Honeywell IS216T User manual

IS216 / IS216T Passive Infrared Motion Sensor - Installation Instructions
PRELIMINARY DRAFT 9/15/09 - 1 -
2.3m - 2.7m
(7.5ft - 9ft)
+12 VDC, 18mA
24 VDC, 30mA
+
24 VDC, 30mA
T
T
C
NC
_
NC
NC
WIRE / CÂBLAGE / CABLEADO /
FIAÇÃO
2
1
3
5
4
0.3-1.0mm
2
(22-18 AWG)
H
L
H
L1 - 3
3 - 5
SET / CONFIGURATION / CONFIGURACIÓN / CONFIGURAÇÃO
L = Low (pulse count 2)
L = Basse (compte
d'impulsions = 2)
L = Baja (contador de
pulsos 2)
L = Baixa (Contador de
pulsos 2)
H = High (pulse count 1)
H = Haute (compte
d'impulsions = 1)
H = Alta (contador de
pulsos 1)
H = Alta (Contador de
pulsos 1)
LED ENABLE
H
L
LED
!

#
"
IS216T
*Plan View
*Vue de dessus
*Vista de planta
*Vista de plano
*
*
Satisfactory / Satisfaisant / Satisfactorio / Satisfactório No / Non / No / Não
OPEN / OUVERTURE /
ABRIR / ABRIR
LOCATION / EMPLACEMENT / UBICACIÓN/ COLOCAÇÃO
MOUNT / MONTAGE / MONTAJE / MONTAGEM

IS216 / IS216T Passive Infrared Motion Sensor - Installation Instructions
PRELIMINARY DRAFT 9/15/09 - 2 -
ENGLISH FRANÇAIS
LED OPERATION
LED Indication
Condition S1 ON S1 OFF Relay
warm up
(2 minutes)
slow blink slow blink closed
normal off off closed
alarm on for 3
seconds off open for 3
seconds
trouble fast blink fast blink - -
Note: After applying power to the sensor, the LED will temporarily
remain enabled for a 10 minute walk test period. To restart the 10
minute walk test mode, switch S1 ON, and then OFF again.
TROUBLESHOOTING
Momentarily power down the sensor. If the trouble does not clear,
replace the sensor. (Please check the power and all wiring before
replacing the sensor.)
Fonctionnement de la LED
Indication de la LED
Condition S1 ON S1 OFF Relais
d’alarme
Chauffe
(2 minutes) flash lent flash lent fermé
normal éteinte éteinte fermé
alarme allumée 3
secs éteinte ouvert durant 3 secs
défaut flash rapide flash rapide - -
Note: Après la mise sous tension du détecteur, la LED reste active 10
minutes pour réaliser un test de detection. Pour relancer le test de
detection, placer S1 sur ON puis sur OFF. La LED restera active 10
minutes.
DÉPANNAGE
Mettez temporairement le détecteur hors tension. Si le problème
persiste, remplacez le détecteur. (Vérifiez l'alimentation ainsi que tous
les câblages avant de remplacer le détecteur.)
ESPAÑOL PORTUGUÊS
OPERACIÓN DE LED
Indicación de LED
Condición S1 Encendido S1 Apagado Relè
Calentamiento
(2 minutos) Parpadeo lendo Parpadeo lendo Cerrado
Normal Apagado Apagado Cerrado
Alarma Encendido por
3 segundos Apagado Abierto por
3 segundos
Avería Parpadeo
rápido Parpadeo rápido - -
Nota: Después de encender el sensor, el LED permanecerá
temporalmente habilitado para un recorrido de prueba de 10 minutos.
Para reiniciar el modo de recorrido de prueba de 10 minutos,
encienda el S1 (ON), luego apáguelo (OFF).
SOLUCIÓN DE PROBLEMAS
Apague el sensor momentáneamente. Si la avería persiste, reemplace el
sensor. (Revise la alimentación y todo el cableado antes de reemplazarlo.)
OPERAÇÃO DE LED
Indicação de LED
Condição S1 Ligado S1 Desligado Relay
Establização (2
minutos) Piscar lento Piscar lento Fechado
Normal Desligado Desligado Fechado
Alarme Ligado por
3 segundos Desligado Aberto por 3
segundos
Problema Piscar rápido Piscar rápido - -
Nota: Após ligar o sensor, o LED ficará temporalmente pronto para uma
caminhada de prova de 10 minutos. Para iniciar de novo o modo de
caminhada de prova de 10 minutos, ligue o S1 (ON), depois o desligue
(OFF).
SOLUÇÃO DE PROBLEMAS
Desligue o sensor momentaneamente. Se o problema não for
solucionado, substitua o sensor. (Verifique a energia e toda a fiação
antes de substituir o sensor.)
DETECTION PATTERNS / COUVERTURE DE DETECTION / PATRÓN DE DETECCIÓN / PADRÃO DE COBERTURA
Top View / VUE DE DESSUS / Vista dall’ Alto / VISTA DESDE ARRIBA
Side View / VUE DE COTE / Vista Laterale / VISTA LATERAL

