USER MANUAL
Before usingthesound bar, please read this manual
thoroughly and retainit for future reference.
Model: HS214
2.1 Channel Sound Bar Home Theater System
EN FR DE IT SP SL HR NL
CZ SK HU PT SR MK SQ

2
EN
Contents
Important Safety Instructions 3
Safety ...........................................................................................................................................................................................3
Warning.......................................................................................................................................................................................4
Package Contents 5
Product Diagram 6
Main Unit ...................................................................................................................................................................................6
Remote Control........................................................................................................................................................................7
Instructions 7
Prepare the Remote Control ...............................................................................................................................................7
Replace the Remote Control Battery................................................................................................................................7
Precautions Concerning Batteries
..................................................................................................................................7
Placement and Mounting.....................................................................................................................................................8
Wall Mounting (if using option-B).....................................................................................................................................8
Connections 9
Connect to HDMI ARC Socket
........................................................................................................................................... 9
Connect to OPTICAL Socket
.......................................................................................................................................... 9
Connect to COAXIAL Socket
................................................................................................................................................... 9
Connect to AUX Socket
.............................................................................................................................................10
Connect Power ......................................................................................................................................................................10
Basic Operation 10
Standby/On ............................................................................................................................................................................10
Select Modes
Automatic Power O Function
Auto Wake
.............................................................................................................................................................................10
How to Enable Auto Wake ................................................................................................................................................10
......................................................................................................................................
........................................................................................................................................................................
10
10
Select a Preset Sound Eect
Adjust the Volume
...........................................................................................................................................
...............................................................................................................................................................11
11
OPTICAL / COAXIAL / HDMI ARC / AUX Operation 11
Bluetooth Operation 11
Pair Bluetooth-enabled Devices...................................................................................................................................... 11
Listen to Music from Bluetooth Device........................................................................................................................ 12
USB Operation 12
Troubleshooting 13
14
EN

EN
3
third grounding prong. The wide blade or the
third prong is provided for your safety. If the
provided plug does not t into your outlet,
consult an electrician for replacement of the
obsolete outlet.
10 Protect the power cord from being walked on
or pinched particularly at plugs, convenience
receptacles, and the point where they exit
from the apparatus.
11
the manufacturer.
12 Use only with the cart, stand, tripod,
bracket or table specied by the
manufacturer, or sold with the
apparatus. When a cart or rack is
used, use caution when moving the cart/
apparatus combination to avoid injury from
tip-over.
13 Unplug the apparatus during lightning storms
or when unused for long periods of time.
14 Refer all servicing to qualied personnel.
Servicing is required when the apparatus has
been damaged in any way, such as power
supply cord or plug is damaged, liquid has
been spilled or objects have fallen into the
apparatus, the unit has been exposed to rain
or moisture, does not operate normally, or has
been dropped.
15 This equipment is a Class II or double
insulated electrical appliance. It has been
designed in such a way that it does not require
a safety connection to electrical earth.
16 The apparatus shall not be exposed to
dripping or splashing. No objects lled with
liquids, such as vases, shall be placed on the
apparatus.
17 Minimum distance around the apparatus for
18 The ventilation should not be impeded by
covering the ventilation openings with items,
such as newspapers,table-cloths, curtains, etc.
19 No naked ame sources, such as lighted
candles, should be placed on the apparatus.
20 Batteries should be recycled or disposed of as
per state and local guidelines.
21 The use of apparatus in moderate or tropical
climates.
Important Safety Instructions
The lightning ash with arrowhead
symbol, within an equilateral triangle, is
intended to alert the user to the presence
of uninsulated“dangerous voltage”within
the product’s enclosure that may be of
sucient magnitude as to constitute a
risk of electric shock to persons.
The exclamation point within an
equilateral triangle is intended to
alert the user to the presence of
important operating and maintenance
(servicing) instructions in the literature
accompanying the appliance.
Safety
1 Read these instructions– All the safety and
operating instructions should be read before
this product is operated.
2 Keep these instructions – The safety and
operating instructions should be retained for
future reference.
3 Heed all warnings – All warnings on the
appliance and in the operating instructions
should be adhered to.
4 Follow all instructions– All operating and
usage instructions should be followed.
5 Do not use this apparatus near water – The
appliance should not be used near water or
moisture – for example, in a wet basement or
near a swimming pool and the like.
6 Clean only with a dry cloth.
7Do not block any ventilation openings.
Install in accordance with the manufacturer’s
instructions.
8 Do not install near any heat sources such as
radiators, heaters, stoves, or other apparatus
9 Do not defeat the safety purpose of the
polarized or grounding plug. A polarized
plug has two blades with one wider than the
other. A grounding plug has two blades and a
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
AVIS
RISQUE DE CHOC
ÉLECTRIQUE NE PAS PUVRIR
EN

