HOMCOM 821-018V70 Installation guide

1

2
EN_Contents
Reliable Humidity Control
1. BEFORE YOU BEGIN........................................... 03
2. FOR YOUR SAFETY ............................................05
3. WHERE TO USE ................................................. 09
4. QUICK START GUIDE ......................................... 10
5. PRODUCT OVERVIEW ........................................11
6. HOW TO USE..................................................... 12
7. CLEANING AND CARE......................................... 18
8. TROUBLESHOOTING .......................................... 19
9. SPECIFICATIONS ............................................... 20
10. STORAGE AND DISPOSAL.................................. 21
Safeguard and Protect
Effectively Removes Moisture

3
1. BEFORE YOU BEGIN
1.1 PRODUCT DESCRIPTION
The dehumidifier is used to remove excessive moisture from the air. The resulting reduction
in relative humidity protects buildings and their contents from the adverse effects of excess
humidity.
The environmentally friendly R290 is used as the refrigerant. R290 has no damaging
influence on the ozone layer (ODP), a negligible greenhouse effect (GWP) and is
availableworldwide. Because of its efficient energy properties, R290 is highly suitable as a
coolant forthis application. Special precautions must be taken into consideration due to the
coolant's highflammability.
WARNING
Any person who is involved with working on or breaking into a refrigerant circuit
should hold a current valid certificate from an industry-accredited assessment
authority, which authorizes their competence to handle refrigerants safely in
accordance with an industry, recognized assessment specification.
WARNING
Servicing shall only be performed as recommended by the equipment
manufacturer. Maintenance and repair requiring the assistance of other skilled
personnel shall be carried out under the supervision of the person competent in
the use of flammable refrigerants.
1.2 SYMBOLS FROM THE UNIT AND USER MANUAL
If the user ignores this warning and mishandles the product, it may result in serious
and fatal injury or death to the user.
If the user ignores this note and mishandles the product, it may result in injury to the
user, or material damages.
This unit uses a flammable refrigerant.
If refrigerant leaks and comes in contact with fire or heating part, it will create
harmful gas and there is risk of fire.
Read the USER MANUAL carefully before operation.
Further information is available in the USER MANUAL, SERVICE MANUAL, and the like.
Service personnel are required to carefully read the USER MANUAL and SERVICE
MANUAL before operation.

4
THE FOLLOWING SHOULD ALWAYS BE OBSERVED FOR SAFETY
⚫This appliance is intended to be used by expert or trained users in shops, in light industry
and on farms, or for commercial use by lay persons.
⚫This appliance can be used by children aged from 8 years and above and persons with
reduced physical, sensory or mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning use of the appliance in a safe
way and understand the hazards involved. Children shall not play with the appliance.
Cleaning and user maintenance shall not be made by children without supervision.
⚫The unit is designed only for use with R-290(propane) gas as the designated refrigerant.
⚫The refrigerant loop is sealed. Only a qualified technician should attempt to service!
⚫Do not discharge the refrigerant into the atmosphere.
⚫R-290 (propane) is flammable and heavier than air.
⚫It collects first in low areas but can be circulated by thefans.
⚫If propane gas is present or even suspected, do notallow untrained personnel to attempt
to find the cause.
⚫The propane gas used in the unit has no odor.
⚫The lackof smell does not indicate a lack of escaped gas.
⚫If aleak is detected, immediately evacuate all persons fromthe store, ventilate the room
and contact the local fire department to advisethem that a propane leak has occurred.
⚫Do not let anypersons back into the store until the qualified servicetechnician has arrived
and that technician advises that itis safe to return to the store.
⚫No open flames, cigarettesor other possible sources of ignition should be usedinside or in
the vicinity of the units.
⚫Component parts are designed for propane and non-incentive and non-sparking.
Component parts shall only be replaced with identicalrepair parts.
⚫If the supply cord is damaged, it must be replaced by the manufacturer, its service agent
or similarly qualified persons in order to avoid a hazard.
⚫The A-weighted sound pressure level is below 36 dB.
⚫The appliance shall be disconnected from its power source during maintenance.
FAILURE TO ABIDE BY THIS WARNING COULD RESULT IN AN EXPLOSION,
DEATH, INJURY AND PROPERTY DAMAGE.

