Hitachi SJ-PB(T) User manual

INSTRUCTION MANUAL
Thank you for purchase of “HITACHI INVERTER”. This manual
explains about treatment of “SJ-PB(T) (Profibus-DP Option)”. By
reading this manual and an instruction manual of inverter use practically
for installation, maintenance, and inspection. After reading this manual,
keep it handy for future reference.
Make sure to reach this manual to the end user.
Table of Contents
Chapter1 INTRODUCTION 1
Chapter2 INSTALLATION 5
Chapter3 WIRING,CONNECTING 6
Chapter4 SETTING 8
Chapter5 OPERATING 10
Chapter6 COUNTERMASUREFORABNORMALIT 21
Appendix PARAMETER CROSS-REFERENCE LIST 22
SJ300/L300P SERIES
SJ-PB
(
T
)
(Profibus‑DPOption
Profibus‑DPOptionProfibus‑DPOption
Profibus‑DPOption)
NB622BX
Hitachi Inverter
After reading this manual, keep it at handy for future reference.

- Request -
Thank you for purchase of “SJ-PB(T) (Profibus-DP Option)”.
This instruction manual explains about treatment and maintenance of “SJ-PB(T)”. Before using the product,
carefully read this manual with the instruction manual of inverter, and keeps it handy for quick reference of
operator and maintenance inspector. Before installing, operating, maintenance and inspection read this
manual carefully and follow the instructions exactly.
Always keep various kinds of specification mentioned in this manual and use exactly. And make sure to
prevent trouble by correct inspection and maintenance. Make sure to reach this manual to the end user.
- About treatment of this manual -
(1)Please consent that mentioned items of this manual may be change without permission.
(2)Keep this manual carefully not to lose because it can not be reissued
(3)All right reserved.
(4)Contents in this manual is written to make assurance doubly sure but, but please contact if you have
some doubts about spelling mistakes, omitted word etc.
(5)Please agree that there is no responsibility for effects resulted, in spite of contents above mentioned.
- About trademark -
(1)Profibus is registered trademark of Profibus Nutzerorganisation.
Revision History Table
No.Revision contents The date of issued Manual No.
1. Initial release of Manual NB622X May. 2001 NB622X
2. Looking at again details. Oct. 2001 NB622AX
3. Adding mention of SJ-PBT. Looking at again details. June. 2002 NB622BX
Except this table, revised only spelling mistakes omitted words, and error writings without notice.

SAFETY PRECAUTIONS
!
SAFTY PRECAUTIONS
Carefully read this manual and all of the warning labels attached to the inverter before installing, operating,
maintaining, inspecting, it. Safety precautions are classified into “Warning” and “Caution” in this manual.
：Indicates a potentially hazardous situation which, if not avoided, can result in serious
injury or death.
：Indicates a potentially hazardous situation which, if not avoided, can result in minor to
moderate injury, or serous damage to the product
The situation described in may, if not avoided, lead to serious results. Important safety
measures are described in CAUTION (as well as WARNING) so be sure observe them.
Notes are described in this manual in “(Note)”. Carefully read the contents and follow them exactly.
CAUTION
In all the illustrations in this manual, covers and safely device are occasionally removed to describe the
details. When the product is operated, make sure that the covers and safety devices are placed as they
were specified originally and operate it according to the instruction manual.
WARNING
!
CAUTION
!
CAUTION
!

SAFETY PRECAUTIONS
!
!
WARNING
Wiring:
Wiring work shall be carried out by electrical experts.
Otherwise, there is a danger of electric shock, fire and/or damage of product.
Implement wiring after checking that the power supply is off.
Otherwise, there is a danger of electric shock and/or fire.
Operating:
Be sure not to touch the surface or the terminal of option board while energizing.
Otherwise, there is a danger of electric shock and/or fire.
Be sure not to remove the Profibus option printed board while operating.
Otherwise, there is a danger of electric shock and/or fire.
Maintenance, Inspection and Part Replacement:
Wait at least 10 minutes after turning off the input power supply before performing maintenance and
inspection.
(Confirm the charge lamp on the inverter is off, checks direct current voltage between P-N terminals and
confirm it is less than 45V)
Otherwise, there is a danger of electric shock.
Make sure that only qualified persons will perform maintenance, inspection, and part replacement
(Before starting the work, remove metallic objects from your person (wristwatch, bracelet, etc.).
Be sure to use tools protected with insulation.)
Otherwise, there is a danger of electric shock and/or injury.
Note:
Never modify the unit.
Otherwise, there is a danger of electric shock and/or injury.
CAUTION
Installation:
Be sure not to let the foreign matter enter such as wire clippings, spatter from welding, metal shaving,
dust etc.
Otherwise, there is a danger of fire.
Be sure to fix inverter to option printed board with an attached fixed screw.
Otherwise, there is a danger of connecting error.
Be sure to fasten the screws connecting signal wire in side of option printed board. Check for any
loosening of screw.
Otherwise, there is a danger of connecting error.
Wiring:
Be sure to fasten the screws not to loose.
Otherwise, there is a danger of connecting error.
Operation:
Check rotary direction, abnormal motor noise and vibrations during operating.
Otherwise, there is a danger of injury to personnel and/or machine breakage