4
Caution:
- Use of controls or adjustments or performance
of procedures other than those described
herein, may result in hazardous radiation
exposure or other unsafe operation.
-
not expose this apparatus to rain or moisture.
The apparatus must not be exposed to
dripping or splashing and objects lled with
liquids, such as vases, must not be placed on
apparatus.
- The mains plug/appliance coupler is used as
the disconnect device, the disconnect device
must remain readily operable.
- Danger of explosion if battery is incorrectly
replaced. Replace only with the same or
equivalent type.
Warning
• The battery (batteries or battery pack) shall not
be exposed to excessive heat such as sunshine,
• Before operating this system, check the
voltage of this system to see if it is identical to
the voltage of your local power supply.
• Do not place this unit close to strong magnetic
• Do not place this unit on the amplier or
receiver.
• Do not place this unit close to damp areas as the
• If any solid object or liquid falls into the
system, unplug the system and have it checked
further.
• Do not attempt to clean the unit with chemical
clean, dry or slightly damp cloth.
• When removing the power plug from the wall
outlet, always pull directly on the plug, never
yank on the cord.
• Changes or modications to this unit not
expressly approved by the party responsible
for compliance will void the user’s authority to
operate the equipment.
• The rating label is pasted on the bottom or
back of the equipment.
WARNING
DO NOT INGEST BATTERY, CHEMICAL BURN
HAZARD
If you think batteries might have been
swallowed or placed inside any part of the
body, seek immediate medical attention.
Keep new and used batteries away from
children. If the battery compartment does
not close securely, stop using the product
and keep it away from children. The remote
control supplied with this product contains
a coin/button cell battery. If the coin/button
cell battery is swallowed, it can cause severe
internal burns in just 2 hours and lead to
death.
Correct Disposal of this product. This
marking indicates that this product
should not be disposed with other
household wastes throughout the EU.
To prevent possible harm to the environment or
human health from uncontrolled waste disposal,
recycle it responsibly to promote the sustainable
reuse of material resources. To return your used
device, please use the return and collection
systems or contact the retailer where the product
was purchased. They can take this product for
environmental safe recycling.
Hereby, Hisense International Co., Ltd
declares that the 2.1 channel sound
bar with built in subwoofer is in
compliance with Directive
2014/53/EU.
EN
Europe-European Union Notice
Radio products with the CE alert marking comply
with the RED Directive (2014/53/EU) issued by the
Commission of the European Community.
Frequency range: 2402-2480MHz
Versions of software or rmware aecting
compliance with essential requirements:
HW: HS214-01-A0F
Maximum RF output power of the product: +9dBm
Accessories/components marketed together:
Remote control
WARNING: This product contains chemicals
known to the State of California to cause cancer
and birth defects or other reproductive harm. For
more information: www.watts.com/prop65
The Bluetooth word mark and logos are registered
trademarks owned by Bluetooth SIG,. Inc.
HDMI is a trademark or registered trademark of
HDMI Licensing, LLC in the United States and/or
other countries.
Manufactured under license from Dolby
Laboratories. Dolby, Dolby Audio, and the
double-D symbol are trademarks of Dolby
Laboratories.