5
2. FOR YOUR SAFETY
2.1 GENERAL PRECAUTION
Your safety is the most important thing we concerned!
◼Turn off the dehumidifier
when cleaning.
◼Unplug the power cord
when not in use
◼Do not operate with wet
hands.
◼Prevent water from spilling
onto the machine.
◼Do not unplug while the unit
is operating.
◼Do not unplug by pulling on
the power cord.
◼Always use a power outlet
that is grounded.
◼Do not use an extension
cord or anadapter plug.
◼Keep the air inlet and outlet
free of obstacles.
◼Do not tilt or turn over the
unit.
◼Do not put objects on the
unit
◼Do not climb or sit on the
product.
◼Take care to ensure that
children do not play with
the unit.
◼Do not insert fingers or
other objects into the air
outlet.
◼Ensure the unit is far away
from fire, inflammable, or
explosive objects.
◼Do not store in dusty
place,or expose under
corrosive environment.
◼Service or repair should be
performed by a qualified
technician.
◼Replace the assembly with
the manufacturer approved
replacement parts.

6
2.2OPERATIONALPRECAUTIONS
WARNING- to reduce the risk of fire, electric shock or injury to persons or property:
◼Always operate the unit from a power source of equal voltage, frequency and rating as
indicated on the product identification plate.
◼Do not leave the unit running unattended.
◼Do not touch the air inlet or the aluminum fins of the unit.
◼Do not operate the unit if it is dropped, damaged or showing signs of product malfunction.
◼Do not operate the product with damaged plug or cord. If it is not working properly, contact a
qualified electrician or service centre for examination and repair, never try to dismantle it by
yourself (user).
◼The unit shall be installed in accordance with national wiring regulations.
◼Do not use means to accelerate the defrosting process or to clean, other than those
recommended by the manufacture.
◼The appliance shall be stored in a room without continuously operation sources (for example:
open flames, an operating gas appliance or an operating electric heater).
◼The appliance shall be stored so as to prevent mechanical damage from occurring.
◼Do not piece or burn, even after use.
◼Be aware that refrigerants may not contain an odour.
◼Pipe-work shall be protected from physical damage and shall not be installed in an unventilated
space, if that space is smaller than 4m².
◼Compliance with national gas regulations shall be observed.
◼Keep any required ventilation openings clear of obstruction.
◼The appliance shall be stored in a well-ventilated area where the room size corresponds to the room
area as specified for operation.
If you don't understand something or need help, please contact the dealer services.

7
2.3 SAFETY PRECAUTIONS ON SERVICING
Please follow these warnings when to undertake the following when servicing a dehumidifier with
R290.
2.3.1 Checks to the area
Prior to beginning work on systems containing flammable refrigerants, safety checks arenecessary to
ensure that the risk of ignition is minimized. For repair to the refrigeratingsystem, the following
precautions shall be complied with prior to conducting work on thesystem.
2.3.2 Work procedure
Work shall be undertaken under a controlled procedure so as tominimize the risk of aflammable gas or
vapor being present while the work is being performed.
2.3.3 General work area
All maintenance staff and others working in the local area shall be instructed on the nature ofwork
being carried out. Work in confined spaces shall be avoided. The area around theworkspace shall be
sectioned off. Ensure that the conditions within the area have been madesafe by control of flammable
material.
2.3.4 Checking for presence of refrigerant
The area shall be checked with an appropriate refrigerant detector prior to and during work, toensure
the technician is aware of potentially flammable atmospheres. Ensure that the leakdetection
equipment being used is suitable for use with flammable refrigerants, i.e. no sparking,adequately
sealed or intrinsically safe.
2.3.5 Presence of fire extinguisher
If any hot work is to be conducted on the refrigeration equipment or any associated parts,appropriate
fire extinguishing equipment shall be available to hand. Have a dry powder orCO2 fire extinguisher
adjacent to the charging area.
2.3.6 No ignition sources
No person carrying out work in relation to a refrigeration system which involves exposing anypipe
work that contains or has contained flammable refrigerant shall use any sources of ignition in such a
manner that it may lead to the risk of fire or explosion. All possible ignition sources, including cigarette
smoking, should be kept sufficiently far away from the site of installation, repairing, removing and
disposal, during which flammable refrigerant can possibly be released to the surrounding space. Prior
to work taking place, the area around the equipment is to be surveyed to make sure that there are no
flammable hazards or ignition risks. “No Smoking” signs shall be displayed.

