Hitachi CU-UHD4000-S7 User manual

CAMERA CONTROL UNIT
CU-UHD4000-S7
OPERATING INSTRUCTIONS
Please read these additional Information and operating instructions carefully for
proper operation and keep them for future reference.
Additional Information

1
New Functions
The camera control unit CU-UHD4000-S7 has the additional new functions to the
standard model by connection with the SK-UHD4000-S7 and CA-UHF4000-S7.
●Two 12G-SDI outputs for 4K signal
●Simultaneous 2K SDR and 4K HDR signal outputs
●Independent 2K DTL function
●BT.2020 matrix function for 4K signal
●HD output signal format display on Color Bars
●Moving Color Bars
●Audio test tones (400Hz & 1000Hz) on Color Bars
●CAM ID SUB display with up to twenty characters on Color Bars
●Return SDI signal with embedded audio can be output at the camera head and be
mixed in the intercom headset
●Optical level of both of the camera head and CCU display on PIX OUT
These New Functions are available with the following version or later version.
CPU software version: V1.00C or later version.
FPGA software version: V4.200 or later version.
Note
SD-SDI outputs are eliminated from the standard model specifications.

2
Facility names and functions (Rear)
13
2
4K 12G OUTPUT connectors (BNC)
4K video signal is fed out through single BNC cable.
4K 3G OUTPUT connectors (BNC)
Outputs 4K video signals. Each 4K video is mapped into four 3G-SDI/HD-SDI signals or two 3G-SDI
signals.
HD SDI connectors (BNC)
Six (6) sets of HDTV SDI video signals are output.
The MENU and DIAGNOSTIC characters are superimposed on the PIX output.
In the table below, the signal outputs are selected via the CCU MENU.
Output Signals
SYSTEM FORMAT
59.94Hz
50.00Hz
29.97Hz
25.00Hz
23.98Hz
4K 3G
OUTPUT
Scanning
2160/59.94p
2160/50p
2160/29.97p
2160/25p
2160/23.98p
Signal
Link Quad (3Gx4) Quad (3Gx4)
Quad (1.5Gx4)
or
Dual (3Gx2)
Quad (1.5Gx4)
or
Dual (3Gx2)
Quad (1.5Gx4)
or
Dual (3Gx2)
Division
Square Div. or
2-Sample
Interleave Div.
Square Div. or
2-Sample
Interleave Div.
Square Div. or
2-Sample
Interleave Div.
Square Div. or
2-Sample
Interleave Div.
Square Div. or
2-Sample
Interleave Div.
3G-SDI
format
Level A or B Level A or B
Level B
(Dual link)
Level B
(Dual link)
Level B
(Dual link)
4K 12G
OUTPUT
Signal 12G-SDI 12G-SDI 6G-SDI 6G-SDI 6G-SDI
HD
OUTPUT
HD
Down-
Convert
1080/59.94p,
1080/59.94i,
720/59.94p,
1080/50p,
1080/50i,
720/50p,
1080/59.94p,
1080/59.94i,
1080/29.97PsF,
720/59.94p,
1080/50p,
1080/50i,
1080/25PsF,
720/50p,
1080/59.94p,
1080/59.94i,
1080/23.98PsF,
720/59.94p,
HD Cut-Out
1080/59.94p,
1080/59.94i
1080/50p,
1080/50i
1080/29.97p 1080/25p 1080/23.98p
1
2
3

3
Facility names and functions (Rear)
4K 12G OUTPUT / 4K 3G signal output combinations
Note-1: To use both 12G output and Quad output simultaneously,
set Image Division to 2-Sample Interleave (2SI) and 3G-SDI Format to Level A (A) in
OUTPUT SELECT menu in the CCU.
Note-2: To use both 6G output and Dual/Quad output simultaneously,
set Image Division to 2-Sample Interleave (2SI) and 3G-SDI Format to DUAL in
OUTPUT SELECT menu in the CCU.

4
Function menu
New functions are in the additional menu.
