HoMedics HL858DM User manual

1
VER: A001 202203
I
In ns st tr ru uc ct ti io on n M Ma an nu ua al l
Automatic
Upper Arm Blood Pressure Monitor
Model No. HL858DM

2
VER: A001 202203
Table of Contents
Medical Disclaimer……………………………………………………………………………03
Intended Use………………………………………………………………………………..…03
About Blood Pressure………………………………………………………………………04
Measurement Method……………………………………………………………………06
Accuracy……………….…………………………………………………………………0
Precautions………………………………………………………………………….08
Device Overview……………………………………………………………………………….11
Symbol Definitions………………………………………………………………………….13
Features……………………………………………………………………………………………15
Installing Batteries………………………………………………………………………….20
Using the AC/DC Adapter……………………………………………………………21
Applying the Cuff…………………………………………………………………………….22
Measurement Procedure………….…………………………………………………….23
Memory Function…………………………………………………………………………….26
Bluetooth Transmission……………………………………………………………….2
Storage and Maintenance……………………………………………………………….29
Troubleshooting……………………………………………………………………………….31
Limited Warranty…………………………………………………………………………….32
Specifications………………………………………………………………………………….33
Note………………………………………………………………………………………….…….35
Appendix…………………………………………………………………………………….…….36
Blood Pressure Diary……………….……………………………………………….…….39

3
VER: A001 202203
Medical Disclaimer
This manual and product are not meant as a substitute for advice
provided by your doctor.
You are not to use the information contained herein, or this product
for diagnosing or treating a health problem or prescribing any
medication. If you have or suspect that you have a medical problem,
promptly consult your healthcare provider.
Intended Use
This device uses the oscillometric method to automatically measure
systolic and diastolic blood pressure as well as heart rate.
The measurement position is at human being’s arm.
All values can be read out in the LCD panel. Measurement position is
at human being’s upper arm. The intended user of this
over-the-counter device is adults aged 18 years and older with arm
circumference ranging from 9 inches to 1 inches (approx.23 cm to
43 cm) for home use.
HL858DM features BP Category Indicator that will show the
information with the readings on the screen for the user tracking their
blood pressure level.
HL858DM is equipped with an Advanced IHB (Irregular heartbeat)
detection feature to collect and analyze pulses. If the specific
irregular heartbeats are detected and it may affect blood pressure
reading with deviation, the device will give the user a warning signal.
The feature can inform the user that the measured blood pressure
reading may be inaccurate once the specific irregular heartbeats are
detected.
Besides, the device features a built-in "Bluetooth Transmission"
function, which enables the device automatically transmit measuring
results to paired Bluetooth-enabled device. Also, users could simply
synchronize the current date and time, and check the battery status
of blood pressure monitor by means of DailyChek
®
application software
with
the paired Bluetooth-enabled device.

4
VER: A001 202203
About Blood Pressure
A. What is blood pressure?
Blood pressure is the measurement of the force of blood pushing
against the walls of the arteries. Arterial blood pressure is
constantly fluctuating during the course of the cardiac cycle. The
highest pressure in the cycle is called the systolic blood pressure,
and represents the pressure in the artery when the heart is beating.
The lowest pressure is the diastolic blood pressure, and represents
the pressure in the artery when the heart is at rest. Both the
systolic and the diastolic pressure are necessary for a physician to
evaluate the status of a patient's blood pressure.
Many factors such as physical activity, anxiety or the time of day,
can influence your blood pressure. Blood pressure is typically low
in the mornings and increases from the afternoon to the evening.
It is on average lower in the summer and higher in the winter.
B. Why is it useful to measure blood pressure
at home?
Having one's blood pressure measured by a doctor in a hospital or
a clinic, is often associated with a phenomenon called “White Coat
Hypertension” where the patient becomes nervous or anxious,
thus raising his blood pressure. There are also numerous other
factors that might cause your blood pressure to be raised at a
specific time of day. This is why medical practitioners recommend
home monitoring as it is important to get readings of blood
pressure during different times of the day to really get an idea of
your real blood pressure.
Medical practitioners generally recommend the “Rule of 3”, where
you are encouraged to take your blood pressure three times in a
row (at 3 ~ 5 minute interval), three times a day for three days.
After three days you can average all the results and this will give
you an accurate idea of what your blood pressure really is.

