HX-RIO3 Series
Analog Input Module (RTD, TC)
RIO3-RTD / RIO3-TC
User Manual

2
HX-RIO3 Series
REVISION HISTORY
REV
PAGE
REMARKS
DATE
EDITOR
1.01
New Document
05 NOV 2020
(OPR), (PF)

3
HX-RIO3 Series
Table of Contents
1Important Notes ......................................................................................................................................... 4
1.1 Safety Instruction............................................................................................................................... 5
1.1.1 Symbols..................................................................................................................................... 5
1.1.2 Safety Notes .............................................................................................................................. 5
1.1.3 Certification................................................................................................................................ 5
2Analog Input Module List........................................................................................................................... 6
3Specification .............................................................................................................................................. 7
3.1 RIO3-RTD4T...................................................................................................................................... 7
3.1.1 Wiring Diagram.......................................................................................................................... 7
3.1.2 LED Indicator............................................................................................................................. 8
3.1.3 Channel Status LED .................................................................................................................. 8
3.1.4 Environment Specification......................................................................................................... 9
3.1.5 Specification............................................................................................................................. 10
3.1.6 Mapping Data into the Image Table......................................................................................... 11
3.1.7 Configuration Parameter –10 Bytes ....................................................................................... 12
3.1.8 Data Value............................................................................................................................... 13
3.2 RIO3-RTD8C ................................................................................................................................... 14
3.2.1 Wiring Diagram........................................................................................................................ 14
3.2.2 LED Indicator........................................................................................................................... 15
3.2.3 Channel Status LED ................................................................................................................ 15
3.2.4 Environment Specification....................................................................................................... 16
3.2.5 Specification............................................................................................................................. 17
3.2.6 Mapping Data into the Image Table......................................................................................... 18
3.2.7 Configuration Parameter –18 Bytes ....................................................................................... 19
3.2.8 Data Value............................................................................................................................... 20
3.3 RIO3-TC4T ...................................................................................................................................... 21
3.3.1 Wiring Diagram........................................................................................................................ 21
3.3.2 LED Indicator........................................................................................................................... 22
3.3.3 Channel Status LED ................................................................................................................ 22
3.3.4 Environment Specification....................................................................................................... 23
3.3.5 Specification............................................................................................................................. 24
3.3.6 Mapping Data into the Image Table......................................................................................... 26
3.3.7 Configuration Parameter –8 Bytes ......................................................................................... 27
3.3.8 Data Value............................................................................................................................... 28
4Dimension................................................................................................................................................ 29
4.1 10-Pts. Spring Type......................................................................................................................... 29
4.2 20-Pin Connector Type.................................................................................................................... 30
5Mounting.................................................................................................................................................. 31
5.1 I/O Inserting and Removing Devices............................................................................................... 31
5.2 RTB (Removable Terminal Block)................................................................................................... 32
6G-Bus Pin Description ............................................................................................................................. 33
7APPENDIX............................................................................................................................................... 34
7.1 Product List...................................................................................................................................... 34
7.2 Glossary........................................................................................................................................... 35

