RESET (listen for click; Reset button will
latch, and on some devices, a green light will turn on). The
power supply cord is ready for operation.
NOTE:
■The Reset button must be pushed in for proper operation.
■The power supply cord must be replaced if it fails to trip when
the test button is pressed or fails to reset.
■Do not use the power supply cord as an off/on switch. The
power supply cord is designed as a protective device.
■A damaged power supply cord must be replaced with a new
power supply cord obtained from the product manufacturer
and must not be repaired.
■The power supply cord contains no user serviceable parts.
Opening the tamper-resistant case voids all warranty and
performance claims.
A.Test button
B.Reset button
TEST
RESET
A
B
This room air conditioner is equipped with a power supply cord
required by UL. This power supply cord contains state-of-the-art
electronics that sense leakage current. If the cord is crushed, the
electronics detect leakage current and power will be
disconnected in a fraction of a second.
To contact a qualified .electrical installer
It is the customer’s responsibility:
To assure that the electrical installation is
adequate and conforms to the Nation Electrical
Code,ANSI/NFPA 70-last edition,and all local
codes and ordinances.
Copies of the standards listed may be obtained from:
Nation Fire Protection Association
1 Batterymarch Park
Quincy,Ma 02169-7471
www.nfpa.org
This
portable air conditioner is equipped with a power supply
cord with a three-prong grounding plug. The cord must
be plugged into a mating, grounded three-prong outlet,
grounded in accordance with all local codes and
ordinances. If a mating outlet is not available, it is the
customer's responsibility to have a properly grounded
three-prong outlet installed by a qualified electrical
installer.
portable air conditioner must be grounded. This
115 V (103.5 min. to 126.5 max.)
15 A time-delay fuse or circuit breaker
Power Supply Cord
Electrical Requirements
NOTE:
■ The flexible exhaust hose allows placement of the air
conditioner at least 20" from window or door.
■ Confirm you are using the correct size air conditioner for
the space to be cooled, per sizing recommendations, below:
NOTE: Match BTUs to room use and location:
■ Shaded room reduce to next smaller size
■ Sunny room increase to next larger size
■ For kitchens, increase to next larger size

WARNING
The length of the exhaust hose is specially designed according to the specification of the product.
Do not replace, or extend , or otherwise modify the hose.
NOTE:
■ For best performance, allow at least 20 in of air space on all sides of the unit for good air circulation.
■ Do not block the air outlet.
■ Provide easy access to the grounded 3 prong outlet.
6
Vertical Sliding Window Horizontal Sliding Window
INSTALLATION INSTRUCTIONS
Unpack the Air Conditioner
Remove packaging materials
■Remove and recycle packaging materials.
Remove tape and glue residue from surfaces before turning
on the air conditioner. Rub a small amount of liquid dish soap
over the adhesive with your fingers. Wipe with warm water
and dry.
■Do not use sharp instruments, rubbing alcohol, flammable
fluids, or abrasive cleaners to remove tape or glue. These
products can damage the surface of your air conditioner.
■
■
Handle the air conditioner gently.
Keep unit upright at least 2 hours prior to use.
WARNING
Excessive Weight Hazard
Use two or more people to move and install
air conditioner.
Failure to do so can result in back or other injury.
Caution: Installation accessories are stored in the top of the carton, and are required for proper cooling
performance. Please remove all accessories from packing materials before use.

7
Window Vent Panel And Extensions
The window installation kit allows you to install the air conditioner in most vertical-sliding windows 18'' to 50'' wide, or
horizontal sliding windows from 18'' to 50'' high.
1.Please check your window size and choose the fit
from the above table.
2.If your window size requires more than 2 panels,
after adjusting the length, please secure the panels
with rivets, E.
Rivet E
HI KJ
Panel Length
18" 18" 18"
911
16
"
Panel H (18") Panel K (18") Panel J (18")
Panel I 911
16
"
( )
Panel H
Panel H
For window openings from 19" to 26",
use the window vent panel(Panel H) and a
extension panel (Panel I).
Panel H
Panel I
Panel H
Panel I
Panel H
Panel H
Panel J
Panel J
For window openings from 27" to 34",
use the window vent panel(Panel H) and a
extension panel (Panel J).
For window openings from 35" to 50", use the
window vent panel and two extension panels
(Panel K and Panel J).
Panel H
Panel K
Panel J
Panel H
Panel J
Panel K
Fig. "a"
Fig. "c"Fig. "d"
Fig. "b"

A
8
Install The Portable Air Conditioner
5. Confirm the hose is locked in place before
operating.
Window Installation
Install Exhaust Hose and Adapter
A. Outer slider section
B. Window exhaust adapter
3. Insert the coupling into the slot on the back of the air
conditioner.
4. Slide down to lock the hose into place.
A
B
NOTE: Product must be used with included Duct
Window installation kit for effective cooling.
exhaust hose assembly
flexible exhaust hose
coupling
window exhaust adapter
A. Flexible exhaust hose assembly
1. Roll the air conditioner to selected location. see “Location
Requirements” in page 4.
2. Preparing the exhaust hose assembly:
Press the flexible exhaust hose into the coupling and the
window exhaust adapter, Both the coupling and window
exhaust adapter have integral clips that snap onto the hose.
Your window installation kit has been designed to fit most
standard vertical and horizontal window applications. Roll the
air conditioner to selected location. see “Location
Requirements” in page 4.
1. Attach the window exhaust adapter to the outer slider
section (the piece with the large exhaust hole).
