Holmes HAWF3195R User manual

WARRANTY INFORMATION
5 YEAR LIMITED WARRANTY
Sunbeam Products, Inc. doing business as Jarden Consumer Solutions or if in Canada, Sunbeam Corporation (Canada)
Limited doing business as Jarden Consumer Solutions (collectively “JCS”) warrants that for a period of five years from
the date of purchase, this product will be free from defects in material and workmanship. JCS, at its option, will
repair or replace this product or any component of the product found to be defective during the warranty period.
Replacement will be made with a new or remanufactured product or component. If the product is no longer available,
replacement may be made with a similar product of equal or greater value. This is your exclusive warranty. Do NOT
attempt to repair or adjust any electrical or mechanical functions on this product. Doing so will void this warranty.
This warranty is valid for the original retail purchaser from the date of initial retail purchase and is not transferable.
Keep the original sales receipt. Proof of purchase is required to obtain warranty performance. JCS dealers, service centers,
or retail stores selling JCS products do not have the right to alter, modify or any way change the terms and conditions of this
warranty.
This warranty does not cover normal wear of parts or damage resulting from any of the following: negligent use or
misuse of the product, use on improper voltage or current, use contrary to the operating instructions, disassembly, repair
or alteration by anyone other than JCS or an authorized JCS service center. Further, the warranty does not cover: Acts
of God, such as fire, flood, hurricanes and tornadoes.
What are the limits on JCS’s Liability?
JCS shall not be liable for any incidental or consequential damages caused by the breach of any express, implied or
statutory warranty or condition.
Except to the extent prohibited by applicable law, any implied warranty or condition of merchantability or fitness for a
particular purpose is limited in duration to the duration of the above warranty.
JCS disclaims all other warranties, conditions or representations, express, implied, statutory or otherwise.
JCS shall not be liable for any damages of any kind resulting from the purchase, use or misuse of, or inability to use the
product including incidental, special, consequential or similar damages or loss of profits, or for any breach of contract,
fundamental or otherwise, or for any claim brought against purchaser by any other party.
Some provinces, states or jurisdictions do not allow the exclusion or limitation of incidental or consequential damages or
limitations on how long an implied warranty lasts, so the above limitations or exclusion may not apply to you.
This warranty gives you specific legal rights, and you may also have other rights that vary from province to province,
state to state or jurisdiction to jurisdiction.
How to Obtain Warranty Service
In the U.S.A.
If you have any questions regarding your product, this warranty, or would like to obtain warranty service, please visit
our website at www.holmesproducts.com or call 1-800-546-5637 and a convenient service center address will be
provided to you.
In Canada
If you have any questions regarding your product, this warranty, or would like to obtain warranty service, please visit
our website at www.holmesproducts.com or call 1-800-546-5637 and a convenient service center address will be
provided to you.
PLEASE READ AND SAVE THESE IMPORTANT INSTRUCTIONS
Owner’s Guide
HAWF3195R
WARRANTY INFORMATION
Remote Twin
Window Fan
In the U.S.A., this warranty is offered by Sunbeam Products, Inc. doing business as Jarden Consumer Solutions located
in Boca Raton, Florida 33431. In Canada, this warranty is offered by Sunbeam Corporation (Canada) Limited doing
business as Jarden Consumer Solutions, located at 20B Hereford Street, Brampton, Ontario L6Y OM1. If you have any
other problem or claim in connection with this product, please write our Consumer Service Department. PLEASE DO
NOT RETURN THIS PRODUCT TO ANY OF THESE ADDRESSES OR TO THE PLACE OF PURCHASE.
9100010009858 HAWF3195R07EM1 Printed In China
© 2007 Sunbeam Products, Inc. doing business as Jarden Consumer Solutions. All Rights Reserved. Distributed by
Sunbeam Products, Inc. doing business as Jarden Consumer Solutions, Boca Raton, Florida 33431.
HAWF3195R_07EM1.qxd 10/15/07 2:49 PM Page 1

For example, if you have set your thermostat to 75
degree and the room temperature drops to 74 degrees or
lower then the fan will automatically turn off. The fan will
then turn on again when the room temperature exceeds
75 degrees.