4
HX-RIO3 Series
1 Important Notes
Solid state equipment has operational characteristics differing from those of electromechanical equipment.
Safety Guidelines for the Application, Installation and Maintenance of Solid-State Controls describes some
important differences between solid state equipment and hard-wired electromechanical devices.
Because of this difference, and because of the wide variety of uses for solid state equipment, all persons
responsible for applying this equipment must satisfy themselves that each intended application of this
equipment is acceptable.
In no event will HITACHI be responsible or liable for indirect or consequential damages resulting from the use
or application of this equipment.
The examples and diagrams in this manual are included solely for illustrative purposes. Because of the many
variables and requirements associated with any installation, HITACHI cannot assume responsibility or liability
for actual use based on the examples and diagrams.
Warning!
✓If you don't follow the directions, it could cause a personal injury, damage to the equipment or
explosion
✓Do not assemble the products and wire with power applied to the system. Else it may cause an electric
arc, which can result into unexpected and potentially dangerous action by field devices. Arching is
explosion risk in hazardous locations. Be sure that the area is non-hazardous or remove system power
appropriately before assembling or wiring the modules.
✓Do not touch any terminal blocks or IO modules when system is running. Else it may cause the unit to an
electric shock or malfunction.
✓Keep away from the strange metallic materials not related to the unit and wiring works should be
controlled by the electric expert engineer. Else it may cause the unit to a fire, electric shock or
malfunction.
Caution!
✓If you disobey the instructions, there may be possibility of personal injury, damage to equipment
or explosion. Please follow below Instructions.
✓Check the rated voltage and terminal array before wiring. Avoid the circumstances over 50℃of
temperature. Avoid placing it directly in the sunlight.
✓Avoid the place under circumstances over 85% of humidity.
✓Do not place Modules near by the inflammable material. Else it may cause a fire.
✓Do not permit any vibration approaching it directly.
✓Go through module specification carefully, ensure inputs, output connections are made with the
specifications. Use standard cables for wiring.
✓Use Product under pollution degree 2 environment.

5
HX-RIO3 Series
1.1 Safety Instruction
1.1.1 Symbols
1.1.2 Safety Notes
The modules are equipped with electronic components that may be destroyed by
electrostatic discharge. When handling the modules, ensure that the environment (persons,
workplace and packing) is well grounded. Avoid touching conductive components, G-BUS
Pin.
1.1.3 Certification
UL Listed Industrial Control Equipment, certified for U.S.
See UL File E196687
CE Certificate
EN 61000-6-2; Industrial Immunity
EN 61000-6-4; Industrial Emissions
Reach, RoHS (EU, CHINA), EAC
Identifies information about practices or circumstances that can cause an explosion in a
hazardous environment, which may lead to personal injury or death property damage, or
economic loss
Identifies information that is critical for successful application and understanding of the
product.
Identifies information about practices or circumstances that can lead to personal injury,
property damage, or economic loss.
Attentions help you to identity a hazard, avoid a hazard, and recognize the Consequences.

6
HX-RIO3 Series
2 Analog Input Module List
RIO3-Number
Description
ID (hex)
RIO3-RTD4T
Analog Input 4 Channels, RTD / Resistance Input, 10 RTB
3704
RIO3-RTD8C
Analog Input 8 Channels, RTD / Resistance Input, 20P Connector
3708
RIO3-TC4T
Analog Input 4 Channels, Thermocouple / mV Input, 10 RTB
3804

7
HX-RIO3 Series
3 Specification
3.1 RIO3-RTD4T
3.1.1 Wiring Diagram
Pin No.
Signal Description
Signal Description
Pin No.
0
RTD Channel 0+
RTD Channel 0-
1
2
RTD Channel 1+
RTD Channel 1-
3
4
RTD Channel 2+
RTD Channel 2-
5
6
RTD Channel 3+
RTD Channel 3-
7
8
AGND
AGND
9

8
HX-RIO3 Series
3.1.2 LED Indicator
3.1.3 Channel Status LED
Status
LED
To indicate
No Signal
Off
Input Sensor Open or Input Range Over
Normal Operation
Normal Operation
On Signal
Green
Sensor Connected and Input Range Valid
Normal Operation
Normal Operation
LED No.
LED Function / Description
LED Color
0
Input Channel 0
Green
1
Input Channel 1
Green
2
Input Channel 2
Green
3
Input Channel 3
Green

9
HX-RIO3 Series
3.1.4 Environment Specification
Environmental Specification
Operation Temperature
-40℃~ 70℃
UL Temperature
-20℃~ 60℃
Storage Temperature
-40℃~ 85℃
Relative Humidity
5% ~ 90% Non-condensing
Operating Altitude
2,000m
Mounting
DIN Rail
General Specification
Shock Operating
IEC 60068-2-27: 2008/ 15g, 11bs
Vibration Resistance
Based on IEC 60068-2-6
DNVGL-CG-0039: 2016/ Vibration Class B, 4g
Industrial Emissions
EN 61000-6-4: 2007 + A1: 2011
Industrial Immunity
EN 61000-6-2: 2005
Protection Class
Variable / IP20
Installation Position
Vertical and horizontal installation is possible.
Product Certifications
CE, UL, EAC