CCU MENU structure
■ＣＵ ＦＵ ＮＣＴ ＩＯＮ ＜＞
ＢＵＺＺＥＲ ：Ｅ ＮＡＢＬＥ
ＳＤＩ ＡＵＤＩＯ ：Ｏ ＦＦ
ＣＣＵ ＩＤ ： １
ＣＡＢＬＥ ＭＯＤＥ ：Ｈ ＹＢＲＩＤ
ＰＡＲＡ ＭＯＤＥ ：Ｏ ＦＦ
ＳＹＳ ＦＯＲＭＡＴ ＞２１６０ｐ
：５９．９４Ｈｚ
ＴＩＭＥ／ＤＡＴＥ： ＞１７．１０．３０
１２：００
■ＯＵＴＰＵ Ｔ Ｓ ＥＬＥＣＴ ＜＞
４Ｋ ＯＵＴＰＵＴ ：２ＳＩ ［Ａ］
４Ｋ ＣＯＬＯＲ ：ＢＴ．７０９
ＨＤ１［１／２］ ：１０８０ｉ
ＨＤ２［１／２］ ：１０８０ｉ
ＷＦＭ／ＰＩＸ ：１０８０ｉ
ＨＤ４［１／２］ ：１０８０ｉ
ＣＵＴ－ＯＵＴ ＰＯ ＳＩＴ ＩＯＮ
Ｈ ＰＨＡＳＥ ： ０
Ｖ ＰＨＡＳＥ ： ０
ＨＤ ＦＩＬＴＥＲ： ＭＩＤ ＬＯＷ
■ＲＥＴＵＲ Ｎ Ｓ ＥＬＥＣＴ ＜＞
ＲＥＴ．ＣＨ ＳＥ ＬＥＣＴ
ＣＨ１ ：ＲＥＴ ．Ａ１
ＣＨ２ ：ＲＥＴ ．Ａ２
ＣＨ３ ：ＲＥＴ ．Ａ３
ＣＨ４ ：ＲＥＴ ．Ａ４
ＣＡ ＨＤ－ＳＤＩ２ ：ＲＥＴ ．Ｂ１
ＡＳＳＩＧＮＭＥＮＴ ：＞
■ＭＩＣ Ｇ ＡＩＮ ＜＞
ＭＩＣ１ ：－６０ｄＢ
ＭＩＣ２ ：－６０ｄＢ
ＭＩＣ ＲＥＭＯＴＥ ：Ｓ ＴＡＮＤＡＲＤ
■ＳＹＳ Ｆ ＯＲＭ ＡＴ ＜
□５９．９４Ｈｚ
□５０．００Ｈｚ
□２９．９７Ｈｚ
□２５．００Ｈｚ
□２３．９８Ｈｚ
ＳＥＴ ＤＡＴＡ ：Ｐ ＵＳＨ＜＋＞
■ＡＳＳＩＧ ＮＭＥ ＮＴ ＜
ＳＥＬＥＣＴ ＴＹ ＰＥ
ＲＥＴ Ａ１ ：１０８０ｉ／ ＰｓＦ／Ｐ
ＲＥＴ Ａ２ ：１０８０ｉ／ ＰｓＦ／Ｐ
ＲＥＴ Ａ３ ：１０８０ｉ／ ＰｓＦ／Ｐ
ＲＥＴ Ａ４ ：１０８０ｉ／ ＰｓＦ／Ｐ
ＲＥＴ Ｂ１ ：１０８０ｉ／ ＰｓＦ／Ｐ
ＲＥＴ Ｂ２ ：１０８０ｉ／ ＰｓＦ／Ｐ
■ＫＮＥＥ／ ＣＬＩ Ｐ（ＨＤ） ＜
＊ＴＯＴＡＬ ＫＮＥＥ ： ２
＊Ｒ ＫＮＥＥ ： ０
＊Ｂ ＫＮＥＥ ： ０
＊ＴＯＴＡＬ ＳＬＯＰ Ｅ： １３
＊Ｒ ＳＬＯＰＥ ： ０
＊Ｂ ＳＬＯＰＥ ： ０
＊ＫＮＥＥ ：Ｏ Ｎ
＊ＷＨＩＴＥ ＣＬＩＰ ： ０
＊ＷＨＩＴＥ ＣＬＩＰ ：Ｏ Ｎ
■ＰＩＸ Ｄ ＩＳＰ ＬＡＹ［ＢＡＲＳ］ ＜＞
ＣＡＭ ＩＤ ：Ｏ Ｎ
ＣＡＭ ＩＤ ＳＵＢ ：＞
ＣＣＵ ＩＤ ：Ｏ Ｎ
ＣＣＵ ＩＰ ：Ｏ Ｎ
ＳＤＩ ＦＯＲＭＡＴ ：Ｏ Ｎ
ＯＵＴＰＵＴ ：Ａ ＬＬ
■ＣＯＬＯＲ ＢＡ ＲＳ ＜＞
ＴＥＳＴ ＴＯＮＥ ：Ｏ ＦＦ
