HMPRO50 OPERATOR’S MANUAL
2www.holemaker.com
Holemaker PRO 50 Portable Magnetic Drilling Machine
Congratulations on the purchase of your Holemaker Pro 50 portable magnetic drilling machine.
Holemaker drilling machines are designed to deliver fast, efficient hole drilling performance in portable applications.
TABLE OF CONTENTS
Important Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3 -4
Power Supply Requirement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Special Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Technical Data. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Contents of Package . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Machine Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8-10
Basic Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Maintenance and Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Machine Parts Breakdown. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13 - 20
Electrical Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
LIMITED WARRANTY
THE MANUFACTURER RESERVES THE RIGHT TO MAKE
Imported And Distributed By
INDUSTRIAL TOOL & MACHINERY SALES
18 BUSINESS ST, YATALA, QLD AUSTRALIA 4207
PHONE [phone] FAX [phone]
[email protected] www.industrialtool.com.au
IMPROVEMENTS AND MODIFICATIONS TO DESIGN WITHOUT PRIOR NOTICE.
2
Industrial Tool & Machinery Sales (hereinafter refered to as ITMS) will, within twelve (12) months from the
original date of purchase, repair or replace any goods found to be defective in materials or workmanship.
This warranty is void if the item has been damaged by accident, neglect, improper service or other causes
not arising out of defects in materials or workmanship.
This warranty does not apply to machines and/or components which have been altered, changed, or
modified in any way, or subjected to overloading or use beyond recommended capacities and specifications.
Worn componentry due to normal wear and tear is not a warranty claim.
Goods returned defective shall be returned prepaid freight to ITMS or agreed repair agent, which shall be
the buyer’s sole and exclusive remedy for defective goods. ITMS accepts no additional liability pursuant to
this guarantee for the costs of travelling or transportation of the product or parts to and from ITMS or the
service agent or dealer, such costs are not included in this warranty.
Our goods come with guarantees which cannot be excluded under the Australian Consumer Law.
You are entitled to replacement or refund for a major failure and to compensation for other reasonably
foreseeable loss or damage. You are also entitled to have the goods repaired or replaced if the goods
fail to be of acceptable quality and the failure does not amount to a major failure.

HMPRO50 OPERATOR’S MANUAL
www.holemaker.com 3
IMPORTANT SAFETY INSTRUCTIONS
WARNING!
WHEN USING ELECTRICAL TOOLS,BASIC SAFETY PRECAUTIONS SHOULD ALWAYS BE FOLLOWED
TO REDUCE RISK OF FIRE,ELECTRIC SHOCK AND PERSONAL INJURY .
READ AND SAVE ALL INSTRUCTIONS FOR FUTURE REFERENCE.
1. Keep Work Area Clean
• Cluttered areas and benches increase risk of injuries.
2. Consider Work Area Environment
• Do not expose power tools to rain.
• Do not use power tools in damp or wet locations.
• Keep work area well lit.
• Do not use tool in presence of flammable liquids or gases.
3. Guard Against Electric Shock
• Prevent body contact with grounded surfaces. For example: pipes, radiators, ranges and refrigerator enclosures.
4. Keep Children Away
• Do not let visitors contact tool or extension cord.
• All visitors should be kept away from work area.
5. Store Idle Tools
• When not in use, tools should be stored in a dry, high and locked-up place, out of reach of children.
6. Do Not Force Tool
• It will do the job better and safer at the rate for which it was intended.
7. Use Right Tool
• Do not force a small tool or attachment to do the job of a heavy-duty tool.
• Do not use tool for unintended purpose. For example: Do not use a circular saw for cutting tree limbs or logs.
8. Dress Properly
• Do not wear loose clothing or jewellery. They can be caught in moving parts.
• Rubber gloves and non-skid footwear are recommended when working outdoors.
• Wear protective hair covering to contain long hair.
• Always wear safety glasses
• Use face or dust mask if necessary
• Use hearing protection
9. Do Not Abuse Electrical Cord
• Never carry tool by cord or yank it to disconnect from receptacle.
• Keep cord away from heat, oil and sharp edges.
10. Secure Work
• Use clamps or a vise to hold work. It’s safer than using your hand and it frees both hands to operate tool.
11. Do Not Overreach
• Keep proper footing and balance at all times.
3

