Hobby King B-17G User manual

An R/C model airplane is not a toy and is not suitable for pilot under 14 years.
If you are a beginner, it is necessary to let an experienced airplane pilot assist you.
Read the instructions carefully before any use.
WARNING:
MADE IN CHINA
B-17G
B-17GB-17G
Flying Fortress
INSTRUCTION MANUAL
Flying Fortress
INSTRUCTION MANUAL

B-17G Electric R/C model is not a toy and is not suitable for the polit under 14
years old.
1. Do not fly near houses or buildings; Children's play areas, Road traffic, railways
airports, overhead power lines and pylons. Do not fly over people.
2. The ideal location for flying is a wide-open space in four directions with no people.
(If using a model airfield, be sure to contact the airfield's administrator for
permission.)
3. The battery should not be overcharged or put on the flammable material or near
flammable material when it is being charged.
4. Always check that other pilots are not using the same frequency (band) in the
same area before flight and make sure there you are flying in a safe area.
5. Do not fly in the strong winds.
6. Do not try to catch the plane by hand when it is flying.
7. The children who are younger than 14 years old should be assisted by an
experienced adult when the plane is being flown.
8. This model aircraft is designed to be powered by an electric motor. Flying this
model aggressively may lead to serious accidents or injuries.
9.Do not touch the propeller when the motors is running, it could lead to serious
injuries.
WARNING:
B-17GB-17G
ASSEMBLY AND OPERATING INSTRUCTIONS
Specifications
Dear Customer
Wingspan: 1600mm
Length: 1110mm
Weight: 2200g
Servo: 7 x 9g high speed micro servos
Battery: 11.1V,3S,2600mAh,25C Li-polymer battery
ESC: 4 x 30A Brushless speed controller
Motor: 4 x 1600KV Outrunner Brushless motor
Many thanks for purchasing such a fantastic model aircraft designed for the
hobby enthusiast and much gratitude for placing your trust in us.
Very little work is required to prepare the model ready for flying. You can
make it as easy as possible to operate your new aero plane safely by taking
the trouble to read through these instructions attentively ,before you fly it for
the first time.
WARNING
ASSEMBLY AND OPERATING INSTRUCTIONS
WARNING
WARNING
1 2

B-17GB-17G
Fuselage
Horizontal tail
Main wing(left)
Main wing(right) Vertical tail
Accessories
Get two wings connected with the reinforced board glued, in the meantime,
put glue between wings.(Accessories-1)
Connect the signal lead in right wing to the left, number in accordance,
another lead left to the receiver, same way in numbers.
Put 2 Power Y-lead connected.(Accessories-8)
Disarm motor cover and servo rocker.
Connect steel wire to the servo rocker, wire through cover hole.
Screw the servo rocker.
(Accessories-1)
Assembly Assembly
Assembly
Assembly
3 4

B-17GB-17G
Fix helms angle on control surface for both sides and screw them tight.
(Accessories-6)
Get control steel wire connected. (Accessories-1)(Accessories-6)
Pull out steel wire from the fuselage and connect it to horizontal tail, then
assemble the vertical tail to be sure that steel wire inside the slot.
Fix the fuselage and wings.(Accessories-5)
Fix the propeller blades and connecting pieces correctly and screw it tight.
Stabilize the propeller with spinner and nut .
(Accessories-3)(Accessories-4)(Accessories-7)
Put the machine guns and here comes the complete B-17G.
(Accessories-2)
Assembly Assembly
Assembly
Assembly
Assembly
Assembly
Assembly
5 6

B-17GB-17G
Checking the position of the Center of Gravity as Shown bellow Pre-Flight Check
Tips
7 8

B-17GB-17G
Flight Problem SolvingFlight Problem Solving
Problem Solving
Flight
Flight
9 10
