Honeywell 2020 User manual

™
2020
Cordless Base Accessory
User’s Guide
Draft 5/30/08

Disclaimer
Honeywell International Inc. (“Honeywell”) reserves the right to make changes
in specifications and other information contained in this document without prior
notice, and the reader should in all cases consult Honeywell to determine
whether any such changes have been made. The information in this publication
does not represent a commitment on the part of Honeywell.
Honeywell shall not be liable for technical or editorial errors or omissions con-
tained herein; nor for incidental or consequential damages resulting from the
furnishing, performance, or use of this material.
This document contains proprietary information that is protected by copyright.
All rights are reserved. No part of this document may be photocopied, repro-
duced, or translated into another language without the prior written consent of
Honeywell.
©2005 - 2008 Honeywell International Inc. All rights reserved.
Other product names or marks mentioned in this document may be trademarks
or registered trademarks of other companies and are the property of their
respective owners.
Web Address: www.honeywell.com/aidc
Note: For additional information and programming instructions related to the
imagers, refer to the user’s manual for the specific scanner model.

Product Agency Compliance
USA
FCC Part 15 Subpart C
This device complies with part 15 of the FCC Rules. Operation is subject to
the following two conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including interference
that may cause undesired operation.
Caution: Any changes or modifications made to this equipment not
expressly approved by Honeywell may void the FCC
authorization to operate this equipment.
UL Statement
UL listed: UL60950-1 for I.T.E product safety.
Canada
Industry Canada
This device complies with Canadian RSS-210.
Operation is subject to the following conditions:
1. This device may not cause interferenc, and
2. This device must accept any interference, including interference that may
cause undesired operation of this device.
Conformité à la règlementation canadienne
Cet appareil ISM est conforme à la norme CNR-210 du Canada.
Son fonctionnement est assujetti aux conditions suivantes :
1. Cet appareil ne doit pas causer de brouillage préjudiciable.
2. Cet appareil doit pouvoir accepter tout brouillage reçu, y compris le
brouillage pouvant causer un fonctionnement indésirable.

cUL Statement
cUL listed: CSA C22.2 No.60950-1-03 for I.T.E product safety.
Europe
The CE mark on the product indicates that this device is in conformity
with all essential requirements of the 1999/5/EC R&TTE Directive. In
addition, complies to 2006/95/EC Low Voltage Directive, when shipped
with recommended power supply. For further information please
contact:
Honeywell Imaging & Mobility Europe BV
International Inc.
Nijverheidsweg 9-13
5627 BT Eindhoven
The Netherlands
Honeywell shall not be liable for use of our product with equipment (i.e.,
power supplies, personal computers, etc.) that is not CE marked and does
not comply with the Low Voltage Directive. This equipment is intended for
use throughout the European Community and has been assessed to the
following standards:
EN 300 328
EN 301 489-1
EN 301 489-17
EN60950-1
Waste Electrical and Electronic Equipment Information
Honeywell complies with Directive 2002/96/EC OF THE EUROPEAN
PARLIAMENT AND OF THE COUNCIL on waste electrical and electronic
equipment (WEEE).
This product has required the extraction and use of natural resources for its
production. It may contain hazardous substances that could impact health
and the environment, if not properly disposed.
In order to avoid the dissemination of those substances in our environment
and to diminish the pressure on the natural resources, we encourage you to
use the appropriate take-back systems for product disposal. Those systems
will reuse or recycle most of the materials of the product you are disposing in
a sound way.
The crossed out wheeled bin symbol informs you that the product
should not be disposed of along with municipal waste and invites you to use
the appropriate separate take-back systems for product disposal.
If you need more information on the collection, reuse, and recycling systems,
please contact your local or regional waste administration.

You may also contact your supplier for more information on the
environmental performances of this product.
Germany
If your product is marked with the GS symbol, then the product has
been issued a GS certificate showing compliance to IEC 60950-1.
Australia/NZ
C-Tick Statement
Conforms to AS/NZS 3548 EMC requirements.
Japan (2020-5B)
Complies with Technical Regulations Conformity Certification of Specified Radio
equipment.
Mexico
Safety approval conforms to NOM-019.
Comision Federal de Telecomunicaciones (radio aprobación)
International
CAUTION: RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN
INCORRECT TYPE. The battery should be disposed of by a qualified
recycler or hazardous materials handler. Do not incinerate the battery or
dispose of the battery with general waste materials.
Radio Technology
Class II
CB Scheme
Certified to CB Scheme IEC 60950-1.
!