HMPRO50 OPERATOR’S MANUAL
4www.holemaker.com
12. Maintain Tools With Care
• Keep tools sharp and clean for better and safer performance.
• Follow instructions for lubricating and changing accessories.
• Inspect tool cords periodically and if damaged, have repaired by authorized service facility.
• Inspect extension cords periodically and replace if damaged.
• Keep handles dry, clean, and free from oil and grease.
13. Disconnect Tools
• Unplug when not in use, before servicing, and when changing accessories, such as cutters.
14. Remove Adjusting Keys And Wrenches
• Form habit of checking to see that keys and adjusting wrenches are removed from tool before turning it on.
15. Avoid Unintentional Starting
• Do not carry a plugged-in tool. Always disconnect from power source before moving.
• Be sure switches are off before connecting to a power source.
16. Outdoor Use Of Extension Cords
• When tool is used outdoors, use only extension cords intended for use outdoors and so marked.
17. Stay Alert
• Watch
Fig. 1
Always use cutter guard supplied with machine to reduce the risk of injury. (refer fig. 1)
what you are doing. Use common sense. Do not operate tool when you are tired.
• Do not use when taking medications that may cause drowsiness.
18. Check Damaged Parts
• Before further use of the tool, any damaged parts should be repaired and performance verified prior to operation.
• Check alignment of moving parts, binding of parts, breakage of parts, mounting, and any other conditions
that may affect its operation. Any part that is damaged should be properly repaired or replaced
by an authorized service center.
• Do not use this tool if switches do not turn it on and off. Have defective switches replaced by authorized
service center.
4
IMPORTANT SAFETY INSTRUCTIONS
19. Use Cutter Guard
•

HMPRO50 OPERATOR’S MANUAL
www.holemaker.com 5
GROUNDING INSTRUCTIONS
POWER SUPPLY REQUIREMENTS
WARNING!
Improperly connecting the grounding wire can result in the risk of electrical shock.
Prior to use check condition of the power cord, which has to be free of any cuts, or similar damages.
Attention!: This unit has a class one of insulation and
absolutely requires the power source
to be equipped with a protection circuit.
Power source should be protected with the difference-current circuit cut-out and protected with a 10A fuse - for 230V.
At building sites, power should be supplied from a separation transformer such as Type AVM, with minimum power of
2000 VA and with second class protection.
Check with a qualified electrician if you are in doubt as to whether the outlet
is properly grounded. Do not modify the plug provided with tool. Never remove
the grounding prong from the plug. If the cord or plug is damaged, have it
repaired before using. If the plug will not fit the outlet, have a proper outlet
installed by a qualified electrician. The Holemaker must be plugged into an
appropriate outlet, properly installed and grounded in accordance with all codes
and ordinances. The plug and outlet should look similar to those in Figure A.
If in doubt of proper grounding, call a qualified electrician.
WARNING!
DO NOT USE HOLEMAKER DRILLING MACHINES ON SURFACES OR MATERIALS BEING
WELDED.DOING SO CAN RESULT IN DAMAGE TO THE DRILLING MACHINE.
EXTENSION CORDS
Use only 3-wire extension cords that have 3-prong grounding-type plugs and 3-pole receptacles that accept the
tool’s plug. Replace or repair damaged cords. Make sure your extension cord is in good condition. When using
an extension cord, be sure to use one heavy enough to carry the current your product will draw. An undersized cord
will cause a drop in line voltage resulting in loss of power and overheating. See table for the correct size to use
depending on cord length and nameplate amperage rating. If in doubt, use the next heavier gauge. The smaller the
gauge number, the heavier the cord.
12-16
VOLTS
240V
AMPERAGE
0-6
6-10
10-12
14
RECOMMENDED WIRE GAUGE
12
MINIMUM GAUGE FOR EXTENSION CORDS
TOTAL LENGTH OF CORD IN METRES
0 - 15 15 - 30 30 - 60 60 - 90
18 16 16 14
18 16 14 12
16 16 14 12
NOT RECOMMENDED
DRIP LOOP: To help prevent cutting fluids from traveling
along power cord and contacting power source, tie a drip
loop in power cord as shown in Figure C.
5

