Hitachi RAS-24G1R User manual

– 1 –
ENGLISH
INDOOR UNIT/OUTDOOR UNIT
INDOOR UNIT
OUTDOOR UNIT
Instruction manual Page 1~18
To obtain the best performance and ensure years
of trouble free use, please read this instruction
manual completely.
Bedienungsanleitung Seite 19~36
Bitte lesen Sie diese Bedienungsanleitung
aufmerksam durch, um durch richtige Bedienung
jahrelangen und störungsfreien Betrieb zu
gewährleisten.
Mode d’emploi Page 37~54
Des performances optimales et un fonctionnement
à long terme seront assurés en appliquant les
présentes instructions aprés avoir entierement lu ce
mode d’emploi.
Manuale di istruzioni Pag. 55~72
Per ottenere le migliori prestazioni e la massima
affidabilità nel tempo, leggere con cura le seguenti
istruzioni.
Manual de instrucciones Página 73~90
Para obtener el mejor funcionamiento y asegurar
años de uso libre de problemas, lea cuidadosamente
este manual de instrucciones.
Manual de instruções página 91~108
A fim de obter o melhor desempenho e garantir
anos de uso sem problemas, leia completa e
cuidadosamente este manual de instruções.
HITACHI
RAS-24G1R
RAC-24G1
MODEL
RAS-24G1R/RAC-24G1
SPLIT TYPE

– 2 –
!
SAFETY PRECAUTION
●Please read the “Safety Precaution” carefully before operating the unit to ensure correct
usage of the unit.
●Pay special attention to signs of “ Warning” and “ Caution”. The “Warning” section
contains matters which, if not observed strictly, may cause death or serious injury. The
“Caution” section contains matters which may result in serious consequences if not observed
properly. Please observe all instructions strictly to ensure safety.
●“ ” sign in attached figure indicates prohibition.
●Please keep this manual after reading.
WARNING
PRECAUTIONS DURING INSTALLATION
●Please ask your sales agent or qualified technician for the installation
of your unit. Water leakage, short circuit or fire may occur if you install
the unit yourself.
●Please use earth line.
Do not place the earth line near water or gas pipes, lightning-conductor,
or the earth line of telephone. Improper installation of earth line may
cause electric shock.
●A circuit breaker should be installed depending on the mounting site of
the unit. Without a circuit breaker, the danger of electric shock exists.
●Do not install near location where there is flammable gas. The outdoor
unit may catch fire if flammable gas leaks around it.
●Please ensure smooth flow of water when installing the drain hose.
CAUTION
!
!
PRECAUTIONS DURING SHIFTING OR MAINTENANCE
PRECAUTIONS DURING OPERATION
●Avoid an extended period of direct air flow for your health.
W
A
R
N
I
N
G
!
●Should abnormal situation arises (like burning smell), please stop operating
the unit and turn off the circuit breaker. Contact your agent. Fault, short circuit
or fire may occur if you continue to operate the unit under abnormal situation.
●Please contact your agent for maintenance. Improper self maintenance may
cause electric shock and fire.
●Please contact your agent if you need to remove and reinstall the unit.
Electric shock or fire may occur if you remove and reinstall the unit yourself
improperly.
WARNING
!
●Do not put objects like thin rods into the panel of blower and suction side
because the high-speed fan inside may cause danger.
●During thunder storm, disconnect and turn off the circuit breaker.
●Do not use any conductor as fuse wire, this could cause fatal accident.
!

– 3 –
ENGLISH
PRECAUTIONS DURING OPERATION
●The product shall be operated under the manufacturer specification and
not for any other intended use.
●Do not attempt to operate the unit with wet hands, this could cause fatal
accident.
●When operating the unit with burning equipments, regularly ventilate the
room to avoid oxygen insufficiency.
●Do not direct the cool air coming out from the air-conditioner panel to face
household heating apparatus as this may affect the working of apparatus
such as the electric kettle, oven etc.
●Do not place plants directly under the air flow as it is bad for the plants.
●Please ensure that outdoor mounting frame is always stable, firm and
without defect. If not, the outdoor unit may collapse and cause danger.
●Do not splash or direct water to the body of the unit when cleaning it as this
may cause short circuit.
●Do not put water container (like vase) on the indoor unit to avoid water
dripping into the unit. Dripping water will damage the insulator inside the
unit and causes short-circuit.
●When operating the unit with the door and windows opened, (the room humidity is always above
80%) and with the air deflector facing down or moving automatically for a long period of time,
water will condense on the air deflector and drips down occasionally. This will wet your furniture.
Therefore, do not operate under such condition for a long time.
●If the amount of heat in the room is above the cooling capability of the unit (for example: more
people entering the room, using heating equipments and etc.), the preset room temperature
cannot be achieved.
●Do not climb on the outdoor unit or put objects on it.
●Please switch off the unit and turn off the circuit breaker during cleaning, the
high-speed fan inside the unit may cause danger.
●Turn off the circuit breaker if the unit is not to be operated for a long period.
C
A
U
T
I
O
N
!

