HOMCOM 713-090V70 Installation guide

ASSEMBLY & INSTRUCTION MANUAL
INcxa016_UK
713-090V70
IMPORTANT, RETAIN FOR FUTURE REFERENCE: READ CAREFULLY

PACKING DETALS:TOTAL 2 BOXES
BOX-1/2
NO. PARTS QTY NO. PARTS QTY NO. PARTS QTY
A
G
H
I
J
K
L
E
F
1
1
1
1
2
4
4
1
1
BOX-2/2
NO. PARTS QTY
B
C
D
1
1
1
R
L
2

Safety Rules
Lift Chair Parts
Assembly Instructions
Lift and Recliner Function
Functional Description Of Massager
4
5
6
8
9
Troubleshooting 12
We're excited for you to regain your independence with Homcom! To ensure the best
experience, please read this guide carefully before using your new lift chair.
Be sure to keep this manual close by, preferably in your chair pocket so that you can
always refer to it as needed.
3

SAFETY RULES
● Never set the lift chair in wet/damp areas or where dust can accumulate as these could
cause an electrical fault or a mechanical dysfunction.
● Never use the lift chair inside your home if the room temperature is over 40°C.
● Never place the lift chair near a heat source (oven, chimney, fernace etc...) or in direct
sunlight.
Do Not use the lift chair if:
● The lift chair is wet.
● Your hands are wet.
● Only clean the chair with a dry cloth.
Situations where you should not use the lift chair:
Switch the lift chair's system off if it gets wet or seems not to be working properly, if any
part of the lift char is damaged or malfunctioning, if any part of the lift chair appears to be
damaged or wiring is exposed.
Usage:
● lndoors, avoid high temperatures and wet or damp areas.
Precaution:
● Never sit on the remote or place heavy objects on top of it.
● Do not drop the remote on the floor.
● Do not tug on the electric cable.
● Do not use the remote with wet fingers.
● Do not pressor touch the buttons with sharp objects.
● Never unplug the remote without first turning the power off.
● The lift chair should rest for 30 minutes after it has been used for 30 minutes.
When the system of the lift chair is not in use:
● Make sure it is switched off.
● Unplug the lift chair's system from the wall outlet when you are not going to use it for
long periods of time.
● Keep the lift chair in a clean and dry place.
4

Disassembling the massage armchair:
● Do not remove the back of the armchair .
● Do not try to disassemble or repair the armchair yourself.
Correct way to handle the mains plug:
● Check that you have the right voltage.
● Never use force on the cable or plug.
● Never pull the cable with wet hands.
● When removing the plug, hold the plug itself, do not pull on the cable.
● Do not use the armchair massage system if either the cable or the plug are damaged.
1)Back
2)Armrests
3)Seat
4)Footrest
5)Control unit
The Parts forming the massage armchair:
5

L4
K4
J2
I1
E1
D1
C1
B1 A1
H1
G1
F1
3
(A)
(J)(K) (L)
01
6

(C)
(D)
(H)
(I)
(G)
02
03
04
(B)
(E)
(F)
7

Lift And Recliner Function
● Pressing the right button, the back will move down and the
footrest will rise up. And if you press the left button the Lift
chair will return to normal position, after that continue to
press the left button Lift chair will rise up smoothly.
● To stop the chair at any time simply release the button tha
is being pressed.
Warning
Never press both buttons together as this will damage your
chair.
Never stand up while the chair is still working in order to
avoiding accdent.
8

PRODUCT FEATURE
● 8 Vibration Motors
● Eight Massaging modes
● Five Adjustable intensity
● Four massage zones, each zone can be operated individually
● The default timing is 15-30 min
HOW TO USE
1. Insert adapter jack into the socket found on back of the massage chair, then plug the
adapter into a wall outlet.
FUNCTIONAL DESCRIPTION OF MASSAGER
Back / Lumbar / Thigh / Leg
Massage zone selection
Massage Time
Massage modes selection
Massage intensity
Massage ON/OFF
9