10
HX-RIO3 Series
3.1.5 Specification
Items
Input Specification
Inputs Per Module
4 Channels
Indicators
4 Green Input Status LEDs
Sensor Types
RTD Input Range
RTD Input
Input Range
PT100, PT200, PT500, PT50
-200~850℃
PT1000
-200~350℃
JPT100, JPT200, JPT500, JPT50
-200~640℃
JPT1000
-200~350℃
NI100, NI200, NI500
-60~250℃
NI1000
-60~180℃
NI120
-80~260℃
NI1000LG
-50~120℃
Resistance Input
Input Range
100mΩ/Bit
0~2000Ω
10mΩ/Bit
0~327Ω
20mΩ/Bit
0~620Ω
50mΩ/Bit
0~1200Ω
Excitation Current
About 1mA
Connection Method
3-Wire
Conversion Time
< 150ms, All Channel
Data Format
16 Bits singed Integer (2' complement)
Module Accuracy
PT100, PT1000 Type Input Range
-0.5℃Full Scale @ 25℃ambient
All Type Input Range
-±0.1% Full Scale @ 25℃ambient
-±0.3% Full Scale @ -40 ~ 70℃ambient
Resolution of Data
RTD Type: ±0.1℃/ F, Resistance Type: 100mΩ, 10mΩ, 20mΩ, 50mΩ
Calibration
Not Required
Diagnostic
Sensor open or range over, then conversion data = 0x8000 (-32768)
General Specification
Power Dissipation
Max. 130mA @ 5Vdc
Isolation
I/O to Logic: Photocoupler Isolation
Field power: Not Connected

11
HX-RIO3 Series
UL Filed Power
Supply voltage: 24Vdc nominal, Class 2
Field Power
Not used, Field Power passes through to the next module
Wiring
I/O Cable Max. 2.0mm2(AWG 14)
Torque
0.8Nm (7lb-in)
Weight
60g
Module Size
12mm x 99mm x 70mm
Environment Condition
Refer to ‘Environment Specification'
3.1.6 Mapping Data into the Image Table
Input Module Data
Analog Input Ch0
Analog Input Ch1
Analog Input Ch2
Analog Input Ch3
Input Image Value
Bit No
Bit7
Bit6
Bit5
Bit4
Bit3
Bit2
Bit1
Bit0
Byte 0
Analog Input Ch0 Low byte
Byte 1
Analog Input Ch0 High byte
Byte 2
Analog Input Ch1 Low byte
Byte 3
Analog Input Ch1 High byte
Byte 4
Analog Input Ch2 Low byte
Byte 5
Analog Input Ch2 High byte
Byte 6
Analog Input Ch3 Low byte
Byte 7
Analog Input Ch3 High byte
If the input of channel is open or over-ranged, its conversion data will be 0x8000 (-32678)