ＭＩＣ１［Ｌ］ ：１ＫＨｚ
ＭＩＣ２［Ｒ］ ：１ＫＨｚ
ＭＯＶＩＮＧ ：Ｏ ＦＦ
Ｈ ＳＰＥＥＤ ：２
Ｖ ＳＰＥＥＤ ：２
■ＨＤＲ／Ｓ ＤＲ ＜＞
４Ｋ ＯＵＴＰＵＴ ：ＳＤＲ
＊ＨＤ ＯＵＴＰＵＴ ：Ｓ ＤＲ
ＨＤＲ ＳＥＬＥＣＴ ：Ｈ ＬＧ６００
－ＨＤ ＳＤＲ－
＊ＧＡＩＮ ： ０．０ｄＢ
＊ＢＬＡＣＫ ： ０
ＫＮＥＥ／ＣＬＩＰ ：＞
■ＳＹＳＴＥ Ｍ Ｔ ＩＭＩＮＧ ＜＞
ＧＬ Ｈ ＰＨＡＳＥ ：１０８［ １７２８］
■ＰＩＸ Ｄ ＩＳＰ ＬＡＹ［ＣＡＭＥＲＡ］ ＜＞
ＮＤ ＦＩＬＴＥＲ ：Ｏ Ｎ
ＣＣ ＦＩＬＴＥＲ ：Ｏ Ｎ
ＩＲＩＳ ：Ｏ Ｎ
ＣＵＴ ＯＵＴ ：Ｏ ＦＦ
ＣＡＢＬＥ ＣＯＮＤ ．：Ｏ Ｎ［ＧＲＡＰＨ］
■ＴＩＭＥ／ ＤＡＴ Ｅ ＜
ＤＡＴＥ ＤＩＳＰ ：Ｙ ＭＤ
ＴＩＭＥ ＤＩＳＰ ：Ｏ Ｎ
ＹＥＡＲ ：１７
ＭＯＮＴＨ ：１０
ＤＡＹ ：３０
ＨＯＵＲ ：１２
ＭＩＮＵＴＥ ：３０
ＳＥＴ ＤＡＴＡ ：Ｐ ＵＳＨ＜＋＞
■ＣＡＭ Ｉ Ｄ Ｓ ＵＢ ＜
［ＣＨＡＲＡＣＴＥＲ ＥＤ ＩＴ］
＿
ＣＨＡＲＡ ＴＹＰＥ ：Ｃ ＡＰＩＴＡＬ
ＣＨＡＲＡＣＴＥＲ ：Ａ
ＳＥＴ ：Ｐ ＵＳＨ ＞
ＩＮＳＥＲＴ ：Ｐ ＵＳＨ ＞
ＢＡＣＫ ＳＰＡＣＥ ：Ｐ ＵＳＨ ＞
ＡＬＬ ＣＬＥＡＲ ：Ｐ ＵＳＨ ＜＋＞
■ＨＤ ＤＴ Ｌ１ ＜＞
ＨＤ ＤＴＬ ：Ｏ Ｎ
ＬＥＶＥＬ ： ０
Ｈ ＧＡＩＮ ： －８０
Ｖ ＧＡＩＮ ： －８０
Ｈ ＣＲＩＳＰ ：－１２ ０
Ｖ ＣＬＩＳＰ ：－１２ ０
ＤＴＬ ＦＲＥＱ ：１７ＭＨｚ
ＬＥＶＥＬ ＤＥＰ ： ０
■ＨＤ ＤＴ Ｌ２ ＜＞
ＤＴＬ ＫＮＥＥ ：Ｏ Ｎ
ＷＨＩＴＥ ： １１ ０
ＢＬＡＣＫ ： １１ ０
ＫＮＥＥ ＤＴＬ ： ０
ＳＫＩＮ ＤＴＬ ：Ｏ ＦＦ
ＣＨ ＳＥＬＥＣＴ ：Ｃ Ｈ１
ＣＨ１ ＬＥＶＥＬ ： ０
ＣＨ２ ＬＥＶＥＬ ： ０
ＳＫＩＮ ＧＡＴＥ ：Ｏ ＦＦ
ＣＨ ＳＥＬＥＣＴ ：Ｃ Ｈ１
■ＬＡＮ Ｓ ＥＴＴ ＩＮＧ ＜＞
ＩＰ ：１９ ２．１６８. １． １０
ＣＯＮＦ＞：１９ ２．１６８. １． １０
ＳＵＢＮＥＴ ：２５ ５．２５５.２５５． ０
ＣＯＮＦ＞：２５ ５．２５５.２５５． ０
ＧＡＴＥＷＡＹ： ０． ０. ０． ０
ＣＯＮＦ＞： ０． ０. ０． ０
ＳＥＴ ：ＰＵ ＳＨ ＜＋＞
■ＩＰ ＳＥ ＴＴＩ ＮＧ ＜
ＩＰ ：１９ ２．１６８. １． １０