IS216 / IS216T Passive Infrared Motion Sensor - Installation Instructions
PRELIMINARY DRAFT 9/15/09 - 3 -
SPECIFICATIONS CARACTERISTIQUES ESPECIFICACIONES ESPECIFICAÇÕES
Power: 8.5 – 15.4 VDC
(UL: 10 – 14 VDC), nominal 12
VDC, 18mA max; AC Ripple: 50
to 120 Hz; 3 V peak-to-peak at
nominal 12 VDC
Alimentation: 8,5 à 15,4 Vcc
(UL: 10 – 14 Vcc) ; 16 mA nominal à
12 Vcc, 18 mA max.; 3 Vc-à-c à
12 Vcc
Energía: 8.5 – 15.4 VDC
(UL: 10 – 14 VDC), nominal 12 VCD,
18mA max; Oscilación de CA: 50 a
120 Hz, 3V pico a pico a 12 VCD
nominales
Energia: 8.5 – 15.4 VDC
(UL: 10 – 14 VDC), nominais a
12 VDC, 18mA máx; Oscilación
AC: 50 Hz a 120 Hz; 3V pico-a-
pico a 12 VDC nominais
Alarm Relay: Form A (Normally
Closed); 30 mA, 24 VDC max.; 40
Ohms resistance max.
Relais d’alarme: Normalement
fermé 30 mA, 24 Vcc max., 40 Ohms
de résistance max.
Relé de alarma: De A (normalmente
cerrado); 30 mA, 24 Vcc max, 40
Ohms resistencia máxima
Relé de alarme: Forma A
(normalmente fechado); 30 mA,
24 VDC máx.; 40 Ohms
resistência máxima.
Tamper Switch (IS216T):
Closed with cover in place; 30
mA, 24 VDC
Autoprotection (IS216T) : Fermée
avec le capot en place 30 mA, 24 Vcc Salida de tamper (IS216T): Cerrado con la tapa en su sitio; 30
mA, 24 Vcc
Tamper (IS216T):
Normalmente fechado (com
tampa colocada); 30 mA, 24 VDC
Operating Temperature:
– 10°to 55°C (14°to 131°F)
(Indoor use environment)
Température de fonctionnement:
– 10°C à +55°C
Temperatura de funcionamiento:
– 10°C to +55°C (para uso en
interiores)
Temperatura de Operação:
– 10°to 55°C (aplicação
interior)
Relative Humidity: 5% - 95%,
non-condensing Humidité relative: 5% à 95% sans condensation Humedad relativa: 5% to 95% sin condensación Umidade relativa: 95%; sem condensação
Temperature Compensation:
Advanced Dual Slope Compensation en température: A double pente Compensación de temperatura: Doble pendiente avanzada Compensação de
Temperatura: Dupla
Compensacao
Dimensions: 8.57 cm x 6.03 cm x
3.81 cm (3-3/8 in x 2-3/8 in x
1-1/2 in)
Dimensions: 8.57 cm x 6.03 cm x
3.81 cm
Dimensiones: 8.57 cm x 6.03 cm x
3.81 cm
Dimensões: 8.57 cm x 6.03 cm x
3.81 cm
Weight: 66.62 g (2.35 oz);
Packaged: 92.14 g (3.25 oz) Masse: 66.62 g; Emballé: 92.14 g Peso: 66.62 g; Embalaje del producto: 92.14 g Peso: 66.62 g; Com a embalagem: 92.14 g
APPROVAL LISTINGS / AGREMENT / HOMOLOGACIÓN /
HOMOLOGAÇÃO
FCC part 15, Class B verified
IC, ICES-003, Class B verified
CE
cULus Listed