12
HX-RIO3 Series
3.1.7 Configuration Parameter –10 Bytes
Byte
Decimal
Bit
Description
Default Value
0
00-07
The selection Sensor Type
=00h: PT100, 0.00385, -200~850°C, 0.1°C/count
=01h: PT200, 0.00385, -200~850°C, 0.1°C/count
=02h: PT500, 0.00385, -200~850°C, 0.1°C/count
=03h: PT1000, 0.00385, -200~350°C, 0.1°C/count
=04h: PT50, 0.00385, -200~850°C, 0.1°C/count
=10h: JPT100, 0.003916, -200~640°C, 0.1°C/count
=11h: JPT200, 0.003916, -200~640°C, 0.1°C/count
=12h: JPT500, 0.003916, -200~640°C, 0.1°C/count
=13h: JPT1000, 0.003916, -200~350°C, 0.1°C/count
=14h: JPT50, 0.003916, -200~640°C, 0.1°C/count
=20h: NI100, 0.00618, -60~250°C, 0.1°C/count
=21h: NI200, 0.00618, -60~250°C, 0.1°C/count
=22h: NI500, 0.00618, -60~250°C, 0.1°C/count
=23h: NI1000, 0.00618, -60~180°C, 0.1°C/count
=30h: NI120, 0.00672, -80~250°C, 0.1°C/count
=53h: NI1000LG, 0.00500, -50~120°C, 0.1°C/count
=80h: Resistance Input, 1~2000Ω, 100mΩ / 1count
=81h: Resistance Input, 1~327Ω, 10mΩ / 1count
=82h: Resistance Input, 1~620Ω, 20mΩ / 1count
=83h: Resistance Input, 1~1200Ω, 50mΩ / 1count
=Others: Reserved
0: PT100
1
00
Temperature Type
0: Celsius(°C), 1: Fahrenheit(°F)
0: Celsius(°C)
01
Reserved
0
02
Data Resolution
0: 0.1℃, ℉/ Bit, 1: 1℃, ℉/ Bit
0
03
Reserved
0
04
Filter Type
0: Normal Filter, 1: Enhanced Filter
0: Normal Filter
05-07
Reserved
0
2~3
-
CH0 Offset Value
0
4~5
-
CH1 Offset Value
0
6~7
-
CH2 Offset Value
0
8~9
-
CH3 Offset Value
0

13
HX-RIO3 Series
3.1.8 Data Value
Resistance Temperature Detector Input Range
Type
Input Range
PT100
-200 ~ 850 ℃
PT200
-200 ~ 850 ℃
PT500
-200 ~ 850 ℃
PT1000
-200 ~ 350 ℃
PT50
-200 ~ 850 ℃
JPT100
-200 ~ 640 ℃
JPT200
-200 ~ 640 ℃
JPT500
-200 ~ 640 ℃
JPT1000
-200 ~ 350 ℃
JPT50
-200 ~ 640 ℃
NI100
-60 ~ 250 ℃
NI200
-60 ~ 250 ℃
NI500
-60 ~ 250 ℃
NI1000
-60 ~ 180 ℃
NI120
-80 ~ 260 ℃
NI1000LG
-50 ~ 120 ℃
Resistance Input Range
Type
Input Range
100mΩ/Bit
0 ~ 2000 Ω
10mΩ/Bit
0 ~ 327 Ω
20mΩ/Bit
0 ~ 620 Ω
50mΩ/Bit
0 ~ 1200 Ω

14
HX-RIO3 Series
3.2 RIO3-RTD8C
3.2.1 Wiring Diagram
Pin No.
Signal Description
Signal Description
Pin No.
0
RTD Channel 0+
RTD Channel 0-
1
2
RTD Channel 1+
RTD Channel 1-
3
4
RTD Channel 2+
RTD Channel 2-
5
6
RTD Channel 3+
RTD Channel 3-
7
8
AGND
AGND
9
10
RTD Channel 4+
RTD Channel 4-
11
12
RTD Channel 5+
RTD Channel 5-
13
14
RTD Channel 6+
RTD Channel 6-
15
16
RTD Channel 7+
RTD Channel 7-
17
18
AGND
AGND
19

15
HX-RIO3 Series
3.2.2 LED Indicator
3.2.3 Channel Status LED
Status
LED
To indicate
No Signal
Off
Input Sensor Open or Input Range Over
Normal Operation
Normal Operation
On Signal
Green
Sensor Connected and Input Range Valid
Normal Operation
Normal Operation
LED No.
LED Function / Description
LED Color
0
Input Channel 0
Green
1
Input Channel 1
Green
2
Input Channel 2
Green
3
Input Channel 3
Green
4
Input Channel 4
Green
5
Input Channel 5
Green
6
Input Channel 6
Green
7
Input Channel 7
Green