ＳＥＮＤ ：１９ ２．１６８. １． １０
ＥＤＩＴ
ＯＣＴＥＴ１：１９ ２
２：１６ ８
３： １
４： １０
ＳＥＮＤ ：ＰＵ ＳＨ ＜＋＞
■ＳＵＢＮＥ Ｔ Ｓ ＥＴＴＩＮＧ ＜
ＳＵＢＮＥＴ ：２５ ５．２５５.２５５． ０
ＳＥＮＤ ：２５ ５．２５５.２５５． ０
ＥＤＩＴ
ＯＣＴＥＴ１：２５ ５
２：２５ ５
３：２５ ５
４： ０
ＳＥＮＤ ：ＰＵ ＳＨ ＜＋＞
■ＧＡＴＥＷ ＡＹ ＳＥＴＴＩＮＧ ＜
ＧＡＴＥＷＡＹ： ０． ０. ０． ０
ＳＥＮＤ ： ０． ０. ０． ０
ＥＤＩＴ
ＯＣＴＥＴ１： ０
２： ０
３： ０
４： ０
ＳＥＮＤ ：ＰＵ ＳＨ ＜＋＞
The menus marked by the dotted lines are new or have been changed from the standard model.

5
Function menu
1. OUTPUT SELECT menu
■ＯＵＴＰＵＴ ＳＥＬＥＣＴ ＜＞
４Ｋ ＯＵＴＰＵＴ ：２ＳＩ［Ａ］
４Ｋ ＣＯＬＯＲ ：ＢＴ．７０９
ＨＤ１［１／２］ ：１０８０ｉ
ＨＤ２［１／２］ ：１０８０ｉ
ＷＦＭ／ＰＩＸ ：１０８０ｉ
ＨＤ４［１／２］ ：１０８０ｉ
ＣＵＴ－ＯＵＴ ＰＯＳＩＴＩＯＮ
Ｈ ＰＨＡＳＥ ： ０
Ｖ ＰＨＡＳＥ ： ０
ＨＤ ＦＩＬＴＥＲ ：ＭＩＤ ＬＯＷ
Item
Setting
Factory setting
Description
SYS FORMAT
59.94, 50.00
29.97, 25.00,
23.98
59.94, 50.00
29.97, 25.00,
23.98
4K OUTPUT
SQD[B], 2SI[B],
SQD[A], 2SI[A]
SQD[QUAD],
SQD[DUAL],
2SI[DUAL]
2SI[A]
2SI[DUAL]
Assigns output signal of 4K OUTPUT
connector. (*1)
SQD: Square division
2SI: 2-Sample Interleave division
A/B: SMPTE425M Level-A/B
QUAD/DUAL: Mapping link
4K COLOR
BT.709, BT.2020
BT.709
Sets the color matrix for 4K output only.