8
2.3.7 Ventilated area
Ensure that the area is in the open or that it is adequately ventilated before breaking into the system
or conducting any hot work. A degree of ventilation shall continue during the period that the work is
carried out. The ventilation should safely disperse any released refrigerant and preferably expel it
externally into the atmosphere.
2.3.8 Checks to the refrigeration equipment
Where electrical components are being changed, they shall be fit for the purpose and to the correct
specification. At all times the manufacturer’s maintenance and service guidelines shall be followed. If
in doubt consult the manufacturer’s technical department for assistance.
The following checks shall be applied to installations using flammable refrigerants:
–The charge size is in accordance with the room size within which the refrigerant containing parts are
installed;
–The ventilation machinery and outlets are operating adequately and are not obstructed;
–If an indirect refrigerating circuit is being used, the secondary circuit shall be checked for the
presence of refrigerant;
–Marking to the equipment continues to be visible and legible. Markings and signs that are illegible
shall be corrected;
–refrigeration pipe or components are installed in a position where they are unlikely to be exposed to
any substance which may corrode refrigerant containing components, unless the components are
constructed of materials which are inherently resistant to being corroded or are suitably protected
against being so corroded.
2.3.9 Checks to electrical devices
Repair and maintenance to electrical components shall include initial safety checks and component
inspection procedures. If a fault exists that could compromise safety, then no electrical supply shall be
connected to the circuit until it is satisfactorily dealt with. If the fault cannot be corrected immediately
but it is necessary to continue operation, an adequate temporary solution shall be used. This shall be
reported to the owner of the equipment so all parties are advised.
Initial safety checks shall include:
-those capacitors are discharged: this shall be done in a safe manner to avoid possibility of sparking;
-that there no live electrical components and wiring are exposed while charging, recovering or
purging the system;
-that there is continuity of earth bonding.

9
3. WHERE TO USE
3.1
Installation
1. Place the unit on a firm, level
surface in an area with at least
20cm of free space around it
allow for proper air circulation.
2. Operate this unit in an ambient
temperature from 5°C to 35°C.
3. Keep doors and windows close
for better energy saving.
4. Do not operate in close
proximity to walls, curtains, or
other objects that may block
inlet and outlet.
5. Do not operate the unit
beneath furniture or where the
air flow is restricted.
6. Do not operate or store the
unit in direct sunlight or rain.
WARNING!
Install the unit in rooms which exceed 4 m².
Do not install the unit in a place where inflammable gas may leak.
NOTE!
The manufacture may provide other suitable example or may provide
additional information about the refrigerant odour.

10
4. QUICK START GUIDE
Making dry and comfortable
Smartly senses room humidity and
maintain your ideal levels.
1. Unpacking the appliance and check for any
damage or scratches on the machine.
2. If tipped more than 45°, allow the unit to set
upright for at least 2 hours before start up.
3. Check the bucket is empty and re-install
correctly before plug in the dehumidifier. Be sure the
bucket full indicator does not light up.
4. Press POWER to turn on the dehumidifier.
5. Press MODE repeatedly to choose Auto
Sunny (60%RH), Auto Rainy (40%RH), or Continuous
Drying.
6. Press SLEEP for silent operating with dim
light before go to bed.
7. Press TIMER repeatedly to set a 1-hour to
24-hour delay OFF before you go out.
8. Press POWER again to turn the unit off.
For more operational instructions, please read
the following pages.
To dry clothes quickly.
Continuous dehumidifying to speed
the drying process.
Sleep well into the night.
Silence dehumidifying and dims the
lights when you sleep.

11
5.PRODUCT OVERVIEW
Front view
Air Outlet
Back view
Control
panel
Air filter
Continuous
drainage
Front Case
Water tank
Castor
FEATURES
✓Powerful moisture removal (Up to 12L/day dehumidification)
✓Antibacterial Filter
✓Continuous Drainage or 2L Water Tank
✓Laundry Drying Function/ Child Lock / Auto-Defrost
✓Touch Screen / Touch control buttons
✓Humidity Monitor shows current air humidity.
✓Auto mode automatically adjusts humidity levels.
✓Effectively removes moisture, dust, and dust mites from the air.
✓Low power consumption-energy efficient.
✓A-24 hour timer to set the time of operation.
✓Quiet fan has two speed settings. (Noise:≤36dB（A）)
✓Sleep mode dims the control panel light when you sleep.