16
HX-RIO3 Series
3.2.4 Environment Specification
Environmental Specification
Operation Temperature
-40℃~ 70℃
UL Temperature
-20℃~ 60℃
Storage Temperature
-40℃~ 85℃
Relative Humidity
5% ~ 90% Non-condensing
Operating Altitude
2,000m
Mounting
DIN Rail
General Specification
Shock Operating
IEC 60068-2-27: 2008/ 15g, 11bs
Vibration Resistance
Based on IEC 60068-2-6
DNVGL-CG-0039: 2016 / Vibration Class B, 4g
Industrial Emissions
EN61000-6-4: 2007 +A1: 2011
Industrial Immunity
EN61000-6-2: 2005
Protection Class
Variable / IP20
Installation Position
Vertical and horizontal installation is possible.
Product Certifications
CE, UL, EAC

17
HX-RIO3 Series
3.2.5 Specification
Items
Input Specification
Inputs Per Module
8 Channels
Indicators
8 Green Input Status LEDs
Sensor Types
RTD Input Range
RTD Input
Input Range
PT100, PT200, PT500, PT50
-200 ~ 850℃
PT1000
-200 ~ 350℃
JPT100, JPT200, JPT500, JPT50
-200 ~ 640℃
JPT1000
-200 ~ 350℃
NI100, NI200, NI500
-60 ~ 250℃
NI1000
-60 ~ 180℃
NI120
-80 ~ 260℃
NI1000LG
-50 ~ 120℃
Resistance Input
Input Range
100mΩ/Bit
0 ~ 2000Ω
10mΩ/Bit
0 ~ 327Ω
20mΩ/Bit
0 ~ 620Ω
50mΩ/Bit
0 ~ 1200Ω
Excitation Current
About 1mA
Connection Method
3-Wire
Conversion Time
280ms / All Channel
Data Format
16 Bits singed Integer (2' complement)
Module Accuracy
PT100, PT1000 Type Input Range
-0.5℃Full Scale @ 25℃ambient
All Type Input Range
-±0.1% Full Scale @ 25℃ambient
-±0.3% Full Scale @ -40 ~ 70℃ambient
Resolution of Data
RTD Type : ±0.1℃/ F, Resistance Type : 100mΩ, 10mΩ, 20mΩ, 50mΩ
Calibration
Not Required
Diagnostic
Sensor open or range over, then conversion data = 0x8000 (-32768)
General Specification
Power Dissipation
Max. 120mA @ 5Vdc
Isolation
I/O to Logic: Isolation
Field power: Not Connected

18
HX-RIO3 Series
UL Field Power
Supply voltage: 24Vdc nominal, Class 2
Field Power
Not used, Field Power passes through to the next module
Wiring
Connector Type, up to AWG22
Module Connector: HIF3BA-20D-2.54DSA
Weight
60g
Module Size
12mm x 99mm x 70mm
Environment Condition
Refer to ‘Environment Specification'
3.2.6 Mapping Data into the Image Table
Input Module Data
Analog Input Ch0
Analog Input Ch1
Analog Input Ch2
Analog Input Ch3
Analog Input Ch4
Analog Input Ch5
Analog Input Ch6
Analog Input Ch7
Input Image Value
Bit No
Bit7
Bit6
Bit5
Bit4
Bit3
Bit2
Bit1
Bit0
Byte 0
Analog Input Ch0 Low byte
Byte 1
Analog Input Ch0 High byte
Byte 2
Analog Input Ch1 Low byte
Byte 3
Analog Input Ch1 High byte
Byte 4
Analog Input Ch2 Low byte
Byte 5
Analog Input Ch2 High byte
Byte 6
Analog Input Ch3 Low byte
Byte 7
Analog Input Ch3 High byte
Byte 8
Analog Input Ch4 Low byte
Byte 9
Analog Input Ch4 High byte
Byte 10
Analog Input Ch5 Low byte
Byte 11
Analog Input Ch5 High byte
Byte 12
Analog Input Ch6 Low byte
Byte 13
Analog Input Ch6 High byte
Byte 14
Analog Input Ch7 Low byte
Byte 15
Analog Input Ch7 High byte
If the input of channel is open or over-ranged, its conversion data will be 0x8000(-32678)