Patents
Please refer to product packaging for patent information.

Required Safety Labels
Scanner
Compliance
Label
locations
Item Number,
Serial
Number and
Revision
Information
location

Base
Compliance
Label
locations
Item Number,
Serial
Number and
Revision
Information
location

i
Chapter 1 - Getting Started
About This Manual .......................................................1-1
Unpacking the System .................................................1-1
Models .........................................................................1-1
Cordless System: Main Components...........................1-2
About the Battery .........................................................1-2
Proper Disposal of the Battery .....................................1-3
Connecting the Base....................................................1-3
Connecting the Base with USB..............................1-4
Connecting the Base with Keyboard Wedge..........1-4
Connecting the Base with RS-232 Serial Port .......1-6
Connecting the Base with RS-232 Wedge.............1-6
Linking Image Scanner to Base ...................................1-8
Communication Between the Cordless System
and the Host ..............................................................1-8
Chapter 2 - Programming the Interface
Introduction ..................................................................2-1
Programming the Interface - Plug and Play .................2-1
Keyboard Wedge Connection ......................................2-1
Laptop Direct Connect ...........................................2-1
RS-232...................................................................2-2
Wand Emulation Plug & Play .................................2-2
IBM 4683 Ports 5B, 9B, and 17 Interface ....................2-3
IBM SurePos ...............................................................2-4
USB PC or Macintosh Keyboard............................2-5
USB HID.................................................................2-5
USB Com Port Emulation.......................................2-6
Serial Wedge ...............................................................2-7
Programming the Interface - Terminal ID Method .......2-7
Supported Terminals....................................................2-8
Keyboard Country ......................................................2-10
Keyboard Style...........................................................2-12
Table of Contents

ii
Keyboard Modifiers.................................................... 2-13
RS-232 Baud Rate............................................... 2-16
RS-232 Word Length: Data Bits, Stop Bits, and Parity
2-17
RS-232 Receiver Time-Out .................................2-18
RS-232 Handshaking........................................... 2-18
Host ACK Selection .............................................2-19
Host ACK Enable.................................................2-20
Wand Emulation .......................................................2-22
Wand Emulation Connection ...............................2-22
Wand Emulation Data Block Size ........................2-22
Wand Emulation Delay Between Blocks.............. 2-23
Wand Emulation Overall Checksum ....................2-23
Wand Emulation Transmission Rate ...................2-24
Wand Emulation Polarity .....................................2-24
Wand Emulation Idle............................................ 2-25
Chapter 3 - Basic System Operation
Cordless Base .............................................................3-1
RF (Radio Frequency) Module Operation.................... 3-1
Cordless Image Scanner .............................................3-1
System Conditions....................................................... 3-2
Linking Process ..................................................... 3-2
Image Scanner Is Out of Range ............................3-2
Image Scanner Is Moved Back Into Range ........... 3-2
Out of Range and Back into Range with
Data Accumulation Mode On ........................... 3-2
Base Charge Mode ..................................................... 3-3
Beeper and LED Sequences and Meaning .................3-4
Image Scanner LED Sequences and Meaning...... 3-4
2020 LED Sequences and Meaning ......................3-4
Image Scanner Modes................................................. 3-5
Unlinking the Image Scanner................................. 3-5

iii
Single Image Scanner Operation.................................3-5
Locked Link Mode - Single Image Scanner ...........3-6
Open Link Mode - Single Image Scanner ..............3-6
Override Locked Image Scanner ...........................3-6
Multiple Image Scanner Operation...............................3-7
Image Scanner Name .................................................3-8
Image Scanner Report...............................................3-10
Application Work Groups ...........................................3-10
Application Work Group Selection .......................3-11
Resetting the Standard Product Default Settings:
All Application Work Groups ...................................3-12
Resetting the Standard Product Default Settings:
Current Application Work Group..............................3-12
Chapter 4 - Utilities
To Add a Test Code I.D. Prefix to All Symbologies......4-1
Show Software Revision ..............................................4-1
Show Data Format .......................................................4-1
Base Address...............................................................4-1
Resetting the Standard Product Default Settings:
Current Application Work Group................................4-2
Resetting the Standard Product Default Settings:
All Application Work Groups ......................................4-2
Visual Xpress Introduction ...........................................4-3
Installing Visual Xpress from the Web ...................4-4
QuickView ....................................................................4-4
Installing QuickView from the Web ........................4-4
Chapter 5 - Serial Programming Commands
Conventions .................................................................5-1
Menu Command Syntax ..............................................5-1
Query Commands ..................................................5-2
Concatenation of Multiple Commands ...................5-2
Responses .............................................................5-3
Examples of Query Commands .............................5-3