HMPRO50 OPERATOR’S MANUAL
6www.holemaker.com
TECHNICAL DATA
6
Supply voltage: ………………………………… 220-240V/ 50-60 Hz.
Motor power ……………………………………………………. 1260 W
Total power …………………………………………………….. 1300 W
Machine speeds (under load): ………………............ Gear 1: 200rpm
Gear 2: 400rpm
Insulation class ………………………………………………….. First
Arbor bore ………………………………………………………. MT 2
Tool holder …………………………………. (
3
/
4
" Weldon) 19.05 mm
Capacities: max. Holemaker cutter diameter ………................ 52mm
max. drilling depth with standard arbor ………...... 52mm
max. drilling depth with optional arbor ….……...... 75mm
Magnet Dead Lift (on 25 mm plate) ………....................... 12000 N
Dimensions:
electromagnetic base …........................................... 90x180x48 mm
Length of the power cord ……………………............................... 3 m
Total weight ………………………………...…...................... 16.5 kg
Noise level ……………………………………………...………….. 85 dB

HMPRO50 OPERATOR’S MANUAL
www.holemaker.com 7
SPECIAL INSTRUCTIONS
1. Read and follow operator’s manual thoroughly.
2. DO NOT touch rotating cutter or parts.
3. Always stop machine completely and unplug from power source before changing cutters, clearing swarf,
refilling lubrication or performing adjustments.
4. Never wear loose clothing or gloves when working near cutting area or machine arbor.
5. Always wear eye protection. Any tool can shatter.
6. Always use safety chain or strap provided with machine.
7. Always use proper tooling. Keep cutters securely fastened.
8. DO NOT use dull or broken cutters.
9. Beware of ejected slugs at end of cut. They become HOT during the cut.
10. Keep all safety features functioning and working properly.
11. Keep bottom of magnet burr free and clear of chips and debris.
12. To reduce the risk of electrical shock, DO NOT remove or alter electrical panels or use machine in damp
areas.
13. Use only authorized service centers for repairs.
Remove all contents from packaging and inspect to ensure no damage was incurred during shipping.
Your Holemaker package should include the following:
QTYDESCRIPTION
METAL CARRY CASE
HOLEMAKER PRO50 MACHINE
1
1
SAFETY CHAIN WITH CLIP
HEX WRENCH 5
1
1
OPERATORS MANUAL
#2MT ARBOR ASSEMBLY
1
COOLANT BOTTLE ASSEMBLY
1
DRILL DRIFT
3
SPOKE HANDLE WITH KNOBS
WHAT YOU SHOULD KNOW BEFORE YOU DRILL
1. Type of material to be drilled, Brinnell or Rockwell hardness, material thickness and position should all be
determined to ensure proper selection of cutting tools.
2. Remove any excessive mill scale or rust from surface to be drilled.
3. When drilling thin materials, it is recommended that you placea steel plate under the work piece and Holemaker
magnet area to increase magnetic holding force.
4. Material that has been flame cut may become heat treated and therefore difficult to drill. Avoid drilling near such
areas whenever possible.
5. Special cutter lubricant is available for using the Holemaker and annular cutters in the horizontal
position. Consult you distributor for more information.
Caution: Do not drill on material where welding is also simultaneously being performed. Drilling machine will
be damaged.
Caution: Powering drilling machine from generator without proper surge protection device between
generator and drilling machine may cause damage to the Printed Circuit Board in machine.
The Holemaker Pro 50 is not designed for use on steel thinner than 3/8” or 10mm, as the magnet’s adhesive
power would be significantly reduced which can cause machines failure or individuals injury.
The machines built in “Smart Magnet Technology” will detect insufficient magnetic adhesion, and will
cause the machines motor on/off button to not engage. Although it is not recommended, this feature can
be bypassed by following the attached “Smart Magnet Technology Bypass” instruction leaflet.
7
1
SAFETY GUARD 1
1
1
HEX WRENCH 4
Assemble three spoke handles to feed hub. NOTE: Feed hub assembly
is mounted on right side of machine frame – if necessary, it can be reversed