HD1[1/2]
1080p, 1080i,
720p,
CUT-OUT[p],
CUT-OUT[i]
1080p, 1080i,
1080PsF, 720p,
CUT-OUT
1080i
1080i
Assigns signal of HD1[1/2] connector.
HD2[1/2]
Assigns signal of HD2[1/2] connector.
HD4[1/2]
Assigns signal of HD4[1/2] connector.
WFM/PIX
1080p, 1080i,
720p
1080p, 1080i,
1080PsF, 720p
1080i
1080i
Assigns output signal of WFM/PIX
connectors.
CUT-OUT
POSITION
Specifies the position of HD screen cut
from 4K screen, when CUT-
OUT signal
is selected on HD1, 2, 4.
H PHASE
-120 to +120
0
Specifies horizontal phase.
V PHASE
-135 to +135
0
Specifies vertical phase.
HD FILTER
HIGH, MID HIGH,
MID LOW, LOW
MID LOW
Changes frequency of low-pass filter for
HD down-converter.
2. HDR/SDR menu
■ＨＤＲ／ＳＤＲ ＜＞
４Ｋ ＯＵＴＰＵＴ ：ＳＤＲ
＊ＨＤ ＯＵＴＰＵＴ ：ＳＤＲ
ＨＤＲ ＳＥＬＥＣＴ ：ＨＬＧ６００
－ＨＤ ＳＤＲ－
＊ＧＡＩＮ ： ０．０ｄＢ
＊ＢＬＡＣＫ ： ０
ＫＮＥＥ／ＣＬＩＰ ：＞
Item Setting Factory
setting
Description
4K OUTPUT
SDR, HDR
SDR
Sets SDR/ HDR for 4K output.
HD OUTPUT
Note-1
SDR, HDR
SDR
Sets SDR/ HDR for HD output.
HDR SELECT
HLG600,
HLG1200,
HPQ
HLG600
Sets HDR curve.
HD SDR
GAIN
0.0 to -18dB,
0.1 steps
0dB
Adjusts SDR signal level only when
setting simultaneous SDR and HDR
output.
BLACK
-128 to 127
ON
Adjusts BLACK level of SDR signal
only when setting simultaneous SDR
and HDR output.
KNEE/CLIP
Moves to KNEE/CLIP (HD) menu.
Note-1 When selecting SDR as the 4K signal output mode, HDR is NOT
AVAILABLE on the HD outputs.

6
Function menu
3. KNEE/CLIP (HD) menu
KNEE/CLIP (HD) menu is enabled only when setting simultaneous SDR and HDR are output.
■ＫＮＥＥ／ＣＬＩＰ（ＨＤ） ＜
＊ＴＯＴＡＬ ＫＮＥＥ ： ２
＊Ｒ ＫＮＥＥ ： ０
＊Ｂ ＫＮＥＥ ： ０
＊ＴＯＴＡＬ ＳＬＯＰＥ： １３
＊Ｒ ＳＬＯＰＥ ： ０
＊Ｂ ＳＬＯＰＥ ： ０
＊ＫＮＥＥ ：ＯＮ
＊ＷＨＩＴＥ ＣＬＩＰ ： ０
＊ＷＨＩＴＥ ＣＬＩＰ ：ＯＮ
Item
Setting
Initial
setting
Description
TOTAL KNEE
-128 to +127
2
Adjusts Total Knee level
R KNEE
-128 to +127
0
Adjusts R individual channel knee level
B KNEE
-128 to +127
0
Adjusts B individual channel knee level
TOTAL SLOPE
-128 to +127
13
Adjusts Total slope level
R SLOPE
-128 to +127
0
Adjusts R individual channel slope level
B SLOPE
-128 to +127
0
Adjusts B individual channel slope level
KNEE
ON,OFF
ON
Knee function ON and OFF
WHITE CLIP
-128 to +127
0
Adjusts White Clip level
WHITE CLIP
ON,OFF
ON
White Clip function ON and OFF
4. SYSTEM TIMING menu
■ＳＹＳＴＥＭ ＴＩＭＩＮＧ ＜＞
ＧＬ Ｈ ＰＨＡＳＥ ：１０８［１７２８］
Item
Setting
Initial
setting
Description
GL H PHASE
-128(-2048) to
+127(2047)
108 (1728)
Adjusts whole system phase against
genlock signal.