Setting Auto Mode
1. Press the Mode button to scroll to the desired auto
speed setting (A3, A2, or A1).
2. Choose the desired temperature setting by pressing
the Temp Up (+) or Temp Down (-) buttons. You may
select a temperature between 60 and 80 degrees
Fahrenheit. Once the desired temperature is set, the
digital display will return to show the ambient room
temperature. View the set temperature by pressing
either the Temp Up (+) or Temp Down (-) buttons.
IMPORTANT: If the fan does not start in the Auto
mode, please be sure that the set temperature is below
the current room temperature. Lower the set temperature
if you would like for the fan to start or switch over to the
manual speed modes.
Setting the Timer
1. Hold both the Temp Up (+) and Temp Down (-)
buttons down until the digital display flashes “00”.
2. Press the (+) or (-) buttons to change time in 1 hour
increments. Note selection ranges from 1 to 16
hours. When in the timer mode, the time remaining
will be displayed.
NOTE:
•The Timer Light will glow indicating the timer function
is active.
•If Timer is set when fan is ON, the time displayed will
turn the fan OFF once elapsed. If Timer is set when
fan is OFF, the time displayed will turn the fan ON.
(The default ON speed setting is Manual Low)
•Timer function can be turned off by pressing the
MODE key at any time.
CLEANING/MAINTENANCE
INSTRUCTIONS
Follow these instructions to correctly and safely care for
your fan. Please remember:
•Always unplug the fan before cleaning.
•Do not allow water to drip on or enter into fan
housing.
•Be sure to use a soft cloth moistened with a mild
soap solution.
•Do not use gasoline, thinner or benzene as a cleaner.
Fan Cleaning
Clean the fan grills, extender screen, and extender panels
with a soft, damp cloth. Please use caution around the
motor housing area. Do not allow the motor or other
electrical components to be exposed to water. Also, using
a soft bristle brush attachment, a vacuum cleaner may be
used to extract dust buildup on the grill areas. Note to
turn the fan off before cleaning.
FAN STORAGE
When storing your fan in the off season, it is important to
keep it in a safe dry location. It is important to protect
the fan head from dust. We strongly recommend using
the original box from purchase.
WINDOW FAN ACCESSORIES
it is flush on both the top and bottom of the Window
Fan.
5. To keep the fan in place, carefully close the window
so that the bottom edge of the window rests on the
flat area on the top of the fan.
For Slider Windows
1. Set the Fan Vertically in your window opening with
the left side of the fan situated on the bottom and
the Built-In-Extender panel on top.
2. Set the fan into your window opening (note that in
most cases the window screen does not have to be
removed or left open).
3. If the fan does not fit snugly to the top and bottom
of the window casing, attach the Slider Safe®
Extender Panel and adjust the built-in extender
screen until the fan fits securely in your window.
WARNING: BE SURE FAN IS SECURELY INSTALLED IN
YOUR WINDOW AT ALL TIMES. DO NOT LEAN OR PUSH ON
THE FAN WHILE IT IS IN THE WINDOW.
REMOTE CONTROL
Your remote control requires (2) AAA batteries for
operation. To install the batteries, simply depress the back
of the remote with your thumb on the indentations.
Insert batteries according to the diagram shown inside
and replace cover.
•Do not mix old and new batteries.
•Do not mix alkaline, standard (carbon-zine), or
rechargeable (nickel-cadmium) batteries.
The remote controls the Mode, Speed, Temperature, and
Timer settings.
OPERATING INSTRUCTIONS
1. Plug cord into any standard 120 volt AC outlet.
2. To turn the fan on and control the speed, press the
mode button. Note that pressing the mode button will
allow you to cycle through the speed setting (High =
3, Med = 2, Low = 1) as well as the Automatic
Thermostat Temperature settings (Auto High = A3,
Auto Medium = A2, Auto Low = A1). 0 indicates the
Off position.
3. Set the airflow direction by sliding the fan directional
switches located above each fan blade. Note that the
fan blades work independently from one another and
can be used for air intake (bring fresh air in from
outside), exhaust (push air out from within the room)
or exchange (cycles air in and out of the room
simultaneously).