– 4 –
INDOOR UNIT
NOTE
(1) Installation and the electrical connection of the units shall be performed only by authorized service
personnel.
(2) Only the outside unit part is splash-proofed.
(3) 3.GSGV (Acoustic noise information)
The maximum sound pressure level is less than 70dB (A) (maximum limited level according to ISO/DIS
3989, IEC 704-1).
1090mm (4215/16 inch)
810mm (317/8inch)
295mm (115/8inch)
620mm (2413/32 inch)
185mm (79/32 inch)
350mm (13 25/32 inch)
WIDTH HEIGHT DEPTH
RAS-24G1R
RAC-24G1
HITACHI
Cabinet
Discharge Grille
Remote Controller ●
OUTDOOR UNIT
Suction Grille
Air Filter
Air Deflectors
Front Cover

–5 –
ENGLISH
PUSH PUSH
INDOOR UNIT CONTROL PANEL
INDOOR UNIT INDICATORS
●OPERATION lamp
(This lamp lights during operation)
●TIMER lamp
(This lamp lights when the timer is working)
●DRY lamp
(This lamp lights during dehumidifying
operation)
●FILTER lamp
When the device is operated for a total of
about 100 hours, the Filter lamp lights to
indicate that it is time to clean the filter. The
lamp goes out when the POWER SWITCH
set to OFF and ON again.
●Press the mark “PUSH”on the left and right
sides of the suction grille to open it.
●After the work is finished, slightly lift the suction
grille and then close it.
Press the mark “PUSH”on the left and right
sides (marked ●) and center (marked O) on the
suction grille to fix it securely.
●TEMPORARY SWITCH
Use this switch to start and stop when the remote
controller does not work.
●By setting the temporary switch, the operation
is done in previously set operation mode.
●When the operation is done using the
temporary switch after the power source is
turned off and turn on again, the operation is
done in automatic mode.
●POWER SWITCH

–6 –
NAMES AND FUNCTIONS OF REMOTE CONTROL UNIT
■This controls the operation function and timer setting of the room air conditioner. The range of
control is about 4 meters. If indoor lighting is controlled electronically, the range of control may be
shorter.
Precautions for Use
●Do not put the remote controller in direct
sunlight and high temperature.
●Do not drop it on the floor, and protect
it from water.
●If you press the FUNCTION selector
button during operation, the air
conditioner may stop for about 3 minutes
for protection before you can start it
again. (unless you turn off and on again
the power source)
You can use the remote controller by fixing it on the
wall with the accessory parts.
●Before fixing it,
make sure the
unit can be
controlled by the
remote control
unit at the fixing
position.
REMOTE
CONTROLLER
HOLDER
C
˚
Hr.
HITACHI
°C
ON/OFF Button
Press this button to start operation.
Press it again to stop operation.
FUNCTION Button
Select the operation mode.
(Page 10)
SLEEP Button
Use this button to set the sleep
timer. (Page 8)
Reserve Button
Timer setting reservation.
OFF TIMER Button
Select the turn OFF time.
ON TIMER Button
Select the turn ON time.
Transmission Sign
The transmission sign blinks
when a signal has been send.
TEMPERATURE Button
Room temperuture setting.
Value will change quicker when
keep pressing.
(Page 7)
FAN SPEED Button
Select the fan speed for
cooling and circulation mode.
(Page 10)
AUTO SWING Button
Control the angle of the
horizontal air deflector.
( Page 12)
CANCEL Button
Cancel timer reservation.
Signal Transmission

–7 –
ENGLISH
AUTOMATIC OPERATION
■The device will automatically determine the operation mode either COOL or DEHUMIDIFY, depending
on the initial room temperature.
1
Press the (START/STOP) button
●Operation start with a “beep”.
Press the (START/STOP) button
●Please make sure you have been selected the (Automatic) mode
by use the (FUNCTION) Button.
●The fan speed selector does not work at this operation.
STOP