3. PIX DISPLAY [CAMERA] menu
■ＰＩＸ ＤＩＳＰＬＡＹ［ＣＡＭＥＲＡ］ ＜＞
ＮＤ ＦＩＬＴＥＲ ：ＯＮ
ＣＣ ＦＩＬＴＥＲ ：ＯＮ
ＩＲＩＳ ：ＯＮ
ＣＵＴ ＯＵＴ ：ＯＦＦ
ＣＡＢＬＥ ＣＯＮＤ ：ＯＮ［ＧＲＡＰＨ］
Item
Setting
Initial
setting
Description
ND FILTER
OFF, ON
ON
Displays ND filter type on PIX OUT.
CC FILTER
OFF, ON
ON
Displays Color Temperature Correction
filter type on PIX OUT.
IRIS
OFF, ON
ON
Displays F-number of lens iris on PIX
OUT.
CUT OUT
OFF, WIRE,
CORNER
OFF
Displays marker of CUT-OUT area, when
CUT-OUT signal is selected on HD/SD1,2.
OFF
: No display
WIRE
: Displays the area with rectangle
CORNER
: Displays four corners of the
area
CABLE COND.
OFF
ON[NUMBER],
ON[GRAPH]
OFF
Sets the display for the receiving optical
level of both the camera head and CCU.
OFF
: No display
ON[NUMBER]
: Data[0 to 100] display
ON[GRAPH]: Four segments display
ＣＡＭ［■■■■］ ＣＣＵ［■■■■］
４．１／６４ＮＤ Ｂ．３２００Ｋ Ｆ８．０
CAM&CCU Optical Level
Segment indicator is same as CCU LED optical indicators.
CABLE COND.:ON[GRAPH]
CABLE COND.:ON[NUMBER]
ＣＡＭ［１００］ ＣＣＵ［１００］
４．１／６４ＮＤ Ｂ．３２００Ｋ Ｆ８．０
CAM&CCU Optical Level

7
Function menu
4. PIX DISPLAY [BARS] menu
■ＰＩＸ ＤＩＳＰＬＡＹ［ＢＡＲＳ］ ＜＞
ＣＡＭ ＩＤ ：ＯＮ
ＣＡＭ ＩＤ ＳＵＢ ：＞
ＣＣＵ ＩＤ ：ＯＮ
ＣＣＵ ＩＰ ：ＯＮ
ＳＤＩ ＦＯＲＭＡＴ ：ＯＮ
ＯＵＴＰＵＴ ：ＡＬＬ
Item
Setting
Initial
setting
Description
CAM ID OFF, ON ON Displays Camera ID number on color
bars.
CAM ID SUB
Moves to CAM ID SUB menu.
CCU ID
OFF, ON
ON
Displays CCU ID on color bars.
CCU IP
OFF, ON
ON
Displays CCU IP address on color bars.
SDI FORMAT PFF, ON ON Displays SDI FORMAT information on
color bars.
OUTPUT ALL, PIX ALL
Selects output channels that display CAM
ID/CCU ID/CCU IP on color bars.
5. CAMERA ID SUB menu
CAMERA ID SUB with up to twenty characters is set in this menu.
■ＣＡＭ ＩＤ ＳＵＢ ＜
［ＣＨＡＲＡＣＴＥＲ ＥＤＩＴ］
＿
ＣＨＡＲＡ ＴＹＰＥ ：ＣＡＰＩＴＡＬ
ＣＨＡＲＡＣＴＥＲ ：Ａ
ＳＥＴ ：ＰＵＳＨ ＞
ＩＮＳＥＲＴ ：ＰＵＳＨ ＞
ＢＡＣＫ ＳＰＡＣＥ ：ＰＵＳＨ ＞
ＡＬＬ ＣＬＥＡＲ ：ＰＵＳＨ ＜＋＞
Item
Setting
Initial
setting
Description
[CHARACTER
EDIT]
Moves the cursor by and buttons
to edit character.