5
VER: A001 202203
About Blood Pressure
A. AHA blood pressure classifications:
Standards for assessment of high or low blood pressure without
regard to age, have been established by the American Heart
Association (AHA 201 ), as shown in the below chart.
BLOOD PRESSURE CATEGORY
SYSTOLIC mm Hg
(upper number)
DIASTOLIC mmHg
(lower number)
NORMAL LESS THAN 120 and LESS THAN 80
ELEVATED 120-129 and LESS THAN 80
HIGH BLOOD PRESSURE
(HYPERTENSION)STAGE 1
130-139 or 80-89
HIGH BLOOD PRESSURE
(HYPERTENSION)STAGE 2
140 OR HIGHER or 90 OR HIGHER
HYPERTENSIVE CRISIS
(consult your doctor immediately)
HIGNER THAN 180 or HIGHER THAN 120
However the above chart is not exact for classification of blood
pressure and it's intended to be used as a guide in understanding
non-invasive blood pressure measurements. Please consult with
your physician for proper diagnosis.
B. Variations in blood pressure:
Individual blood pressures vary greatly both on a daily and a
seasonal basis. These variations are even more pronounced in
hyper tense patients. Normally the blood pressure rises while at
work and is at its lowest during sleeping period.
(hyper tense: eans a person who has high blood
pressure sy pto .)
The graph below illustrated the variations in blood pressure
over a whole day with
measurement taken
every five minutes.
The thick line
represents sleep. The
rise in blood pressure
at 4 PM (A in the
graph) and 12 AM (B
in the graph)
correspond to an attack
of pain.
(Direct arterial pressure recording in unrestricted man.
Beven, Honour & Stott: Clin. Sci. 36:329. 1969)

6
VER: A001 202203
Measurement Method
HL858DM Automatic Upper Arm Blood Pressure Monitor measures
blood pressure and heart rate by oscillometric method, meaning the
fluctuations in pressure are measured. Once the cuff is wrapped
around your upper arm, just turn on the monitor and inflation
automatically starts. The inflation of the cuff creates pressure around
the arteries inside upper arm.
Within the cuff is a gauge which senses the fluctuations (oscillations)
in pressure. The fluctuation measured represents the degree of
intensity that your arteries contracting with each heart beat, and also
a result of the pressure that the cuff has placed on the upper arm. The
monitor measures these contractions and converts the information to
a digital value. This is the result displayed on the monitor screen.
Once the measurement is complete, the cuff will automatically
deflate.
Note!
* The patient is an intended operator.
* The applied part is the cuff.

7
VER: A001 202203
Accuracy
HL858DM Automatic Upper Arm Blood Pressure Monitor has been
clinically tested against a scientific device called mercury
sphygmomanometer, considered the gold standard in blood pressure
measurement.
All HL858DM Automatic Upper Arm Blood Pressure Monitors have
performed equivalent to measurements taken with this scientific
device and are within the accuracy limits prescribed by the American
National Standard for Electronic or Automated Sphygmomano-
meters.
The SPHYGMOMANOMETER was clinically investigated according to
the requirements of ISO 81060-2:2018.