5
Package Contents
•
AC Power Cord
Main Unit Remote Control R03(Size AAA)Battery x2
Wall Mounting Kit
User Manual/Quick Start Guide
HDMI Cable
EN

6
Product Diagram
Main Unit
1Remote Control Sensor
Receive signal from the remote control.
2 LED Indicators
• Red : In STANDBY mode.
• Optical mode.
• Blue : In Bluetooth mode.
• White : In HDMI ARC mode.
•
•
•
Coaxial mode.
6Wall Mount
Install the wall mounting screws into
the wall mount of the unit.
3(ON/OFF) Button
Switch the unit between ON and STANDBY mode.
5 +/- (Vol+/Vol-) Buttons
Increase/decrease the volume level.
4 (SOURCE) Button
Select the play mode.
7AC Socket
Connect to the power supply.
8IR Repeater
Transfer the signal received from
remote control to the TV
10 HDMI ARC Socket
Connect to a TV via HDMI cable.
11 Aux Socket
Connect to an external audio device.
13 USB Socket
Insert the USB device to play music.
9 COAXIAL Socket
Connect to a coaxial audio output on the TV.
12 OPTICAL Socket
Connect to an optical audio output on the TV.
3
9
4
12
5
10 11 12 13
87
6 6
Light green
Green : In AUX mode.
Yellow : In USB mode.
EN

7
Remote Control
1 (ON/OFF) Switch the unit between ON and
STANDBY mode.
2 (MUTE)Mute or resume volume.
3
SURR
DIM -
DIM +
buttons Select MOVIE/MUSIC/NEWS sound eect.
Adjust the surround ON/OFF.
4
In Bluetooth/USB mode:
Skip to previous/next track.
5
Play/pause/resume playback in Bluetooth/
USB mode. Press and hold to activate the
pairing function in Bluetooth mode or
disconnect the existing paired Bluetooth device.
6
VOL+/VOL- Increase/decrease the volume level.
Increase/decrease the bass level.
7
SOURCE Select the play mode.
11
EQ
Decrease the display brightness.
8
Instructions
Prepare the Remote Control
The Remote Control allows the unit to be operated from a distance.
•
operations may be disrupted if there are any obstacles between the unit and the remote control.
26.2 feet (8m) inch, remote control
• If the Remote Control is operated near other products that generate infrared rays, or if other remote control
devices using infrared rays are used near the unit, it may operate incorrectly. Conversely, the other products
may operate incorrectly.
First-time Use:
Put the 2 x AAA batteries (included) into the remote control before use.
Replace the Remote Control Battery
1. Push the tab on the side of the battery tray towards the tray and then
pull the battery tray out of the remote control.
2. Remove the old batteries. Place 2 x new AAA batteries into the battery
tray withthe correct polarity (+/-) as indicated.
3. Slide the battery tray back into the slot in the remote control.
Precautions Concerning Batteries
• When the remote control is not to be used for a long time (more
than a month), remove the batteries from the remote control to
prevent it from leaking.
• If the batteries leak, wipe away the leakage inside the battery
compartment and replace the batteries with new ones.
•
• Do not heat or disassemble batteries.
• Keep away from heat or moisture.
• Do not carry or store batteries with other metallic objects.
Doing so could cause batteries to short circuit, leak or explode.
•
type.
1
3
5
7
10
11
4
2
6
8
9
,
Increase the display brightness.
9
BASS + , BASS -10
1
2
3
EN

8
EN
Placement and Mounting
Placement
A If your TV is placed on a table, you can place the
unit on the table directly in front of the TV stand,
centered with the TV screen.
B If your TV is attached to a wall, you can mount
the unit on the wall directly below the TV screen.
Wall Mounting (if using option-B)
Note:
-
personal injury and property damage (if you intend to install this product yourself, you must check
for installations such as electrical wiring and plumbing that may be buried inside the wall). It is the
installer’s responsibility to verify that the wall will safely support the total load of the unit and wall
brackets.
- Additional tools (not included) are required for the installation.
- Do not overtighten screws.
- Keep this instruction manual for future reference.
-
A B
540MM
may
EN