for lefthand operation by simply removing the fastener and hub from frame.
Remove hub pinion shaft from right side of frame and insert it into left side of
frame. Replace hub and fastener into frame and tighten securely. Install the
arbor into the drill motor by inserting the arbor body into the spindle. By turning
the arbor while inserting, the arbor tang will properly line up in the spindle.
Turn the arbor until it bottoms out in the spindle and then tap lightly with a
plastic hammer to secure.
SPECIAL INSTRUCTIONS
1. Read and follow operator’s manual thoroughly.
2. DO NOT touch rotating cutter or parts.
3. Always stop machine completely and unplug from power source before changing cutters, clearing swarf,
refilling lubrication or performing adjustments.
4. Never wear loose clothing or gloves when working near cutting area or machine arbor.
5. Always wear eye protection. Any tool can shatter.
6. Always use safety chain or strap provided with machine.
7. Always use proper tooling. Keep cutters securely fastened.
8. DO NOT use dull or broken cutters.
9. Beware of ejected slugs at end of cut. They become HOT during the cut.
10. Keep all safety features functioning and working properly.
11. Keep bottom of magnet burr free and clear of chips and debris.
12. To reduce the risk of electrical shock, DO NOT remove or alter electrical panels or use machine in damp
areas.
13. Use only authorized service centers for repairs.
Remove all contents from packaging and inspect to ensure no damage was incurred during shipping.
Your Holemaker package should include the following:
QTYDESCRIPTION
METAL CARRY CASE
HOLEMAKER PRO50 MACHINE
1
1
SAFETY CHAIN WITH CLIP
HEX WRENCH 5
1
1
OPERATORS MANUAL
#2MT ARBOR ASSEMBLY
1
COOLANT BOTTLE ASSEMBLY
1
DRILL DRIFT
3
SPOKE HANDLE WITH KNOBS
WHAT YOU SHOULD KNOW BEFORE YOU DRILL
1. Type of material to be drilled, Brinnell or Rockwell hardness, material thickness and position should all be
determined to ensure proper selection of cutting tools.
2. Remove any excessive mill scale or rust from surface to be drilled.
3. When drilling thin materials, it is recommended that you placea steel plate under the work piece and Holemaker
magnet area to increase magnetic holding force.
4. Material that has been flame cut may become heat treated and therefore difficult to drill. Avoid drilling near such
areas whenever possible.
5. Special cutter lubricant is available for using the Holemaker and annular cutters in the horizontal
position. Consult you distributor for more information.
Caution: Do not drill on material where welding is also simultaneously being performed. Drilling machine will
be damaged.
Caution: Powering drilling machine from generator without proper surge protection device between
generator and drilling machine may cause damage to the Printed Circuit Board in machine.
The Holemaker Pro 50 is not designed for use on steel thinner than 3/8” or 10mm, as the magnet’s adhesive
power would be significantly reduced which can cause machines failure or individuals injury.
The machines built in “Smart Magnet Technology” will detect insufficient magnetic adhesion, and will
cause the machines motor on/off button to not engage. Although it is not recommended, this feature can
be bypassed by following the attached “Smart Magnet Technology Bypass” instruction leaflet.
7
1
SAFETY GUARD 1
1
1
HEX WRENCH 4
Assemble three spoke handles to feed hub. NOTE: Feed hub assembly
is mounted on right side of machine frame – if necessary, it can be reversed
for lefthand operation by simply removing the fastener and hub from frame.
Remove hub pinion shaft from right side of frame and insert it into left side of
frame. Replace hub and fastener into frame and tighten securely. Install the
arbor into the drill motor by inserting the arbor body into the spindle. By turning
the arbor while inserting, the arbor tang will properly line up in the spindle.
Turn the arbor until it bottoms out in the spindle and then tap lightly with a
plastic hammer to secure.

