HMS Anybus Modbus-TCP/RTU Gateway User manual

Anybus®Modbus-TCP/RTU Gateway
USER MANUAL
HMSI-168-77 3.0 ENGLISH

Important User Information
Liability
Every care has been taken in the preparation of this document. Please inform HMS Industrial Networks AB of any
inaccuracies or omissions. The data and illustrations found in this document are not binding. We, HMS Industrial
Networks AB, reserve the right to modify our products in line with our policy of continuous product development.
The information in this document is subject to change without notice and should not be considered as a commit-
ment by HMS Industrial Networks AB. HMS Industrial Networks AB assumes no responsibility for any errors that
may appear in this document.
There are many applications of this product. Those responsible for the use of this device must ensure that all the
necessary steps have been taken to verify that the applications meet all performance and safety requirements in-
cluding any applicable laws, regulations, codes, and standards.
HMS Industrial Networks AB will under no circumstances assume liability or responsibility for any problems that
may arise as a result from the use of undocumented features, timing, or functional side effects found outside the
documented scope of this product. The effects caused by any direct or indirect use of such aspects of the product
are undefined, and may include e.g. compatibility issues and stability issues.
The examples and illustrations in this document are included solely for illustrative purposes. Because of the many
variables and requirements associated with any particular implementation, HMS Industrial Networks AB cannot as-
sume responsibility for actual use based on these examples and illustrations.
Intellectual Property Rights
HMS Industrial Networks AB has intellectual property rights relating to technology embodied in the product de-
scribed in this document. These intellectual property rights may include patents and pending patent applications in
the USA and other countries.
Trademark Acknowledgements
Anybus®is a registered trademark of HMS Industrial Networks AB. All other trademarks are the property of their re-
spective holders.
Copyright © 2016 HMS Industrial Networks AB. All rights reserved.
Anybus®Modbus-TCP/RTU Gateway User Manual
HMSI-168-77 3.0

Anybus®Modbus-TCP/RTU Gateway User Manual HMSI-168-77 3.0
Table of Contents Page
1 Preface ............................................................................................................................... 3
1.1 About This Document.....................................................................................................3
1.2 Document history...........................................................................................................3
1.3 Conventions ..................................................................................................................4
1.4 Terminology...................................................................................................................4
2 Introduction ...................................................................................................................... 5
3 Installation ........................................................................................................................ 6
3.1 Mounting on DIN Rail .....................................................................................................6
3.2 MAC ID and Default IP Address ......................................................................................6
3.3 Connections ..................................................................................................................7
3.4 LED Indicators...............................................................................................................8
4 Configuration ................................................................................................................... 9
4.1 IP Configuration.............................................................................................................9
4.2 Web Configuration Interface .........................................................................................12
A Internal Registers.......................................................................................................... 15
B Technical Data................................................................................................................ 17
C Regulatory Compliance............................................................................................... 18

This page intentionally left blank

Preface 3 (20)
1 Preface
1.1 About This Document
This manual describes how to install and configure Anybus Modbus-TCP/RTU Gateway.
For additional related documentation and file downloads, please visit the Anybus support web-
site at www.anybus.com/support.
1.2 Document history
Summary of recent changes
Change Where (section no.)
Major rewrite —
Revision list
Version Date Author Description
1.00...1.13
2.00 2009-10-09 KeL New template
2.01 2011-05-13 KeL Minor update
2.02 2012-03-12 KeL Minor update
2.03 2012-09-21 KaD Minor update
3.00 2016-04-11 ThN New layout and structure
Major rewrite
Anybus®Modbus-TCP/RTU Gateway User Manual HMSI-168-77 3.0

