Hollywood Racks 1 Instruction manual

Trike Adapter Model #1
Assembly and installation instructions
Fits Hollywood Racks Sportrider models “Y” and “Z” series
And Hollywood Trail Rider HR200 (max. weight 40 lbs)
For “X’ series Sportriders (2009-2016), please contact us at 800/747-4085 or
email: [e-mail]
Not to be used on any trailer, fifth wheel or vehicle being towed
by another vehicle
Not to be used with adult trikes or electric recumbent trikes
Weight Limit: 60 lbs
Model HR200 Trail Rider max weight 40 lbs
The trike Adapter 1 will carry one trike.
A
1
Hollywood Racks
Parts List: Qty
A Long Connector 1
B Universal Connector 1
C Short Connector 1
D Hardware and hex key
E Tie down strap 2
NOT TO BE USED WITH ADULT TRIKES

2
The small wheel adapters must be used on 16” wheels.
Please determine the model number of your Sportrider.
The HR200, HR1000Y, HR1400Y and HR1450Y use
standard length wheel holders (max wheelbase 60”).
The HR1000R and HR1450R recumbent racks use
longer length wheel holders (max wheelbase 72”).
Installation procedure for delta style trikes
Installation procedure:
1. Measure width between center of tires (track) and distance between center of hubs (wheelbase).
2. Install left side wheel holder on driver’s side wheel support tube.
3. Slide the long connector Aalong passenger side wheel tube.
4. For standard length wheel holders, install the universal connector Bonto the end closest to the car.
5. For longer length wheel holders, install the universal connector Bonto the end furthest from the car.
Trike adapter assembled to HR1450-Y
(standard length wheel holders)
6. Slide short connector Conto outside end of long connector A.
7. Install wheel holders onto universal and short connectors.
8. Place bike directly behind rack (rear wheel on driver’s side), then “center” the trike between vehicle’s
side view mirrors.
9. Using the measurements taken in step 1, adjust the single driver’s side wheel holder and long
connector for the wheelbase.
10. Adjust the distance between the two passenger side wheel holders (track). You may need to flip
the universal connector around to obtain the correct dimension.
11. Snug up all knobs and set screws, then lift the trike onto the rack to check the dimensions. If
the trike is centered behind the car and the wheels are correctly seated in the wheel holders, finish
tightening up the knobs and set screws. Install the screws into the ends of the connector tubes.
12. Install the Sportrider frame hook onto the center mast per the Sportrider general instructions.
Use the correct length version, depending on your trike. Push the hook firmly down onto the frame.
13. Attach the wheel straps and optional extra tie down straps.
Optional positions of universal connector

3
Installation procedure for most tadpole style trikes
Follow the same procedure as above for Delta style trikes,
except the center mast will have to be either folded down
to the side (models HR1400, HR1450, HR1450R) or
removed (models HR1000 and HR1000R). This is due
to the interference of the tadpole’s seat.
The tie down straps must be used when carrying tadpole
style racks.
Tie down strap used to secure trike to rack
HR1000R-Y shown with mast folded down for carrying
longer wheelbase tadpole
HR1000R-Y shown with mast removed for
carrying tadpole

Hollywood Racks
Limited Lifetime Warranty (effective January 1, 2008):
Hollywood Racks will warranty its car racks and accessories during the time that an original retail purchaser owns the product
subject to the exclusions and limitations of this warranty. Hollywood Racks will remedy defects in materials and workmanship by
repairing or replacing (at its option) the complete rack or a defective part without charge for labor or parts. Hollywood Racks may
elect (at its option) to issue a refund equal to the purchase price paid for the product.
This warranty does not cover problems caused by normal wear and tear including (but not limited to) weather, scratches, dents,
rust, accidents, unlawful vehicle operation, misuse, abuse, neglect, theft, unauthorized modifications, or unauthorized repair. No
warranty is given for defects resulting in incorrect assembly, incorrect installation onto the vehicle, installation on a “no fit” vehicle,
incorrect attachment of bicycles onto the rack, or overloading of the rack’s weight restrictions. This warranty terminates if the
original retail purchaser transfers the product to any other person.
If a product is believed to be defective, the original retail purchaser should contact either the original retailer or Hollywood Racks
directly at 800-747-4085 or at [e-mail]
Disclaimer of Liability: Repair or replacement of a defective product or the issuance of a refund or credit (as determined by
Hollywood Racks) is a purchaser’s exclusive remedy under this warranty. Damage to a purchaser’s vehicle, cargo, bicycles and
or to any other person is excluded. This warranty is expressly made in lieu of any and all other express warranties, whether oral
or written.
Hollywood Racks shall not be liable for any direct, indirect, consequential, incidental, special, punitive or any other damages in
connection with the purchase, use or handling of this product. Some states do not allow the exclusion or limitation of
consequential or incidental damages and the above limitation may not apply to you. This warranty gives you specific legal rights
and you have other rights, which vary from state to state.
Hollywood Racks
12812 S. Spring St. Los Angeles, CA 90061
Tel [phone] [phone] FAX [phone]
www.hollywoodracks.com email: [e-mail]
Customer Service Hours: M-F 8:00AM to 3:00 PM PST
V2.2 061218 Made in Taiwan