HMPRO50 OPERATOR’S MANUAL
8www.holemaker.com
This drilling machine’s spindle has a 19mm Weldon Shank type and is specifically designed for use with Annular cutters.
Annular cutter (1) is located inside arbor body (2) and is fastened with grub screws (3). When fastening the cutter
in the arbour, ensure that the grub screws are firmly tightened to avoid them coming loose during operation. It is
important to position the cutter in relation to the arbour in such a way that fixing flats on the cutter shank are
positioned opposite to the grub screws (3). Both grub screws(3) should be used to fasten the cutter. The Pilot Pin (5)
is located inside the cutter to easily position the annular cutter over centre of a planned hole. During drilling as the cutter
goes into the material, the pilot pin moves back into the arbour body and pressurizes the discharge spring (4).That spring
ejects the slug which is a by-product of drilling the hole with a centre free cutter.
START UP AND OPERATION
The machine is supplied in a metal box. Some components of the
drilling machine are coated with grease film for protection during transit and
storage. Prior to use of the machine this should be wiped clean.
NOTE: As a power saving function, Switching the Magnet Switch(1) to “I” will supply the electromagnet with
50% power. Switching the Start-Stop Switch(2) to “I” will increase the electromagnet to 100% power.
CONTROL PANEL
Control elements include:
- Magnet Switch (1),
- Start-Stop Switch (2),
a) In order to start the machine press the magnet switch (1) on “I”. Now you can start the motor by pressing
Start-Stop Switch (2) green button “I”
b) Stopping the motor is executed with red button „O” ( the motor is switched OFF but the electromagnetic base is still ON).
c) To move machine into next drilling spot, stop the motor as described above and push the magnet switch (1) to the
position “O”.
Principle of Annular cutter’s work
CAUTION: READ THE WHOLE INSTRUCTIONS MANUAL
BEFORE ATTEMPTING TO START UP
8

HMPRO50 OPERATOR’S MANUAL
www.holemaker.com 9
Before you cut
Before positioning the machine on work piece always make sure that:
- work piece is made of ferrous material
- thickness of work piece is adequate for secure magnetic adhesion (mild
steel - 10mm is recommended)
- Ensure no part of magnet overhangs the steel workpiece
- surface of steel under the magnet is flat
- wipe, brush or sand down clean surface where you intended to place the
drilling machine, so that you remove rust, paint, dirt etc which would reduce adhesive
power of the electromagnetic base.
Install annular cutter in the machine before plugging it into mains.
Place the machine so that the tool is over the centre of the hole you intend to make
and turn the magnetic base ON.
Always make sure prior to use that the machine is secured from falling
down with a chain/strap.
9
An example of a safety chain/strap use.

HMPRO50 OPERATOR’S MANUAL
10 www.holemaker.com
Cutting
- Choose a suitable lubricating fluid and fill the coolant tank.
The cooling system is an integral part of the machine and should always be used.
Warning: The cooling system works gravitationally, therefore it can be used
only when in vertical position of the drilling machine. In other positions, a
cutting paste should be used
- Check workings of cooling system. Open the coolant tank’s tap and apply
pressure on the pilot by turning spokes counter clockwise. As the pilot starts to sink
into the cutter, cooling liquid should start to run down the groove in pilot pin. If there is
no liquid flowing down, check if the tap is fully opened. It may take a few seconds for
cooling liquid to fill the whole system.
- Turn the motor on.
Bring the cutter gently into contact with the work piece and slowly start to
apply pressure on the cutter.
Making a hole with an annular cutter should ideally be done in one pass.
Do not peck drill.
WARNING : When the annular cutter goes through the material the
slug can be pushed out often with considerable strength.
Pay attention to avoid injury.
- After a hole is made the cutter should be retracted and both the motor
and the electromagnet should be switched OFF.
- When work with the machine is finished the power cord should be
disconnected from the power source, the machine should be cleaned up from swarf,
coolant etc and the cutter should be removed and cleaned.
10
- Select a suitable rpm speed for the machine to run at, using the table below as a guide.
Once a suitable speed has been decided upon, select that speed using the gear switch on the
side of the gearbox.

