Holman WS5056C User manual

Instruction Manual
Solar Powered
Outdoor Weather
Data Collector
Indoor Receiver
Product Code: WS5056C
Solar Weather Centre
With Wireless Weather Vane

Thank you for purchasing the Holman 5056 Solar Powered Weather Station. The system
consists of a data gathering Solar Powered outdoor weather collector which is mounted on the
outside of your home and transmits the collected data wirelessly to a pad inside the house that
displays all the readings and results.
Please read the operating instructions carefully to familiarise yourself with the features and
modes of operation before using the instrument.
Package Contents
Carefully unpack and remove the contents:
• 1xweatherstationmainIndoorunit
• Allinonedatacollectorwithsolarpanel
• 1xstainlesssteelmast
• Stainlesssteelaccessoryforxing
• 1xbatterycharger
• 1xlithiumLIPObattery
Technical Details
• Sixkeys:MODE,+,-,IN,OUT,SNOOZE/LIGHT
• Timedisplayin12hror24hrformat
• Continuousperpetualcalendarupto2099
• DisplayofDate,MonthandDayofweek
• DayofweekdisplayinEnglishonly
• Dualalarmwithsnoozefunction(5minutealarminterruption)
• 5weatherforecast:sunny,partlysunny,cloudy,rainy,storm
• Barometerandbarof12hourshistoryforairpressure
• Indoor/outdoortemperatureandhumiditywithtrend
• Max./min.oftemperatureandhumidity
• Thermometermeasuringrangeinside:0°Cto+50°C,outside-20°C~60°C
• Temperaturedisplayelectivein°Cor°F
• Livingspacehumidity
• Moonphase
• Windspeedinmph/kmh,windspeed0~256kmh
• Winddirectionin16directions
• Rainfallinmmandinchanddisplayof1hour,24hour,TOTAL(0~999.99mm)
• UVindex
• LUXdisplay(0~120KLUX)
• Feellike
• Dewpoint
• WindChill
• Heatindex
• Lowbatteryindicationforindoor
• BluebackgroundilluminationLED.
• Mainunitbatteries:2xAA,LR06,1.5V
TECHNICALDETAILS

INSTALLATION
All in one outdoor data collector , solar powered
• Frequency:917MHz
• Transmissionrange:100metersinopenarea.
 **Actualdistancemaybevarieddependingupontheenvironment,andcanbe
shortened by interference such as concrete walls.
• Solarpowered+built-inRechargeablebattery:3.7V,1800maH
Installation
• Already tted with Lithium Poly (LIPO) rechargeable battery.
• OpenthebatterycoverlocatedatthebackofthemainunitandremoveLIPObattery
and charge it with the charger supplied. This should not take longer than one hour.
• Beforeclosingthebatterycover,pushtheinsideblackswitchfromOFFtoON(very
 important),andcheckiftheredLEDlightisashingwhentheswitchisturnedtoON,
this means the transmission is working. Then close the battery cover properly.
• TheredLEDlightwillashapproximatelyevery1minutewhentransmittingthesignal
to the inside main unit.
The Indoor Receiver
• TheIndoorReceivercanbeplacedontoanyatsurfaceorwallmountedatthedesired
 locationbythehanginghole,Itisimportanttocheckthattheradiosignalcanbe
received before mounting.
SWITCH

OUTDOORDATACOLLECTOR/MANUALSETUP
Mounting the outdoor weather data collector onto the stainless steel mast
Foraccurateresults,theoutdoordatacollectormetalpoleshouldbesecurelymountedontoa
horizontalsurfacewhereitisatleast1meterabovetheground,andinanopenareaawayfrom
trees and other coverings where rainfall or wind speed may be reduced and cause
Inaccurate readings.
Note:
1. Pleaseensurethatthewindspeedandwinddirectionarmsarefreetomoveandnot
touching or resting on anything nearby.
2. ThereismarksW,S,E,Nontheshaftofthewindsensor,pleasemakesurethe“N”
 pointstotheNorthdirection.
3. Set-uptheindoorreceiverandoutdoordatacollectorinanOPENaspossiblearea.
This means trying to avoid concrete walls or anything that may cause interference
between the two units as this may shorten the transmission distance.
4. Set-uptheoutdoordatacollectorinaveryopenareaoutside,inthedirectsunlight,
 avoidshadedareasasthiswillcausetheUVtoreadincorrectly.
5. PositionthebubbleinthemiddleofthelevelIndicator,thisisimportanttoensurethe
rain gauge and wind measurements are accurate.
6. Fixthemetalpoleasourabovepictureillustrates,makesurethemetalpoleis 
 mountednomorethan60mmbelowthesurface,thisistoensurethatthewindsensor
has room to move around freely.