2. Turn the unit ON by pressing the ON/OFF button once, The LED will illuminate when
power is on.
3. urn on the massage in each zone by pressing the Massage zone. LEDs will illuminate
when each zone is activated. To turn off a zone, press the button again.
4. To choose a desired massage mode, press the MODE button. To change modes, press
MODE button until LED for desired mode illuminates
5. To change the massage intensity press the +/- button.
6. NOTE：Discontinue use immediately if you feel any discomfort or pain.
7. NOTE: for your benefit, the massage chair is equipped with an auto shut-off feature that
will turn the chair unit off after 15 /30minutes of continuous use.
8. DO NOT use for more than 30minutes of continuous use.
IMPORTANT SAFETY INSTRUCTIONS
When using an electrical appliance, basic precautions should always be followed, includ-
ing the following:
1. This product is for use on a 12V circuit Make sure that the product
2. Only use this product with original power supply type nr : IVP1200-0500
3. Always unplug the massager from the power source after use, and before cleaning.
4. Do not reach for massager if it has fallen into water. Unplug immediately.
5. An appliance should never be left unattended when plugged in. Unplug from outlet when
not in use, before putting on or taking off parts or attachments.
6. Do not use outdoors.
7. Do not carry this appliance by supplied cord as a handle.
8. Keep the cord away from heated surfaces.
9. Close supervision is necessary when this appliance is used by on or near children,
invalids or disabled persons.
10. This unit is not a toy. Children should not use it or play with it.
11. Do not operate where aerosol (spray) products are being used or where oxygen is
being administered.
12. Do not use near eyes or other highly sensitive areas.
13. To disconnect, push "POWER" key to "OFF" place, make sure all functions stopped,
then remove plug from outlet.
14. Keep cord away from heated surfaces.
15. Use this appliance only for its intended use as described in this manual. Do not use
attachments not provided with the unit.
10

HEALTH CAUTION FOR MASSAGE CHAIRS
● If you have any concerns regarding your health, consult your doctor before using this
product.
● Individuals with pacemakers should not use this product.
● If you experience pain in a muscle or joint for a prolonged period of time. Discontinue
use and consult your doctor. Persistent pain could be a symptom of a more serious condi-
tion.
MAINTENANCE INSTRUCTIONS
TO STORE:
Place unit in its box or safe, dry, cool place. Avoid contact with sharp edges or pointed
objects which might cut or puncture the fabric. Do not wrap power cord around the unit. Do
not hang the unit by power cord.
TO CLEAN:
● Insure the unit is unplugged from the power source, and allow to cool before cleaning.
● Do not place in any liquid to clean. Clean fabric cover by wiping with a damp sponge,
using a mild detergent or suds. Pat dry with clean, dry cloth.
● Do not use abrasive cleaners, brushes, gasoline, kerosene, glass /furniture polish, paint
thinner or water hotter than 120*to clean the unit.
● To clean the unit, make sure the massager is unplugged. Allow the unit to cool and the
wipe down with a damp clean cloth. Do not use any strong chemical cleaners.
11

TROUBLESHOOTING
PROBLEM POSSSIBLE CAUSE
lf the lift chair is not working, check the following chart. Make sure you turn the power off
and unplug from the wall outlet.
lf you have any questions, please contact us. Do not disassemble or repair any part of the
lift chair yourself.
The lift chair does not func-
tion when the button on the
control unit is activated.
Check that the plug is
pushed into the wall oultlet
properly. Check whether the
power supply button is on.
Input voltage 100-240
115V 230V
V
Input AC frequency 50-60 Hz
Output voltage 29 V
Output current 1.8 A
Output power 52.2 W
Average active efficiency 88.21 %
Efficiency at low load (10 %) 88.21 %
No-load power consumption 0.041
100-240
50-60
29
1.8
52.2
88.43
88.43
0.112 W
12