9
Connections
Connect to HDMI ARC Socket
Your Soundbar supports HDMI with Audio
Return Channel (ARC). If your TV is HDMI ARC
compliant, you can hear the TV audio through
your Soundbar by using a single HDMI cable.
1 Use a High Speed HDMI cable to connect
the HDMI ARC connector on your Soundbar
and the HDMI ARC connector on the TV.
- The HDMI ARC connector on the TV might
TV user manual.
2 On your TV, turn on HDMI-CEC operations.
For details, see the TV user manual.
Tips:
- Your TV must support the HDMI-CEC and
ARC function. HDMI-CEC and ARC must be
set to On.
- The setting method of HDMI-CEC and
ARC may dier depending on the TV. For
details about ARC function, please refer to
your TV user manual.
- Only HDMI 1.4 compatible cables can
support the ARC function.
Connect to COAXIAL Socket
• You can use a COAXIAL cable (not included)
to connect the TV's COAXIAL OUT socket
and the COAXIAL socket on the unit.
Tip:
• While in OPTICAL ,HDMI ARC or
COAXIAL mode, if there’s no sound output
from the unit, you may need to activate
PCM signal output on your source device
(eg. TV, DVD or Blu-ray player).
Connect to AUX Socket
A Use a RCA to 3.5mm audio cable (not
included) to connect the TV’s audio output
socket and the AUX socket on the unit.
B Use a 3.5mm to 3.5mm audio cable (not
included) to connect the TV’s or external
audio device Aux socket to the Aux socket
on the unit.
be labelled dierently. For details, see the
BA
AUX
EN

Connect to OPTICAL Socket
- Remove the protective cap of the OPTICAL
socket, then connect an OPTICAL cable
to the TV’s OPTICAL OUT socket
and the OPTICAL socket on the unit.
10
Connect Power
Risk of product damage!
- Ensure that the power supply voltage
corresponds to the voltage printed on the
back or the underside of the unit.
-
connections.
• Connect the mains cable to the AC Socket
of main unit and then into a mains socket.
The unit automatically turns to STANDBY mode
after about15 minutes if the TV or the external
unit is disconnected or switched o.
•
• Please turn the unit o completely to save
energy when not in use.
Select Modes
Press the (SOURCE) button repeatedly on
the unit or the SOURCE button on the remote
control to select the desired mode. The LED
indicator on the front of the main unit will show
which mode is currently in use.
Basic Operation
Standby/On
socket, the main unit will be in STANDBY mode.
• Press the button on the unit or on the
remote control to switch the unit ON.
• Press the button again to switch the unit
back to STANDBY mode.
• Disconnect the mains plug from the mains
socket if you want to switch the unit OFF
completely.
Auto Wake
•
•
•
If a TV or an external device is connected (AUX /
OPTICAL / COAXIAL / HDMI ARC), the unit will
switch on automatically when the TV or the
external device is switched on.
EN
Before connecting the AC power cord,
ensure you have completed all other
To switch the unit o completely, disconnect
the mains plug from the mains socket.
How to Enable Auto Wake
sequentially. While in STANDBY mode, the
RED LED is breathing.
Auto Wake O: white and red LED blink twice
sequentially. While in STANDBY mode, the LED
is in solid red.
Short press the (SOURCE) button and
+(VOL +) button on the unit to enable or
disable Auto Wake function.
Auto Wake On: white and green LED blink twice
•
EN