CHAPTER 1 INTRODUCTION
1
1.1 INSPECTION UPON UNPACKING
Make sure to treat the product carefully not to give shock and vibration while unpacking. Check that the product is
the one you ordered, no defect, and that there is no damage during transportation.
(Contents of packing)
(1) SJ-PB(T)(Profibus-DP option printed board):1 (Regarding SJ-PBT, also Install network connector)
(2) Instruction manual:1
(3) Screws fixed printed board (M3 times 8 mm):2
If you discover any problems, contact your sales agent immediately.
1.2 INQUIRY OF THE PRODUCT AND WARRANTY FOR THE PRODUCT
1.2.1 REQUIRE WHILE INQUIRING
If inquiry of breakage, question, damage etc. is needed, please tell the following information to the supplier you
ordered or the nearest Hitachi Distributor.
(1) Type(SJ-PB(T))
(2) Manufacturing number (Item of label, that labeled surface of PCB. X&&&&&& &:6 figures number.
Or ######## #:8 figures serial number.)
(3) Date of purchasing
(4) Contents of inquiry
・Damage parts and its condition etc.
・Question parts and their contents etc.
In order to shorten impossible working time, standing spare unit is recommended.
1.2.2 WARRANTY OF THE PRODUCT
This product is guaranteed to last for one year after purchase. But, the next case is toll repair, even if within
warranty period.
(1) In case caused by operating mistake, and incorrect repair and modification.
(2) Trouble caused by reasons except the shipped product.
(3) In case of using in range over the value of specification.
(4) In case caused by natural calamity, disaster, and secondary disaster.
Warranty mentioned here means warranty for shipped product itself. Damage caused by trouble of shipped
product is not guaranteed.
[Toll repair]
Any explanation and repair after the warranty period (one-year) shall be charged to the purchaser. And also any
explanation and repair out of warranty mentioned above, even within warranty period, shall be charged to the
purchaser. If you require the toll repair, please contact your Hitachi distributor.

CHAPTER 1 INTRODUCTION
2
1.3 Outline of product
SJ-PB(T) is Profibus-DP communication board for SJ300/L300P series inverter.
SJ300/L300P series inverter can get to connect another devices via Profibus-DP when install SJ-PB(T).
SJ-PB(T) is possible to use for all models of SJ300/L300P series.
The SJ-PB(T) option board communicates according to the Profibus Protocol Standard DIN 19245 part 1 & 3.
This means that it can communicate with all masters that comply with this standard, but it does not necessarily
mean that all services available in the Profibus standard are supported. The “Profibus Profile for Variable Speed
Drives” (order no. 3.072), also known as Profidrive, is a subset of Profibus which only supports the services
relevant to speed control applications.
In a control system the option board will act as a slave that can be read and written to, from a Profibus-DP master.
It will not initiate communication to other nodes, it will only respond to incoming telegrams.
(Note) RS485 communication function is disabled by installing SJ-PB(T) to the inverter.
Difference between SJ-PB and SJ-PBT is only connector for networking. Others are no difference.
1.4 Appearance and Names of Parts
Figure 1-1 indicates the appearance of SJ-PB(T).
Serial channel status (D12)
Fieldbus On/Off
(
D14
)
Fieldbus dia
g
nosis
(
D13
)
Connector for connection to SJ300/L300P(Rear of unit)
Profibus contact (open type)
0
5
0
5
Right rotary switch for setting Node Address (a times ten factor) (note)
Left rotary switch for setting Node Address (one to nine) (note)
Figure 1-1 Appearance of SJ-PB(T)
note: please see chapter 4.1.1 Node Address