19
HX-RIO3 Series
3.2.7 Configuration Parameter –18 Bytes
Byte
Decimal
Bit
Description
Default Value
0
00-07
The selection Sensor Type
=00h: PT100, 0.00385, -200~850°C, 0.1°C /count
=01h: PT200, 0.00385, -200~850°C, 0.1°C/count
=02h: PT500, 0.00385, -200~850°C, 0.1°C/count
=03h: PT1000, 0.00385, -200~350°C, 0.1°C/count
=04h: PT50, 0.00385, -200~850°C, 0.1°C/count
=10h: JPT100, 0.003916, -200~640°C, 0.1°C/count
=11h: JPT200, 0.003916, -200~640°C, 0.1°C/count
=12h: JPT500, 0.003916, -200~640°C, 0.1°C/count
=13h: JPT1000, 0.003916, -200~350°C, 0.1°C/count
=14h: JPT50, 0.003916, -200~640°C, 0.1°C/count
=20h: NI100, 0.00618, -60~250°C, 0.1°C/count
=21h: NI200, 0.00618, -60~250°C, 0.1°C/count
=22h: NI500, 0.00618, -60~250°C, 0.1°C/count
=23h: NI1000, 0.00618, -60~180°C, 0.1°C/count
=30h: NI120, 0.00672, -80~250°C, 0.1°C/count
=53h: NI1000LG, 0.00500, -50~120°C, 0.1°C/count
=80h: Resistance Input, 1~2000Ω, 100mΩ /1count
=81h: Resistance Input, 1~327Ω, 10mΩ /1count
=82h: Resistance Input, 1~620Ω, 20mΩ /1count
=83h: Resistance Input, 1~1200Ω, 50mΩ/1count
=Others: Reserved
0: PT100
1
00
Temperature Type
0: Celsius(°C), 1: Fahrenheit(°F)
0: Celsius(°C)
01
Reserved
0
02
Data Resolution
0: 0.1℃, ℉/ Bit, 1: 1℃, ℉/ Bit
0
03
Reserved
0
04
Filter Type
0: Normal Filter, 1: Enhanced Filter
0: Normal Filter
05-07
Reserved
0
2~3
-
CH0 Offset Value
0
4~5
-
CH1 Offset Value
0
6~7
-
CH2 Offset Value
0
8~9
-
CH3 Offset Value
0
10~11
-
CH4 Offset Value
0
12~13
-
CH5 Offset Value
0
14~15
-
CH6 Offset Value
0
16~17
-
CH7 Offset Value
0

20
HX-RIO3 Series
3.2.8 Data Value
Resistance Temperature Detector Input Range
Type
Input Range
PT100
-200 ~ 850 ℃
PT200
-200 ~ 850 ℃
PT500
-200 ~ 850 ℃
PT1000
-200 ~ 350 ℃
PT50
-200 ~ 850 ℃
JPT100
-200 ~ 640 ℃
JPT200
-200 ~ 640 ℃
JPT500
-200 ~ 640 ℃
JPT1000
-200 ~ 350 ℃
JPT50
-200 ~ 640 ℃
NI100
-60 ~ 250 ℃
NI200
-60 ~ 250 ℃
NI500
-60 ~ 250 ℃
NI1000
-60 ~ 180 ℃
NI120
-80 ~ 260 ℃
NI1000LG
-50 ~ 120 ℃
Resistance Input Range
Type
Input Range
100mΩ/Bit
0 ~ 2000Ω
10mΩ/Bit
0 ~ 327Ω
20mΩ/Bit
0 ~ 620Ω
50mΩ/Bit
0 ~ 1200Ω