11
Adjust the Volume
Press the + / - buttons on the unit or VOL+ / VOL-
on the remote control to adjust the volume.
If you wish to turn the sound o, press the
button on the remote control. Press the button
again or press the + / - buttons on the unit or
VOL+ / VOL- on the remote control to unmute.
While playing, press the NEWS / MOVIE/ MUSIC
buttons on the remote control to select the preset
equalizers:
MOVIE(recommended for watching movie)
MUSIC (recommended for listening to music)
NEWS (recommended for listening to news)
OPTICAL/ COAXIAL/HDMI ARC /AUX Operation
1 Ensure that the unit is connected to the TV or
audio device.
2 Press the button repeatedly on the unit or the
SOURCE button on the remote control to select
the OPTICAL, COAXIAL, HDMI ARC, AUX mode.
3 Operate your audio device directly for playback
features.
4 Press the +/– button on the unit or VOL+ / VOL-
Tip:
• While in OPTICAL , HDMI ARC or COAXIAL
mode, if there’s no sound output from the unit,
you may need to activate PCM signal output
on your source device (eg. TV, DVD or Blu-ray
player).
• For the digital audio out that the unit do not
support, the LED light would be purple and
blink three times.
Bluetooth Operation
Pair Bluetooth-enabled Devices
The rst time you connect your bluetooth device to
thisunit, you need to pair your device to this unit.
Note:
- The operational range between this unit
and a Bluetooth device is approximately 26
feet (8m) (without any object between the
Bluetooth device and the unit).
- Before you connect a Bluetooth device to this
unit, ensure you know the device’s capabilities.
- Compatibility with all Bluetooth devices is not
guaranteed.
- Any obstacle between this unit and a Bluetooth
device can reduce the operational range.
- If the signal strength is weak, your Bluetooth
receiver may disconnect, but it will re-enter
pairing mode automatically.
1 During ON mode, press the button
repeatedly on the unit or the SOURCE button
on the remote control to select
Bluetooth mode. The Blue indicator light
will ash.
2 Activate your Bluetooth device and select the
search mode. “Hisense HS214” will appear
on your Bluetooth device list.
•
button on the remote control to enter
into pairing mode again .
You will hear audio prompt from the unit and
3 Select “Hisense HS214” in the pairing list.
After audio prompt, the system is successfully
connected and the Bluetooth indicator will
light up solidly.
4 Play music from the connected Bluetooth device.
Note: While adjusting the volume, the status LED
indicator will ash once. When the volume has
hit maximum/minimum value level, the status LED
indicator will ash quickly.
on the remote control to adjust the volume to
your desired level.
EN

12
To disconnect the Bluetooth function, you can :
- Switch to another source on the unit.
- Disable the function from your Bluetooth device.
The Bluetooth device will be disconnected from
the unit after audio prompt.
- Press and hold the button on the
remote control.
Tips:
• Enter "0000" for the password if necessary.
• If no other Bluetooth device pairs with this
unit within two minutes, the unit will
recover its previous connection.
• The unit will also be disconnected when your
device ismoved beyond the operational range.
• If you want to reconnect your device to this
unit, place it within the operational range.
• If the device is moved beyond the operational
range, when it is brought back, please check if
the device is still connected to the unit.
• If the connection is lost, follow the instructions
above to pair your device to the unit again.
Listen to Music from Bluetooth Device
- If the connected Bluetooth device supports
Advanced Audio Distribution Prole (A2DP),
you can listen to the music stored on the
device through the unit.
- If the device also supports Audio Video Remote
Control Prole (AVRCP), you can use the unit's
remote control to play music stored on the
device.
1 Pair your device with the unit.
2 Play music via yourdevice (if it supports A2DP).
3 Use supplied remote control to control play
(if it supports AVRCP).
- To play/pause, press the button
on the remote control.
- To skip a track, press the , buttons on
the remote control.
USB Operation
1 Insert an USB device.
2 Press the button repeatedly on the unit
or press the SOURCE button on the remote
control to select USB mode.
3 During playback:
- To play/pause, press the button
- To skip to the previous/next track, press the
buttons on the remote control.
Tip:
• The unit can support USB devices with up to
64 GB memory.
•
•
This unit can play MP3.
• The unit support FAT32.
• Embedded USB full speed host for USB
applications should not exceed 6.5Mbps.
• For the le in FLAC format,the max block
size 8107/8109 can support 4608 as
the maximum.
EN
on the remote control.
,
This unit can support WAV/WMA/FLAC.
EN