Auto Mode
Your fan is equipped with the AccuTemp PlusTM Digital
Thermostat that will automatically turn the fan ON and
OFF depending upon the preset comfort temperature. This
is ideal for nighttime operation when temperatures can
drop below comfort levels.
PLEASE READ AND SAVE THESE
IMPORTANT SAFETY INSTRUCTIONS FEATURES - OPERATIONS
When using electrical appliances, basic safety precautions
should always be taken including the following:
1. Read all instructions before using this appliance.
2. Use fan only for purposes described in the instruction
manual.
3. To protect against electrical shock do not immerse
unit, plug or cord in water or spray with liquids. Plug
the appliance directly into a 120V AC electrical outlet.
4. Close supervision is necessary when any appliance is
used by or near children.
5. Unplug from outlet when not in use, when moving
fan from one location to another, before putting on
or taking off parts and before cleaning.
6. Avoid contact with moving parts.
7. Do not operate in the presence of explosive and/or
flammable fumes.
8. To avoid fire hazard, NEVER place the cord under
rugs or any parts near an open flame, cooking or
other heating appliance.
9. Do not operate any appliance with a damaged cord
or plug after the appliance malfunctions, or has been
dropped/damaged in any manner.
10. The use of attachments not recommended or sold by
the appliance manufacturer may cause hazards.
11. Do not use outdoors.
12. Do not let the cord hang over the edge of a table,
counter or come in contact with hot surfaces or leave
exposed to high traffic areas.
13. To disconnect, grip plug and pull from wall outlet.
Never yank on cord.
14. Always use on a dry, level surface.
15. Do not operate fan until fully assembled with all
parts properly in place.
16. This product is intended for household use ONLY and
not for commercial or industrial applications.
PLEASE READ AND SAVE
THESE IMPORTANT SAFETY
INSTRUCTIONS
INSTALLATION INSTRUCTIONS
NOTE: MAKE SURE YOU REMOVE ALL CONTENTS OF THE
PACKAGE. PLEASE CHECK PACKAGING MATERIALS FOR
PARTS THAT COULD BE REQUIRED TO ASSEMBLE YOUR
FAN.
This window fan has been designed to fit double-hung
windows with minimum openings of 24 inches (60 cm)
wide and 12 inches (30 cm) high.
NOTE: This fan is designed and recommended for use
with a screen in the window.
Window Fan Installation
1. Align the Window Fan horizontally in the window
with the controls facing you and the Built-In Extender
Panel to the right.
2. Set the fan into your window opening (note that in
most cases the window screen does not have to be
removed or left open).
3. If the fan does not fit snugly to the left and right of
the window casing, pull out the Built-In Extender
Panel until the fan sits safely in your window.
4. If the fan still does not fit snugly attach the Slider
Safe®Extender Panel located in the polyfoam
packaging in the original box. Align the slot in the
Slider Safe®Extender Panel along the tab located on
the left side of your Window Fan. Slide the Slider
Safe®Extender Panel completely down the tab until
FEATURES - OPERATIONS
CLEANING/MAINTENANCE
THIS APPLIANCE HAS A POLARIZED PLUG (one blade is wider than the
other). To reduce the risk of electric shock, this plug is intended to fit in
a polarized outlet only one way. If the plug does not fit fully in the
outlet, reverse the plug. If it still does not fit, contact a qualified
electrician to install the proper outlet.
DO NOT ATTEMPT TO MODIFY THIS PLUG OR DEFEAT THIS
SAFETY FEATURE IN ANY WAY.
A. Front Grill
B. Left Fan Directional Switch
C. Control Panel
D. Mode Button
E. LED Display
F. Tem p Up (+)
G. Temp Down (-)
H. Right Fan Directional Switch
I. Extender Locks
J. Extender Panel (not shown)
K. Built-In Extender Panel
L. Remote Control (not shown)
ABCDEFGHIK
Figure 1
If you have any questions regarding your product or
would like to learn more about other Holmes®
products, please contact our Consumer Service
Department at 1-800-546-5637 or visit our website at
www.holmesproducts.com
Window Fan
Extender Panel
To order please go to
www.holmesproducts.com
or call 1-800-546-5637
HAWF3195R_07EM1.qxd 10/15/07 2:49 PM Page 2