CHARA TYPE CAPITAL
SMALL
NUMBER
SYMBOL
CAPITAL Selects a kind of character.
CAPITAL: A to Z
SMALL: a to z
NUMBER: 0 to 9
SYMBOL: _ ! % ’ [ ] * + , - . / : ; < > ?
CHARCTER
A
Selects character by and buttons.
SET
Pushes button to set the character.
INSERT
Moves the cursor to the insert position
and then pushes button to insert.
BACK SPACE Pushes button to delete the left
character of the cursor.
ALL CLEAR
Pushes and buttons
simultaneously to delete all characters.
PIX OUT display on BAR
Signal Format
CAM ID SUB
CAM ID
CCU IP address
ＣＡＭ［■■■■] ＣＣＵ［■■■■]
１０８０／５９．９４i
ａｂｃｄｅＡＢＣＤＥ０１２３４＿：＊／ー
ＣＡＭ ＩＤ： １ ＣＣＵ ＩＤ： １
ＣＣＵ ＩＰ：１９２．１６８． １． １０
CCU ID

8
Function menu
6. COLOR BARS menu
■ＣＯＬＯＲ ＢＡＲＳ ＜＞
ＴＥＳＴ ＴＯＮＥ ：ＯＦＦ
ＭＩＣ１［Ｌ］ ：１ＫＨｚ
ＭＩＣ２［Ｒ］ ：１ＫＨｚ
ＭＯＶＩＮＧ ：ＯＦＦ
Ｈ ＳＰＥＥＤ ：２
Ｖ ＳＰＥＥＤ ：２
Item
Setting
Initial
setting
Description
TEST TONE
OFF, ON
OFF
Audio test tone ON/OFF
MIC1[L]
400Hz, 1KHz
1KHz
Selects the test tone frequency for Lch.
MIC2[R]
400Hz, 1KHz
1KHz
Selects the test tone frequency for Rch.
MOVING
OFF, ON
OFF
Moving color bars ON/OFF
H SPEED -9 to 9 2 Adjusts the horizontal moving speed and
direction
(-): Left, (+): Right
V SPEED -9 to 9 2 Adjusts the vertical moving speed and
direction.
(-): Up, (+): Down
7. HD DTL1
■ＨＤ ＤＴＬ１ ＜＞
ＨＤ ＤＴＬ ：ＯＮ
ＬＥＶＥＬ ： ０
Ｈ ＧＡＩＮ ： －８０
Ｖ ＧＡＩＮ ： －８０
Ｈ ＣＲＩＳＰ ：－１２０
Ｖ ＣＬＩＳＰ ：－１２０
ＤＴＬ ＦＲＥＱ ：１７ＭＨｚ
ＬＥＶＥＬ ＤＥＰ ： ０
Item
Setting
Initial
setting
Description
DETAIL
ON,OFF
ON
Detail On and OFF
LEVEL
-128 to +127
0
Adjusts Detail level
H GAIN
-128 to +127
-80
Adjusts H. detail gain
V GAIN
-128 to +127
-80
Adjusts V. detail gain
H CRISP
-128 to +127
-120
Adjusts H detail crisp
V CRISP
-128 to +127
-120
Adjusts V detail crisp
DTL FREQ
13, 14, 15, 16,
17, 18, 19
17 MHz
Sets the boost frequency of detail.
LEVEL DEP
-128 to +127
0
Adjusts the level dependent of detail
8. HD DTL2
■ＨＤ ＤＴＬ２ ＜＞
ＤＴＬ ＫＮＥＥ ：ＯＮ
ＷＨＩＴＥ ： １１０
ＢＬＡＣＫ ： １１０
ＫＮＥＥ ＤＴＬ ： ０
ＳＫＩＮ ＤＴＬ ：ＯＦＦ
ＣＨ ＳＥＬＥＣＴ ：ＣＨ１
ＣＨ１ ＬＥＶＥＬ ： ０
ＣＨ２ ＬＥＶＥＬ ： ０
ＳＫＩＮ ＧＡＴＥ ：ＯＦＦ
ＣＨ ＳＥＬＥＣＴ ：ＣＨ１
Item
Setting
Initial
setting
Description
DTL KNEE
OFF, ON
ON
DETAIL KNEE
ON and OFF
WHITE
-128 to +127
110
Adjusts Positive limit of the detail level
BLACK
-128 to +127
110
Adjusts Negative limit of the detail level
KNEE DTL
-128 to +127
0
Adjusts the detail level in a highlight
knee area.