EN
13
Troubleshooting
I can’t nd the Bluetooth name of
this unit on my Bluetooth device for
Bluetooth pairing
• Ensure the Bluetooth function is activated on
your Bluetooth device.
• Ensure you have paired the unit with your
Bluetooth device.
This is a 15 mins power o function,
one of the ERPII standard requirement
for saving power
• When the unit's external input signal level is
too low, the unit will be turned o automatically
in 15 minutes. Please increase the volume level
of your external device.
To keep the warranty valid, never try to repair the
unit yourself. If you encounter problems when
using this unit, check the following points before
requesting service.
No power
• Ensure that the AC power cord of the
unit is properly connected.
• Ensure that there is power at the AC outlet.
• Press standby button to turn the unit on.
Remote control does not work
• Before you press any playback control button,
• Reduce the distance between the remote
control and the unit.
• Insert the batteries with its polarities (+/-)
aligned as indicated.
• Replace the batteries.
• Aim the remote control directly to the sensor
in the front of the unit and there is no obstacle
between the remote control and the unit.
No sound
• Increase the volume. Press VOL+ on the
remote control or +on the unit.
• Press on the remote control to ensure
the soundbar is not muted.
•
source.
• When using either of the Digital inputs, if there
is no audio:
- Try setting the TV output to PCM or
- Connect directly to your Blu-ray/other source,
some TVs do not pass through digital audio.
• Your TV may be set to variable audio output.
FIXED or STANDARD, not VARIABLE. Refer to
your TV’s user manual for more detailed
information.
• If using Bluetooth, ensure that the volume on
your source device is turned up and the device
is not muted.
Ensure that the audio output setting is set to
SOURCE
EN

EN
EN
14
Model Name HS214
Soundbar
Power Supply 100-240V~ 50/60Hz
Power Consumption 20W
Standby Power 0.45W
USB Port for Playback
USB Compatibility
5V
Hi-Speed USB (2.0) / FAT32
WAV、MP3、WMA、FLAC
Dimension (WxDxH) 25.59 x 3.74 x 2.42 inches / (650 x 95 x 61.5 mm )
Net Weight 4.78 lbs (2.17kg)
Impedance 4Ω+8Ω x 2
Frequency Response 40Hz-20KHz
Bluetooth Version V4.2
Bluetooth Maximum Power Transmitted (EU) 9dBm
Frequency Bands 2402 ~ 2480 MHz
54W + 27W x 2
Total 108W
Remote Control
Distance/Angle 8m / ±30°; 90°
Battery Type AAA Zn-Mn battery
Amplier(Output power)
USB Playback Support/File Formats
EN

Avant d'utiliser la barre de son, veuillez lire attentivement ce
manuel et le conserver pour référence ultérieure.
MANUEL DE L'UTILISATEUR
Système Home Cinéma — Barre de son 2.1
Modèle : HS214

2
FR
Table des matières
Consignes de sécurité 3
Sécurité .......................................................................................................................................................................................3
Avertissement...........................................................................................................................................................................4
Contenu de l’emballage 5
Diagramme du produit 6
Unité principale .......................................................................................................................................................................6
Télécommande.........................................................................................................................................................................7
Instructions 7
Préparer la télécommande ..................................................................................................................................................7
Remplacer la pile de la télécommande ..........................................................................................................................7
Précautions concernant les piles ......................................................................................................................................7
Placement et montage .........................................................................................................................................................8
Support mural (si vous utilisez l’option-B) .....................................................................................................................8
Connexions 9
Connexion à la prise COAXIAL............................................................................................................................................9
Connexion à la prise HDMI ARC .........................................................................................................................................9
Connexion à la prise AUX ....................................................................................................................................................9
Connexion à la prise OPTICAL.......................................................................................................................................... 10
Branchement électrique .................................................................................................................................................... 10
Fonctionnement de base 10
Veille/Marche ........................................................................................................................................................................ 10
Réveil automatique ............................................................................................................................................................. 10
Comment activer l’activation automatique ............................................................................................................... 10
Fonction d’arrêt automatique.......................................................................................................................................... 10
Sélection des modes ........................................................................................................................................................... 10
Réglage du volume.............................................................................................................................................................. 11
Sélection d’un eet sonore prédéni............................................................................................................................ 11
Fonctionnement OPTIQUE / COAXIAL / HDMI ARC / AUX 11
Fonctionnement avec source Bluetooth 11
Associer des appareils compatibles Bluetooth.......................................................................................................... 11
Écouter de la musique à partir d’un périphérique Bluetooth .............................................................................. 12
Fonctionnement USB 12
Dépannage 13
Spécications 14