iv
Menu Commands ........................................................5-4
Programming the Interface .................................... 5-4
Chapter 6 - Product Specifications
2020-5 Product Specifications.....................................6-1
Chapter 7 - Maintenance
Repairs ........................................................................7-1
Maintenance ................................................................ 7-1
Cleaning the Device............................................... 7-1
Inspecting Cords and Connectors .........................7-1
Replacing the 2020 Interface Cable: .....................7-2
Assembling the Battery Charge Sleeve Kit.................. 7-3
Troubleshooting Base.................................................. 7-4
Chapter 8 - Customer Support
Technical Assistance...................................................8-1
Online Technical Assistance.................................. 8-1
Product Service and Repair......................................... 8-2
Online Product Service and Repair Assistance ..... 8-2
Limited Warranty.......................................................... 8-3

2020 User’s Guide 1 - 1
1
Getting Started
About This Manual
This User’s Guide provides installation and programming instructions for the
2020 system. Product specifications, dimensions, warranty, and customer
support information are also included.
Honeywell products are factory programmed for the most common terminal and
communications settings. If you need to change these settings, programming is
accomplished by scanning the barcodes in this guide.
An asterisk (*) next to an option indicates the default setting.
Unpacking the System
After you open the shipping carton containing the product, take the following
steps:
• Check for damage during shipment. Report damage immediately to the
carrier who delivered the carton.
• Make sure the items in the carton match your order.
• Save the shipping container for later storage or shipping.
Models
Models Description
4820SF0C1CBE Cordless Area Image Scanner, Green aimer, Spe-
cial Focus
4820SR0C1CBE Cordless Area Image Scanner, Green aimer, Stan-
dard Range
4820ISFE Industrial Cordless Area Image Scanner, Green
aimer, Special Focus
4820ISRE Industrial Cordless Area Image Scanner, Green
aimer, Standard Range
2020-5BE Cordless Base that supports the following inter-
faces: Keyboard wedge, TTL level 232, TTL level
232 serial wedge, IBM 4683, wand emulation,
USB keyboard, USB HID, USB retail (IBM Sure-
POS)
2020-CBE Charge-Only Base

1 - 2 2020 User’s Guide
Cordless System: Main Components
About the Battery
Use only the Li-ion battery packs provided by Honeywell. Use of any
battery not sold/manufactured by Honeywell may result in damage not
covered by the warranty.
Power is supplied to the cordless image scanner by a rechargeable battery that
is integrated in the image scanner handle. Each image scanner is shipped with
a battery. (See
Product Specifications beginning on page 6-1 . )
Charging Information
The battery is designed to charge while the image scanner is positioned in the
cordless base unit. Refer to "2020 LED Sequences and Meaning" on page 3-4
for an interpretation of the Charge Status indicators.
• Place the image scanner in the base that is connected to an appropriate
power supply.
Battery Recommendations
• Batteries are shipped approximately 30% to 60% charged and should be fully
charged for maximum charge capacity.
in Handle
Battery Contained
Image Scanner
2020
Cordless Base
!

2020 User’s Guide 1 - 3
• The battery is a lithium ion cell and can be used without a full charge, and can
also be charged without fully discharging, without impacting the battery life.
There is no need to perform any charge/discharge conditioning on this type
of battery.
• Do not disassemble the battery. There are no user-serviceable parts in the
battery.
• Keep the base connected to power when the host is not in use.
• Replace a defective battery immediately since it could damage the image
scanner.
• Don’t short-circuit a battery or throw it into a fire. It can explode and cause
severe personal injury.
• Although your battery can be recharged many times, it will eventually be
depleted. Replace it after the battery is unable to hold an adequate charge.
• If you are not sure if the battery or charger is working properly, send it to
Honeywell or an authorized Honeywell service center for inspection. Contact
the Product Service Department (page 8-1) for additional information.
Proper Disposal of the Battery
When the battery has reached the end of its useful life, the
battery should be disposed of by a qualified recycler or
hazardous materials handler. Do not incinerate the battery or
dispose of the battery with general waste materials. You may
send batteries to Honeywell (postage paid). The shipper is
responsible for complying with all federal, state, and local laws
and regulations related to the packing, labeling, manifesting,
and shipping of spent batteries. Contact the Product Service
Department (page 8-1) for recycling or disposal information. Since you may find
that your cost of returning the batteries significant, it may be more cost effective
to locate a local recycle/disposal company.
Connecting the Base
A base can be connected between the keyboard and PC as a “keyboard wedge,”
plugged into the serial port, plugged into a USB port, or connected to a portable
data terminal in wand emulation or non decoded output mode.
Turn off power before connecting the base, then power up the computer once
the base is fully connected. When the base is connected and powered up, put
the image scanner in the base to establish a link. The green LED on the base
flashes to indicate the image scanner’s battery is charging.