12
6. HOW TO USE
6.1 CONTROL PANEL
Display:
A. The screen will display current relative
humidity (%) when the machine is turned on.
And display “一一” when the machine is off.
B. The screen will display following function:
1. Timer set; 2. Error code;
3. Long press HUM key to display Room
temperature (℃);
C. The indicators will light up when the
corresponding function is turned on.
POWER BREATHING LIGHT
INDICATOR
DESCRIPTION
Steady On:
Humidity levels below 60% relative humidity.
Flashing Blue:
Defrosting is in progress.
Steady On:
Above 60% and below 80% relative humidity.
Flashing Green:
The air purifying function is individually turned on.
Steady On:
High humidity above 80% relative humidity.
Flashing Red:
Indicates the water tank is almost full.

13
6.2 FUNCTION KEYS AND INDICATORS
Power Button
Press to switch the machine on or off.
Mode Button
Press to choose Sunny, Rainy and Continuous Drying mode.
Fan Speed Button
/Safe Lock Button
Press to choose fan speed High and Low.
Long press to turn child lock function on or off.
Humidity Button
Adjusts the humidity set-point within the range of 20%-80%.
Timer Button
Sets a time for the unit to automatically start or stop.
Sleep Button
Press to turn sleep mode on or off.
Child Lock Light
Lights up when Child lock function is turned on.
Fan Speed Light
Lights up when switch to High or Low speed.
Bucket Full Light
Lights up when water tank is almost full.
Mode Light
Operation functions of Sunny, Rainy, and Continuous drying.
Digital Display
Displays humidity value, Timer setting or Temperature.

14
6.3 SETTINGS
a. Dehumidification Mode Setting
Press POWER key to turn on the unit after plug in.
The dehumidifier starts with sunny mode and air purifying function.
Press MODE key repeatedly to switch the mode:
•Sunny mode: auto dehumidifying with 60%RH, High fan speed.
•Rainy mode: auto dehumidifying with 40%RH, high fan speed.
•Continuous mode: continuous dehumidifying
b. Set Sleep Mode:
Press SLEEP key to turn on sleep function.
It will operate in silent mode with low fan speed and dims all the lights.
Press any button to wake up the indicators.
Press SLEEP key again to exit the sleep mode.
c. Set Humidity (setting range: 20%-95%):
Press the HUM key to check the humidity set-point under current mode.
Press the HUM key repeatedly to adjust humidity set-point.
Set appropriate humidity levels to create a comfortable environment.
Note: The HUM key cannot be set in the continuous mode.
d. Set Fan Speed:
Press SPEED key to switch the speed between High speed and Low speed.
Note: The fan speed cannot be set when the indicator is off in sleep mode and defrosting
progress.
e. Child Lock Function:
The child lock function is designed to prevent children from playing unit.
To active: Long press the SPEED/LOCK key for 5 seconds to disable all the buttons.
To unlock: Press and hold again to cancel the child lock.
f. Overload Protection
In the event of a power loss, to protect the compressor there is a 3-minute delay until
the compressor restarting.

15
g. Timer Setting（setting range: 1hour-24hours）:
To turn off
(When power on)
To turn on
(When power off)
Cancel the timer
h. Water full indicator:
The machine automatically shuts off once the water tank is full, alerting the user through
an indicator light and buzzing for 15 times.It reminds you to check:
◼If the water tank is full, empty and re-install the water tank.
◼If the water tank is not in position, the full indicator always on and the unit is
inoperative.
◼Re-install the tank correctly, and the unit will auto operating as your last setting.
i. Room Temperature Inspection
In addition to the humidity level, the digital display can also indicate the current room
temperature. Please check as follows:
Press and hold the TIMER button for 5 seconds.
The screen displays the temperature in degree Celsius.
j. Auto defrost function
At low room temperatures, frost may buildup at the evaporator reducing the airflow
across it during dehumidifying.
The unit will automatically start defrosting and the POWER indicator flashing.
When the room temperature below18℃or the humidity sensor failures, the compressor stops
for 10 minutes during the automatic defrost function and the fan keeps running.
Press Timerkeyto turn
on the timer function
PressTimerkey to turn
on the timer function
Press Timerrepeatedly to
set the delay OFF time.
Press Timerrepeatedly to
set the delay ON time.
Press Timer repeatedly until the screen shows ‘00’
Note: when press POWER will also exit the timer setting.

16
6.4 DRAINAGE
There are two ways of removal collected water produced by the unit.
A. Manual draining: Empty water tank by manual.
B. Continuous draining: Use gravity to drain condensate water by attaching a drain hose.
6.4.1 Emptying the water tank
⚫Unplug the dehumidifier from its power
source.
⚫Pull on the water tank and simply slide out
of the body of the dehumidifier.
⚫Do not remove the float out of the tank.
Make sure that the float can move freely
and that it will actuate the level switch
when the tank is full.
⚫Clean the inside of the tank as well as the
outside.
⚫Allow the tank to air-dry completely and
slide it back into place within the
dehumidifier.
⚫After you have replaced the tank, plug the
unit back into its power source.
Warning!!!
Use only mild soap, water and soft cloth. Do not use any commercial cleaning solvents.