UL COMPLIANCE NOTES
-Product must be tested once each year.
NOTES DE CONFORMITÉ
-Le produit doit être testé au moins une fois par an
NOTAS DE CUMPLIMIENTO UL
-Se debe probar el producto una vez al año.
NOTAS DE CUMPRIMENTO DA NORMATIVA UL
-O produto deve ser provado uma vez por ano.
FCC NOTICE: This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and
can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
−Reorient or relocate the receiving antenna.
−Increase the separation between the equipment and receiver.
−Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
−Consult the dealer or an experienced radio/television technician for help.
The user is cautioned that changes or modifications not expressly approved
by Honeywell could void the user’s authority to operate this equipment.
IC NOTICE:This Class B digital device complies with the Canadian ICES-
003.
Cet appareil numérique de la Classe B est conforme à la norme NMB-003 du
Canada.
This Class B digital device complies with RSS-210 of the IC rules. Operation
is subject to the following two conditions: (1) this device may not cause
harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
Cet appareil numérique de la Classe B est conforme à la norme CNR-210 des
règles d’IC. L’utilisation de ce dispositif est autorisée seulement aux deux
conditions suivantes ; (1) il ne doit pas produire de brouillage, et (2)
l’utilisateur du dispositif doit être prêt à accepter tout brouillage radioélectrique
reçu, même si ce brouillage est susceptible de compromettre le
fonctionnement du dispositif.
To obtain applicable EU compliance Declaration of Conformity for this product, please refer to our Website:
Les déclarations de conformité aux normes Européennes de ce produit sont disponibles sur notre site Internet à l’adresse :
Para obtener la Declaración de conformidades de cumplimiento aplicable para este producto, consulte en nuestro sitio Web :
Para obter a Declaração de Conformidades de adequação aplicável para este produto, consulte nosso site:
http://www.security.honeywell.com/hsce/international/index.html.
ACCESSORIES / ACCESSOIRES / ACCESORIOS /
ACCESSÓRIOS
SMB-10
(P/N 0-000-110-01) Swivel Mount Bracket Rotule de montage
Soporte giratorio de instalación en techo
Suporte Giratório de Montagem no Teto
SMB-10C
(P/N 0-000-111-01) Swivel Mount Ceiling Bracket Rotule de plafond
Soporte de instalación en techo giratorio
Suporte de Montagem no Teto Giratório
SMB-10T
(P/N 0-000-155-01)
Swivel Mount Bracket w/Tamper
Rotule de montage avec autoprotection
Soporte giratorio de instalación con tamper
Suporte Articulado com Tamper

IS216 / IS216T Passive Infrared Motion Sensor - Installation Instructions
PRELIMINARY DRAFT 9/15/09 - 4 -
 2009 Honeywell International Inc. Honeywell is a registered trademark of Honeywell International Inc.
All other trademarks are the properties of their respective owners. All rights reserved. Made in China.
For the latest U.S. warranty information, please go to: www.honeywell.com/security/hsc/resources/wa or
Please contact your local authorized Honeywell representative for product warranty information.
Contacter un revendeur Honeywell autorisé pour obtenir des informations sur la garantie de ce produit.
Por favor contacte con su distribuidor Honeywell Security para información sobre la garantía del producto.
Entre em contato com seu representante Honeywell autorizado para obter informações de garantia do produto.
P/N 800-04582 Rev B