Press the (ROOM TEMPERATURE) button
●Temperature setting change by 1°C for each 1 time press.
Up
Down
●You can raise or lower the temperature setting by a maximum of
3°C.
●The display does not indicate the preset temperature in the Automatic
mode. Device will receive the setting by a “beep”.
■You can slightly adjust the room temperature.
1
°C
°C
■CONDITION OF AUTOMATIC OPERATION
●The selected mode of operation will not change during the operation even though the room
temperature change.
Over 27°C COOL
16 ~ 27°C
FUNCTION
27°C
Slightly lower than the
room temperature QUIET
FAN SPEED
HIGH at start, LOW after
the preset temperature is
reached
DEHUMIDIFY
-
INITIAL ROOM
TEMPERATURE (APPROX.)
TEMPERATURE
SETTING
HITACHI
°C
HITACHI
°C
▲ ▲
-

–8 –
CIRCULATION OPERATION
■When the room temperature is higher than the thermostat set temperature, only the fan operates to
circulate the upper hotter air downwards. This makes temperature distribution of the room evenly at
heating.
1
Press the (START/STOP) button
●Operation start with a signal received sound “beep”.
Press the (START/STOP) button
●Make sure you have been select the (Circulate) mode by using
the (FUNCTION) Button.
●You can select the fan speed and desired temperature.
●This operation is useful in winter when using other heating equipment.
STOP

HITACHI
°C
HOW TO SET THE SLEEP TIMER
Mode
Sleep timer
Indication
1 hour 2 hours 3 hours 7 hours
Sleep timer off
44 44
1
Sleep Timer: The device will continue working for the designated
number of hours and then turn off.
Point the signal window of the remote controller toward the indoor
unit, and press the SLEEP button.
The timer information will be displayed on the remote controller.
The TIMER lamp lights with a beep from the indoor unit.
How to Cancel Reservation
Point the signal window of the remote controller toward the indoor unit, and press the (CANCEL)
button.
The (RESERVED) sign goes out with a beep and the (TIMER) lamp turns off on the indoor unit.
NOTE
If you set the sleep timer when the off-timer or
on/off-timer has been set earlier, the sleep timer
becomes effective instead of the off- or on/off-
timer set earlier.
Example: Setting 3 hours
sleep time.
Hr.
HITACHI
°C

–9 –
ENGLISH
Cooling
“”
and
dehumidifying
“”
Explanation of the sleep timer
The device will control the FAN SPEED and room temperature automatically
so as to be quiet and good for people’s health.
You can set the sleep timer to turn off after 1, 2, 3 or 7 hours. The FAN
SPEED and room temperature will be controlled as shown below.
Function Operation
The settings of room temperature and circulation are not varied.
The FAN SPEED will be set to
LOW immediately.
Fan
“”
Operation with the sleep timer

Sleep
timer set
30 minutes later 3 hours later
7 hours later
2 hours
later
6 hours
later

–10 –
MANUAL OPERATION [Cooling ●Dehumidify ●Circulation]
■Please use under below condition when you want to set the function mode, room temperature and
fan speed by manually.
DEHUMIDIFYING
Room Temperature 16°C above
COOLING
Outdoor Temperature 22-42°C
1
OPERATION MODE SELECTION
●Every time you press the button, the mode will change as the below
sequence
(Auto) [(Cool) [(Dehumidify) [(Circulation)

4
Press the (START/STOP) button
●Operation start with a signal received sound “beep”.
Press the (START/STOP) button
●As the settings are stored in memory in the remote control unit, you
only have to press the (Start/Stop) button next time.
STOP
2
ROOM TEMPERATURE SETTING
Up
Down
●The cooling operation does not start if the
temperature setting is higher than the current
room temperature.
°C
Dehumidify 16~26°C
Cooling 25~28°C
▲ ▲
3
FAN SPEED SETTING
●Every time you press the button, fan speed will change as the below sequence.
●COOLING
CIRCULATION
NOTE
(Auto) : The FAN SPEED is HIGH at first and varies to MED or LOW
automatically when the preset temperature has been reached.
●DEHUMIDIFYING : LOW (FIXED)
: ( )
}
Dehumidify Function
When the room temperature is higher than the temperature setting: The device will dehumidify the room,
reducing the room temperature to the preset level.
When the room temperature is lower than the temperature setting: Dehumidifying will be performed with
the room temperature set slightly lower than the current room temperature, whatever the temperature
setting. The function will stop (the indoor unit will stop emitting air) as soon as the room temperature
becomes lower than the setting.
:AUTO [HIGH [MED [LOW
:( [[[)
HITACHI
°C
HITACHI
°C
■Recommend Temperature
HITACHI
°C
HITACHI
°C