17
6.4.2. CONTINUOUS DRAINAGE
Condensate water can be automatically flow into a bucket or drain by gravity with a water hose.
•Set the unit in a horizontal surface and
stable position.
•Switch off the unit before operating.
•Gently take out the water tank from the
dehumidifier.
•Securely and properly connect the drain hose
and make sure it is not kinked and clear of
obstruction.
•Put back the water tank.
•Place the outlet of hose over a drain or
bucket and ensure that water could freely
flow out of the unit.
•Do not submerge the end of hose into
water;otherwiseit can cause "Air Lock" in the
hose.
To avoid water spillage:
•As the negative pressure of condensate
drain pan is large, tilt the drain hose
downward toward the floor.It is appropriate
that the degree of inclination should exceed
20 degrees.
•Straighten the hose to avoid a trap existing
in the hose.
Inner
Diameter
=9.5mm

18
7. CLEANING AND CARE
•CLEANING THE AIR FILTER (every two weeks)
◼The air filter is removable for easy cleaning. Do not operate the unit without an air filter, or the
evaporator may be contaminated. Do not clean the appliance with any chemicals.
Pic1. Switch off the unit and remove air filter.
Warning!!!
Do not touch the evaporatorsurface with
bare-hand, or could cause injury of your
fingers.
Pic2. Rinse the air filter under running water.
Pic3. Re-install the air filter.

19
8. TROUBLESHOOTING
When
Please confirm
Solution
The unit is
not operating.
✓Check the power connection in
securely.
➢Insert the power cord securely into
the wallOutlet.
✓Check if the water level indicator
lights up?
➢Empty the water tank and re-install
correctly.
✓Check the room temperature.
➢The range of operating temperature is
5-35℃.
There is little
formation of
condensate.
✓Check the air filter for dirt.
➢Clean the air filter as necessary.
✓Check if the air duct is blocked.
➢To clear the obstacle.
✓Check if the room temperature is
below 20℃.
➢This is normal. Low humidity in low
temperature environment.
✓Set humidity level is higher than
currenthumidity value.
➢Set the humidity level below current
humidity value.
Water
Leakage
✓Overflow while moving the unit.
➢Empty the water tank before
transport.
✓Check if the drain hose is kinked or
bends.
➢Straighten the hose to avoid a trap
existing.
Excessive
Noise
✓Check if the unit is securely
positioned.
➢Place the unit on horizontal and firm
ground.
✓Check if any loose, vibrating parts.
➢Secure and tight the parts.
✓Noise sounds like water flowing.
➢Noise comes from flowing refrigerant.
This is normal.
Emitting
hot
✓The air outlet is hotter than room
temperature a bit.
➢This is normal. The compressor
produce heat that has been removed
by the air exhausted.
Error
Code
E2
✓Humidity sensor dampened or
failure.
➢To clean or replace the humidity
sensor.
CL
✓Display when Room temperature is
below 5°C（41°F）.
➢Normal. The compressor stops, and
the fan keeps running.
CH
✓Display when Room temperature is
above35℃（95°F）.
➢Normal. The compressor stops, and
the fan keeps running.
LO
✓Display when Room relative
humidity is bellow 20%RH.
➢Normal. The compressor stops, and
the fan keeps running.
HI
✓Display when Room relative
humidity is above 95%RH.
➢Normal. The compressor and the fan
keep running.

20
9. SPECIFICATIONS
Model No.
OL12-BD001E
Power Supply
AC220V-240V/50Hz
Power Consumption
180W (30℃, RH80%)
156W (27℃, RH60%)
Rated Current
0.95A (30℃, RH80%)
0.88A (27℃, RH60%)
Dehumidify Capacity
12kg/24h (30℃, RH80%)
6.8kg/24h (27℃, RH60%)
Noise
≤36dB(A)
Water Tank Capacity
2L
Refrigerant /Charge
R290/60g
Minimum room size
4 m2 (Floor area)
Fuse type
T-Type, AC 250V, 3.15A
Operating temperature
5ºC-30ºC
Dimension
280x200x500mm
Net weight
12kg
Note: Specifications subject to change without notice