Preface 4 (20)
1.3 Conventions
Unordered (bulleted) lists are used for:
• Itemized information
• Instructions that can be carried out in any order
Ordered (numbered or alphabetized) lists are used for instructions that must be carried out in
sequence:
1. First do this,
2. Then open this dialog, and
a. set this option...
b. ...and then this one.
Bold typeface indicates interactive parts such as connectors and switches on the hardware, or
menus and buttons in a graphical user interface.
Monospaced text is used to indicate program code and other
kinds of data input/output such as configuration scripts.
This is a cross-reference within this document: Conventions, p. 4
This is an external link (URL): www.hms-networks.com
This is additional information which may facilitate installation and/or operation.
This instruction must be followed to avoid a risk of reduced functionality and/or
damage to the equipment, or to avoid a network security risk.
Caution
This instruction must be followed to avoid a risk of personal injury.
WARNING
This instruction must be followed to avoid a risk of death or serious injury.
1.4 Terminology
In this document the TIA-232/485 serial communication standards are referred to as
RS-232/485 when describing hardware, and as EIA-232/485 in the software interface.
Anybus®Modbus-TCP/RTU Gateway User Manual HMSI-168-77 3.0

Introduction 5 (20)
2 Introduction
Fig. 1 Overview
The Anybus Modbus-TCP/RTU Gateway allows Modbus RTU devices be connected to a
Modbus TCP network. The gateway functions as a Modbus TCP server and performs a trans-
parent conversion between the two protocols. All Modbus accesses that are not addressed to
the virtual slave of the Anybus Modbus-TCP/RTU Gateway will be forwarded to the Modbus
RTU network.
The maximum frame length (number of registers) that can be used is limited only by the Modbus
specification and the functionality of the connected Modbus RTU devices. All Modbus function
codes are supported.
Configuration is carried out using the built-in web interface. The IP address of the gateway can
be set using the Anybus IPconfig utility.
Anybus®Modbus-TCP/RTU Gateway User Manual HMSI-168-77 3.0

Installation 6 (20)
3 Installation
3.1 Mounting on DIN Rail
Mounting
Fig. 2 Mounting on DIN rail
1. Hook the unit onto the upper lip of
the rail.
2. Press the unit towards the rail until it
snaps into place.
Removing
Fig. 3 Removing from DIN rail
1. Insert a flat-head screwdriver into
the slotted tab on the bottom of the
unit and pull the tab gently
downwards.
2. Pull the bottom end of the unit free of
the rail and lift the unit from the rail.
3.2 MAC ID and Default IP Address
The default IP address of a Anybus Modbus-TCP/RTU Gateway is 10.200.1.n, where ncorre-
sponds to the last number in the MAC ID, which is printed on the label on the side of the unit.
The MAC ID is in hexadecimal format. If the MAC ID is 00:30:11:FA:00:1F, the IP address will
be 10.200.1.31, since the hexadecimal value 1F = 31.
MAC ID
Fig. 4 Label with MAC ID
Anybus®Modbus-TCP/RTU Gateway User Manual HMSI-168-77 3.0

Installation 7 (20)
3.3 Connections
In this document the TIA-232/485 serial communication standards are referred to as
RS-232/485 when describing hardware, and as EIA-232/485 in the software interface.
3.3.1 Terminal Block
Fig. 5 Terminal block
Terminal block connections
Pin Label Description
24 Vin+ Power 9–24 V DC/AC
23 Vin- PE ground
22 DI:DI 2 Digital Input 2 + (10–24 VDC)
21 DI:DI 1 Digital Input 1 + (10–24 VDC)
20 DI:COM Digital Input Common -
19 NC Not used
18 NC Not used
17 RS232:RX RS-232 Receive
16 RS232:TX RS-232 Transmit
15 COM Serial common (signal ground)
14 RS-485:A RS-485 Line A
13 RS-485:B RS-485 Line B
3.3.2 D-sub Connector
The 9-pin male D-sub connector provides an RS-232 interface. The Anybus Modbus-TCP/RTU
Gateway is configured as a DTE device.
6 9
51 (male)
Fig. 6 D-sub connector
D-sub connector pin layout
Pin Function
1 CD (Carrier Detect)
2 Rx (Receive)
3 Tx (Transmit)
4 DTR (Data Terminal Ready)
5GND (Signal Ground)
6 DSR (Data Set Ready)
7RTS (Request To Send)
8 CTS (Clear To Send)
9 RI (Ring Indicator)
Anybus®Modbus-TCP/RTU Gateway User Manual HMSI-168-77 3.0