1 - 4 2020 User’s Guide
Connecting the Base with USB
A base can be connected to the USB port of a computer.
1. Connect the appropriate interface cable to the base first and then to the
computer. Make sure the cables are secured in the wireways in the bottom
of the base and that the base sits flat on a horizontal surface.
2. Program the base for the USB interface by scanning the appropriate
programming barcode See page 2-5.
3. Verify the base operation by scanning a barcode.
For additional USB programming and technical information, refer to the
Honeywell “USB Application Note,” available at www.honeywell.com/aidc.
Connecting the Base with Keyboard Wedge
1. Turn off power and disconnect the keyboard cable from the back of the ter-
minal/computer.

2020 User’s Guide 1 - 5
2. Connect the appropriate interface cable to the base and to the terminal/
computer and keyboard. Make sure the cables are secured in the wireways
in the bottom of the base and that the base sits flat on a horizontal surface.
3. Turn the terminal/computer power back on.
4. Program the base for the keyboard wedge interface. See "Keyboard Wedge
Connection" on page 2-1.
5. Verify the base operation by scanning a barcode.

1 - 6 2020 User’s Guide
Connecting the Base with RS-232 Serial Port
1. Turn off power to the terminal/computer.
2. Connect the appropriate interface cable to the base. Make sure the cables
are secured in the wireways in the bottom of the base and that the base sits
flat on a horizontal surface.
Note: For the base to work properly, you must have the correct cable for your
type of terminal/computer.
3. Plug the serial connector into the serial port on your computer. Tighten the
two screws to secure the connector to the port.
4. Once the image scanner has been fully connected, power up the computer.
Connecting the Base with RS-232 Wedge
The 2020 uses TTL signal levels to wedge into an RS-232 serial network. Use
only 2020 serial wedge cables to prevent damage to the base. Refer to RS-232
Baud Rate on page 2-16 to set the baud rate and communications protocol.
1. Turn off power to the computer.
2. Disconnect the existing serial cable from the computer.
3. Connect the appropriate interface cable to the base. Make sure the cables
are secured in the wireways in the bottom of the base and that the base sits
flat on a horizontal surface.

2020 User’s Guide 1 - 7
Note: For the base to work properly, you must have the correct cable for your
type of computer.
4. Plug the serial connector into the serial port on your computer. Tighten the
two screws to secure the connector to the port.
5. Plug the other serial connector into the host connection and tighten the two
screws.
6. Plug the power supply to the base and plug into the AC source.
7. Once the base has been fully connected, power up the computer.

1 - 8 2020 User’s Guide
Linking Image Scanner to Base
When newly shipped or defaulted to factory settings, the base and image
scanner are not linked. Once the image scanner is placed into the base, the
software automatically links the image scanner and the base. If the image
scanner and base have previously been linked, you do not receive any feedback.
If this is the first time that the image scanner and base are linked, both devices
emit a short chirp when their radios link. At this point, you are set to one image
scanner to one base.
1. Provide power to the base.
2. Place the image scanner into the base. The image scanner and base link.
3. To determine if your cordless system is set up correctly, scan one of the
sample barcodes in the back of this manual. If the image scanner provides
a single good read beep and the green LED lights, the image scanner has
successfully linked to the base. If you receive a triple error beep and the red
LED lights, the image scanner has not linked to the base. Refer to page 7-4
for troubleshooting information.
Communication Between the Cordless System
and the Host
The cordless image scanner provides immediate feedback in the form of a “good
read” indication (a green LED on the image scanner and an audible beep) after
a barcode is scanned correctly and the base has acknowledged receiving the
data. This is possible since the cordless system provides two-way
communication between the image scanner and the base.
Image Scanner
2020 Cordless Base
Green LED
Red LED