CHAPTER 1 INTRODUCTION
3
1.5 Profibus-DP Supported Version
SJ-PB(T) can use following Manufacturing number (MFG No) of SJ300/L300P series.
After Manufacturing number : XX8KXXXXXXXXXXXX（SJ300-0.4-55kW / L300P-11-75kW supported）
XXEMXXXXXXXXXXXX（SJ300-75-132kW / L300P-90-132kW supported）
(Note) Manufacturing number is written in specifications label on main body of SJ300/L300Pseries. Refer to
figure 1-2, figure 1-3.
(Figure1-2, 1-3 are the example of SJ300 series. L300P series are the same manner as SJ300 series.)
1.6 Technical features of Profibus-DP
•Physical media: EIA RS 485 twisted pair cable or fiber optic.
•Baud rate: 9.6 kbaud up to 12Mbaud.
•Maximum number of nodes: 126
•Maximum number of I/O: 244 bytes/slave.
•Bus topology: Master-Slave communication. The figure below gives an overview of a Profibus-DP network.
•Cyclic user data transfer between DP-Master and DP-Slaves.
•Watch-Dog Timer at the DP-Slaves
•Connecting or disconnecting stations without affecting other stations.
•Powerful diagnosis mechanisms, 3 hierarchical levels of the diagnosis messages.
•Synchronization of inputs and/or outputs.
•All messages are transmitted with Hamming Distance HD=4.
Specifications label
Figure 1-2 Position of specifications label
Figure 1-3 Contents of specifications label
Invertermodel
Maximumapplicablemotor
Inputratings
Outputratings
Manufacturing
ManufacturingManufacturing
Manufacturingnumber
numbernumber
number
118KT1234510001
118KT1234510001118KT1234510001
118KT1234510001
0101

CHAPTER 1 INTRODUCTION
4
1.7 Production specification
Bacicaly, the environmental specification of the SJ-PB(T) is in accordance with SJ300/L300P series inverter.
Please refer the instruction manual of SJ300/L300P series.
But only application temperature of SJ-PB(T) is different. Please note.
application temperature : 0 to 50 degree
Figure 1-4 Bus cycle time of a Profibus-DP Mono Master system (2 bytes I/O data/slave)

CHAPTER 2 INSTALLATION
5
2.1 Mounting method of option board
Figure 2-1 describes how to mount the option board to the option port 1 or 2.
There are four holes on the option board, match the two of them with the screw holes on the option port 1 or 2.
and mount the other two holes with the guide posts which are located on the option port 1 and 2. To avoid
connection failure, secure the option board with screws after connection.
Option board
Guide posts for mounting the
option board.
Option port 1
Option port 2
Screw holes for secure option board.
(M3 Screws)
Figure 2-1 Installation of option board

CHAPTER 3 WIRING, CONNECTING
6
3.1 Physical interface
Isolation: The bus is galvanically separated from the other electronics with an on board DC/DC converter. Bus
signals (A-line and B-line) are isolated via photo couplers.
Profibus-DP communication ASIC: VPC3 chip from ProfiChip.
Bus connection: The SJ-PB connects to the Profibus network with a 9-pin female DSUB connector. For the pin
layout, refer to Table 3-1.
Table3-1PinLayoutofSJ-PB
Pin Name Function
Housing Shield Connected to PE
1 Not Connected -
2 Not Connected -
3 B-Line Positive RxD/TxD according to RS 485 specification
4 RTS Request To Send (note)
5 GND BUS Isolated GND from RS 485 side (note)
6 +5V BUS Isolated +5V from RS 485 side (note)
7 Not Connected -
8 A-Line Negative RxD/TxD according to RS 485 specification
9 Not Connected -
(note) +5V BUS and GND BUS are used for bus termination. Some devices, like optical transceivers (RS485 to
fibre optics) might require external power supply from these pins. RTS is used in some equipment to determine
the direction of transmission. In standard applications only A-Line, B-Line and Shield are used.
The SJ-PBT connects to the Profibus network with a 6-poles 2pieces connector. For the pin layout, refer to
Table 3-2.
Table3-2PinLayoutofSJ-PBT
Pin Name Function
1 B-Line(in) Positive RxD/TxD according to RS 485 specification
2 A-Line(in) Negative RxD/TxD according to RS 485 specification
3 Shield Connected to PE
4 B-Line(out) Positive RxD/TxD according to RS 485 specification
5 A-Line(out) Negative RxD/TxD according to RS 485 specification
6 Shield Connected to PE
3.2 Profibus connectors
On the SJ-PB, any standard Profibus connector can be used. Depending on baudrate, IP-classing and physical
size of connector there are several different manufacturers and models, the prizing may also vary. For more
information it is recommended to contact the manufacturer, e.g., Siemens or Erni.
SJ-PBT: In this case, the network connector is attached with SJ-PBT option board.