Installation 8 (20)
3.3.3 Ethernet Connector
The RJ-45 socket provides a 10/100 Mbps Ethernet network connection.
1 8
Fig. 7 Ethernet connector
Ethernet connector pin layout
Pin Function
1 TD+
2 TD-
3 RD+
4, 5, 7, 8 Termination
6 RD-
3.4 LED Indicators
Fig. 8 LED Indicators
LED Indication Meaning
Status
OFF No power
Green System is operating normally
Orange System is starting up
Red Hardware fault
Flashing red Error during initialization
Serial Link
Flashing green Receiving serial packet (on either port)
Flashing red Transmitting serial packet (on either port)
Orange System is starting up
Activity Flashing green Receiving Ethernet packet
Flashing red Ethernet collision
Link Green 10 Mbps Ethernet network detected
Orange 100 Mbps Ethernet network detected
Anybus®Modbus-TCP/RTU Gateway User Manual HMSI-168-77 3.0

Configuration 9 (20)
4 Configuration
4.1 IP Configuration
4.1.1 Installing the IPconfig Utility
IPconfig is a Windows-based tool used for TCP/IP network configuration of a HMS devices. The
tool will detect all connected devices and allow configuration of their IP address, netmask, de-
fault gateway, DNS and hostname.
1. Download IPconfig from www.anybus.com/support.
2. Extract the contents of the zip archive in a folder on your computer and double-click the
executable file to run the installer.
4.1.2 Scanning for Connected Devices
Make sure that the devices to be configured are connected on the same Ethernet subnet as the
computer running IPconfig. Use standard Ethernet cables.
When IPconfig utility started it will scan the available local networks. All detected devices will be
presented in a list in the main window. To refresh the list, click on Scan.
Fig. 9 IPconfig main window
IP IP address of the device
SN Subnet mask
GW Default gateway
DHCP Automatically managed IP configuration
Version Firmware version
Type Product name
MAC Ethernet MAC address (System ID)
Anybus®Modbus-TCP/RTU Gateway User Manual HMSI-168-77 3.0

Configuration 10 (20)
4.1.3 Ethernet Configuration
To change the TCP/IP settings for a device, either double-click on the entry or right-click on it
and select Configuration.
Fig. 10 Ethernet configuration
Notes
• Do not enable DHCP if there is no DHCP server available on the network.
See also IPconfig Settings, p. 11
• You can add a name for the device in the Hostname field. Only characters a-z, A-Z,
0–9 and _ (underscore) are allowed.
• The default password for authentication of the new settings is admin. To change the
password, check the Change password box and enter the current password in the
Password field and the new password in the New password field.
For security reasons the default password should always be changed.
Click Set to save the new settings. The device will be automatically restarted. The new settings
can be tested by opening a web browser and entering the IP address assigned to the device.
Anybus®Modbus-TCP/RTU Gateway User Manual HMSI-168-77 3.0

Configuration 11 (20)
4.1.4 IPconfig Settings
Additional settings for IPconfig can be accessed by clicking on Settings.
Fig. 11 IPconfig settings
Network Interface Check this option to select a specific network interface to use when scanning for
devices on a computer with multiple interfaces.
Internal DHCP Server If a device has been set to use DHCP but there is no DHCP server on the
network, the device may no longer be detected in a scan. To recover the device,
an internal DHCP server in IPconfig can be activated.
Click the checkbox to enable the option, then click OK to close the window.
IPconfig will automatically refresh, and the missing device should now be
detected. Select the device and change its configuration to use manual
addressing instead of DHCP.
Disable the internal DHCP server after the device has been recovered.
Anybus®Modbus-TCP/RTU Gateway User Manual HMSI-168-77 3.0