8
VER: A001 202203
 Do not take a measurement in a low (less than 41 ℉/5 ℃) and high
(more than 104 ℉/40 ℃) temperature, nor in a place outside humidity
ranges (15 % ~ 93 % R.H.), and altitude ranges ( 00 ~ 1060 hPa), or
you may get inaccurate readings.
 Wait 30 ~ 45 minutes before measurement if you’ve just consumed
caffeinated beverages or smoked cigarettes.
 Rest at least 5 ~ 10 minutes before taking a measurement.
 To allow your blood vessels to return to the condition prior to taking the
measurement, please wait at least 3 ~ 5 minutes in between
measurements. You may need to adjust the wait time according to
your personal physiological situation.
 We recommend you using the same arm (preferably the left arm) and
measuring around the same time each day.
 Sit down comfortably and place your elbow on the table with your feet
flat on the floor. Please do not cross your legs during measurements.
 Keep the cuff at heart level. Relax your hand with the palm facing up.
 Perform measurements in a quiet and relaxed environment at room
temperature.
 Do not move or shake the device during a measurement. Please keep
quiet and do not talk during measurements.
 This product is not suitable for:
 Pregnant women
 People with arrhythmias
 Undergoing intravenous injection on any limb
 Currently in a dialysis treatment
 In pre-eclampsia condition
Precautions
* Do not use this manual and product as a substitute for advice, diagnosing or
treating a health problem or prescribing any medication by your doctor. If you
have a medical problem, promptly consult your healthcare provider.
* Read the Instruction Manual thoroughly before measuring and keep it at hand
for your reference at any time.
* This device uses the oscillometric method to measure systolic and diastolic
blood pressure as well as your heart rate. It’s recommended for use by people
over the age of 18 and not to be used on infant or children.
* The device is designed for home use and not suitable for clinical use.
* The patient is an intended operator, who can operate the device by himself or
herself, not necessarily by a physician or operator.
* This monitor is not intended for use in the MR environment.

9
VER: A001 202203
Precautions
 For those who have had a mastectomy or lymph node clearance, it
is recommended to take a measurement on the unaffected side.
 When used among medical electronic equipment on the same limb,
pressurization of the cuff may cause temporarily malfunction to
other devices.
 Keep in mind that blood pressure naturally varies from time to time
throughout the day and is affected by lots of different factors such
as stress, eating, smoking, alcohol consumption, medication, and
physical activity, etc.
 Normally the blood pressure rises while at work and is at its lowest
during sleeping period.
 Blood pressure measurements should be interpreted by a
physician or a trained health professional who is familiar with your
medical history. Using the unit and recording the results regularly
for your physician to interpret, you will keep your physician
informed of the continuing changes in your blood pressure.
 If you have one of the circulatory problems as arteriosclerosis,
diabetes, liver disease, kidney disease, severe hypertension,
peripheral circulation……, please consult your healthcare
professional before using the device.
 Results are not intended for direct diagnosis. Please consult with a
physician if you have any questions or concerns about your results.
 Blood pressure measurements taken with this device are
equivalent to those obtained by a trained observer using the cuff /
stethoscope auscultation method and are within the accuracy
limits prescribed by the Standard of EN 1060-4.
 If the cuff is worn incorrectly, or the shape of the upper arm is
special (for example, the circumference of the upper arm differs
largely from the circumference of the forearm), excessive gap
might occur between the arm cuff and the arm, and it might lead to
measurement errors or inaccuracies. If you have any question
about the condition of cuff wearing and/or measurement result,
please consult your healthcare professional.
 The applied part is cuff.

10
VER: A001 202203
Precautions
*Attention
！
1. Do not use the device on infants, children, or those who cannot express their own
intention. To avoid accidental strangulation, keep this product away from children and
do not drape tube around neck.
2. The medical device should not used adjacent to or stacked with other equipment. In
case adjacent or stacked use is necessary. The medical device should be observed to
verify normal operation in the configuration in which it will be used.
3. Consider the electromagnetic compatibility of the device (ex. power disturbance, radio
frequency interference etc.) Please use it indoor only.
4. Over high frequency measurements may result in blood flow interference, which is
likely to cause uncomfortable sensations, such as partial subcutaneous hemorrhage, or
temporary numbness to your arm. In general, these symptoms should not last long.
However, if you do not recover in time, please seek your medical practitioners for help.
