HME Clear-Com RS-701 User manual

RS-701
BELTPACK
QUICK
REFERENCE
GUIDE
www.clearcom.com
Controls, LEDs & Connectors
1Volume control –rotates to adjust volume
level 2Talk button –talk to all on intercom
channel
Press and hold while talking, or tap to latch on
3Talk LED –lights when intercom channel active
4Call LED –lights when call button is pressed 5
Call button –alerts all on intercom channel
6Power LED –lit while beltpack power is on
7Intercom cable receptacle
(3-pin XLR female)
8Intercom cable receptacle
(3-pin XLR male)
9Headset cable receptacle
(4-pin XLR male)
1
2 3 4 5 6
7 8 9

DIP Switch settings
* = defaults
1Select
* ON = Dynamic
*OFF = Electret
2Headset Output Level
* ON = High
* OFF = Low
3Min Volume
* ON = Silent at min level
*OFF = Not silent at min level
4LEDs On/Off
* ON = LEDs normal operation
*OFF = All LEDs dark
5Call-on Talk Enable
*ON = Call occurs when talk on
* OFF = No call when talk on
6Talk Latch Enable
* ON = Latch enabled
*OFF = Latch disabled
Headset connector pins
1
Mic−/ DC−
2
Mic+
3
Spkr−
4Spkr+ / DC+ (15V
nom
20mA)
DIP switch
Sidetone adjustment
Use small, flat-blade screwdriver
to adjust screw inside hole.
Loosen slotted screw inside
keyhole in belt clip, on back of
beltpack.
Swivel belt clip and slide it up
and down to expose DIP switch
and sidetone adjustment.
Intercom connector pins
1
Common
2
Power
(
15V-30V)
3Signal
DIP Switch settings & Sidetone adjustment