Configuration 12 (20)
4.2 Web Configuration Interface
Right-click on the entry for the gateway in IPconfig and select Open Web Interface to open its
local web server in your default browser. You can also type the IP address directly into the web
browser address field.
The default login user name is admin and the default password is admin.
Fig. 12 Logging in to the web interface
For security reasons the default password should be changed after the first login.
The user name cannot be changed.
4.2.1 Network
Fig. 13 Network settings
The Network settings page allows viewing and changing the TCP/IP settings. These are the
same settings as those entered in IPconfig.
When DHCP is enabled the unit will automatically receive the settings for IP address, subnet
mask, default gateway, and DNS. Contact your network administrator if in doubt.
Click on Save Settings to save the new configuration.
Do not select Dynamic IP unless there is an active DHCP server on the local
network.
Anybus®Modbus-TCP/RTU Gateway User Manual HMSI-168-77 3.0

Configuration 13 (20)
4.2.2 Modbus
Fig. 14 Modbus settings
Serial Settings (Modbus RTU/ASCII)
Transmission Mode RTU or ASCII
Slave Response
Timeout
Default = 200 ms
Physical Interface EIA-485 (terminal), EIA-232 (terminal) or EIA-232 (D-sub)
Baudrate 300, 600, 1200, 2400, 4800, 9600, 19200, 38400, 57600 or 115200 bps
Character Format Parity and number of stop bits
Extra delay between
messages
Some nodes may require extra time to finish handling a message before receiving
another. This setting adds a delay between each message.
Character delimiter The “silent” period to be regarded as a delimiter between one message and the
next. If set to 0 (zero) the default Modbus setting of 3.5 characters is used. The
actual time will then depend on the baud rate.
Ethernet Settings (Modbus TCP)
Port Number The port to use for Modbus TCP communication. Default = 502
Gateway Registers Queries sent to the specified address offset will be handled by the internal
registers in the gateway instead of being forwarded to the Modbus RTU network.
See Internal Registers, p. 15. Default = disabled.
Server Idle Timeout Idle timeout for the Modbus TCP connection. If no Modbus TCP query is received
within this time the connection will close. Default = 60 seconds.
IP Authentication If enabled, specifies the IP address and netmask of the device that is allowed to
connect to the gateway. Default = disabled.
Anybus®Modbus-TCP/RTU Gateway User Manual HMSI-168-77 3.0

Configuration 14 (20)
4.2.3 Status
Fig. 15 Status page
Status
Number of
Connections
Number of Modbus masters connected to the gateway
Valid Responses Valid responses from the Modbus RTU slaves
Serial Timeouts Modbus RTU slave timeouts
CRC Errors CRC errors on incoming Modbus RTU responses
Buffer Overruns Input buffer overruns (incoming Modbus RTU responses that are exceeding 300
bytes)
Exception Responses Exception responsed from connected Modbus RTU slaves
4.2.4 Admin
Fig. 16 Admin page
This page allows you to change the default password for the gateway. The user name cannot
be changed.
For security reasons the default password should be changed after the first login.
Anybus®Modbus-TCP/RTU Gateway User Manual HMSI-168-77 3.0