SKIN DTL
Note-1
ON, OFF
OFF
Skin tone Detail ON and OFF
CH SELECT
CH1,CH2,
CH1+2
CH1
Selects CH for skin tone detail
CH1 LEVEL
-128 to +127
0
Adjusts CH1 skin tone detail level
CH2 LEVEL
-128 to +127
0
Adjusts CH2 skin tone detail level
SKIN GATE
OFF, ON
OFF
Skin Tone Detail gate ON and OFF
CH SELECT
CH1, CH2
CH1
Selects the skin tone detail area where
gate marker is displayed.
Note-1 The HD signal SKIN-TONE DTL detection settings are adjusted in
the CAMERA HEAD MENU.

9
Specifications
■Input output signals (CU-UHD4000-S7)
Camera Control Unit CU-UHD4000-S7
4K 12G OUTPUT 1/2
12G-SDI or 6G-SDI
・2 Sample Interleave division
・2 channels embedded audio available
･12G-SDI: SMPTE ST 2082-1
・
6G-SDI: SMPTE ST 2081-1
BNC x2
4K 3G OUTPUT 1/2/3/4
3G-SDI/HD-SDI x4 or 3G-SDI x2
・Square Division or 2 Sample Interleave division
・2 channels embedded audio available
･3G-SDI：SMPTE424/425 Level-A/B
・
HD-SDI: SMPTE292M
BNC x4
HD OUT
HD1(1/2)
HD2(1/2)
HD4(1/2)
3G-SDI or HD-SDI
・Down-converted
(1080p/1080i/1080PsF/720p)
・HD Cut-out (1080p/1080i)
・2 channels embedded audio available
･3G-SDI：SMPTE424/425 Level-A
・
HD-SDI
：
SMPTE292M
BNC x6
(x2 + x2 + x2)
HD OUT
HD3 (WFM)
3G-SDI or HD-SDI
・Down-converted
(1080p/1080i/1080PsF/720p)
・2 channels embedded audio available
･3G-SDI：SMPTE424/425 Level-A
・
HD-SDI
：
SMPTE292M
BNC x1
HD OUT
HD3 (PIX)
3G-SDI or HD-SDI
・Down-converted
(1080p/1080i/1080PsF/720p)
・2 channels embedded audio available
･3G-SDI：SMPTE424/425 Level-A
・
HD-SDI
：
SMPTE292M
BNC x1
RET.A IN (1/2/3/4)
3G-SDI or HD-SDI
(1080p/1080i/1080PsF/ 720p)
･3G-SDI：SMPTE424/425 Level-A
・
HD-SDI
：
SMPTE292M
BNC x4
RET.B IN (1/2)
3G-SDI or HD-SDI
(1080p/1080i/1080PsF/ 720p)
･3G-SDI：SMPTE424/425 Level-A
・
HD-SDI
：
SMPTE292M
BNC x2

10
Camera Control Unit CU-UHD4000-S7
MIC OUT 1
0dBm/600Ω
XLR-3pin
MIC OUT 2
0dBm/600Ω
XLR-3pin
INTERCOM (HEAD SET)
0dBu MAX+15dB
XLR-5pin(Female)
Remote 1
1.5Vp-p
4pin
Remote 2
1.5Vp-p
4pin
Remote 3
RJ-45
COMMUNICATION
D-sub 25pin
・
INTERCOM
0dBm , 600Ω at 4Wire
0dBu or -15dBu ,200Ω at 2Wire
TALLY OUT(R/G)
Contact
D-sub 9pin
24Vdc, 10mA
WFM CONTROL
WFM 0-7 0/5V
D-sub 15pin
MIC REMOTE
MIC1,2 Gain
D-sub 15pin
TRUNK
RS-422 (150k baud)
(RS-232C : Option)
D-Sub 9 pin