3
FR
doivent pas être modiés. Si la che fournie ne
rentre pas dans votre prise murale, consultez
un électricien pour le remplacement de la prise
secteur inutile.
10 Protégez le cordon d’alimentation de tout
piétinement et empêchez qu’il soit pincé, et
plus particulièrement au niveau des prises
de courant et de l’endroit où il est branché à
l’appareil.
11 Utilisez uniquement des fixations/accessoires
recommandées par le fabricant.
12 Utilisez uniquement un chariot,
socle, trépied, support ou table
spécifiés par le fabricant ou vendu
avec l’appareil. Lorsqu’un chariot ou
rack est utilisé, soyez prudent quand vous
déplacez l’ensemble chariot/appareil de
manière à éviter les blessures en cas de chute.
13 Débranchez l’appareil en cas d’orage ou
lorsqu’il est inutilisé pendant de longues
périodes.
14 Confiez toute réparation à un personnel
qualié. Une réparation est nécessaire lorsque
l’appareil a été endommagé d’une manière
ou d’une autre, tels que lorsque le cordon
d’alimentation ou la che sont endommagés,
du liquide a été renversé, des objets sont
tombés à l’intérieur, l’appareil a été exposé à la
pluie ou à l’humidité, qu’il ne fonctionne pas
correctement ou qu’il est tombé.
15 Cette unité est un appareil électrique à
double isolation de Classe II. Il a été conçu de
telle sorte qu'il ne nécessite pas une connexion
à la terre pour la sécurité électrique.
16 Ne placez pas sur l’appareil des objets remplis
de liquide tels que des vases.
17 La distance minimale autour de l’appareil pour
une ventilation susante est de 5 cm.
18 Ne pas entraver la ventilation en recouvrant les
ouvertures de ventilation avec des objets tels
que journaux, nappes de table, rideaux, etc.
19 Ne pas placer de sources de flammes nues,
comme des chandelles, sur le produit.
20 Les piles doivent être recyclées ou mises au
rebut conformément aux directives nationales
et locales.
Déclaration:
Convient pour une utilisation dans les climats
tempérés ou tropicaux
Consignes de sécurité
Le symbole éclair avec une èche dans un
triangle équilatéral est destiné à alerter
l’utilisateur de la présence d’une tension
dangereuse non isolée dans le capot
du produit qui peut être d’une ampleur
suffisante pour constituer un risque de
décharge électrique pour les personnes.
Le point d’exclamation dans un triangle
équilatéral est destiné à alerter l’utilisateur
de la présence d’instructions importantes
d’utilisation et de maintenance dans la
documentation accompagnant l’appareil.
Sécurité
1 Lisez ces instructions – Toutes les consignes
de sécurité et de fonctionnement doivent être
lues avant d’utiliser ce produit.
2 Conservez ces instructions – Les instructions
de sécurité et de fonctionnement doivent être
conservées pour référence ultérieure.
3 Respectez tous les avertissements - Tous
les avertissements sur cet appareil et dans
les instructions d’utilisation doivent être
respectées.
4 Suivez toutes les instructions – Toutes les
instructions et consignes d’utilisation doivent
être suivies.
5 N’utilisez pas cet appareil près de l’eau.
L’appareil ne doit jamais être utilisé près de
l’eau ou de l’humidité, tel que dans un sous-sol
humide ou près d’une piscine ou similaires.
6 Nettoyez l’appareil uniquement à l’aide d’un
chion sec.
7 Ne bloquez pas les ouvertures de ventilation.
Installez l’appareil en suivant les instructions
du fabricant.
8 Ne placez pas l’appareil près d’une source de
chaleur, tels que des radiateurs, des bouches
d’air chaud, des gazinières ou tout autre
appareil (y compris des amplificateurs) qui
produisent de la chaleur.
9 Le produit est fourni avec un cordon
d’alimentation standard EU et une fiche
moulée qui, pour des raisons de sécurité, ne
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN

4
FR
AVERTISSEMENT
NE PAS AVALER LA PILE, RISQUE DE BRÛLURES
CHIMIQUES
Si vous pensez que les piles ont été avalées
ou insérées à l’intérieur d’une partie du
corps humain, consultez immédiatement
avec un médecin. Gardez les piles neuves et
usagées hors de la portée des enfants. Si le
compartiment de la batterie ne se ferme pas
correctement, cessez d’utiliser le produit et
gardez-le hors de la portée des enfants. Si la
pile bouton est avalée, elle peut provoquer de
graves brûlures internes en à peine deux heures
et peut provoquer la mort.
AVERTISSEMENT: Ce produit contient des
produits chimiques reconnus par l’État de
Californie pour provoquer des cancers et des
anomalies congénitales ou d’autres troubles de
la reproduction. Pour plus d’informations: www.
watts.com/prop65
Mise au rebut de ce produit. Ce
pictogramme indique que ce produit ne
doit pas être jeté avec les autres déchets
ménagers dans toute l’Europe. Afin de
prévenir toute nuisance possible à
l’environnement ou à la santé humaine causée par
une élimination incontrôlée des déchets, recyclez
ce produit de manière responsable pour promouvoir
la réutilisation durable des ressources matérielles.
Pour retourner votre appareil usagé, veuillez utiliser
les systèmes de reprise et de collecte ou contactez
le revendeur où vous avez acheté le produit. Le
revendeur peut emmener ce produit pour son
recyclage propre et sûr.
Avis Europe-Union européenne
Les produits radio portant l’étiquette d’alerte CE sont
conformes à la directive RED (2014/53/UE) émise
par la Commission de la Communauté européenne.
Gamme de fréquences: 2402-2480MHz
Versions de logiciels ou de micrologiciels aectant
la conformité aux exigences essentielles:
HW: HS214-01-A0F
Puissance de sortie RF maximale du produit: +9dBm
Accessoires/composants commercialisés ensemble:
Télécommande
Par la présente, Hisense International
Co., Ltd déclare que la barre de son
2.1 canaux avec caisson de basses
intégré est conforme à la directive
2014/53/EU.
HDMI est une marque commerciale ou déposée
de HDMI Licensing, LLC aux États-Unis et/ou dans
d’autres pays.
Attention :
- An de réduire le risque d’incendie ou d’électrocution,
ne pas exposer cet appareil à la pluie ou à
l’humidité. Cet appareil ne doit pas être exposé à
des égouttements ou éclaboussures, ni des objets
remplis de liquides, tels que des vases, ne doivent
être placés sur l’appareil.
- Si la fiche secteur ou le coupleur de l’appareil
est utilisé comme sectionneur, ce dispositif doit
toujours rester facilement accessible.
- Le fait de remplacer la pile par une autre pile qui
ne convient pas présente un risque d’explosion.
Remplacer uniquement par une pile de type
identique ou équivalent.
Avertissement
• La batterie (les batteries ou le bloc-batterie) ne
doit pas être exposée à une chaleur excessive
telle que des feux ouverts ou d’autres sources de
chaleur directe.
• Avant de faire fonctionner ce système, vérier que
sa tension est identique à celle de l’alimentation
électrique locale.
• Ne pas placer cet appareil à proximité de champs
magnétiques puissants.
• Ne pas placer cet appareil sur l’amplicateur ou
le récepteur.
• Si un objet solide ou du liquide tombe dans le
système, débrancher le système et le faire vérier
par un personnel qualié avant de le remettre en
marche.
• Ne pas tenter de nettoyer l’appareil avec
des solvants chimiques car cela pourrait en
endommager la surface. Utiliser un chiffon
propre, sec ou légèrement humide.
• Pour débrancher la che du cordon d’alimentation
de la prise murale, toujours tirer directement sur
la che, ne jamais tirer sur le cordon.
• Tout changement ou modification de cet
appareil non expressément approuvé par la
partie responsable de la conformité annulera le
droit de l’utilisateur d’utiliser l’appareil.
• L’étiquette des caractéristiques nominales est
collée sur la face inférieure ou arrière de l’appareil.
Fabriqué sous licence de Dolby Laboratories. Dolby,
Dolby Audio et le symbole avec deux D sont des
marques déposées de Dolby Laboratories.
Les marques et logos Bluetooth sont des marques
déposées appartenant à Bluetooth SIG, Inc.

5
FR
TélécommandeUnité principale
• La conception et les spécications sont sujettes à changement sans préavis.
Contenu de l’emballage
Manuel d’utilisation / Guide de démarrage rapide
2 × piles R03 (taille AAA)
Câble HDMI Cordon d’alimentation
secteur EU
Kit du support mural