Appendix A: Internal Registers 15 (20)
A Internal Registers
Register Name Values Options Comment
1 Digital input 1 status 0 or 1 Read only
2 Digital input 2 status 0 or 1 Read only
3 Active MBTCP connections 0 - 10 Read only
4 Active internal connections 0 - 10 Read only
Serial status (Modbus TCP)
5 Valid responses 0 - 65535 Can be cleared
6 Serial time outs 0 - 65535 Can be cleared
7CRC errors 0 - 65535 Can be cleared
8 Input buffer overruns 0 - 65535 Can be cleared
9 Frame errors 0 - 65535 Can be cleared
10 Exceptions responses 0 - 65535 Can be cleared
Serial status (buffered messages)
11 Valid responses 0 - 65535 Can be cleared
12 Serial time outs 0 - 65535 Can be cleared
13 CRC errors 0 - 65535 Can be cleared
14 Input Buffer overruns 0 - 65535 Can be cleared
15 Frame errors 0 - 65535 Can be cleared
16 Exceptions responses 0 - 65535 Can be cleared
Serial status (internal requests and web pages)
17 Valid responses 0 - 65535 Can be cleared
18 Serial time outs 0 - 65535 Can be cleared
19 CRC errors 0 - 65535 Can be cleared
20 Input Buffer overruns 0 - 65535 Can be cleared
21 Frame errors 0 - 65535 Can be cleared
22 Exceptions responses 0 - 65535 Can be cleared
Configuration registers
23 Modbus TCP Port 1 - 65535 Default: 502
24 Gateway Modbus address -1 to 255
-1 Disabled Default
0 - 255 Enabled
25 Modbus TCP idle time out 0 - 65535 Default: 60 seconds
0 Disabled
1 - 65535 Enabled
26 Baud rate 2400 2400 bps
4800 4800 bps
9600 9600 bps Default
19200 19200 bps
38400 38400 bps
57600 57600 bps
115200 115200 bps
27 Parity 0 - 2
0 No parity Default
1 Even parity
2 Odd parity
28 Number of stop bits 1 - 2 Default: 1 stop bit
29 Slave time out time 25 - 65535 Default: 1000 ms
30 Physical interface 0 - 2
0 EIA-485 (terminal) Default
1 EIA-232 (DSUB)
2 EIA-232 (terminal)
Anybus®Modbus-TCP/RTU Gateway User Manual HMSI-168-77 3.0

Appendix A: Internal Registers 16 (20)
Register Name Values Options Comment
Authentication
31 Valid IP address 1 0 - 255 First byte of IP address
0 Disabled IP address authentication
disabled
1 - 255 Enabled
32 Valid IP address 2 0 - 255 Enabled Second byte of IP address
33 Valid IP address 3 0 - 255 Enabled Third byte of IP address
34 Valid IP address 4 0 - 255 Enabled Fourth byte of IP address
35 Mask for Valid IP address 1 0 - 255 Enabled First byte of mask
36 Mask for Valid IP address 2 0 - 255 Enabled Second byte of mask
37 Mask for Valid IP address 3 0 - 255 Enabled Third byte of mask
38 Mask for Valid IP address 4 0 - 255 Enabled Fourth byte of mask
Valid commands:
Command Name
3 Read Holding Registers
6 Preset Single Register
16 Preset Multiple Registers
Anybus®Modbus-TCP/RTU Gateway User Manual HMSI-168-77 3.0

Appendix B: Technical Data 17 (20)
B Technical Data
Technical Specifications
Model name Anybus Modbus-TCP/RTU Gateway
Order code AB7702
Ethernet 10/100 Mbit/s
Serial Interfaces EIA-232 with full modem control (RTS, CTS, DCD,
DTR, DSR, RI)
EIA-485
Protocols Modbus RTU, ASCII, TCP
Baud rates 300–115200 bps
Mounting DIN rail (EN 50022)
Housing Grey plastic (LEXAN 940) Self-extinguishing accord-
ing to UL94–V0
Dimensions (W x D x H) 90 x 70 x 58 mm
Operating temperature -40 to +65 °C
Storage temperature -40 to +85 °C
Humidity range 5–95 % RH, non-condensing
Housing class IP20
Power supply 9–24 V DC or AC, SELV
Power consumption 2.0 W
Certifications CE, CULUS
Anybus®Modbus-TCP/RTU Gateway User Manual HMSI-168-77 3.0

Appendix C: Regulatory Compliance 18 (20)
C Regulatory Compliance
This product is in compliance with the EMC directive 2014/30/EC through conformance with the
following standards:
EN 61000-6-4 (2007)
Emission standard for industrial environment
• EN 55016-2-3, Class A (2010)
• EN 55022, Class A (2011)
EN 61000-6-2 (2005)
Immunity for industrial environment
• EN 61000-4-2 (2009)
• EN 61000-4-3 (2006)
• EN 61000-4-4 (2012)
• EN 61000-4-5 (2014)
• EN 61000-4-6 (2014)
E214107
Field wiring terminals shall be connected with minimum wire size 24 AWG.
Anybus®Modbus-TCP/RTU Gateway User Manual HMSI-168-77 3.0