LCDDISPLAY
LCD overview
1. Weather
2. SunshineforLUX
3. Rain
4. UVindex
5. Wind direction
6. Wind speed
7. Date
8. Month
9. Dayofweek
10. Moonphase
11. Radiocontrolled
 symbol(thisisnot
 applicableinAustralia)
12. Time
13. Alarm
14. Outdoorhumidity
trend
15. Summer/Wintertime
 symbol(notapplicable
 inAustralia)
16. Outdoorhumidity
17. Indoorhumidity
18. Outdoortemperature
19. Outdoortemperature
trend
20. Heatindex
21. Windchill
22. RFsymbol
23. Max/Minforoutdoor
temperature and
humidity
24. Livingface
25. DewPoint
26. FeelLike
27. Indoortemperature
28. Max/Minforindoor
temperature and
humidity
29. Indoortemperature
trend
30. Indoorhumiditytrend
31. Indoorlowbattery
32. Barof12hourair
pressure history
33. Airpressurereading.
A=MODEB=+C=-D=INE=OUTF=SNOOZE/LIGHTG=reset

OUTDOORWEATHERVANE/INITIALOPERATION
1.WindDirection2.Solarpanel3.RFchannel(holdfortransmittingRFsignal)
4.Raingauge5.UVindexandLUXsensor6.Levelindicator(tojudgeifset
uphorizontally)7.ON/OFFforpower8.Built-inrechargeablebattery9.
Windspeedsensor10.Metalpole11.Coverforthermometerandhygrometer
Initial Operation
• ChargetheLIPObattery
• Turnontheswitch
• Afterturningontheswitch,themainunitwillconnectwiththeout-
 doordatacollectorbyRFsignal.
 TheRFsignalsymbolattheoutsideunitwillash.
• Thisprocesstakesabout3minutes.Thenthedisplayshowstheout
 doortemperature/humidity/windspeed/winddirection/rainfall/UV
 index,incaseoffailureofreception,pleasepress“OUT“formore
 than3secondstoreceiveagain.
1910
11
8
7
2
3
4
56

INITIALOPERATION/ALARM
Manual time set-up
PleaseNote:
Theclockautomaticallychangesfromset-upmodetotimedisplaymodeifno
keysarepressedfor20seconds.PressandholdMODEkeyfor3secondsto
get back to set up mode
• Pressandholdkey“MODE“for3seconds.
• The12hr/24hrwillbeashing.Use“+“and“-“toselect
• Press“MODE“toconrm.
• TheDM(date/month/MD(month/date)willbeashing,Use“+“and“-“
to select
• Press“MODE“toconrm.
• Thedisplayforthemonthwillbeashing.Use“+“and“-“toselect
the month.
• Press“MODE“toconrm.
• Thedisplayforthedatewillbeashing.Use“+“and“-“toselect
the date.
• Press“MODE“toconrm.
• Thedisplayforthehourwillbeashing.Use“+“and“-“toselectthe
hour.
• Press“MODE“toconrm.
• Thedisplayfortheminuteswillbeashing.Use“+“and“-“to
select the minutes..
• Press“MODE“toconrm.
• TheC/Ffortemperaturewillbeashing,Use“+“and“-“toselect.
• Press“MODE“toconrm.
• Thehpa/inhgforairpressurewillbeashing,Use“+“and“-“to
select.
• Press“MODE“toconrm.
• Themm/inchforrainfallandkmh/mphforwindspeedwillbeashing,
 Use“+“and“-“toselect.
• Press“MODE“toconrm.
• Pleasefollowtheabovestepstochooseindividualsettings,suchas
 12/24hour,C/F,languagesetc.
Daily alarm set-up
• Press“MODE”toswitchfromtimedisplaytoA1display
• Pressandholdthekey“MODE”for3seconds,thealarmtimeis
shown
• Thehourdisplayofthealarmtimeisashing.Use“+“and“-“to
select the hour
 thenfollowwiththeminutes.Use“+“and“-“toselect.
• Press“MODE”toconrm.
• FollowthesamesettingforA2.

Daily alarm on/o
WheninthemodeofA1:
• Press“-“toactivatethealarm1
• Press“-“twicecancelthealarm1.
• Followthesamesettingforalarm2.
Information:
• Theclockautomaticallychangesfromset-upmodetotimemodeif
 nokeysarepressedfor20seconds.
• Thealarmsoundsfor2minutesifnokeyispressedtostopit.
Snooze function
Toactivatethesnoozefunction,followthestepsbelow
• Pressthekey“SNOOZE/LIGHT“,whilethealarmsounds,toactivate
 thesnoozefunction.
• Ifthesnoozefunctionisactivated,alarmsymbolisashing.
• Thealarmrepeatafter5minutes.
• Thesnoozefunctioncanbestoppedbypressinganykey.
12/24 hours mode
Thetimedisplaycanbein12hrAM/PMor24hourmode,pleasefollowthe
manualset-uptoselect
°C/°F temperature display
Thetemperaturedisplaycanbein°Cor°F,pleasefollowthemanualset-up
to select.
Max./ Min. for the indoor/outdoor temperature and humidity
Press“+“fordisplayingofindoor/outdoormax./min.oftemperatureandhu-
midity,hold“+“formorethan3secondstoclearupthemax./min.
Trend arrow for the indoor/outdoor temperature and humidity
Thereareat,upanddownarrowsforthetrendofthetemperatureandhu-
midity
SNOOZE/TIME/TEMPERATURE