HMPRO50 OPERATOR’S MANUAL
www.holemaker.com 11
- Every 250 hours of work check condition of carbon brushes. If their length is
less than 5 mm they should be replaced with new genuine brushes. After replacement,
new brushes should be run-in without load for about 20 min. Repair and service work
is to be performed by authorized service agents only.
- Keep the magnet clean and free of chips, oil or other contaminants.
- Inspect arbor, sleeve and support bracket for visible wear.
- Replace any worn parts and tighten any fasteners that may have come loose during
daily usage.
MAINTENANCE AND SERVICE
11
CANCELLING CLEARANCE
the screws (2) fixing the strip to the drill body visible through the openings in the slider (5). To
loosen screws (2), the slider should be placed in such a position (using feed handles) so that the
openings make the screws visible. After loosening the screws slide the slider up and down several
times so that the pressure strip aligns itself and cancels clearance.
After carrying out these steps and canceling clearance, tighten screws (2) starting from the middle
screw. The slider should be located symmetrically relative to the middle screw. Next, tighten the
neighboring screws (2) moving the slider in the degree necessary for making them visible.
Then, tighten screws (3) until any noticeable resistance is felt. When the screw in this position and
blocked with a hexagonal key, tighten counter nut (4). The screws (3) counteract the machining
force and protect the pressure strip from shifting during operation.

HMPRO50 OPERATOR’S MANUAL
12 www.holemaker.com
BASIC TROUBLESHOOTING
1. Magnetic base not holding securely
• Material is too thin.
• Surface of material being drilled must be free of chips, debris, rust and mill scale.
• Does size of cutter exceed machine’s rated capacity?
• Check magnet face for unevenness, nicks and burrs.
2. Drill motor running, arbor and spindle not turning
• Possible sheared drive train component.
3. Motor slows when drilling
• Is an extension cord being used? If so, see page 5 for recommended wire gages and cord lengths.
• Excessive downfeed pressure during drilling cycle will cause motor to slow and overheat.
• Does cutting tool need to be resharpened?
4. Coolant system not working
• Coolant system is gravity dependent, machine must be in a upright position to operate properly.
• Dirt or debris in coolant tank.
• Consistency of coolant mixture too thick.
• Is correct pilot pin being used?
• Vent hole in coolant tank lid blocked.
5. Slugs not ejecting from cutter
• Lack of coolant causing slugs to expand in cutter bore.
• Is correct pilot pin being used?
• Possible broken internal arbor parts.
6. Breaking cutters
• How is coolant being applied? Coolant must be supplied to interior of cutter.
• Excessive feed pressure being applied when cutter initially contacts work surface.
• Confirm material hardness.
• Drilling stacked materials with incorrect cutter.
• Dull cutters; dull or chipped cutting edges require excessive feed pressure, resulting in breakage.
•
•
Movement of machine on material - See “1. Magnetic base not holding securely”
Inconsistent hardness in material can cause cutter breakage
7. Oversized or rough holes
• Insufficient coolant.
• Excessive feed pressure.
• Dull cutter.
12

HMPRO50 OPERATOR’S MANUAL
www.holemaker.com 13
HMPRO50 MAGNETIC DRILLING MACHINE HOLEMAKER PRO 50
ITEM PART NUMBER QTYNOITPIRCSED
SPPRO5001
SPPRO5002
SPPRO5003
SPPRO5004
SPPRO5005
SPPRO5006
SPPRO5007
SPPRO5008
SPPRO5009
SPPRO5010
SPPRO5011
SPPRO5012
SPPRO5013
SPPRO501304
SPPRO5015
SPPRO5016
SPPRO5017
SPPRO5018
SPPRO5019
SPPRO5020
SPPRO5021
SPPRO5022
SPPRO5023
SPPRO5024
SPPRO5025
FRAME ASSEMBLY,
MOTOR COMPLETE 230V,
CONTROL PANEL 230V
GUARD ASSY,
STOP ROD
LOWER SLEEVE,
UPPER SLEEVE,
SAFTY PIPE,
PINION SHAFT,
SPOKE HANDLE INCLUDING KNOB (ASSY),
ARBOR SET - AMT2-C19/2-2
COOLANT SYSTEM
POWER CORD 230V 3x1,5
STRAIN RIELIEF PG11
NYLON WASHER SR1940,
EXTERNALE RETAINING RING 28z
SCREW M4X10 PHCRMS
SPRING WASHER-4.1
SPRING WASHER-4.3
PUSH SPRING,
SOCKET BUTTON HEAD CAP SCREW WITH FLANGE M5x25,
SOCKET BUTTON HEAD CAP SCREW WITH FLANGE M5x20,
CROSS RECESSED PAN HEAD TAPPING SCREW 3,5x13
WASHER,LOCK,INTERNAL STAR 3,7
SEAL O-RING 5x2
1
2
3
4
5
6
7
8
9
10
11
12
13
13.4
15
16
17
18
19
20
21
22
23
24
25
1
1
1
1
1
1
1
1
1
3
1
1
1
1
4
1
2
2
1
2
1
1
4
4
2
13

HMPRO50 OPERATOR’S MANUAL
14 www.holemaker.com
SPPRO5001 FRAME ASSEMBLY
ITEM PART NUMBER QTYNOITPIRCSED
SPPRO500101
SPPRO500102
SPPRO500103
SPPRO500104
SPPRO500105
MAIN BODY ASSY
D-RING STRAP
ELECTROMAGNETIC BASE,
SPRING WASHER 6,1
HEX. SOCKET BOLT M6x25
1.1
1.2
1.3
1.4
1.5
1
1
1
4
4
14

HMPRO50 OPERATOR’S MANUAL
www.holemaker.com 15
SPPRO500101 MAIN BODY ASSEMBLY
ITEM PART NUMBER QTYNOITPIRCSED
SPPRO50010101
SPPRO50010102
SPPRO50010103
SPPRO50010104
SPPRO50010105
SPPRO50010106
SPPRO50010107
SPPRO50010108
SPPRO50010109
SPPRO50010110
MAIN BODY
PRESSURE PLATE
SLIDE INSERT - LEFT
SELF LUBRICATING SLEEVE 28,05H7x32x16,
SPRING WASHER
DISC SPRING 4,2x10x0,5
HEX SOCKET BOLT-M5X20
ROUND WASHER 5,3
HEX SET SCREW M5X10
NUT M5
1.1.1
1.1.2
1.1.3
1.1.4
1.1.5
1.1.6
1.1.7
1.1.8
1.1.9
1.1.10
1
1
1
2
4
32
5
5
3
3
15

HMPRO50 OPERATOR’S MANUAL
16 www.holemaker.com
SPPRO5002 MOTOR COMPLETE 230V
ITEM PART NUMBER QTYNOITPIRCSED
SPPRO500201
SPPRO500202
SPPRO500203
SPPRO500205
SPPRO500207
SPPRO500208
SPPRO500209
SPPRO500210
SPPRO500211
SPPRO500212
SPPRO500213
SPPRO500214
SPPRO500215
SPPRO500216
SPPRO500217
SPPRO500218
SPPRO500219
SPPRO500220
SPPRO500221
SPPRO500222
SPPRO500223
SPPRO500224
SPPRO500225
SPPRO500226
SPPRO500227
SPPRO500228
SPPRO500229
SPPRO500230
MOTOR ASSY/230V
GEARCASE ASSY
MOTOR HOUSING
MOTOR WIRE ASSY
NEUTRAL MOTOR WIRE ASSY
SHIFT DRIVE PIN (USA-5)
COMPRESSION SPRING (USA 5)
SHIFT LEVER
SHIFT PIN SHORT
GEAR z 52, m=1.25mm
SQUARE KEY 6x6x15
WASHER, THRUST 10x1 (2x2)
BEARING WASHER 8,1
SHIFT FORK
PINION SHAFT z12, z20 ASSY
PINION SHAFT Z=12 ASSY,
LABEL, SHIFT LEVER
BEARING, NEEDLE RHNA 081210
SPRING PIN 4x16
EXTERNALE RETAINING RING 25z
SPRING WASHER M5
HEX. SOCKET BOLT M5x35
HEX. SOCKET BOLT M5x40
SCREW M3x5 PHCRMS
CROSS RECESSED RAISED COUNTERSUNK HEAD SCREW M5x10
SCREW M4X12 PHCRMS
SPRING WASHER-4.3
SPRING WASHER-4.1
2.1
2.2
2.3
2.5
2.7
2.8
2.9
2.10
2.11
2.12
2.13
2.14
2.15
2.16
2.17
2.18
2.19
2.20
2.21
2.22
2.23
2.24
2.25
2.26
2.27
2.28
2.29
2.30
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
4
2
2
3
2
2
16