Weather forecast
Sunny Slightly Sunny Cloudy Rainy Storm
PleaseNote:Thechangingofthebarometricpressureisusedtopredictthe
coming weather. The forecast is an indication and the pictures can at times
be incorrect.
Barometer and bar and data of history for the past 12 hour of air pres-
sure.
Theprevious12hoursshownonthebargraphareanindicationoftherising
or falling in atmospheric pressures.
AirpressurecanbereadinhPaandinHg.
Hold“IN“forexchangeofSunshineandairpressurereading.
Air pressure setting and weather icon selection by SNOOZE/LIGHT
button
TheairpressurereadingcanbeadjustedbyholdingtheSNOOZE/LIGHTfor
3second,thealtitudewillbeashing,press“+“or“-“toadjust.Thenpress
SNOOZE/LIGHTagain,theweathericonwillbeashing,press“+“or“-“to
selectweatherpicture,pressSNOOZE/LIGHTtoconrm.
Wind speed in mph/kmh
Thewindspeedcanbeshowninmphandkmh,andwillrecordfrom0to
256kmh.Pleasefollowthemanualset-uptoselectmph/kmh,thedisplayof
thewindspeedisupdatedevery1minute.
Wind direction
Therewillbe16winddirections,thedisplayofthedirectionisupdatedevery
1minute.
Rainfall display
• Rainfallcanbeshowninmmandinch,andwillrecordfrom0to
FORECAST/WINDDIRECTION/RAINFALL

 999.99mm.Pleasefollowthemanualset-uptoselectthe
 mm/inch.
• Press“-“toshowtherainfallin1hour,presstwicefor24
 hours,then3timesforTOTAL.
• Press“-“formorethan3secondstoclearupthevolume
 accordingly,suchas,ifshowing1hour,thisclearsthedata
 in1hourdisplay,othersunchanged,ifshowing24hours,
 clearupthedatain24hourdisplay,othersunchanged.
• Themax.amountofrainfallthatwillberecordedis 
 999.99mm(99.99inch),thedisplaywillashingwhenthe
 maxhasbeenreached,youwillneedtomanuallyclearout
 thedata,otherwise,thedatawillnolongerrecord.
• TomanuallycleartheTotalrainfall,selecttheTotalsetting
 andholdtheminusbuttoninfor3secondsormoreand
the display will disappear.
NOTE:Therainfallmeasurementsupdateatmidnight.Ifthisisin-
convenientitisbesttomaketheclock12hoursoutofsync-i.e.PM
insteadofAM.Thentheupdateoccursat12noon.Soitiseasyto
seethelast24hoursrainreading.
Sunshine LUX reading
TherangeforLUXis0~120KLUX
Hold“IN“forexchangeSunshineandairpressurereading.
UV Index
TheUVindexwillbedisplay.
Feel like and Dew point
Press“IN“tochecktheDEWPOINTandFEELLIKE
Wind chill and Heat Index
Press“OUT“tochecktheHEATINDEXandWINDCHILL
Illumination
Pressthekey“SNOOZE/LIGHT“toactivatethedisplayillumination
for10seconds.
UVINDEX/DEWPOINT/HEATINDEX

Moon phase display
The weather station uses saved data to show the moon phase
 A B C D E F G H
A:Newmoon B:Increasingcrescent C:Firsthalf
D:Increasing3/4 E:Fullmoon F:Decreasing3/4
G:Lasthalf H:Decreasingcrescent
Living space humidity
The weather station uses saved data to determine the humidity in the living
space and shows the respective symbols.
comfortable,dry, humid
Low battery condition display
The weather station displays the low battery condition symbol to remind you
thebatteriesoftheindoorreceiverneedtobeexchanged.
There will be an unhappy face displayed in between the indoor temperature
andhumidityreadings,thiswillmeanthebatteriesneedtobereplaced.
RF connection to the outdoor data collector
Pressandholdthekey“OUT“for3secondstosearchforoutdoordata
collector,theRFsignalsymbolattheoutsideareawillashingwhentrying
toconnect.RFreceptionisweakerinroomswithconcretewalls(e.g.inthe
basement)andinocebuildings,thedistancewillbeshortenifhaveinterfer-
ence.Forextremecases,pleaseputthemainunitnearawindow.
MOONPHASE/LIVINGSPACEHUMIDITY

WARRANTY
Shouldyouhaveanyquestionsaboutthisproductoritsoperationplease telephone
our customer service help line on 1300 716 188.
Holmanoera1 year replacement warranty from the original date of purchase.
To claim warranty the product must be returned with a copy of the original receipt.
We will honour all statutory guarantees that this product is of acceptablequality
(Includingthatitistforpurpose).
HOLMAN INDUSTRIES
11WaltersDrive,
OsbornePark,
WesternAustralia6017.
Ph:1300716188
www.holmanindustries.com.au
Solar Powered
Outdoor Weather
Data Collector
Indoor Receiver