HMPRO50 OPERATOR’S MANUAL
www.holemaker.com 17
SPPRO500201 MOTOR ASSEMBLY
ITEM PART NUMBER QTYNOITPIRCSED
SPPRO50020101
SPPRO50020102
SPPRO50020103
SPPRO50020104
SPPRO50020105
SPPRO50020106
SPPRO50020107
SPPRO50020108
SPPRO50020109
SPPRO50020110
SPPRO50020111
MOTOR COVER
GUIDE FAN
ARMATURE ASSY 230V
ARMATURE TOOTH END z12
FIELD 230V
UPPER HOUSING
CROSS RECESSED PAN HEAD TAPPING SCREW 4x16
SPRING WASHER
BRUSH 230V
SPRING BRUSH
HEXAGON BOLT M4x73
2.1.1
2.1.2
2.1.3
2.1.4
2.1.5
2.1.6
2.1.7
2.1.8
2.1.9
2.1.10
2.1.11
1
1
1
1
1
1
4
1
2
2
2
17

HMPRO50 OPERATOR’S MANUAL
18 www.holemaker.com
SPPRO500202 GEARBOX ASSEMBLY
ITEM PART NUMBER QTYNOITPIRCSED
SPPRO50020201
SPPRO50020202
SPPRO50020203
SPPRO50020204
SPPRO50020205
SPPRO50020206
SPPRO50020207
SPPRO50020208
SPPRO50020209
SPPRO50020211
SPPRO50020213
SPPRO50020214
SPPRO50020215
GEARCASE
SPINDLE
GEAR RACK
UPPER SPINDLE BEARING 6206 2Z P6 S 30x62x16
UPPER SPINDLE BEARING 6005 25x47x12
BEARING, NEEDLE RHNA 101610
BEARING, NEEDLE RHNA 081210
EXTERNAL RETAINING RING 30z
EXTERNALE RETAINING RING 25z
INTERNAL RETAINING RING 62W
PIN 6x14
SPRING WASHER 5.1
HEX SOCKET BOLT-M5X20
2.2.1
2.2.2
2.2.3
2.2.4
2.2.5
2.2.6
2.2.7
2.2.8
2.2.9
2.2.11
2.2.13
2.2.14
2.2.15
1
1
1
1
1
1
1
1
1
1
1
2
2
18

HMPRO50 OPERATOR’S MANUAL
www.holemaker.com 19
QTY
SPPRO500217 PINION SHAFT z12, z20 ASSEMBLY
ITEM PART NUMBER DESCRIPTION
2.17.1
2.17.2
2.17.3
2.17.4
SPPRO50021701
SPPRO50021702
SPPRO50021703
SPPRO50021704
GEARSHAFT, 12T/20T (2x2)
HELICAL INPUT GEAR z46
WOODRUFF KEY 3x3.7
BEARING, BALL- 8X22X7
1
1
1
1
QTY
SPPRO500218 PINION SHAFT Z=12 ASSY,
ITEM PART NUMBER DESCRIPTION
2.18.1
2.18.2
2.18.3
SPPRO50021801
SPPRO50021802
SPPRO50021803
GEARSHAFT, 12T (2x2)
CLUSTER GEAR z52/z44, m=1mm
SQUARE KEY 3x3x36
1
1
1
19

HMPRO50 OPERATOR’S MANUAL
20 www.holemaker.com
QTY
SPPRO5003 CONTROL PANEL ASSEMBLY
ITEM PART NUMBER DESCRIPTION
3.1
3.2
3.3
3.4
3.5
3.6
SPPRO500301
SPPRO500302
SPPRO500303
SPPRO500304
SPPRO500305
SPPRO500306
PANEL PLATE ASSY
ELECTRONIC CONTROLLER SW-30M
SWITCH START-STOP /230V
SWITCH MAGNET
METAL LOCK,
INTERFERENCE ELIMINATOR,
1
1
1
1
4
1
20
